Title: Finishing Poured Concrete Surfaces


1
Finishing Poured Concrete Surfaces
2
Finishing Concrete
  • A. Consolidating concrete in order to give the
    uniform plastic mass desired.
  • Tools used in consolidating concrete.
  •        Straight edge
  •        Tampers
  •        Roller screeds
  •        Jitterbugs
  •        Vibrator

3
Finishing Concrete
  • B. Striking-off
  • A leveling operation that takes the humps and
    valleys out of the surface of the concrete and
    gives it a true even surface.

4
Finishing Concrete
  • C. Floating
  •        It helps depress the coarser aggregate
    and brings mortar to the surface.
  •        Tools used for floating concrete.
  • - Darby
  • - Bull float
  • - Wood float

5
Finishing Concrete
  • D. Types of finishes
  •        Broom finish
  • - Used for feeding floors, ramps for livestock,
    driveways and walkways.
  • - The rough texture can be made with a stiff
    floor broom pulled, crossways to the direction
    of travel.
  • The degree of coarseness can be determined by
    the types of broom and the amount of pressure
    applied to it.
  •        Belt finish
  • - Used on driveways, pavements, and livestock
    ramps. - Six inch wide strips of burlap, canvas,
    or rubber belt can be moved back and forth just
    after the wood float process is finished.

6
TOOL SEQUENCE FOR ROUGH CONCRETE SURFACE
  • A. SCREED

7
TOOL SEQUENCE FOR ROUGH CONCRETE SURFACE
  • B. BULL FLOAT

8
TOOL SEQUENCE FOR ROUGH CONCRETE SURFACE
  • C. WOOD FLOAT

FOR BROOM FINISH
9
TOOL SEQUENCE FOR ROUGH CONCRETE SURFACE
  • D. STEEL TROWEL

10
TOOL SEQUENCE FOR ROUGH CONCRETE SURFACE
  • E. POWER TROWEL

11
TOOL SEQUENCE FOR ROUGH CONCRETE SURFACE
  • F. BROOM

12
TOOL SEQUENCE FOR SMOOTH CONCRETE SURFACES
  • A. SCREED

13
TOOL SEQUENCE FOR SMOOTH CONCRETE SURFACES
  • B. BULL FLOAT

14
TOOL SEQUENCE FOR SMOOTH CONCRETE SURFACES
  • C. WOOD FLOAT

15
TOOL SEQUENCE FOR SMOOTH CONCRETE SURFACES
  • D. STEEL TROWEL

16
TOOL SEQUENCE FOR SMOOTH CONCRETE SURFACES
  • E. MAGNESIUM
  • HAND FLOAT

17
TOOL SEQUENCE FOR SMOOTH CONCRETE SURFACES
  • F. POWER TROWEL
