From Textual Information to Numerical Vectors

1
From Textual Information to Numerical Vectors

• Shilpa Venkataramana
• Kent State University

2
Introduction

• To Mine Text we need to process it in a form that
  Data Mining procedures use.
• From earlier chapter, this involves generating
  features in a spread sheet format
• Classical data mining looks at highly structured
  data
• Spreadsheet Model is embodiment of representation
  that is supportive of predictive modeling.
• Predictive text mining is simpler and more
  restrictive than open ended data mining.
• Text mining is unstructured because very far from
  the spreadsheet model that we need to process
  data for prediction.

3
Introduction

• Transformation of data to spreadsheet model is
  methodical and carefully organized procedure to
  fill in cells in a spread sheet.
• We have to determine nature of column in spread
  sheet.
• Features are easy to obtain , some are difficult.
  Features (word in a text-easy) grammatical
  function of a word in a sentence
• Discuss ????
• How to Obtain the kinds of features generated
  from Text

4
Collecting Documents

• Text Mining is collect data
• Web page retrieval application for an intranet
  implicitly specifies the relevant documents to be
  the web pages on the intranet
• If documents are identified, then they can be
  obtained- main issue cleanse the samples and
  ensure high quality
• Web application compromising a number of
  autonomous Websites, one may deploy s/w tool
  such as WebCrawler to collect the documents

5
Collecting Documents

• Other application u have a logging process
  attached to an input data steam for a length of
  time (eg -gt email audit u will log in the
  incoming and outgoing messages at mail server for
  a period of time)
• For RD work of Text Mining - we need generic
  data. Corpus
• Accompanying Software is Reuter which is called
  Reuters corpus(RV1)
• Early days (1960s and 1970s)1 million works was
  considered
• size of collection of size of collection Brown
  corpus consist of 500 samples for 2000 words of
  American English test

6
Collecting Documents

• European corpus was modeled on Brown corpus
  British English
• 1970s 0r 80s more resource were available- govt
  sponsored.
• Some widely used corpora Penn Tree Bank
  (collection manually parsed sentences from
  Journal)
• Resource is World Wide Web. Web crawlers can
  build collections of pages from a particular sit
  such as yahoo. Give n size of web, collections
  require cleaning before use

7
Document Standardization

• When Documents are collected, you can have them
  in different formats-
• Some documents may be collected in word format or
  simple text with ASCII format. To process these
  documents we have to convert them to standard
  formats
• Standard Format XML
• XML is Extensible Markup Language

8
Document Standardization-XML

• Standard way to insert tags onto text to identify
  its parts.
• Each Document is markedoff from corpus through
  XML
• XML will have tags
• ltDategt
• ltSubjectgt
• ltTopicgt
• ltTextgt
• ltBodygt
• ltHeadergt

9
XML An Example

• lt?xml version"1.0" encoding"ISO-8859-1"?gt
• - ltnotegt
• lttogtTovelt/togt
• ltfromgtJanilt/fromgt
• ltheadinggtReminderlt/headinggt
• ltbodygtDon't forget me this
  weekend!lt/bodygt
• lt/notegt

10
XML

• The main reason to identify the parts is to allow
  selection of those parts that is used to generate
  features
• Selected document is concatenated into strings-
  separated by tags
• Document Standardization-
• Why should we care ??
• Advantage of data standardization is mining tools
  can be applied without having to consider the
  pedigree of document.

11
Tokenization

• Document Collected in XMl Format- examine the
  data
• Break the characters into words TOKENS
• Each token is an instance of a type the number
  of tokens is higher than the number of types
• 2 tokens the occurs twice in a sentence. Refer
  to occurrence of a type
• Character space , tab are not tokens but white
  spaces
• Comma, Colon are tokens (between characters) eg-
  USA,INDIA
• between numbers are delimiter (121,135)
• Apostrophe number of uses (Delimiter or part of
  token) eg- DAngelo
• When it is followed by a terminator internal
  quote (Tess.)

12
Tokenization -Pesudocode

• Dash is a terminator a token preceeded ir follwed
  by another dash
• (522-3333)
• Without identifying token it is diffuicult to
  imagine extracting higher level information from
  document

13
Lemmatization

• Once a character stream has been segmented after
  sequence of tokens
• Next Step ?? Convert each tokens to standard
  forms Stemming or Lemmatization. (Application
  dependent)
• Reduce the number of distinct types in corpus and
  increase frequency of occurrence of individual
  types
• English Speakers agree nouns Book and Books are
  2 forms of same word- advantage to eliminate kind
  of variation
• Normalization regularize grammatical variants
  Inflectional Stemming

14
Stemming to a Root

• grammatical variants (singular/plural
  present/past)
• It is always advantageous to eliminate this kind
  of variation before further processing
• When normalization is confined to regular
  grammatical variants such as singular/plural and
  present/past, the process is called Inflectional
  stemming
• The intent of these stemmers is to reach a root
  of no inflectional or derivational prefixes or
  suffixes- end result aggressive stemming Example

• reduce number of types is text

15
Stemming Pseudocode
16
Vector Generation for prediction

• Consider the problem of categorizing documents
• Characteristic feature are tokens or words they
  contain.
• Without deep analysis we can choose to describe
  each document by features that represent the most
  frequent tokens.
• There is collective features called dictionary.
• Tokens or words in the dictionary forms the basis
  for creating a spreadsheet of numeric data
  corresponding to document collection.
• Each Row-gt document column -gtfeature

17
Vector Generation for prediction

• Cells in a spreadsheet is a measurement of
  feature for a document.
• Basic model of data, we will simply check the
  presence or absence of words
• Checking for words is simple because we do not
  check each word in dictionary. We will build a
  hash table. Large samples of digital documents
  are readily available. confidence on variation
  and combinations of words that occurs
• If prediction is our goal then we need one more
  column for correct answer.
• In preparing data for learning, information is
  available from document labels. Our labels are
  binaries and answers which is also called as
  class)
• Instead of generating global dictionary for class
  we consider words in class that we r trying to
  predict.
• If this class is far smaller than the negative
  class which is typical local dictionary is far
  smaller than global dictionary
• Another reduction in dictionary size is to
  compile a lost of stopwords and remove them from
  dictionary.

18

• Stopwords are almost never have any predictive
  capability, such articles a the pronouns as it
  and they.
• Frequency information on the word counts can be
  quite useful in reducing the dictionary size and
  improve predictive performance
• Frequent words are stopwords and can be deleted.
• Alternative approach to local dictionary
  generation is to generate a global dictionary
  from all documents in the collection . Special
  feature selection routines will attempt to
  select a subset of words that have greatest
  potential of prediction- independent(selction
  methods)
• If we have 100 topics to categorize, then 100
  problems to solve . Our choices are 100 small
  dictionary or 1 global dictionary .

19

• Vectors implied by spreadsheet model will be
  regenerated to correspond to small dictionary
• Instead of placing the word in the dictionary -gt
  follow a path printed dictionary and avoid
  storing every variation of word. (no
  singular/plural/past/present)
• Verbs stored in stemming manner.
• Add a layer of complexity in text gain in
  performance and size is reduced
• Universal procedure is trim words to their root
  form -gt difference in meaning (exit /exiting)-
  context of programming (different meanings)
• Small Dictionary- u can capture the best words
  easily.
• Use of tokens and stemming are examples of
  helpful procedures in smaller dictionaries.
  Improve ability of managing of learning and
  accuracy
• Document can be converted to spread sheet .

20

• Each column is feature. Row is a document
• Model of data for predictive text mining in terms
  of spread sheet that populated by ones or zeros.
• Cells represent the presence of dictionary words
  in a document collection. Higher accuracy-gt
  additional transformations
• They are
• Word Pairs and collocations
• Frequency
• Tf-idf
• Word Pairs and Collocations- They serve to
  increase size of dictionary improve performance
  of prediction
• Instead of 0s 1s in cells the frequency of
  word can be used. word the occurs 10 times
  count of the is used)
• Count give better results than binary in cells.
• This leads to compact solutions same solution of
  binary data model. Yet additional frequency yield
  simpler solution.

21

• Frequencies are helpful in prediction but add
  complexity to solutions.
• Compromise that works 3 value system.1/0/2
• Word did not occur -0
• Word occurred one -1
• Word occurred 2 or more times -2
• Capture much added value of frequency without
  adding much complexity to model.
• Another variant is zeroing the values below the
  threshold where tokens min frequency before being
  considered any use.
• Reduce the complexity of spread sheet used in
  Data Mining algorithms
• Other methods to reduce complexity are chi
  square, mutual Information, odds Ratio ..etc
• Next step beyond counting frequency is modify the
  count by perceived importance of that word .

22

• Tf-idf- Compute the weightings or scores of
  words
• Values of positive numbers that we capture the
  absence or presence of the words.
• Eq (a) we see that weight assigned to word j-term
  of frequency modified by a scale factor for
  importance of word. Scale factor is inverse
  document frequency (eq (b))
• Simply checks for number of documents containing
  the word df(j) and reverse scaling.
• Tf-idf(j) tf(j) idf(j) -------? Eq(a)
• Idf(j) log(N/ df(j)) ------? Eq(b)
• When a word appears in a document, the scale is
  lowered and perhaps zero. if word is unique ,
  appears in few documents - scale factor zooms
  upward and appears important
• Alternative of this tf-idf formulation exist, but
  motivation is same. Result is positive score that
  replaces the simple frequency or binary (T/F)
  entry in our cell in spreadsheet.

23

• Another variant is weight the tokens from
  different parts of the document.
• Which Data Transformation Method are BEST????
• No Universal answer.
• Best predictive accuracy is dependent on mating
  all these methods.
• Best variation is one method may not be the one
  for other. Test ALL
• Describe data as populating a spread sheet-cells
  are 0
• Small subset of dictionary words.
• Text Classification a text corpus 1000s words.
  Each individual document ,unique tokens.
• Spread sheet for that document is 0. Rather than
  store all 0s its better to represent the spread
  sheet as a set of sparse vectors (row is list of
  pairs , one element of pair is column and other
  is corresponding nonzero value). By not storing
  the non zero It will increase memory

24
Multi Word Features

• Features are associated with single words (
  tokens delimited with white space)
• Simple scenario is extended to include pair of
  words eg- bon and viant . Instead of separating
  we could feature the word as bonviant.
• Why stop at pairs? Why not consider a multiword
  features??
• Unlike word pairs , the words need not be
  consecutive.
• Eg- Don Smith as feature we can ignore is
  middle name Leroy that may reappear in some
  reference to the person.
• In this case we have to accommodate many
  reference to the noun that involve a number of
  adjectives with desired adjective not the
  adjacent to the noun. Eg- we want to accept a
  phrase broken and dirty vase as an instance
  broken vase

25

• X number if words occurring within a maximum
  window size y(ygtx naturally)
• How features are extracted from text- specialized
  methods???
• If we use frequency methods, combinations of
  words that are relatively frequent.
• Straight forward implementation is simple
  combination of x words in window y
• Measuring the value of multiword feature is done
  correlation between words in potential multiword
  features measures on mutual information or
  likelihood ratio is used!!!
• An algorithm for generating multiword features. A
  straight forward implementation consume lot of
  memory
• Multiword features are not too found in document
  collection, but they are higly predictive

26
(No Transcript)
27

• Labels for Right Answers-
• For prediction an extra column is added to the
  spreadsheet
• Last column contains the labels, looks no
  different from others.
• Its a 0 or 1 indicating a right answer with
  either True/false
• In the sparse vector format are appended to each
  vector separately as either a one (positive
  class) or a Zero (negative class)
• Feature Selection by Attribute Ranking-
• In addition to frequency based approaches,
  feature selection can be done in number of ways.
• Select a set of feature for each category to form
  a local dictionary for the category
• Independent ranking feature attributes according
  to their predictive abilities for category under
  consideration.
• Predictive ability of an attribute can be
  measured by certain quantity how its is
  correlated
• Lets assume n number of documents
  presence or absence of attribute j in x y to
  denote label of document in last column

28

• A commonly used ranking score is information gain
  criterion which is
• The quantity L(j) is number of bits required to
  encode the label and the attribute j minus the
  number of bits required to encode the attribute.
• Quantities are needed to compute L(j). Can be
  easily estimated using the estimators

29
Sentence Boundary Determination

• If the XML markup for corpus doesn't mark
  sentence boundaries, necessary to mark the
  sentence
• Necessary to determine when a period is part of a
  token and when it is not
• For more sophisticated way linguistic parsing,
  the algorithms often require complete sentence as
  input.
• Extraction algorithms operate text a sentence at
  a time
• Algorithms are optimal, sentences are identified
  clearly
• Sentence boundary determination is problem of
  deciding which instances of period followed by
  white space are sentence delimiters and which are
  not, since we assume characters ? !
  classification problem
• Algorithm accuracy and adjustments will give
  better performance

30
(No Transcript)
31
Thank you ? !!!!
