Configuration, Support, and Security for UIUCnet Wireless

1
Configuration, Support, and Security for UIUCnet
Wireless

• Debbie Fligor
• CITES - Network Engineering
• fligor_at_uiuc.edu

2
Todays Topics

• Wireless basics
• UIUCnet Wireless specifics and How-tos
• Frequently asked questions (and their answers)
• Supporting off-campus wireless
• Futures

3
Wireless - an overused word

• Can mean the cellphone network
• Can mean wireless Ethernet
• Can be the new mice and keyboards
• Can be IR from your PDA to your computer
• Can be Bluetooth, a Personal Area Network

4
How to tell what it means

• Context
• With whom youre speaking
• Keywords
• 2G, 2.5G, 3G are cellphone
• IRDA is infra-red
• Bluetooth is short distance, device-to-device
• 802.11(a,b,g) are Wireless Ethernet
• What we will be looking at today

5
Wireless Ethernet Flavors

• 802.11b
• Most used right now
• Shipping since Fall 1999
• 11 Mb/s
• Closer to 8 Mb/s for a single end user
• Less if more than one user
• Cheapest
• Interference starting to happen
• Uses 2.4 GHz frequency range

6
Wireless Ethernet Flavors

• 802.11g
• Uses 2.4 GHz frequency range
• Standard ratified last spring
• 802.11b users rate-limit 802.11g users
• Same interference problems as 802.11b
• More expensive than 802.11b (but prices are
  dropping quickly)
• Faster than 802.11b (sometimes)
• Up to 54 Mb/s
• The standard has 6, 9, 12, 18, 24, 36, 48, 54
  (and 1, 2 ,5.5, 11 for 802.11b support)
• But only requires up to 24

7
Wireless Ethernet Flavors

• 802.11a
• Been shipping for over a year
• 5.5 GHz frequency range
• Less interference (for now)
• A little more expensive (for now)
• Many new cards are dual a/b (or a/b/g)
• Up to 54 Mb/s
• The standard has 6, 9, 12, 18, 24, 36, 48, 54
• But only requires 6, 12, and 24

8
What we use - 802.11b

• Most common
• Ready now
• Currently deploying on campus
• Affordable for home use

9
How it works - 802.11b

• (All wireless Ethernet is basically the same)
• Wireless Access Point (WAP)
• Wireless Ethernet card
• PC/MCIA (PC card)
• Built-in
• Strong signal
• distance
• signal blockers

10
How it works - 802.11b

• The WAP has an Ethernet jack
• The WAP bridges the wireless to the Ethernet
• The wireless card looks like an Ethernet card to
  the computer
• The wireless card talks to the WAP (instead of to
  an Ethernet cable)

11
Security - 802.11b

• Wired Equivalent Privacy (WEP)
• Part of the standard
• Easy to hack (lt 20 minutes)
• Why care? Sniffer software is free
• Get your credit card info
• Get your password(s)
• Without WEP, its even easier

12
UIUCnet Wireless

• The campus service
• 802.11b only (for now)
• Separate security
• Virtual Private Network (VPN)
• Most clients are free
• CITES runs the central server

13
UIUCnet Wireless

• Cant leave wireless net without the VPN software
• Login with NetID NetID Password
• Insures the user is UIUC
• Insures the data is secure WHILE ON THE WIRELESS
  part of the network
• This does not secure the data once it hits the
  wired network
• Guest accounts can be made by departments
• Good for up to 72 hours
• Can be extended if you contact CITES before it
  expires

14
Setting up for UIUCnet Wireless

• Set your computer to use its wireless interface
• Network name (SSID) UIUCnet
• Use DHCP to get your IP address
• Be sure your machine has an IP address
• It should start with 172.21.8-15
• Launch the VPN software and login
• Start using the net

15
Is it really that easy?

• On a good day, yes
• The rest of the time
• Driver/OS issues
• Access Point and card issues
• VPN issues

16
Driver/OS issues

• Windows Update patches
• Anything that changed the kernel or IP stack
• VPN major OS install
• uninstall VPN
• reinstall VPN
• reboot
• Need latest firmware and drivers
• especially newer combo cards

17
Access Point card issues

• 802.11g cards and 802.11b access points
• Should work, but
• Compatibility and settings issues
• Settings changes
• Users shouldnt have to know how to do this

18
VPN Issues

• The 5000 has been a pain
• The 3000 client is MUCH better
• The same interface on Mac and Windows
• No certificate
• Downloadable profiles
• or configure by hand
• Overall less picky
• Still will be times it needs to be re-installed
• 5000 will be powered off December 31
• Must be returned to Cisco

19
Frequently Asked Questions(and their answers)

• These are from the Librarians
• 1. What kind of software do I need?
• VPN
• 2. Do I need a special network card?
• Most 802.11b cards should work, were working on
  a list of cards that will be specifically
  supported by the Help Desk

20
Frequently Asked Questions(and their answers)

• 3. If I have a virus on my computer, can I still
  use wireless?
• No, your VPN account will be disabled when youre
  noticed
• 4. What is my radius password?
• Your NetID Password (like for U of I Direct)
• 5. I downloaded the VPN client and certificate,
  now how do I install it?
• Run the installer and follow the directions
• Then launch the VPN and import the profiles (for
  3000)

21
Frequently Asked Questions(and their answers)

• 6. How can I download the VPN client and
  certificate if I can't connect to begin with?
• http//172.21.0.22
• This is a local web server on the wireless
  network
• It only applies to on-campus wireless (not
  Illini Center, Airport, etc.)
• 7. Can my pda, handheld computer, etc connect
  to wireless?
• With an 802.11b networking card and the VPN
  software

22
Frequently Asked Questions(and their answers)

• These are from the Help Desk
• 1. Where are the locations around campus that
  have wireless access?
• http//www.cites.uiuc.edu/wireless/locations-map.h
  tml
• click on a building to get details
• 2. Why is it prompting me for a "shared secret"
  password?
• On the 5000 it will do that if you dont have a
  certificate installed, or didnt check the use
  certificate button
• On the 3000 if you didnt download the
  configuration

23
Frequently Asked Questions(and their answers)

• 3. What does IKE error mean?
• Probably an error in the VPN client-server
  communications (includes bad passwords)
• 4. I installed everything correctly, why don't I
  get a wireless signal?
• This one is really tough and can be anything from
  drivers to a failed access point

24
Frequently Asked Questions(and their answers)

• 5. Which wireless network am I supposed to select
  when more than one is available?
• UIUCnet
• 6. What exactly is this VPN thing that I need and
  where do I get it (this is a VERY popular
  question)?
• The software you need to use the wireless service
• http//172.21.0.22 or http//www.cites.uiuc.edu/vp
  n

25
Your role in UIUCnet Wireless

• CITES assumes all users will contact the Help
  Desk if assistance is required
• 244-7000
• consult_at_uiuc.edu
• Faculty and Staff might expect their IT support
  staff to know whats going on
• CITES doesnt mind if you help
• Always feel free to send users to the Help Desk
  instead

26
Things you can try

• UIUCnet not ANY for SSID
• Can you ping 172.21.0.22?
• (Before starting the VPN)
• Yes-gt wireless is working, its a VPN issue
• No-gt youre not on the wireless net correctly or
  the server is down (its the DHCP server, its
  not supposed to be down)
• Wireless basics are the same as wired
• Can the OS see the card?
• Do you have link?
• Do you get an IP address via DHCP?

27
Supporting off-campus

• Once theyve gotten used to it, theyll want it
  at home - as net admin, you can help
• 802.11b is affordable for many home users
• Consumer Wireless Access Points lt 150
• Most need Ethernet so you need
• DSL or ISDN
• Cable Modem
• Fixed Wireless (Volo, Prairieinet)
• A few have 56k modems included

28
Supporting off-campus

• Security is still important
• Borrowing bandwidth
• Passwords and credit card info
• Interference from
• Cordless phones
• Other wireless networks
• X10 cameras
• Some microwave ovens
• Bluetooth

29
Supporting off-campus

• How should a home system be setup?
• Pick a network name thats not too obvious
• Turn on WEP encryption
• Its not perfect, but keeps most people out
• Do not use clear-text passwords
• POP email is clear text, unless you ssh tunnel
• WebMail is not clear text, so is safe
• Never use telnet, always use ssh
• Never use ftp, always use scp or sftp
• Make sure any web form is https

30
Supporting off-campus

• What if I have to use clear-text passwords?
• There are a few system where you must
• Encrypt them first
• Use the VPN
• Use an ssh tunnel

31
Going from campus to home(and back)

• UIUCnet Wireless uses DHCP
• Set up DHCP on home WAP
• Name your home wireless network UIUCnet
• It doesnt hurt anything
• Easier to hard-code the network name
• You might have to turn off WEP when you get to
  work and back on when you get home

32
Futures-Hardware

• 802.11a
• hopefully starting Spring 04
• What about 802.11g?
• Will show up on campus when priced as low as b
  radios
• Wont advertise it as g since the b users will
  keep the speeds down

33
Futures-Security

• Replace the VPN?
• Appliance solutions have many problems
• Dont co-exist with the VPN, so people that want
  to use VPN from off-campus are out of luck
• Need lots of extra hardware -- points of failure
  and equipment to maintain
• Considering adding web-based SSL authentication
  in addition to VPN
• This would only allow access to secure services
• http, https, ssh, sftp, sPOP, sIMAP
• Would only need an SSL-capable web browser
• What do you think?

34
For More Information

• UIUCnet Wireless development information
  (includes service offering information)
• http//www.cites.uiuc.edu/wireless/admin
• How to setup your computer for UIUCnet Wireless
  or just the VPN
• http//www.cites.uiuc.edu/wireless
• http//www.cites.uiuc.edu/vpn
• http//www.cites.uiuc.edu/wireless/quickstart.pdf

35
If you really want more info

• OReillys 802.11 Wireless Networks book is
  pretty good
• Lots of info out on the web
• www.wi-fi.org has compatibility info
• Standards available on www.ieee.org
• Free downloads for 802 standards older than 6
  months
• Lots of hits on any search

36
Fun Facts
Average Simultaneous Users
VPN 3000
VPN 5000
37
Fun Facts
Average Simultaneous Users
VPN 3000
VPN 5000
38
Questions?

• wireless_at_uiuc.edu for general questions
• consult_at_uiuc.edu for problems (or call 244-7000)
