Synchronization

1
Synchronization

• Kenneth Chiu

2
Reporting Performance with Percentages

• Suppose A takes 100 s and B takes 80 s. Which is
  correct?
• B is 25 faster than A.
• B is 20 faster than A.
• Notes
• 1/100 .01
• 1/80 .0125

3
Introduction

• Introduction
• Architectures
• Network
• Bus
• Simple Approaches
• Spin on test-and-set
• Spin on read
• New Software Alternatives
• Delays
• Queuing
• Hardware Solutions
• Summary

4
Mutual Exclusion

• Pure software solutions are inefficient
• Dekkers algorithm
• Petersons algorithm
• Most ISAs provide atomic instructions
• Test-and-set
• Atomic increment
• Compare-and-swap
• Load-linked/store-conditional
• Atomic exchange

5
Spinning (Busy-Waiting)

• What is spin-lock?
• Test
• Test-Lock
• Release
• Isnt busy-waiting bad?
• Blocking is expensive
• Adaptive
• What should happen on a uniprocessor?

6
Architectures

• Introduction
• Architectures
• Network
• Bus
• Simple Approaches
• Spin on test-and-set
• Spin on read
• New Software Alternatives
• Delays
• Queuing
• Hardware Solutions
• Summary

7
Architectures

• Multistage interconnection network
• Without coherent private caches
• With invalidation-based cache coherence using
  remote directories
• Bus
• Without coherent private caches
• With snoopy write-through invalidation-based
  cache coherence
• With snoopy write-back invalidation-based cache
  coherence
• With snoopy distributed-write cache coherence

8
Hardware Support for Mutex

• Atomic RMW. Requires
• Read
• Write
• Arbitration
• Locking
• Usually collapsed into one or two transactions.

9
Multistage Networks

• Requests forwarded through series of switches.
• Cached copies (recorded in remote directory)
  invalidated.
• Computation can be done remotely.

10
Bus

• Bus used for arbitration
• Processor acquires the bus and raises a line

11
Simple Approaches

• Introduction
• Architectures
• Network
• Bus
• Simple Approaches
• Spin on test-and-set
• Spin on read
• New Software Alternatives
• Delays
• Queuing
• Hardware Solutions
• Summary

12
Three Concerns

• To minimize delay before reacquisition, should
  retry often.
• Retrying often creates a lot of bus activity,
  which degrades performance.
• Complex algorithms may address first two, but
  then will have high latency for uncontended locks.

13
Performance Under Contention Unimportant?

• Could be argued
• Highly parallel application by definition has no
  lock with contention.
• If you have contention, youve designed it wrong.
• Specious argument
• Non-linear behavior. Contention may be worse with
  bad locks.
• Cant always redesign the program.

14
Spin on Test-And-Set

• Code
• Initial condition
• lock CLEAR
• Lock
• while (TestAndSet(lock) BUSY)
• Unlock
• lock CLEAR
• Performance
• Contention on the lock datum.
• Architectures dont allow lock holder to have
  priority.
• What about priority inheritance?
• General subsystem contention.

15
Spin on Read

• Pseudo-Code
• Lock
• while (lock BUSY or TestAndSet(lock) BUSY)
• Assume short-circuiting.
• Performance
• When busy, reads out of cache.
• Upon release, either each copy updated
  (distributed-write) or read miss.
• Better?

16
Better?
W(i)
P1
R(m)
T(i)
P2
R(m)
T(i)
R
R
P3
R(m)
R(m)
R
R
P4
17
Spin on Read

• Upon release, each processor will incur a read
  miss. Each processor will then read the value.
  One processor will read the new value and do the
  first test-and-set.
• Processors that miss the unlocked window will
  resume spinning. Processors that see the lock
  unlocked will try to test-and-test.
• Each failing test-and-test will invalidate all
  other cache copies, causing them to miss again.

18
Quiescence

• Memory requests before will be slowed down.
• Memory requests after unaffected.
• This is a per-critical section overhead, so short
  critical sections will suffer.
• Fixed priority bus arbitration
• Lock holder has highest priority so will not be
  slowed.
• Race conditions that will upset the priority.
• If released before quiescence, will be processors
  that are still contending for the lock.

19
Spin on Read Analysis

• Several factors
• Delay between detecting the lock has been
  released, and attempting to acquire it with
  test-and-set.
• Invalidation occurs during the test-and-set.
• Invalidation-based cache-coherence requires O(P)
  bus/network cycles to broadcast a value.
• Cant they snoop?
• Broadcasting updates exacerbates the problem.
  (Why?)
• Since they all try the test-and-test.

20
Performance

• Sequent shared-memory with 20 386 processors.
• Write-back, invalidation-based.
• Acquiring and releasing normally takes 5.6
  microsecs.
• Total elapsed time for all processors to execute
  a CS one million times.
• Lock, execute critical section, release, delay
• Mean delay is equal to 5X time of the critical
  section.
• Whats the purpose of the delay?
• Lock and data in separate cache lines.
• Whats false sharing?

21
Performance
Ideal is with free spin-waiting.
22
Quiescence Time

• How to measure?
• A critical section that delays, then uses bus
  heavily.
• If delay is long enough, then time to execute the
  critical section should be the same on one
  processor as on all processors.
• Perform a search.
• What kind of search? (How would you pick the
  times?)

23
Quiescence Time
24
New Software Alternatives

• Introduction
• Architectures
• Network
• Bus
• Simple Approaches
• Spin on test-and-set
• Spin on read
• New Software Alternatives
• Delays
• Queuing
• Hardware Solutions
• Summary

25
Inserting Delays

• Two dimensions
• Insertion location
• After release
• After every access
• Delay length
• static fixed for a particular processor
• dynamic changes

26
CSMA/CD

• Ethernet algorithm
• Listen for idle line
• Immediately try to transmit when idle
• If collision occurs (how do we know?), then wait
  and retry
• Increase wait time exponentially
• Bonus question why does Ethernet have a minimum
  packet size?

27
Delay After Release Detection

• Idea is to minimize unsuccessful test-and-set
  instructions.
• Two kinds of delay
• Static
• Each processor statically assigned a slot from 0
  to N 1.
• Number of slots can be adjusted.
• Few processors
• Many slots, high latency
• Few slots, good performance
• Many processors
• Many slots, good performance
• Few slots, high contention
• Dynamic

28
Dynamic Delay

• CSMA/CD collision has fundamentally different
  properties.
• In locking collision, the first locker
  succeeded.
• In CSMA/CD collision, no sender succeeded.
• What happens with exponential backoff for 10
  lockers?
• Solution is to bound the delay.

29
Delay between References

• Doesnt work well with dynamic delay.
• Backoff continues while locking processor in
  critical section.
• Delay should be tied to number of spinning
  processors, not the length of the critical
  section.
• Any possible alternatives to estimating the
  number of spinning processors?

30
Performance

• 1 microsecond to execute a test-and-set.
• Queuing done with explicit lock.
• Ideal time subtracted to show overhead only.
• One processor time shows latency.
• Static worse with few processors.
• With many processors, backoff slightly worse

31
Spin-Waiting Overhead vs No. of Slots

• Need lots of slots when lots of processors.

32
Queuing

• Use shared counter to keep track of no. of
  spinning processors.
• Two extra atomic instructions per critical
  section.
• Each spinning processor must read counter.
• Use explicit queue
• Doesnt really get anywhere, since need a lock
  for the queue.

33
Use Array of Flags

• Each processor spins on its own memory location.
• To unlock, signal next memory location.
• Use atomic increment to assign memory locations.
• Use modular arithmetic to avoid infinite arrays.

34
Queue

• Code
• Init
• flags0 HAS_LOCK
• flags1..P 1 MUST_WAIT
• queueLast 0
• Lock
• myPlace ReadAndIncrement(queueLast)
• while (flagsmyPlace mod P MUST_WAIT)
• flagsmyPlace mod P MUST_WAIT
• Unlock
• flags(myPlace 1) mod P HAS_LOCK
• What happens on overflow of queueLast? How to
  fix?
• Memory barriers needed?

35
Performance

• Atomic increment is emulated.
• Initial latency is high.

36
Overhead in Achieving Barrier

• Barrier
• Timestamp is taken on release.
• Timestamp taken when last processor acquires the
  lock.

37
Hardware Solutions

• Introduction
• Architectures
• Network
• Bus
• Simple Approaches
• Spin on test-and-set
• Spin on read
• New Alternatives
• Delays
• Queuing
• Hardware Solutions
• Summary

38
Hardware Solutions

• Networks
• Combining
• Hardware queuing
• Bus
• Invalidate only if lock value changes.
• Still has performance degradation as processors
  goes up.
• More snooping
• Snoop read miss data
• Snoop test-and-set requests
• First read miss (snoop miss data)
• If busy, abort
• If free, then try locking bus
• While waiting, monitor the bus.
• Abort if someone else gets the lock

39
Summary

• Memory operations are not free.
• Memory operations are not independent on
  shared-memory machines.
• Writes are expensive.
• Atomic instructions are even more expensive.
• Dont kill the bus.
