Process Synchronization

1
Process Synchronization

• COS 431
• Fall, 2000

2
Coordination of Processes

• Often, processes need to synchronize their
  activities
• sharing resources
• when cooperating
• Unfortunately, processes are asynchronous by
  nature
• Without some means of synchronization race
  condition

num numStudents
num numStudents
num
numStudents num
num
numStudents num
3
Critical Sections/Regions

• Solution mutual exclusion
• Critical regions (critical sections)
• Criteria for solution to race conditions
• mutual exclusion
• make no assumption about speed, num. CPUs
• no process outside its critical region can block
  another
• no starvation

4
A Naïve Approach Disable Interrupts

• One CPU, if process can disable all interrupts,
  can guarantee no race conditions
• have to disable interrupts from I/O
• have to disable timer interrupts
• Problem
• too much power for user process -- usurps
  kernels power
• if anything goes wrong -- may hang entire
  computer!
• doesnt work for multiple CPUs
• Kernel needs the ability to do this, though
• In some multithreaded applications, this can be
  used (e.g., Lisp)

5
Another Simple Approach Locks

• Use a single shared variable as a lock
• Could also be a shared file
• Process looks at variable -- if 0, busy waits, if
  not set to 0
• Problems
• May not be atomic
• Processes may cheat
• Some processors have special instructions (TSL)
  that help this out, though

6
Turn-Taking Strict Alternation

• Idea
• non-critical section
• while (turn ! my-turn) / busy wait /
• critical_section()
• turn next_turn(turn)
• non-critical section
• What if one of the processes is faster than the
  others?
• What if a process is I/O bound?
• Processes block others when not in its critical
  region

7
Turn-Taking Alternation with Interest(Petersons
Solution)

• Idea -- process declares its interest before it
  tries for critical region
• Other processes that are interested block if its
  not their turn and if someone else who is
  interested is in critical section

define FALSE 0 define TRUE 1 define N 2 /
num processes / int turn int interestedN voi
d enter_region(int process) int other
other 1 - process interestedprocess
TRUE turn process while (turn process
interestedother TRUE) void
leave_region(int process) interestedprocess
FALSE

• If only one process ready
• If two processes ready, one in its critical
  section
• Two processes both simultaneously call
  enter_region...

8
Bakery Algorithm

• For multiple processes
• Every process that wants to enter critical
  section given a number
• Lowest number goes first
• Cant guarantee that two wont have same number
• in that case, use tie-breaking convention

BOOLEAN choosingMAXPROC / picking number or
not / int numberMAXPROC / each element
corresponds to a process / void enter(i)
choosingi TRUE / were picking a number
/ numberi find_max(number) 1 / select
next highest number / choosingi FALSE /
done / for (j0 jltn j) while
(choosingj) / busy wait if something is
choosing number / / busy wait till lower
proc. with lower number is done / while (
(numberj ! 0) customer_lt(j,i) )
void leave(i) numberi 0

• What if just one process...?
• What if n, with one in critical region...?
• What if n try to enter critical region at same
  time...?

9
Hardware Support for Synchronization

• Locks dont work in general
• atomicity
• multiple processors?
• Some processors test-and-set-lock (TSL)
  instruction
• When TSL executed
• locks memory bus
• then
• sets a register to the value of some memory
  location (the lock)
• sets the lock to a value meaning locked (e.g.,
  1)
• then unlocks the memory bus
• Why does this work?

10
Mutual Exclusion Using TSL
enter tsl r1,LOCK ! check LOCK cmp r1,0 !
compare old value to 0 jnz enter ! if not zero,
then it was locked, ! so loop ret !
otherwise, return
leave mov LOCK,0 ! just clear the lock ret
11
Whats Wrong with Busy Waiting?

• Wastes processor time
• Priority inversion problem
• Example
• Processes busy wait when cant enter critical
  region
• H high-priority job
• L low-priority job
• Policy always run high-priority jobs when
  possible
• Scenario
• H waiting on I/O
• L runs, enters critical region
• H I/O completes - context switch to H
• H tries to enter its critical region
• What does H do?
• What does L do?

12
Better Idea Blocking

• Make process not runnable instead of busy waiting
• How is this done?
• When does the process wake up?
• Traditional example the bounded buffer problem
• Buffer storage area with n slots
• One process is a producer
• Other is a consumer
• Buffer full producer blocks
• Buffer empty consumer
• Example queues
• Relies on producer waking consumer and vice versa

13
Producer/Consumer Problem
define N 100 int count 0 int bufferN pid_t
producer, consumer
void producer() int item while (TRUE)
item produce_item() if (count N)
sleep() enter_item(item) count
if (count 1) wakeup(consumer)
void consumer() int item if (count 0)
sleep() item remove_item() count--
if (count N-1) wakeup(producer)
consume_item(item)
void consume_item(int item)
printf(itemd\n,item)
int produce_item() int item
printf(\nNext item? ) scanf(d,item)
return(item)
14
Problems with Sleep/Wakeup

• Signals can be lost due to timing
• producer sees buffer full, but interrupted before
  sleep
• consumer takes something from buffer, sends
  signal -- which is lost
• producer goes to sleep
• consumer continues taking stuff out, ultimately
  gt sleeps
• both are sleeping!
• Can add some machinery to kernel -- bit in PCB,
  e.g. -- tells when signal is waiting
• But with gt 2 processes, need more bits for the
  processes gt arbitrary number of bits needed

15
Semaphores

• Motivation problems with blocking
• Idea
• standard way to block processes
• data structure (semaphores) two functions
  defined on them
• Semaphores
• enforce mutual exclusion
• can be used for producer-consumer problems
• Data structure essentially just an integer --
  say, S
• Operations
• P(S) -- also known as Down(S) -- decrement S
• V(S) -- also known as Up(S) -- increment S
• Down(S) and S0 block caller.
• Up(S) and process blocked on S gt unblock it
• Down and Up have to be atomic gt system calls

16
Semaphores

• One way to implement
• typedef structure semaphore
• int count 1
• queue procs
• void Down(semaphore S)
• S.count--
• if (S.count lt 0)
• enqueue(current_proc(),S.procs)
• block(current_proc())

void Up(semaphore S) process
P S.count if (S.count lt 0) P
dequeue(S.queue) wakeup(P)
17
Using Semaphores for Mutual Exclusion

• Traditional name for mutual exclusion semaphore
  is mutex
• Example from the student roster program before

int num_students int rosterMAXSTUDENTS semapho
re mutex ... void add_student(int id) int
currno Down(mutex) / critical region starts
here / currno num_students rostercurrno
id currno num_students currno / end
critical region / Up(mutex) return ...
18
Semaphores and Bounded Buffers

• Single-bounded buffer
• Ex a print queue
• Something else (we wont worry about what right
  now) takes items out of the queue
• What if the queue is full?
• What if the queue is empty?
• Semaphores needed
• mutex - a binary semaphore
• empty -
• counts empty slots
• initialized to number of slots in queue

19
Print Queue Example

• filename bufferSLOTS
• int next_slot 0
• semaphore mutex, empty
• set_count(empty,SLOTS) / would really be set
  by daemon /
• ...
• void print_file(filename file)
• Down(empty)
• Down(mutex)
• / within critical region now /
• buffernext_slot file
• next_slot
• Up(mutex)

• Why is there no Up(empty)?
• What if buffer is empty?
• What if buffer is full?

20
Producer/Consumer Problems and Semaphores

• Complete bounded buffer problem
• Ex. Message queue
• process A writes to it
• process B reads from it
• limited size
• Synchronization problem?
• Solution uses three semaphores
• mutex, a binary semaphore
• empty a counting semaphore -- keeps track of
  empty slots
• full a counting semaphore -- keeps track of full
  slots

21
Producer/Consumer

• message bufferBUFFSIZE
• semaphore empty, full, mutex
• set_count(empty,BUFFSIZE)
• set_count(full,0)
• void producer()
• message msg
• while (TRUE)
• msg compose_message()
• Down(empty)
• Down(mutex)
• / critical region /
• put_message(buffer,msg)
• / end critical region /
• Up(mutex)
• Up(full)

void consumer() message msg while (TRUE)
Down(full) Down(mutex) / critical
region / msg get_message(buffer) / end
critical region / Up(mutex) Up(empty) use
_message(msg)
22
Common Problems When Using Semaphores

• Careful not to get carried way with mutex calls!
  Dont
• void fcn1()
• Down(mutex)
• fcn2()
• Up(mutex)
• void fcn2()
• Down(mutex)
• ...
• Up(mutex)

23
Problems Using Semaphores

• Careful not to cross semaphore calls
• P1
• Down(S)
• Down(T)
• ...
• Up(T)
• Up(S)

P2 Down(T) Down(S) ... Up(S) Up(T)
24
Semaphores in Unix

• POSIX-compliant Unix
• sem_t is the semaphore type
• sem_wait gt Down
• sem_post gt Up
• Used for threads (or processes, if shared)
• Some Unix systems only allocate arrays of
  semaphores
• semget -- creates a set of semaphores as shared
  memory objects, or returns an identifier for such
  a set
• semop--perform operations on the semaphore set
