Guard Control

1
Guard Control Technical Presentation
2
System Overview
Guard Control Basic System Overview
LOCATIONS
READER
CONTROL CENTER
BASE
3
GC-01 Reader
GC-01 Data Acquisition Reader

• Rugged and waterproof
• Internal Lithium-Ion 1800mAh rechargeable battery
  for 6 month use or 300,000 readings
• 8000 time-stamped readings storage capacity
• 360 degrees visual reading indication
• Buzzer vibrator reading indications

4
Base
GC-02 Data Acquisition Base

• Reader docking station for reader data discharge
  to PC and reader battery charger
• RS-232 port for PC connection _at_ 9600baud, full
  duplex
• Rotating communications power portsfor desktop
  or wall mount installation
• Local iButton reader for enrollinglocation,
  events and user tags to PC
• 12VDC, max 500mA power adaptor
• 3-color LED and buzzer indications
• Water dust resistant design
• Also available GS-03 charger only base

RS-232 PLUG
POWER PLUG
5
GA-01 Location Tag
GA-01 Location Tag

• Rugged and waterproof
• Low weight (10 grams)
• 16 byte ID with open or custom facility code
• Randomly coded with 12 Hex digits (over 300
  billion ID options)
• 2-screw wall mounting base, and latching cover
  make the tag irremovable once installed
• Available in different colors black, red,
  yellow, purple and orange

6
Event Wallet
GA-02 Event Wallet

• Portable wallet for special event reporting
  during tour
• 10 event iButtons
• Rugged design
• GA-12 Numeric Event Wallet
• Numeric wallet for special event reporting during
  tour
• iButtons for digits 0 9, with START and END
  buttons to input any numeric sequence

7
Remote Networking
GS-01 DigiTool Light Software
8
Remote Networking
GS-01 DigiTool Light Software

• Master and regular user access levels
• Programmable features users, sites, readers and
  scheduled tours
• Integrated database
• Various reporting options tours, events,
  exceptions and others
• Full reader upload/download and configuration

9
Remote Networking
Remote Networking of Data Acquisition System
CONTROL CENTER GS-02 (DCC) SERVER
MD-N33 / PSTN MODEM
PSTNTELEPHONYNETWORK
REMOTE STATIONS
RS-232
DCC MONITORING CLIENTS
10
Remote Networking
GC-50 Remote Storage / Communicator

• Up/Download remote bases data via telephone
• Local storage of up to 256,000 readings for up to
  two weeks when power is off
• Platform for GC-02 base connects to GC-02 power
  and serial port
• 9600 baud RS-232 communications port to PC for
  local station connection
• RJ-11 phone in / out plugs
• LED buttons for Load Communications
• Internal, battery backed up real-time clock
• Internal buzzer
• Securing screw for GC-02 base
• 9-12 VDC, 30mA to 150mA (max)

11
Remote Networking
GS-02 DigiTool Control Center Software
12
Remote Networking
GS-02 DigiTool Control Center Software

• Local and remote station, global control software
• Microsoft .NET Platform
• Full management of all related objects Sites,
  Locations, Users, Guards, Readers, Tags,
  Stations, Tours, Reports, Clients, Events and
  Groups
• Multi client platform for remote client
  monitoring stations
• Over 500 guards, up to 10,000 locations
• Flexible, schedule based tour planner
• Custom reports
• Wizard driven UI for most objects creation
• Tree view based object structure
• Graphical maps for site hierarchy

13
Thank You! Rosslare Security Products - Technical
Support Centers Israel (global) center 972 3
938 6838 US center 1 866 262 6833 Hong-Kong
center 852 279 55 630 Email
support_at_rosslaresecurity.com
