Title: CIS 267 Data Transmission Lecture Chapter 6


1
CIS 267 Data Transmission Lecture Chapter 6
  • Vaughn L. Lucas

2
A Model of Communication
  • Any form of communication requires four things
  • A source or sender
  • A message
  • A channel or communication medium
  • A receiver

Coding Message Decoding
Sender
Receiver
Channel or Communication Medium
3
Purpose of Text
  • Concerned with one particular means of
    communicating information
  • The transmission of electromagnetic waves
  • VIViD information can be represented by
  • Electromagnetic signals and transmitted over a
    suitable medium
  • See Figure 6.1 p.136

4
Information Transmission
Figure 6.1 from p.136
5
Electromagnetic Signals
  • Function of time
  • Analog -continuous (varies smoothly over time)
  • Digital -discrete (constant level for some time,
    followed by a change to another level)
  • Function of frequency
  • Spectrum (range of frequencies)
  • Bandwidth (width of the spectrum)

6
Periodic Signal Characteristics
  • Amplitude (A) signal value, measured in volts
  • Frequency (f) repetition rate, cycles per second
    or Hertz
  • Period (T) amount of time it takes for one
    repetition, T1/f
  • Phase (F) relative position in time, measured in
    degrees

7
Bandwidth
  • Width of the spectrum of frequencies that can be
    transmitted
  • if spectrum 300 to 3400Hz, bandwidth 3100Hz
  • Greater bandwidth leads to greater costs
  • Limited bandwidth leads to distortion

8
Why Study Analog in Data Comm.?
  • Much of our data begins in analog form must
    understand it in order to properly convert it
  • Telephone system is primarily analog rather than
    digital (designed to carry voice signals)
  • Low-cost, ubiquitous transmission medium
  • If we can convert digital information (1s and 0s)
    to analog form (audible tone), it can be
    transmitted inexpensively

9
Data vs Signals
  • Analog data
  • Voice
  • Images
  • Digital data
  • Text
  • Digitized voice or images

10
Analog Signaling
  • represented by sine waves

phase difference
1 cycle
amplitude (volts)
time
(sec)
frequency (hertz)
cycles per second
11
Signals add to form a composite
12
An infinite number of analog signals makes a
digital signal
13
Signaling Concepts
  • Spectrum
  • range of frequencies contained in a signal
  • Bandwidth
  • Width of a spectrum
  • Data Rate
  • information carrying capacity, related to
    bandwidth but not the same

14
Voice/Audio Analog Signals
  • Easily converted from sound frequencies (measured
    in loudness or decibels/db) to electromagnetic
    frequencies (measured in voltage)
  • Human voice has frequency components ranging from
    20Hz to 20kHz
  • For practical purposes, the telephone system has
    a narrower bandwidth than human voice, from 300
    to 3400Hz

15
Video Signals
  • TV Video Signals are typically analog
  • TV Picture Production

16
Image/Video Analog Data to Analog Signals
  • Image is scanned in lines each line is displayed
    with varying levels of intensity
  • Requires approximately 4Mhz of analog bandwidth
  • Since multiple signals can be sent via the same
    channel, guardbands are necessary, raising
    bandwidth requirements to 6Mhz per signal

17
Digital Signaling
  • represented by square waves or pulses

1 cycle
amplitude (volts)
time
(sec)
frequency (hertz)
cycles per second
18
Digital Text Signals
  • Transmission of electronic pulses representing
    the binary digits 1 and 0
  • How do we represent letters, numbers, characters
    in binary form?
  • Earliest example Morse code (dots and dashes)
  • Most common current form ASCII

19
ASCII Character Codes
  • Use 8 bits of data (1 byte) to transmit one
    character
  • 8 binary bits has 256 possible outcomes (0 to
    255)
  • Represents alphanumeric characters, punctuation,
    and special characters

20
Digital Image Signals
  • Analog facsimile
  • similar to video scanning
  • Digital facsimile, bitmapped graphics
  • uses pixelization
  • Object-oriented graphics
  • image represented using library of objects
  • e.g. Postscript, TIFF

21
Digital Image Signals
  • Pixelization and binary representation
  • Used in digital fax, bitmapped graphics

1-bit code 00000000 00111100 01110110 0111
1110 01111000 01111110 00111100 00000000
22
Transmission Media
  • the physical path between transmitter and
    receiver (channel)
  • design factors affecting data rate
  • bandwidth
  • physical environment
  • number of receivers
  • impairments

23
Impairments and Capacity
  • Impairments exist in all forms of data
    transmission
  • Analog signal impairments result in random
    modifications that impair signal quality
  • Digital signal impairments result in bit errors
    (1s and 0s transposed)

24
Transmission ImpairmentsGuided Media
  • Attenuation
  • loss of signal strength over distance
  • Attenuation Distortion
  • different losses at different frequencies
  • Delay Distortion
  • different speeds for different frequencies
  • Noise
  • distortions of signal caused by interference

25
Using Repeaters
26
Transmission ImpairmentsUnguided (Wireless)
Media
  • Free-Space Loss
  • Signals disperse with distance
  • Atmospheric Absorption
  • Water vapor and oxygen contribute to signal loss
  • Multipath
  • Obstacles reflect signal creating multiple copies
  • Refraction
  • Noise

27
Types of Noise
  • Thermal (white noise) - electron agitation
  • Uniformly distributed, cannot be eliminated
  • Intermodulation
  • when different frequencies collide (harmonics)
  • Crosstalk - from nearby cables
  • Overlap of signals
  • Impulse noise - e.g. atmospheric changes
  • Irregular spikes, less predictable

28
Effects of Noise on a Digital Signal
29
Channel Capacity
  • The rate at which data can be transmitted over a
    given path, under given conditions
  • Four concepts
  • Data rate
  • Bandwidth
  • Noise
  • Error rate

30
Shannon Equation
  • C B log2 (1 SNR)
  • B Bandwidth
  • C Channel
  • SNR Signal-to-noise ratio
