Title: GPU Shading and Rendering: OpenGL Shading Language


1
(No Transcript)
2
GPU Shading and RenderingOpenGL Shading Language
  • Marc Olano
  • UMBC

3
OpenGL Shading
  • High level language
  • OpenGL Shading Language GLslang GLSL
  • Integrated into OpenGL API (no extra run-time)

4
Organization
  • API
  • Vertex Shading
  • Fragment Shading
  • Lots of demos.
  • 2-year old Apple PowerBook G4/1.5GHz
  • ATI Mobility Radeon 9700

5
API-integrated
  • Compiler built into driver
  • Presumably they know your card best
  • IHVs must produce (good) compilers
  • Use built-in parameters (glColor, glNormal, )
  • Add your own
  • Other options can still produce low-level code
  • Cg, ASHLI, RapidMind,
  • With loss of integration

6
Using High-level Code
  • Create shader objectS glCreateShader(GL_VERTEX_
    SHADER)S glCreateShaderObjectARB(GL_VERTEX_SHAD
    ER_ARB)
  • Vertex or Fragment
  • Load shader into objectglShaderSource(S, n,
    shaderArray, lenArray)glShaderSourceARB(S, n,
    shaderArray, lenArray)
  • Array of strings
  • Compile objectglCompileShader(S)glCompileShaderA
    RB(S)

7
Loading Shaders
  • glShaderSource(S, n, shaderArray, lenArray)
  • One string containing entire mmapd file
  • Strings as includes
  • Varying variables between vertex and fragment
  • Strings as lines
  • Null-terminated if lenArray is Null or length-1

8
Using High-level Code (2)
  • Create program objectP glCreateProgram()P
    glCreateProgramObjectARB()
  • Attach all shader objectsglAttachShader(P,
    S)glAttachObjectARB(P, S)
  • Vertex, Fragment or both
  • Link togetherglLinkProgram(P)glLinkProgramARB(P)
  • UseglUseProgramObject(P)glUseProgramObjectARB(P)

9
Using High-level Code (3)
  • Where is my attributes/uniforms
    parameter?iglGetAttribLocation(P,myAttrib)ig
    lGetUniformLocation(P,myAttrib)
  • Set themglVertexAttrib1f(i,value)glVertexAttribP
    ointer(i,)glUniform1f(i,value)

10
Using Low-level Code
  • Load shaderglProgramStringARB(GL_VERTEX_PROGRAM_A
    RB, GL_PROGRAM_FORMAT_ASCII_ARB, length, shader)
  • Vertex or fragment
  • Single string (vs. array)
  • EnableglEnable(GL_VERTEX_PROGRAM_ARB)

11
Useful Tools
  • Shader debugger
  • Immediate updates
  • Choose model/texture
  • Tweak parameters
  • Examine/dump frames
  • Several available
  • Not hard to build
  • OpenGL debugger
  • Trace of calls made
  • Examine resources
  • Breakpoints/actions
  • Graph performance
  • A couple of choices

12
gDEBugger A Professional OpenGL Debugger and
Profiler
  • Provides graphic pipeline information needed to
    find bugs and to optimize application
    performance
  • Shortens debugging and profiling time
  • Improves application quality
  • Optimizes application performance

13
Free gDEBugger License for Academic Users!
  • OpenGL ARB and Graphic Remedy Academic Program
  • Annual program for all OpenGL Academic users
  • License of the full feature version for one year
  • Includes all software updates
  • A limited number of free licenses available
    fornon-commercial developers who are not in
    academia
  • More details http//academic.gremedy.com

14
Non-windows OS
  • Linux
  • gDEBugger in progress
  • Apple OpenGL Profiler and Driver Monitor
  • Free part of OS / Developer tools

15
Vertex DemoBlend Positions
16
High-level Code
void main() float Kin gl_Color.r
// key input // screen position from vertex
and texture vec4 Vp ftransform() vec4
Tp vec4(gl_MultiTexCoord0.xy1.8-.9, 0.,1.)
// interpolate between Vp and Tp
gl_Position mix(Tp,Vp,pow(1.-Kin,8.)) //
copy to output gl_TexCoord0
gl_MultiTexCoord0 gl_TexCoord1 Vp
gl_TexCoord3 vec4(Kin)
17
Main Function
void main() float Kin gl_Color.r
// key input // screen position from vertex
and texture vec4 Vp ftransform() vec4
Tp vec4(gl_MultiTexCoord0.xy1.8-.9, 0.,1.)
// interpolate between Vp and Tp
gl_Position mix(Tp,Vp,pow(1.-Kin,8.)) //
copy to output gl_TexCoord0
gl_MultiTexCoord0 gl_TexCoord1 Vp
gl_TexCoord3 vec4(Kin)
18
Use Standard OpenGL State
void main() float Kin gl_Color.r
// key input // screen position from vertex
and texture vec4 Vp ftransform() vec4
Tp vec4(gl_MultiTexCoord0.xy1.8-.9, 0.,1.)
// interpolate between Vp and Tp
gl_Position mix(Tp,Vp,pow(1.-Kin,8.)) //
copy to output gl_TexCoord0
gl_MultiTexCoord0 gl_TexCoord1 Vp
gl_TexCoord3 vec4(Kin)
19
Built-in Types
void main() float Kin gl_Color.r
// key input // screen position from vertex
and texture vec4 Vp ftransform() vec4
Tp vec4(gl_MultiTexCoord0.xy1.8-.9, 0.,1.)
// interpolate between Vp and Tp
gl_Position mix(Tp,Vp,pow(1.-Kin,8.)) //
copy to output gl_TexCoord0
gl_MultiTexCoord0 gl_TexCoord1 Vp
gl_TexCoord3 vec4(Kin)
20
Swizzle / Channel Selection
void main() float Kin gl_Color.r
// key input // screen position from vertex
and texture vec4 Vp ftransform() vec4
Tp vec4(gl_MultiTexCoord0.xy1.8-.9, 0.,1.)
// interpolate between Vp and Tp
gl_Position mix(Tp,Vp,pow(1.-Kin,8.)) //
copy to output gl_TexCoord0
gl_MultiTexCoord0 gl_TexCoord1 Vp
gl_TexCoord3 vec4(Kin)
21
Vector Construction
void main() float Kin gl_Color.r
// key input // screen position from vertex
and texture vec4 Vp ftransform() vec4
Tp vec4(gl_MultiTexCoord0.xy1.8-.9, 0.,1.)
// interpolate between Vp and Tp
gl_Position mix(Tp,Vp,pow(1.-Kin,8.)) //
copy to output gl_TexCoord0
gl_MultiTexCoord0 gl_TexCoord1 Vp
gl_TexCoord3 vec4(Kin)
22
Built-in Functions
void main() float Kin gl_Color.r
// key input // screen position from vertex
and texture vec4 Vp ftransform() vec4
Tp vec4(gl_MultiTexCoord0.xy1.8-.9, 0.,1.)
// interpolate between Vp and Tp
gl_Position mix(Tp,Vp,pow(1.-Kin,8.)) //
copy to output gl_TexCoord0
gl_MultiTexCoord0 gl_TexCoord1 Vp
gl_TexCoord3 vec4(Kin)
23
Vertex Fragment DemoFresnel Environment Map
24
Trick 1 Where is the Eye
ObjectSpace
ModelViewMatrix
EyeSpace
Projection Matrix
ClipSpace
  • Where is the Eye in Eye Space?
  • (0,0,0)? Not necessarily!
  • Know where it is in Clip Space
  • (0,0,-1,0), looking in the (0,0,1,0) direction
  • Assuming GL_LESS depth test
  • Invert projection to find the eye!
  • Works for any eye position, or even parallel
    projection.

25
Trick 2 Subtract Homogeneous Points
  • Homogeneous point vec4(V.xyz, V.w)
  • 3D equivalent V.xyz/V.w
  • Defers division, makes perspective, translation,
    and many things happy
  • Vector subtraction VE
  • V.xyz/V.w E.xyz/E.w
  • (V.xyzE.w E.xyzV.w)/(V.wE.w)

26
Trick 3 Skip Division for Normalize
  • normalize(V.xyz/V.w) normalize(V.xyz)
  • If V.w isnt negative
  • Put it all together
  • normalize(V-E)
  • normalize(V.xyzE.w - E.xyzV.w)

27
OpenGL State DemoVertex Lighting
28
Lighting Vectors in Eye Space
void main() // convert shading-related
vectors to eye space vec4 P
gl_ModelViewMatrixgl_Vertex vec4 E
gl_ProjectionMatrixInversevec4(0,0,-1,0) vec3
V normalize(E.xyzP.w-P.xyzE.w) vec3 N
normalize(gl_NormalMatrixgl_Normal)
29
Accumulate Each Light
// accumulate contribution from each light
gl_FrontColor vec4(0) for(int i0
iltgl_MaxLights i) vec3 L
normalize(gl_LightSourcei.position.xyzP.w
- P.xyzgl_LightSourcei.position.w)
vec3 H normalize(LV) float diff
dot(N,L) gl_FrontColor
gl_LightSourcei.ambient if (diff gt 0.)
gl_FrontColor
gl_LightSourcei.diffuse diff
gl_FrontColor gl_LightSourcei.specul
ar max(pow(dot(N,H), gl_FrontMaterialShinines
s),0.)
30
Standard Vertex Shader Stuff
// standard texture coordinate and position
stuff gl_TexCoord0 gl_TextureMatrix0gl_Mu
ltiTexCoord0 gl_Position ftransform()

31
Noise
  • Controlled, repeatable randomness
  • Still spotty implementation
  • Can use texture or compute

32
Noise Characteristics
  • Repeatable
  • Locally continuous but distant points
    uncorrolated
  • values -1,1, average 0
  • 1/2  1 cycle per unit
  • Versions for n-D input

33
Noise Subtleties
  • Many noise functions based on a lattice
  • Like a spline between integer coordinates
  • Hash of integer coordinates ? control points
  • Interpolating values easy but poor
  • Even with higher-order interpolation
  • Perlins noise
  • Passes through 0 at each integer
  • Hash gives gradient

34
Modified Noise Olano 2005
  • Three relatively independent modifications
  • New computable hash
  • Change gradient computation
  • Reorder computation
  • Variety of computation/texture options
  • Can just store in a texture
  • Can compute with some texture accesses
  • Can compute with no texture accesses

35
Computable Hash
  • Normal hash chains access to permutation texture
  • Want totally computable hash
  • mod(kx2, m)
  • Still chain for higher-D
  • hash(floor(P.x) hash(floor(P.y)))
  • Not quite as good, but cheap computable
  • Noise usually not used alone

36
Gradient
  • 3D Gradient (fract(P.x), fract(P.y))
  • Each sign from one bit of hash
  • Made slightly more difficult without bitwise ops
  • Allows noise(x) noise(x,0)
  • If 2D noise is stored in a texture
  • Can share the same texture for 1D noise as well
  • Not normally true!

37
Reordered Computation
  • Refactor to be able to build n-D noise from two
    shifted calls to n-1 D noise
  • If 2D noise is stored in a texture
  • Can build 3D noise from 2 texture accesses
  • Can build 4D noise from 4 texture accesses

38
Shader Design Strategies
  • Learn and adapt from RenderMan
  • Noise
  • Layers
  • Multiple Passes
  • Baked computation

39
(No Transcript)
