Title: FiberOptic DownHole Sensing:


1
Fiber-Optic Down-Hole Sensing
  • A Discussion on Applications and Enabling
    Wellhead Connection Technology

SPE/OTC Paper 18121 Perry Joseph Wright Willard
Womack, Ocean Design, Inc 2006 Offshore
Technology Conference, Houston, Tx
2
Economic Drivers for Intelligent Wells
  • The growing shortfall between forecast demand and
    recoverable reserves, requires that the Offshore
    Oil Gas Industry optimize recovery.
  • Historical average production of oil in place
    35
  • Intelligent or Smart Well Technologies permit
    near real time well control
  • Projected recovery using Intelligent Well
    Technologies 50 - 60

3
Intelligent Wells Technologies
  • Intelligent or Smart Well Technology is targeted
    at
  • Increasing production total recovery
  • Reducing CAPEX, OPEX and operating Risk
  • This is achieved using
  • Flow control
  • Feed through isolation packers
  • Control communication
    power cables
  • Down-hole sensors
  • Surface data acquisition control
  • Wellhead optical electrical penetration systems

4
Review of Fiber Sensors in Oil Gas
1999 Weatherford develops First Subsea Optical
P/T Gauge
2000 SENSA (SLB) Installs first permanent DTS
Monitoring System in Shell Expro TA-27 Gas Lift
Well
2002 Norsk Hydro Installs first system containing
multiple FO pressure and temperature gauges in a
single well at Oseberg east E-11C in North Sea
1978 FBG Proposed by Hill
Early 1990s Schlumberger uses point sensor
Spectroscope to monitor oil composition in ground
2001-2005 ODI develops the HT/HP I-Conn Wellhead
Penetration System for use in Vertical
Horizontal x-trees and Down-hole
1999 Weatherford integrates first permanent
FBG-based optical sensor
5
Fiber Sensors
  • There are a number of different optical sensors
    that have been deployed, but they fall into two
    discrete categories
  • Point source sensors
  • Fiber Bragg grating sensors
  • Mechanical point source sensors,
    where a change in a machined part
    is read using the optical signal
  • Distributed sensors
  • DTS Distributed Temperature Sensing
  • DTSS - Distributed Temperature Strain Sensing.
    (Similar to DTS, with the addition of strain
    measurement)

6
Distributed Temperature Sensing - DTS
  • DTS technology uses one of the light scattering
    properties (Raman scattering) of the optical
    fiber that allows the temperature of the fiber to
    be measured along the length of the fiber.
  • Range 10 km
  • Spatial Resolution 1m
  • Thermal Resolution 0.1ºC

7
Fiber Bragg Grating
  • Bragg gratings are sensitized short lengths of
    fiber that allow measurement of the change in
    length of that section of the fiber
  • Multiple gratings can be placed on each fiber in
    series or in parallel
  • These sensors can be used to measure
  • Temperature
  • Pressure
  • Strain
  • Vibration

8
System Performance Vertical X-Trees
  • The vertical tree penetration system includes
  • External bonnet penetrator on BX 150 flange
  • Lower valve block penetrator
  • I-Conn compliant mount assembly
  • I-Conn wet-mate valve block receptacle connector
  • I-Conn wet-mate tubing hanger plug connector
  • Dry mate tubing hanger receptacle connector
  • Dry-mate plug connector on gauge cable

Dry-mate receptacle
Dry-mate plug
9
System Performance Horizontal X-Trees
  • The vertical stab horizontal tree penetration
    system includes
  • Subsea ROV wet-mate optical connector
  • ROV installable compliant stinger assembly
  • Guide funnel
  • I-Conn wet-mate receptacle connector
  • I-Conn wet-mate tubing hanger plug connector
  • Dry mate tubing hanger receptacle connector
  • Dry-mate plug connector on gauge cable

10
System Performance Running Tool
  • The landing string assembly needs many more
    connections and penetrations in various
    configurations than a tree system including
  • Workover umbilical termination
  • Umbilical termination to landing string jumper
  • Upper landing string dry-mate connector
  • Fiber management in one or more locations
  • Optional subsea test tree to landing string
    I-Conn wet-mate connector
  • Lower landing string to tubing hanger running
    tool I-Conn wet-mate connector
  • Lower tubing hanger running tool to tubing hanger
    I-Conn wet-mate connector
  • Optical losses could exceed 3.2 dB, but is offset
    by having the vessel vertically above the well.

Subsea test tree
Landing string
Tubing hanger running tool
Tubing hanger
11
Connector Specification - IWIS
  • The IWIS joint industry project is writing
    standards for operation and qualification of
    optical (and electrical) tree penetration
    systems.
  • API/ISO standard 13628 Petroleum
    and natural gas industries. Design
    and operation of
    subsea production systems,
    Part 6 Subsea production
    control systems.
  • Draft standards submitted to IWIS
  • The standards offer minimum
    performance and qualification
    requirements for optical tree
    penetration hardware.

12
Basic Qualification
  • Optical Performance Tests
  • Optical Performance lt0.5 dB IL -30 dB RL
  • Mate Tests Turbid aligned and misaligned mates
    at 6,000 psi
  • Extreme Temperature Pressure 15,000 psi at
    130ºC
  • Materials Tests
  • Materials compatibility
  • Environmental Tests
  • Hydrostatic Tests 15,000 psi
  • Thermal Cycle, Shock Storage Tests
    130ºC to -40ºC
  • Shock Vibration 3x, 30G, ½ sine, 11ms,
    6-axis 1-150 Hz, 5G, 3-axis.
  • Gas Leak Test 1,000 psi helium
  • Long-Term Creep Test 15,000 psi 130C
  • Third Party Tests
  • ROV Mate Test (at SWRI)

13
Summary
  • The recent SPE conference in Galveston In-well
    Optical Sensing - Subsea Well Applications - Are
    We Ready? addressed the issues surrounding
    uptake of optical fiber as part of the
    intelligent wells technologies.
  • The conclusion was that in general the technology
    is ready for systems trials, but that the
    commercial advantages are still to be proven.
  • The I-Conn wet-mate connection system for
    vertical and ROV stab horizontal systems is being
    reviewed for re-qualification to 20 kpsi
    operating at 177º C
