Title: Crack Control Jointing


1
Jointing of Concrete Pavements
CE 453 April 2, 2008 Larry Stevens, P.E. SUDAS
Director
Add PCC Center logo
2
Primary Benefits of Jointing
  • Crack Control
  • Accommodating slab movements
  • Providing desirable load transfer
  • Dividing the pavement into practical construction
    increments
  • Providing traffic guidance

3
Why is Jointing Necessary?
  • Pavement cracking results from
  • stress caused by concrete drying shrinkage
  • subgrade restraint
  • temperature/moisture differentials
  • applied traffic loads
  • combined effects of restraint curling and warping

4
Crack Development
  • Initial Cracking- Occurs within few hours to few
    months
  • Shrinkage
  • Temperature change during hydration
  • Loss of water during hydration (drying shrinkage)
  • Subgrade and Subbase Restraint
  • Curling and Warping

5
Crack Development
  • Mature Cracking Occurs several months or years
    after placement
  • Curling and warping combine with repetitive
    traffic loads
  • Poorly designed joints
  • Do not provide proper load transfer between slabs
  • Poor subgrade support

6
Initial Cracking from Subgrade/Subbase Restraint
  • Concrete shrinks moderately as it sets
  • Temperature and Drying shrinkage
  • Subgrade or subbase resists the concrete
    contraction
  • The resulting tensile stresses can cause cracking
    before the slab gains sufficient strength

7
Initial Cracking from Temperature changes
  • Heat of hydration peaks shortly after final set
  • After internal temperature peaks and hardening
    occurs, concrete shrinks (which is normal)
  • Significant changes in air temperature shortly
    after construction may cause large change between
    internal and external temperatures.
  • Contraction due to temp reduction vs.
    subgrade/subbase restraint
  • May cause tensile stress to exceed tensile
    strength
  • Solution Early sawing to relieve stress

8
Initial Cracking from Drying Shrinkage
  • For workability, todays concrete requires more
    mix water than what is necessary for chemical
    hydration
  • Normally, the surplus evaporates, moderately
    reducing concrete volume by an acceptable level
  • If excessive water evaporates, volume loss can be
    substantial enough to cause cracking

9
Initial Cracking from Curling
  • Curling results from temperature differences at
    various depths in the slab
  • During daytime, top is warmer than bottom
  • Relative expansion at top causing curling
  • At night, affects are reversed
  • Weight of slab and subbase/subgrade friction are
    factors that help counteract

10
Daytime Curling
11
Nighttime Curling
12
Crack Development
  • Moisture Warping
  • Moisture differential at top and bottom of slab
  • Top usually drier than bottom
  • Causes contraction at top
  • Helps to counteract daytime curling
  • Contraction causes stresses, leads to cracking

13
What happens if jointing isnt done correctly?
¼ Pt Crack
Mid-panel crack
14
What happens if jointing isnt done correctly?
Sympathy Cracks
15
How to Control Cracking
  • Proper timing of sawing of joints
  • Properly designed joint layout
  • Proper curing
  • Uniform soils, moisture, and density
  • Uniform moisture in subgrade
  • Eliminate concentrated wet areas

16
Considerations for Good Jointing
  • Joint Purpose
  • Transverse and longitudinal joints relieve
    stresses
  • Transverse also relieve contraction
  • Environmental Conditions
  • At time of construction
  • Slab Thickness
  • Affects curling and deflections from load
    transfer
  • Thicker pavements less prone to curling

17
Considerations for Good Jointing
  • Load Transfer
  • Desirable across all pavement joints
  • Joint Spacing vs thickness
  • Function of spacing, subgrade, and subbase types
    and thickness
  • Traffic
  • Classification, channelization, truck traffic
    influence load transfer

18
Considerations for Good Jointing
  • Material and Construction Characteristics
  • Influence slab shrinkage
  • Subbase type
  • Affects slab movement and support
  • Shoulder Design
  • Type (including curbs) affects edge support

19
Load Transfer
  • Factors that contribute to load transfer
  • Aggregate interlock
  • Mechanical load transfer devices
  • Quality of subgrade and subbase
  • Skewed joints

20
Aggregate Interlock
  • Interlock between aggregate particles at face of
    joint
  • Occurs below the joint sawcut
  • Helps minimize faulting
  • Suitable load transfer when truck volumes are
    fewer than 80-100 per day per lane

21
Load Transfer
  • Traffic loadings must transfer from one side of
    the joint to the other
  • Measured by joint effectiveness
  • 100 effective will transfer approximately half
    of applied load

22
Aggregate Interlock
  • To Increase Aggregate Interlock, Use
  • Longitudinal tiebars and/or keyways
  • Shorter transverse joint spacings
  • Larger concrete coarse aggregate size
  • Crushed stone (angular creates rough joint space)
  • Stiffer subgrade/subbase (more support)
  • Coarse grained subgrade soils (improved drainage)

23
Mechanical Load Transfers
  • Dowel bars
  • Keeps slabs in horizontal and vertical alignment
  • Provides load transfer
  • Daily and seasonal joint openings have less
    effect on load transfer
  • Lowers deflection and stress in slabs

24
Mechanical Load Transfers
  • Use Dowel Bars When
  • Truck traffic exceeds 120 per day
  • For 8 slabs
  • Recommended at 15 intervals
  • For 9 slabs
  • Recommended at 20 intervals

25
Subgrades and Subbases
  • Proper foundation
  • Reduces joint deflection
  • Assists in aggregate interlock
  • Improves and maintains joint effectiveness under
    repetitive loads
  • Stiffer foundation increases slab stresses
  • Shorter transverse spacing may be required

26
Types of Joints
  • Transverse contraction
  • Longitudinal contraction
  • Transverse Longitudinal construction
  • Expansion and Isolation

27
Maximum Spacing of Transverse and Longitudinal
Joints for Plain Jointed Pavement
28
Transverse Contraction Joints
  • Constructed across pavement lanes and is used to
    control
  • Stresses from volume change due to moisture loss
    and thermal change (curling and warping)
  • Early curing and mature cracking

29
Plain C Transverse Contraction Joints
  • Slab thickness less than 8
  • Sawed to T/3 depth
  • ¼ wide and sealed early entry sawing (Softcut)
    may be used
  • Spaced at 15 intervals

30
Doweled CD Transverse Contraction Joints
  • Arterials and major collectors 8 thick or
    greater (gt120 trucks/lane)
  • Sawed to depth of T/3 (early entry may be used)
    and sealed
  • Dowels at mid-depth
  • 15 intervals for 9 or less 20 for greater
    than 9

31
L Longitudinal Contraction Joints
  • Used to release stresses from dynamic loading and
    restrained curling and warping
  • Allows pavement to hinge
  • Delineates traffic lanes
  • Depth is T/3 joints may or may not be sealed
  • Early sawing is NOT recommended
  • Not deep enough

32
L Longitudinal Contraction Joints
33
Longitudinal Contraction Joints
  • Important considerations
  • Spacing for pavements less than 9 inches
  • 6.5 min. to 12.5 max.
  • Use of gutter joints not recommended for
    thicknesses less than 9
  • Thinner pavements may not crack through at gutter
    joint, causing longitudinal cracks at mid-panel
  • Spacing for pavements greater than 9 inches
  • 14.5 max.

34
26-Foot B-B Pavement
35
31-Foot B-B Pavements
36
Transverse and Longitudinal Construction Joints
  • Necessary for
  • Planned construction interruptions
  • Widening/extending a pavement
  • Emergency interruptions that suspend construction
    for more than 30 minutes
  • Usually butt-type joints with deformed tie bars
    or dowels to provide load transfer and prevent
    vertical movement
  • No joint seal, if deformed bars are used

37
Transverse Construction Joints
  • Used at stopping point (mid-panel)

38
Transverse Construction Joints
  • Used when the pavement ends and traffic will
    cross the joint

39
Transverse Construction Joints
  • Used when an older slab is extended

40
Transverse Construction Joints
  • Used when placed at CD joint location

41
Longitudinal Construction Joints
  • Used when lanes are constructed at different
    times
  • Tie-bars help with load transfer and vertical and
    horizontal control
  • Designed to overcome resistance of
    subgrade/subbase to horizontal movement as
    pavement contracts

42
Longitudinal Construction Joints
  • Timely transverse sawing important to prevent.
  • Sympathy cracking in new lane construction
  • Longitudinal tie-bar stress in cooler weather
    conditions
  • If new lane is in its final set at the same time
    the existing lane is expanding, stress can be
    significant

43
Longitudinal Construction Joints
  • Used to tie existing and new parallel pavements
    together

44
Longitudinal Construction Joints
  • Used when tie-bars are not desired or needed and
    load transfer is required

45
Longitudinal Construction Joints
TOOL JOINT, NO SAW OR SEAL
  • Used in pavements under heavier traffic
    conditions and typically where thickness is 8 or
    greater

46
Transverse Expansion Joints and Isolation Joints
  • Allow pavement movement without damaging adjacent
    structures

47
Transverse Expansion Joints
  • Full-depth, full-width joints with contraction
    joints in between
  • An old practice that allowed excessive C joint
    opening and loss of aggregate interlock
  • Often caused joint pumping and spalling
  • These joints are needed only in special locations
    (i.e. bridge isolation)

48
Transverse Expansion Joints
THICKENED EDGE EXPANSION JOINT
49
Doweled Expansion Joints
50
Isolation Joints
  • Full depth, full width joints to isolate pavement
    from a structure, another paved area, or
    immovable object
  • Also applies to in-pavement structures such as
    drainage inlets, utility accesses, etc.
  • May be used to isolate intersecting street from
    through street

51
Isolation Joints
  • At T- and unsymmetrical intersections or ramps
    that are not doweled so that horizontal movements
    can occur

52
Manhole Boxouts
53
Intake Boxout Joints
54
Slab Reinforced Jointed Pavements
  • Not to be confused with continuously reinforced
    pavements, which have very few joints
  • Plain jointed pavements have no reinforcing
    except at the joints
  • SRJ pavements use bar mats which contain both
    longitudinal and transverse elements
  • Doweled joints are same for both
  • Bar mats are stopped at transverse joint

55
Slab Reinforced Jointed Pavements
  • SRJ primarily used to
  • Control cracking
  • Provide for load transfer
  • Maintain structural integrity between transverse
    joints
  • Random cracking may still occasionally occur, but
    reinforcing serves to hold cracks together

56
Slab Reinforced Jointed Pavements
  • Use of reinforcing steel will not
  • Add to the load carrying capacity of the pavement
  • Compensate for poor subgrade or construction
    practices
  • It will however maintain shear resistance of slab
    by holding cracks together

57
Joint-layout of Urban Streets
  • Step 1 Set transverse contraction and
    longitudinal joints at predetermined locations
  • Higher volume, multi-lane streets may require
    longitudinal joints to delineate lane widths
  • These joints should be placed first

58
Joint-layout of Urban Streets
  • Within the intersection, the street that is paved
    first determines which joints are longitudinal
    and which are transverse
  • Generally, mainline paved prior to adjacent
    streets
  • Longitudinal joints running down city street
    define locations of the first transverse joints
    for the mainline
  • Type of joint used normally depends on pavement
    thickness

59
Placement of Predetermined Joints
Step 1. Set Predetermined Joints1. Set
Longitudinal Joints2. Paved first determines
which are longitudinal and which are
transverse3. Pavement thickness normally
determines type of joint
60
Jointing Urban Streets
  • Step 2 Locate difficult joints
  • Intake locations and boxouts at the corner radii
    are addressed next
  • Extend ends of intake boxouts with two transverse
    joints
  • For radii boxouts, locate corners at least two
    feet from pavement edge

61
Placement of Difficult Joints
Step 2. Locate Difficult Joints1. Intakes -
Across Pavement2. Boxouts - Greater than 2
feet in width - Greater than 70o _at_ curb
62
Placement of Remaining Joints
Step 3. Set Remaining Joints1. Set Remaining
Transverse Joints2. Do not exceed 70o at curb
and keep joint break greater than 120o
63
Final Jointing Layout
Step 4. Label Joints1. ED Joints at
intakes2. B Joints at Intakes3. KT Joints
at Centerline Boxouts4. CD Joints at
Mainline5. C Joints at Side Street
ED
ED
64
Quarter Point Jointing, Concentric Widening
(from 31 to 41)
Painted
65
Typical Quarter Point Jointing with One Side
Widening (from 31 to 41)
66
Typical Gutter Line Jointing(from 31 to 41)
Raised
67
Four-Lane Roadway Widened to Five Lanes with
Raised Median
68
Cul-de-Sac Joint Locations
69
General Jointing Practices for PCC Overlays
70
Questions?
Write a Comment
User Comments (0)
About PowerShow.com
