PIER: PeertoPeer Information Exchange and Retrieval

1
PIER Peer-to-Peer Information Exchange and
Retrieval

• Ryan Huebsch
• Joe Hellerstein, Nick Lanham,
• Boon Thau Loo, Scott Shenker, Ion Stoica
• p2p_at_db.cs.berkeley.edu
• UC Berkeley, CS Division

Berkeley P2P 2/24/03
2
Outline

• Motivation
• General Architecture
• Brief look at the Algorithms
• Potential Applications
• Current Status
• Future Research

3
P2P DHTs are Cool, but

• Lots of effort is put into making DHTs
• Scalable (thousands ? millions of nodes)
• Reliable (every imaginable failure)
• Security (anonymity, encryption, etc.)
• Efficient (fast access with minimal state)
• Load balancing, and others
• Still only a hash table interface, put and get
• Hard (but not impossible) to build real
  applications using only the basic primitives

4
Databases are Cool, but

• Relational databases bring a declarative
  interface to the user/application.
• Ask for what you want, not how to get it
• Database community is not new to parallel and
  distributed systems
• Parallel Centralized, one administrator, one
  point of failure
• Distributed Did not catch on, complicated, never
  really scaled above 100s of machines

5
Databases P2P DHTsMarriage Made in Heaven?

• Well, databases carry a lot of other baggage
• ACID transactions
• Consistency above all else
• So we just want to unite the query processor with
  DHTs
• DHTs Relational Query Processing PIER
• Bring complex queries to DHTs ? foundation for
  real applications

6
Outline

• Motivation
• General Architecture
• Brief look at the Algorithms
• Potential Applications
• Current Status
• Future Research

7
Architecture

• DHT is divided into 3 modules
• Weve chosen one way to do this, but may change
  with time and experience
• Goal is to make each simple and replaceable
• PIER has one primary module
• Add-ons can make it look more database like.

8
Architecture DHT Routing

• Very simple interface
• Plug in any routing algorithm here CAN, Chord,
  Pastry, Tapestry, etc.

• lookup(key) ? ipaddr
• join(landmarkNode)
• leave()
• CALLBACK locationMapChange()

9
Architecture DHT Storage

• Currently we use a simple in-memory storage
  system, no reason a more complex one couldnt be
  used

• store(key, item)
• retrieve(key) ? item
• remove(key)

10
Architecture DHT Provider

• Connects the pieces, and provides the DHT
  interface

• get(ns, rid) ? item
• put(ns, rid, iid, item, lifetime)
• renew(ns, rid, iid, lifetime) ? success?
• multicast(ns, item)
• lscan(ns) ? items
• CALLBACK newData(ns, item)

11
Architecture PIER

• Currently, consists only of the relational
  execution engine
• Executes a pre-optimized query plan
• Query plan is a box-and-arrow description of how
  to connect basic operators together
• selection, projection, join, group-by/aggregation,
  and some DHT specific operators such as rehash
• Traditional DBs use an optimizer catalog to
  take SQL and generate the query plan, those are
  just add-ons to PIER

12
Outline

• Motivation
• General Architecture
• Brief look at the Algorithms
• Potential Applications
• Current Status
• Future Research

13
Joins The Core of Query Processing

• A relational join can be used to calculate
• The intersection of two sets
• Correlate information
• Find matching data
• Goal
• Get tuples that have the same value for a
  particular attribute(s) (the join attribute(s))
  to the same site, then append tuples together.
• Algorithms come from existing database
  literature, minor adaptations to use DHT.

14
Joins Symmetric Hash Join (SHJ)

• Algorithm for each site
• (Scan) Use two lscan calls to retrieve all data
  stored at that site from the source tables
• (Rehash) put a copy of each eligible tuple with
  the hash key based on the value of the join
  attribute
• (Listen) use newData to see the rehashed tuples
• (Compute) Run standard one-site join algorithm on
  the tuples as they arrive
• Scan/Rehash steps must be run on all sites that
  store source data
• Listen/Compute steps can be run on fewer nodes by
  choosing the hash key differently

15
Joins Fetch Matches (FM)

• Algorithm for each site
• (Scan) Use lscan to retrieve all data from ONE
  table
• (Get) Based on the value for the join attribute,
  issue a get for the possible matching tuples from
  the other table
• Note, one table (the one we issue the gets for)
  must already be hashed on the join attribute
• Big picture
• SHJ is put based
• FM is get based

16
Joins Additional Strategies

• Bloom Filters
• Use of bloom filters can be used to reduce the
  amount of data rehashed in the SHJ
• Symmetric Semi-Join
• Run a SHJ on the source data projected to only
  have the hash key and join attributes.
• Use the results of this mini-join as source for
  two FM joins to retrieve the other attributes for
  tuples that are likely to be in the answer set
• Big Picture
• Tradeoff bandwidth (extra rehashing) for latency
  (time to exchange filters)

17
Group-By/Aggregation

• A group-by/aggregation can be used to calculate
• Split data into groups based on value
• Max, Min, Sum, Count, etc.
• Goal
• Get tuples that have the same value for a
  particular attribute(s) (group-by attribute(s))
  to the same site, then summarize data
  (aggregation).

18
Group-By/Aggregation

• At each site
• (Scan) lscan the source table
• Determine group tuple belongs in
• Add tuples data to that groups partial summary
• (Rehash) for each group represented at the site,
  rehash the summary tuple with hash key based on
  group-by attribute
• (Combine) use newData to get partial summaries,
  combine and produce final result after specified
  time, number of partial results, or rate of input
• Can add multiple layers of rehash/combine to
  reduce fan-in.
• Subdivide groups in subgroups by randomly
  appending a number to the groups key

19
Outline

• Motivation
• General Architecture
• Brief look at the Algorithms
• Potential Applications
• Current Status
• Future Research

20
Why Would a DHT Query Processor be Helpful?

• Data is distributed ? centralized processing not
  efficient or not acceptable
• Correlation, Intersection ? Joins
• Summarize, Aggregation, Compress ?
  Group-By/Aggregation
• Probably not as efficient as custom designed
  solution for a single particular problem
• Common infrastructure for fast application
  development/deployment

21
Network Monitoring

• Lots of data, naturally distributed, almost
  always summarized ? aggregation
• Intrusion Detection usually involves correlating
  information from multiple sites ? join
• Data comes from many sources
• nmap, snort, ganglia, firewalls, web logs, etc.
• PlanetLab is our natural test bed (Timothy,
  Brent, and Nick)

22
Enhanced File Searching

• First step Take over Gnutella (Boon)
• Well, actually just make PlanetLab look an
  UltraPeer on the outside, but run PIER on the
  inside
• Long term Value added services
• Better searching, utilize all of the MP3 ID tags
• Reputations
• Combine with network monitoring data to better
  estimate download times

23
i3 Style Services

• Mobility and Multicast
• Sender is a publisher
• Receiver(s) issue a continuous query looking for
  new data
• Service Composition
• Services issue a continuous query for data
  looking to be processed
• After processing data, they publish it back into
  the network

24
Outline

• Motivation
• General Architecture
• Brief look at the Algorithms
• Potential Applications
• Current Status
• Future Research

25
Codebase

• Approximately 17,600 lines of NCSS Java Code
• Same code (overlay components/pier) run on the
  simulator or over a real network without changes
• Runs simple simulations with up to 10k nodes
• Limiting factor 2GB addressable memory for the
  JVM (in Linux)
• Runs on Millennium and Planet Lab up to 64 nodes
• Limiting factor Available/working nodes setup
  time
• Code
• Basic implementations of Chord and CAN
• Selection, projection, joins (4 methods), and
  aggregation.
• Non-continuous queries

26
Simulations of 1 SHJ Join
27
1 SHJ Join on Millennium
28
Outline

• Motivation
• General Architecture
• Brief look at the Algorithms
• Potential Applications
• Current Status
• Future Research

29
Future Research

• Routing, Storage and Layering
• Catalogs and Query Optimization
• Hierarchical Aggregations
• Range Predicates
• Continuous Queries over Streams
• Semi-structured Data
• Applications, Applications, Applications
