Servlets

1
Servlets

• Web Programming course
• Dan Goldwasser
• dgoldwas_at_cs.haifa.ac.il

2
Outline

• Client server communication
• Session tracking

3
Client Request Data

• When a user submits a browser request to a web
  server, it sends two categories of data
• Form Data Data that the user explicitly typed
  into an HTML form.
• For example registration information.
• HTTP Request Header Data Data that is
  automatically appended to the HTTP Request from
  the client.
• For example cookies, browser type, browser IP
  address.

4
Reading Form Data from Servlets

• The HttpServletRequest object contains three main
  methods for extracting form data
• getParameter(str) used to retrieve a single
  form parameter.
• getParameterValues(str) used to retrieve a list
  of form values, e.g. a list of selected
  checkboxes.
• getParameterNames() used to retrieve a full
  list of all parameter names submitted by the
  user.
• We will examine each of these and then explore
  several examples.

5
getParameter(str) Method

• Used to retrieve a single form parameter.
• Possible return values
• String corresponds to the form parameter.
• Empty String parameter exists, but has no
  value.
• null parameter does not exist.

public String getParameter(String name)
6
getParameterValues(str) Method

• Used to retrieve multiple form parameters with
  the same name.
• For example, a series of checkboxes all have the
  same name, and you want to determine which ones
  have been selected.
• Returns an Array of Strings.
• An array with a single empty string indicates
  that the form parameter exists, but has no
  values.
• null indicates that the parameter does not
  exist.

public String getParameterValues(String name)
7
getParameterNames() method

• Returns an Enumeration object.
• By cycling through the enumeration object, you
  can obtain the names of all parameters submitted
  to the servlet.
• Note that the Servlet API does not specify the
  order in which parameter names appear.

public Enumeration getParameterNames()
8
import java.io. import javax.servlet. import
javax.servlet.http. import java.util. public
class ShowParameters extends HttpServlet
public void doGet(HttpServletRequest request,
HttpServletResponse response) throws
ServletException, IOException
response.setContentType("text/html")
PrintWriter out response.getWriter()
String title "Reading All Request Parameters"
out.println(ServletUtilities.headWithTitle(titl
e) "ltBODY BGCOLOR\"FDF5E6\"gt\n
" "ltH1 ALIGNCENTERgt" title
"lt/H1gt\n" "ltTABLE BORDER1
ALIGNCENTERgt\n" "ltTR
BGCOLOR\"FFAD00\"gt\n"
"ltTHgtParameter NameltTHgtParameter Value(s)")
Output a simple HTML table for displaying the
form parameters.
Continued.
9
Enumeration paramNames request.getParameterN
ames() while(paramNames.hasMoreElements())
String paramName (String)paramNames.next
Element() out.print("ltTRgtltTDgt" paramName
"\nltTDgt") String paramValues
request.getParameterValues(paramName) if
(paramValues.length 1) String
paramValue paramValues0 if
(paramValue.length() 0)
out.println("ltIgtNo Valuelt/Igt") else
out.println(paramValue) else
out.println("ltULgt") for(int i0
iltparamValues.length i)
out.println("ltLIgt" paramValuesi)
out.println("lt/ULgt")

• First, use getParameterNames() to retrieve an
  Enumeration of all form parameters.
• Then, iterate through each element within the
  Enumeration.

Continued.
10
out.println("lt/TABLEgt\nlt/BODYgtlt/HTMLgt")
public void doPost(HttpServletRequest request,
HttpServletResponse response)
throws ServletException, IOException
doGet(request, response)
11
(No Transcript)
12
HTTP Request Header Data

• HTTP Request Header Data Data that is
  automatically appended to the HTTP Request from
  the client.
• For example cookies, browser type, etc,

GET / HTTP/1.1 Accept / Accept-Language
en-us Accept-Encoding gzip, deflate User-Agent
Mozilla/4.0 (compatible MSIE 5.0 Windows NT
DigExt) Host www.yahoo.com Connection Keep-Alive
HTTP request headers
13
Accessing HTTP Headers

• To access any of these Headers, use the
  HTTPServletRequest getHeader() method.
• For example
• String connection req.getHeader(Connection)
• To retrieve a list of all the Header Names, use
  the getHeaderNames() method.
• getHeaderNames() returns an Enumeration object.
• For example
• Enumeration enum req.getHeaderNames()

14
Additional HTTP Information

• getMethod()
• Indicates the request method, e.g. GET or POST.
• getRequestURI()
• Returns the part of the URL that comes after the
  host and port. For example, for the URL
  http//randomhost.com/servlet/search, the request
  URI would be /servlet/search.
• getProtocol()
• Returns the protocol version, e.g. HTTP/1.0 or
  HTTP/1.1

15
import java.io. import javax.servlet. import
javax.servlet.http. import java.util. public
class ShowRequestHeaders extends HttpServlet
public void doGet(HttpServletRequest request,
HttpServletResponse response)
throws ServletException, IOException
response.setContentType("text/html")
PrintWriter out response.getWriter()
String title "Servlet Example Showing Request
Headers" out.println(ServletUtilities.headWit
hTitle(title) "ltBODY
BGCOLOR\"FDF5E6\"gt\n" "ltH1
ALIGNCENTERgt" title "lt/H1gt\n"
"ltBgtRequest Method lt/Bgt"
request.getMethod() "ltBRgt\n"
"ltBgtRequest URI lt/Bgt"
request.getRequestURI() "ltBRgt\n"
"ltBgtRequest Protocol lt/Bgt"
request.getProtocol() "ltBRgtltBRgt\n"
"ltTABLE BORDER1 ALIGNCENTERgt\n"
"ltTR BGCOLOR\"FFAD00\"gt\n"
"ltTHgtHeader NameltTHgtHeader Value")
Continued.
16
Enumeration headerNames request.getHeaderNames(
) while(headerNames.hasMoreElements())
String headerName (String)headerNames.nextElem
ent() out.println("ltTRgtltTDgt"
headerName) out.println(" ltTDgt"
request.getHeader(headerName))
out.println("lt/TABLEgt\nlt/BODYgtlt/HTMLgt")
/ Let the same servlet handle both GET and
POST. / public void doPost(HttpServletReques
t request,
HttpServletResponse response) throws
ServletException, IOException
doGet(request, response)
17
CGI Variables

• In addition to HTTP Request headers, you can also
  determine additional information about both the
  client and the server
• IP Address of Client
• Host Name of Client
• Server Name
• Server Port
• Server Protocol
• Server Software

18
import java.io. import javax.servlet. import
javax.servlet.http. import java.util. public
class ShowCGIVariables extends HttpServlet
public void doGet(HttpServletRequest request,
HttpServletResponse response)
throws ServletException, IOException
response.setContentType("text/html")
PrintWriter out response.getWriter()
String variables
"REMOTE_ADDR", request.getRemoteAddr() ,
"REMOTE_HOST", request.getRemoteHost() ,
"SERVER_NAME", request.getServerName() ,
"SERVER_PORT", String.valueOf(request.getServerPor
t()) , "SERVER_PROTOCOL",
request.getProtocol() ,
"SERVER_SOFTWARE", getServletContext().getServerIn
fo()
Continued.
19
String title "Servlet Example Showing CGI
Variables" out.println(ServletUtilities.headW
ithTitle(title) "ltBODY
BGCOLOR\"FDF5E6\"gt\n" "ltH1
ALIGN\"CENTER\"gt" title "lt/H1gt\n"
"ltTABLE BORDER1 ALIGN\"CENTER\"gt\n"
"ltTR BGCOLOR\"FFAD00\"gt\n"
"ltTHgtCGI Variable NameltTHgtValue")
for(int i0 iltvariables.length i)
String varName variablesi0 String
varValue variablesi1 if (varValue
null) varValue "ltIgtNot specifiedlt/Igt"
out.println("ltTRgtltTDgt" varName "ltTDgt"
varValue) out.println("lt/TABLEgtlt/BODYgtlt
/HTMLgt")
20
Generating the Server Response

• Servlets can return any HTTP response they want.

HTTP/1.1 200 OK Date Mon, 06 Dec 1999 205426
GMT Server Apache/1.3.6 (Unix) Last-Modified
Fri, 04 Oct 1996 140611 GMT Content-length
327 Connection close Content-type text/html
lttitlegtSample Homepagelt/titlegt ltimg
src"/images/oreilly_mast.gif"gt lth1gtWelcomelt/h2gtHi
there, this is a simple web page. Granted, it
may
21
Setting the HTTP Status Code

• Normally, your Servlet will return an HTTP Status
  code of 200 OK to indicate that everything went
  fine.
• To return a different status code, use the
  setStatus() method of the HttpServletResponse
  object.
• Be sure to set the status code before sending any
  document content to the client.

22
Using setStatus()

• setStatus takes an integer value. But, its best
  to use the predefined integers in the
  HttpServletResponse. Here are a few
• SC_FORBIDDEN
• Status code (403) indicating the server
  understood the request but refused to fulfill it.
• SC_INTERNAL_SERVER_ERROR
• Status code (500) indicating an error inside the
  HTTP server which prevented it from fulfilling
  the request.
• SC_NOT_FOUND
• Status code (404) indicating that the requested
  resource is not available.

23
Sending Redirects

• You can redirect the browser to a different URL
  by issuing a Moved Temporarily Status Code
• SC_MOVED_TEMPORARILY Status code (302)
  indicating that the resource has temporarily
  moved to another location.
• Because this is so common, the HttpServletResponse
  interface also has a sendRedirect() method.
• Example
• res.sendRedirect( http//www.yahoo.com)

24
import java.io. import javax.servlet. import
javax.servlet.http. public class
WrongDestination extends HttpServlet public
void doGet(HttpServletRequest request,
HttpServletResponse response)
throws ServletException, IOException String
userAgent request.getHeader("User-Agent")
if ((userAgent ! null)
(userAgent.indexOf("MSIE") ! -1))
response.sendRedirect("http//home.netscape.com")
else response.sendRedirect("http//
www.microsoft.com")
25
Servlet Session tracking

• Cookies
• Session API Tracking in Java

26
The Potential of Cookies

• Idea
• Servlet sends a simple name and value to client.
• Client returns same name and value when it
  connects to same site (or same domain, depending
  on cookie settings).
• Typical Uses of Cookies
• Identifying a user during an e-commerce session
• Avoiding username and password
• Customizing a site
• Focusing advertising

27
Creating Cookies

• Three steps to creating a new cookie
• Create a new Cookie Object
• Cookie cookie new Cookie (name, value)
• Set any cookie attributes
• Cookie.setMaxAge (60)
• Add your cookie to the response object
• Response.addCookie (cookie)
• We will examine each of these steps in detail.

28
Sending Cookies to the Client

• Create a Cookie object.
• Call the Cookie constructor with a cookie name
  and a cookie value, both of which are strings.
• Cookie c new Cookie("userID", "a1234")
• Set the maximum age.
• To tell browser to store cookie on disk instead
  of just in memory, use setMaxAge (argument is in
  seconds)
• c.setMaxAge(6060247) // One week
• Place the Cookie into the HTTP response
• Use response.addCookie.
• If you forget this step, no cookie is sent to the
  browser!
• response.addCookie(c)

29
Reading Cookies

• To create cookies, add them to the response
  object.
• To read incoming cookies, get them from the
  request object.
• HttpServletRequest has a getCookies() method.
• Returns an array of cookie objects. This
  includes all cookies sent by the browser.
• Returns a zero-length array if there are no
  cookies.

30
Reading Cookies

• Once you have an array of cookies, you can
  iterate through the array and extract the one(s)
  you want.
• Our next few examples illustrate how this is done.

31
Example RepeatVisitor.java

• This servlet checks for a unique cookie, named
  repeatVisitor.
• If the cookie is present, servlet says Welcome
  Back
• Otherwise, servlet says Welcome aboard.

32
Using Cookies to Detect First-Time Visitors

• public class RepeatVisitor extends HttpServlet
• public void doGet(HttpServletRequest request,
• HttpServletResponse response)
• throws ServletException, IOException
• boolean newbie true
• Cookie cookies request.getCookies()
• if (cookies ! null)
• for(int i0 iltcookies.length i)
• Cookie c cookiesi
• if((c.getName().equals("repeatVisitor"))

• (c.getValue().equals("yes")))
• newbie false
• break

33
Using Cookies to Detect First-Time Visitors
(Continued)

• String title
• if (newbie)
• Cookie returnVisitorCookie
• new Cookie("repeatVisitor", "yes")
• returnVisitorCookie.setMaxAge(606024365)

• response.addCookie(returnVisitorCookie)
• title "Welcome Aboard"
• else
• title "Welcome Back"
• response.setContentType("text/html")
• PrintWriter out response.getWriter()
• // (Output page with above title)

34
(No Transcript)
35
Session API Tracking in Java

• Servlets include a built-in Session API
• Enables you to very easily create applications
  that depend on individual user data
• For example
• Shopping Carts
• Personalization Services
• Maintaining state about the users preferences.

36
Using the Session API

• Steps to using the Java Session API
• Get the Session object from the HTTPRequest
  object.
• Extract Data from the users Session Object
• Extract information about the session object
• - e.g. when was the session created, session ID?
• Add data to the users Session Object.

37
Session Tracking Basics

• Access the session object
• Call request.getSession to get HttpSession object
• HttpSession session request.getSession()
• Look up information (user data) associated with a
  session.
• Call getAttribute on the HttpSession object,
• cast the return value to the appropriate type,
• and check whether the result is null.

38
Session Tracking Basics

• Store information in a session.
• Use setAttribute with a key and a value.
• Discard session data.
• Call removeAttribute discards a specific value
  associated with a specified key (This is the
  most common approach used).
• Call invalidate to discard an entire session (all
  user data) will be lost including data created by
  other servlets or jsp) be careful!.

39
Behind the Scenes

• When you call getSession()
• There is a lot going on behind the scenes.
• Each user is automatically assigned a unique
  session ID.
• How does this sessionID get to the user?
• Option 1
• If the browser supports cookies
• the servlet will automatically create a session
  cookie
• and store the session ID within the cookie.
• (In Tomcat, the cookie is called JSESSIONID)
• Option 2
• If the browser does not support cookies,
• the servlet will try to extract the session ID
  from the URL.

40
Extracting Data From Session

• The Session object works like a Hash Map
• Hash Map that enables you to store any type of
  Java object.
• You can therefore store any number of keys and
  their associated values.
• To extract an existing object,
• use the getAttribute() method.

Integer accessCount (Integer)session.getAttribu
te("accessCount")
41
Extracting Data from Session

• If you want to get a list of
• all keys (or attributes) associated with a
  Session,use the
• getAttributeNames() method.
• returns an Enumeration of all Attribute names
  (keys).

42
Additional Session Info.

• public String getId()
• Returns the unique session ID associated with
  this user, e.g. gj9xswvw9p
• public boolean isNew()
• Indicates if the session was just created (first
  time to this servlet).
• public long getCreationTime()
• Indicates when the session was first created in
  milliseconds since midnight January 1, 1970
  (GMT).
• public long getLastAccessedTime()
• Indicates when the session was last sent from the
  client.

43
Adding Data To Session

• To add data to a session, use the
• putAttribute() method,
• and specify the key_name and value.
• Example
• session.putAttribute("accessCount", accessCount)
• To remove a value, you can use the following
• removeAttribute (String name) method.

44
Terminating Sessions

• public void invalidate()
• If the user does not return to a servlet for XX
  minutes,
• the session is automatically invalidated and
  deleted.
• If you want to manually invalidate the session,
• you can call invalidate().
• For the exact number of Minutes before
  automatic expiration, check the
  getMaxInactiveInterval() method.

45
Example

• Our example tracks the number of visits for each
  unique visitor.
• If this is a first time visit,
• the servlet creates an accessCount of Integer
  Integer Type and assigns it to the Session.
• If the user has visited before,
• the servlet extracts the accessCount and
  increments it, and assigns it to the Session.
• Servlet also displays
• basic information regarding the session
  including
• creation time and time of last access.

46
import java.io. import javax.servlet. import
javax.servlet.http. import java.net. import
java.util. public class ShowSession extends
HttpServlet public void doGet(HttpServletReque
st request,
HttpServletResponse response) throws
ServletException, IOException
response.setContentType("text/html")
PrintWriter out response.getWriter()
String title "Session Tracking Example"
HttpSession session request.getSession(true)
String heading
47
Integer accessCount
(Integer)session.getAttribute("accessCount")
if (accessCount null) // new user
accessCount new Integer(0) heading
"Welcome, Newcomer" else // returning
user heading "Welcome Back"
accessCount new Integer(accessCount.intValue()
1) // Integer is an immutable
(nonmodifiable) data structure. So, you can not
modify the old one in-place.//Instead you have
to to allocate a new one and redo setAttribute.
session.putAttribute("accessCount",
accessCount) out.println(ServletUtilities.he
adWithTitle(title) "ltBODY
BGCOLOR\"FDF5E6\"gt\n" "ltH1
ALIGN\"CENTER\"gt" heading "lt/H1gt\n"
"ltH2gtInformation on Your
Sessionlt/H2gt\n" "ltTABLE
BORDER1 ALIGN\"CENTER\"gt\n"
"ltTR BGCOLOR\"FFAD00\"gt\n"
48
" ltTHgtInfo TypeltTHgtValue\n"
"ltTRgt\n" " ltTDgtID\n"
" ltTDgt" session.getId() "\n"
"ltTRgt\n" "
ltTDgtCreation Time\n" " ltTDgt"
new Date(session.getCreationTime
()) "\n" "ltTRgt\n"
" ltTDgtTime of Last Access\n"
" ltTDgt" new
Date(session.getLastAccessedTime()) "\n"
"ltTRgt\n" "
ltTDgtNumber of Previous Accesses\n"
" ltTDgt" accessCount "\n"
"lt/TRgt"
49
"lt/TABLEgt\n"
"lt/BODYgtlt/HTMLgt") / Handle GET and POST
requests identically. / public void
doPost(HttpServletRequest request,
HttpServletResponse response) throws
ServletException, IOException
doGet(request, response)
50
(No Transcript)
51
(No Transcript)
52
Summary

• What two categories of client data are there? How
  is each accessed?
• How can an HTTP response redirect the client to a
  new URL?
• What is the difference between Java Session
  tracking API to cookies?
• How are cookies used in a Servlet?
• What is an HTTPSession object? How is it used?

53

• Questions?
