Part 1 Introduction

1
Part 1 - Introduction

• WXGA6101 Advanced Programming Issues
• By Rathija Subramaniam
• WGA 050015

2
C History

• The C language, a widely known programming
  language is actually a revised version of the
  good old C.
• Unlike other programming languages, C emerged
  only in 1983.
• It was written by Bjarne Stroustrup at Bell Labs
  during 1983-1985.
• The progress of C comes from C, which lacked
  the object oriented paradigm in it. Thus, C was
  developed as a superset of C.
• The C language is developed to suit the current
  ANSI and ISO standards.
• A lament term for C would be C embedded with
  class, a powerful function in the programming
  environment.
• Throughout the early years of its development, a
  number of C versions were produced. The first
  version 1.0 contained classes, inheritance,
  overloading and polymorphism.
• The 2nd version had multiple inheritances. In
  1990, the C was modified to suit the ANSI/ISO
  Standardization. Again in the year 1991 and 1994,
  the 3rd version with generosity and exceptions
  were developed
• C gained popularity only after a few years of
  its introduction to the programming world as
  programmers found adapting to C was slightly
  difficult in the beginning. Now, however, C has
  become the base for development of other
  programming language.

3
Supported programming paradigm

• The programming paradigm or the grammar of C is
  very wide.
• In the C context, programming paradigm refers
  to the technical grammar, instructive words used
  in the language.
• Similar to other programming language, C has
  its own pattern to work with its paradigm.
• This brings us to the most important aspect of
  C, its object oriented functionality. Other
  paradigms supported by C are, procedural
  programming, object-based programming and generic
  programming.
• The major advantage of C from its paradigm
  perspective would be that, a programmer can
  design and build a program based on one or more
  than one programming paradigm.
• For example, a system build using the C
  language can be done using procedural functions
  or it can be a purely object-oriented program, or
  the program can be done is such a way that it
  contains elements of both paradigms.
• In short, C supports multiple programming
  paradigm which is very useful in creating large
  application.

4
Application Area

• Today, many application and programming language
  run with a C logic.
• Among them, Common Object Request Broker
  Architecture (CORBA) has emerged as a new
  language for the OMG.
• C is also programmed for client server
  architecture. Other application include, business
  application, WMI application, video and audio
  application. In fact, C is also used in many
  Unix system due to its security and portability.
• Other application developed using C
• Adobe Systems
• AliasWavefront Maya
• Apple OS X
• Sun

5
C Features

• Namespace support solves the problem of
  identifier name clashes in large applications.
• Templates to develop a family of related
  functions or classes.
• Exception handling provides a standard method to
  handle run-time errors.
• New-style type-safe casting makes safe type
  conversions even when working with polymorphous
  classes.
• Run-time type identification (RTTI) determines
  the type of a data object at runtime virtual,
  reference, or pointer.
• Three distinct character types overload functions
  based on a distinction between char, signed char,
  and unsigned char.
• New keywords and macros, such as bool, mutable,
  explicit, and type name, provide greater
  flexibility.

6
C Security, Portability, Efficiency,
Extensibility/Maintainability

• Design patterns, the growing focus on design
  patterns and idioms will enable C programmers
  to benefit from successful techniques known to
  expert C programmers, as well as to leverage
  useful strategies and tactics from other language
  communities.
• In turn, this will increase the flexibility and
  extensibility of C programs, without having to
  switch languages.
• For programming in Windows you will have to use
  Visual C. Like elegance, efficiency comes from
  knowing the type of each object at compile time.
• For a small example like the one above,
  performance is probably not an issue.
• However, C is used in application areas where
  performance is essential, such as high-energy
  physics, gaming, and some embedded system
  applications Stroustrup,2003.
• In such applications, programs usually rely on
  highly tuned libraries providing fundamental
  operations. For example, there are vector and
  matrix libraries that make the performance of
  standard scientific and numeric computations as
  good as that of Fortran while significantly
  improving notation.
• Extensibility/ Maintainability Completion of
  the ANSI/ISO Standard -- this will finally allow
  compiler vendors to build robust tools and to
  enable the development of C applications that
  can compile easily on more than one platform and
  more than one compiler.

7
C Compilation/Interpretation/Execution

• The other aspects of C include the advantage of
  its compilation.
• Since the code is designed to compile with the
  ANSI, it runs on any ANSI C compiler.
• However, most profiling runs were done with good
  compiler optimizations disabled to prevent any
  compiler-specific options influencing the output.
• In fact, C involves templates and the Standard
  Template Library for complex techniques. The C
  is optimized to run on various platforms, but the
  most common one would be the Microsoft Visual
  C.
• In short, C provides fast and coherent
  compilation it has global optimization to
  generate efficient codes, built in assembler that
  allows assembly, procedural language to be
  embedded in it to optimize the code.
• C has been configured to adapt to
  interpretation in its latest version. This is one
  of Cs strengths. C is supported by all major
  platform vendors and implemented according to its
  international (ISO) standard It is therefore less
  vulnerable to changes of fashion and the whims of
  commercial organizations than proprietary
  languages.

8
Part II Description Of Language
9
Scalar Data Objects

• A data object is a region of storage that
  contains a value or group of values.
• Each value can be accessed using its identifier
  or a more complex expression that refers to the
  object. In addition, each object has a unique
  data type.
• The data type of an object determines the storage
  allocation for that object and the interpretation
  of the values during subsequent access.
• It is also used in any type checking operations.
  Both the identifier and data type of an object
  are established in the object declaration.

10
Scalar Data Objects (Cont)

• Data types are often grouped into type categories
  that overlap, such as
• Fundamental types versus derived types
• Built-in types versus user-defined types
• Scalar types versus aggregate types
• Example
• double pidouble pi 3.14159265struct
  payrollstruct payroll  char name
        float salary
  employee

11
Structured Objects

• Describes a system for generating an executable
  C program from object-oriented design diagrams.

• Especially an event-trace diagram and a decision
  table are used to describe an operational
  definition. The decision table offers a
  high-level language LOLA for the brief expression
  of controls that are dependent on the data
  structure.
• This language allows the methods to be expressed
  easily, briefly, and visually.
• A C program was generated from these diagrams
  in such a way that the part clichés are edited to
  satisfy LOLA expression and embedded into the
  frame cliché representing the skeleton of the
  whole program

12
Active Objects

• Active Objects are a form of multitasking for
  computer systems. Specifically, they are a form
  of cooperative multitasking. They are an
  important feature of Symbian OS.
• In the scheme, objects may make requests of
  asynchronous services. (For example an
  application may request to send an SMS).
• Once the request has been made, control returns
  to the object immediately. It may choose to do
  other things, or return control back to the
  operating system, which typically will schedule
  other tasks or put the machine to sleep. When
  making the request, the object includes a
  reference to itself.
• When the asynchronous task has completed, the
  operating system will identify the thread
  containing the requesting active object, and wake
  up that thread. An "active scheduler" in that
  thread will identify the object that made the
  request, and pass control back to that object.

13
Active Objects (Cont)

• The implementation of active objects in Symbian
  OS is based around each thread having a "request
  semaphore". This is incremented when a thread is
  due to complete an asynchronous request, and
  decremented when the request has been completed.
  When there are no outstanding requests, the
  thread is put to sleep.
• In practice, there may be many objects in a
  thread, each doing their own task. They can
  interact by requesting things of each other, and
  of active objects in other threads. They may even
  request things of themselves.
• Notice that this is a software implementation of
  a very old idea that was developed to handle
  software interruptions in the 70's. The operating
  system was acting as the first object and the
  peripheral as the second one.

14
Composite Objects

• Composite objects are objects that have an
  externally-discernible structure, and the
  structure can be addressed via the public
  interface of the composite object. The objects
  that comprise a composite object are referred to
  as component objects. Composite objects meet one
  or both of the following criteria
• the state of a composite object is directly
  affected by the presence or absence of one or
  more of its component objects, and/or
• the component objects can be directly referenced
  via the public interface of their corresponding
  composite object.
• It is useful to divide composite objects into two
  subcategories heterogeneous composite objects
  and homogeneous composite objects
• A heterogeneous composite object is a composite
  object that is conceptually composed of component
  objects that are not all conceptually the same.
  For example, a date (made up of a month object, a
  day object, and a year object) is a heterogeneous
  composite object.
• A homogeneous composite object is a composite
  object that is conceptually composed of component
  objects that are all conceptually the same. For
  example, a list of addresses is a homogeneous
  composite object.

15
Composite Objects (Cont)

• The rules for designing heterogeneous composite
  objects are different from the rules for
  designing homogeneous composite objects.
• Composited objects are called fields, items,
  members or attributes, and the resulting
  composition a structure, record, tuple, or
  composite type. The terms usually vary across
  languages. Fields are given a unique name so that
  each one can be distinguished from the others.
  Sometimes an issue of ownership arises when a
  composition is destroyed, should objects
  belonging to it be destroyed as well? If not, the
  case is sometimes called aggregation.
• Example code
• typedef struct int age
• char name
• enum male, female
• sex Person

16
Abstract Data Types

• Definition A set of data values and associated
  operations that are precisely specified
  independent of any particular implementation.
• Also known as ADT.
• One of the simplest abstract data types is the
  stack. The operations new(), push(v, S), top(S),
  and popOff(S) may be defined with axiomatic
  semantics as following.
• new() returns a stack
• popOff(push(v, S)) S
• top(push(v, S)) v
• An abstract data structure is an abstract storage
  for data defined in terms of the set of
  operations to be performed on data and
  computational complexity for performing these
  operations, regardless of the implementation in a
  concrete data structure.
• Selection of an abstract data structure is
  crucial in the design of efficient algorithms and
  in estimating their computational complexity,
  while selection of concrete data structures is
  important for efficient implementation of
  algorithms.
• This notion is very close to that of an abstract
  data type, used in the theory of programming
  languages. The names of many abstract data
  structures (and abstract data types) match the
  names of concrete data structures.

17
Part III Final Evaluation
18
Do you have any basis to agree or disagree with
any claims of its security, portability,
efficiency, extensibility/maintainability?

• Modern critics of the language raise several
  points. First, since C is based on and largely
  compatible with C, it inherits most of the
  criticisms levelled at that language. Taken as a
  whole C has a large featureset, including all
  of C plus a large set of its own additions, in
  part leading to criticisms of being a "bloated"
  and complicated language, especially for embedded
  systems due to features such as exceptions and
  RTTI which add to code size.
• The Embedded C standard was specified to deal
  with part of this, but it received criticism for
  leaving out useful parts of the language that
  incur no runtime penalty. Because of its large
  featureset it can be quite difficult to fully
  master, leading to programmers often bringing
  unnecessarily advanced or complicated solutions
  to simple problems, and it is relatively
  difficult to write a good C parser with modern
  algorithms.This is partly because the C grammar
  is not LALR.Because of this, there are very few
  tools for analyzing or performing non-trivial
  transformations (e.g., refactoring) of existing
  code.
• C is also sometimes compared unfavorably with
  single-paradigm object-oriented languages such as
  Java, on the basis that it allows programmers to
  "mix and match" object-oriented and procedural
  programming, rather than strictly enforcing a
  single paradigm. This is part of a wider debate
  on the relative merits of the two programming
  styles.

19
What aspect of this language did you find most
difficult to learn/understand?

• The difficult part of this language is as
  follows
• The syntax / semantics
• Templates
• Memory managements

20
How would you rate the programming environment?
Compiler/Interpreter messages?

• The C compiler is one of the best compiler I
  would say. This is because C compiler has the
  following advantages over other compilers.
• Small language specification that retains
  object-oriented features.
• Avoids excessive memory consumption.
• Produces predictable run-time requirements.
• Generates ROMable code.
• Removes nonstandard extensions to C. Language
  features that are not authorized by ANSI/ISO are
  eliminated.

21
Design mistakes (in my opinion and others
opinion)?

• There are few condemns in C design features
  such as
• Targets the wrong problem
• Lacks formal foundations
• Unlike components, does not provide reuse
• Leads to inefficient solutions
• Does not differ significantly from other
  abstractions

22
Would you use this language again?

• Yes, I would prefer C in my future assignments.
  My inference for this opinion as below
• A major contribution of C is its support for
  defining abstract data types (ADTs) for
  generic programming.
• Example classes, parameterized types
  exception handling.
• For some systems, C s ADT support is more
  important than using the OO features of language.
• The C s OO features essential to build highly
  flexible extensible software.
• Example inheritance, dynamic binding RTTI

23
Screen Shots
24
Screen Shots
25
Screen Shots
26
Code Snippet

• class channel
• public
• void printHi()
• void setChannel()
• void donechannel()
• private
• char channel1
• char channel2
• char channel3
• char channel4
• char channel5
• void channeldonechannel()
• coutltlt"You have set the channels to the
  following stations"ltltendl
• coutltlt"RTM1 - Channel "ltltchannel1ltltendl
• coutltlt"RTM2 - Channel "ltltchannel2ltltendl

27
REFERENCES

• 1 Mohamed Fayad and Douglas C. Schmidt,
  Object-Oriented Application Frameworks, Special
  Issue on Object-Oriented Application
  Frameworks,volume. 40, No. 10, October 1997.
• 2 Regan, David, ADO.NET and the Middle Tier,
  Net Developers Journal,2003
• 3 Johson, Rod, J2EE Design and Development,
  Published by Wiley Publishing, Inc.2003
• 4 Robert Chartier , Application Architecture
  An N-Tier Approach - Part 1 ,Pioneering Active
  Server
