Mobile Ad Hoc Networks

1
Mobile Ad Hoc Networks
2
Organization

• Introduction and Architecture
• Applications and Challenges
• Media Access Control
• Routing in Ad Hoc Networks
• Transport Layer Issues
• Overarching Issues

3
MANETs Introduction

• MANETs are mobile nodes that form a network in an
  ad hoc manner
• The nodes intercommunicate using single or
  multi-hop wireless links
• Each node in MANETs can operate as a host as well
  as a router
• The topology, locations, connectivity,
  transmission quality are variable

4
MANETs Operations
D
Y
X
S
5
MANET Applications

• Civil
• Wireless LANs/WANs mobile and stationary
• Remote data collection and analysis
• Taxi/Cabs, Buses scheduling
• Disaster recovery
• Communications over water using floats
• Vehicular Ad Hoc Network
• Defense
• Battlefield communications and data transfer
• Monitoring and Planning

6
Issues and Challenges

• Operating in presence of unpredictable mobility
  and environmental changes
• Operating in an error prone media
• Low bandwidth channels
• Low power devices with limited resources
• Maintaining and retaining connectivity and states

• Security infrastructure and communication

7
MAC for MANET

• Special requirements
• Avoid interferences among simultaneous
  transmissions
• Yet, enable as many non-interfering transmissions
  as possible
• Fairness among transmissions
• No centralized coordinators, should function in
  full distributed manner
• No clock synchronization, asynchronous operations

8
Carrier-Sensing in MANET

• Problems
• Hidden terminal problem
• Exposed terminal problem

9
MACs Suitable for MANET

• MACA Karn90
• Propose to solve hidden terminal problem by
  RTS/CTS dialog
• MACAW Bharghavan94
• Increase reliability by RTS/CTS/DATA/ACK dialog
• IEEE 802.11 IEEE 802.11WG
• Distributed and centralized MAC components
• Distributed Coordination Function (DCF)
• Point Coordination Function (PCF)
• DCF suitable for multi-hop ad hoc networking
• Also use RTS/CTS/DATA/ACK dialog

10
IEEE 802.11 DCF

• Uses RTS-CTS exchange to avoid hidden terminal
  problem
• Any node overhearing a CTS cannot transmit for
  the duration of the transfer
• Any node receiving the RTS cannot transmit for
  the duration of the transfer
• To prevent collision with ACK when it arrives at
  the sender
• Uses ACK to achieve reliability

11
IEEE 802.11 DCF

• CSMA/CA
• Contention-based random access
• Collision detection not possible while a node is
  transmitting
• Carrier sense in 802.11
• Physical carrier sense
• Virtual carrier sense using Network Allocation
  Vector (NAV)
• NAV is updated based on overheard RTS/CTS
  packets, each of which specified duration of a
  pending Data/Ack transmission
• Collision avoidance
• Nodes stay silent when carrier sensed busy
  (physical/virtual)
• Backoff intervals used to reduce collision
  probability

12
Disadvantage of IEEE 802.11 DCF

• 802.11 DCF not considered perfect for MANET
• High power consumption
• Hidden terminal problem not totally solved,
  exposed terminal problem not solved
• Cause fairness problem among different
  transmitting nodes
• Can only provide best-effort service
• Active research area in MAC for MANET

13
MAC Advanced Topics

• Support for QoS provisioning
• Power Efficiency
• MAC for Directional Antenna

14
QoS-aware MAC protocols

• IEEE 802.11 Real-time extension
• Black burst contention scheme
• MACA/PR (Multihop Access Collision Avoidance with
  Piggyback Reservation)

15
Extend 802.11 DCF for Service Differentiation
Campbell01

• For high priority packets
• Backoff interval in 0,CWh
• For low priority packet
• Backoff interval in CWh1, CW
• After collision, packet with smaller CW is more
  likely to occupy medium earlier

16
Black Burst Sobrinho99

• Provides differentiation among real-time flow and
  best-effort flow
• Provides fairness and priority scheduling among
  real-time flows
• Fully distributed

17
Black Burst
A
C
B
Media
Busy
A
B
C
Carrier Sense
18
Black Burst
A
B
C
DIFS
Media
Busy
A
B
C
Black Bursts
19
Black Burst
A
B
C
DIFS
Media
Busy
A
B
C
20
Black Burst
A
B
C
DIFS
Media
Busy
A
B
C
21
Black Burst
A
B
C
Media
Busy
A
B
C
22
Black Burst
A
B
C
DIFS
RT A
Media
Busy
RT A
A
B
C
23
Black Bursts

• All nodes begin the priority contention phase
  together
• Higher priority node transmit a longer burst than
  low priority node
• After transmitting its burst, a node listens to
  the channel
• If channel still busy, the node has lost
  contention to a higher priority node

24
MAC Advanced Topics

• Power Efficiency
• Power Saving Make wireless interface sleep at
  appropriate times
• Power Control Use the appropriate transmission
  power

25
Power Saving

• Power Consumptions
• From Spec. of Orinoco 11b WLAN PC Card Proxim
  Co. 2003
• Battery Voltage 5V
• Dose mode 9 mA ( 45 mW)
• Receiver mode 185 mA ( 925 mW)
• Transmit mode 285 mA ( 1425 mW)

26
MAC Layer Approach

• Basic idea turn on/off the radio of specific
  nodes at appropriate times
• IEEE 802.11
• PAMAS
• S-MAC
• STEM
• Asynchronous Wakeup patterns

27
PS Mode in WLANs

• ATIM (Ad hoc Traffic Indication Map) window
  short interval during which the PS hosts wake up
  periodically.
• Assume that hosts are fully connected and
  synchronized.
• In the beginning of each ATIM window, each mobile
  host will contend to send a beacon frame.
• Successful beacon serve for synchronizing mobile
  hosts clock.
• This beacon also inhibits other hosts from
  sending their beacon
• To avoid collisions among beacons, use random
  back-off 0-2CWmin 1

28
PS Mode in WLANs

• After the beacon, host can send a direct ATIM
  frame to each of its intended receivers in PS
  mode.
• After transmitted an ATIM frame, keep remaining
  awake
• On reception of the ATIM frame, reply with an
  ACK and remain active for the remaining period
• - Data is sent based on the normal DCF access.

29
Problems

• PS mode of 802.11 is designed for single hop
  (fully connected) ad hoc network.
• If applied for multi-hop
• Clock synchronization
• Communication delay and mobility are all
  unpredictable
• network merging
• Neighbor discovery
• When a host in PS mode, both its chance to
  transmit and to hear others signal is reduced
  gt inaccurate neighbor information
• Network partitioning
• Inaccurate neighbor information may lead to long
  packet delay or even network (logically)
  partitioning problem.

30
PAMAS Singh98

• A node avoids overhearing packets not addressed
  to it
• so, reduce power consumption of processing
  unnecessary packets
• Use of a separate channel for signaling

31
PAMAS

• When to turn off?
• when a node has no packets to send, it should
  power itself off if a neighbor starts
  transmitting
• if at least one neighbor is transmitting and
  another is receiving, the node should power
  itself off
• How long to be powered off?
• It knows the duration of others transmission
• What if the intended receiver is powered off?
• Have to wait for it to wake up

32
STEM Schurgers02

• Sparse Topology and Energy Management
• Basic idea to wake up nodes only when they need
  to forward data
• using asynchronous beacon packets in a separate
  control channel to wake up nodes
• latency is traded off for energy savings

33
Wakeup mechanisms

• On-demand wake-up
• STEM, Remote Activated Switch(RAS)
• Scheduled rendezvous
• 802.11, Bluetooth, etc
• Asynchronous wakeup
• Power saving protocols Tseng02
• Asynchronous wake-up Zheng03

34
MANET Power Saving Protocols Tseng02

• Three asynchronous wakeup patterns
• Dominating-awake-interval
• Periodically-fully-awake-interval
• Quorum-based

35
Tsengs Protocol

• Beacon interval
• For each PS host, it divides its time axis into a
  number of fixed length interval
• Active window
• On state
• Beacon window
• PS hosts send its beacon
• MTIM window
• Other hosts send their MTIM frames to the PS
  host.
• Excluding these three windows, PS host with no
  packet to send or receive may go to the sleep
  mode.

36
Dominating-Awake-Interval

• Dominating awake property
• AW gt BI/2 BW
• This guarantees any PS hosts beacon window to
  overlap with any neighboring PS hosts active
  window.
• In every two beacon interval, PS host can receive
  all its neighbors beacon ? short response
  time?suitable for highly mobile
• The sequence of beacon intervals are
  alternatively labeled as odd and even interval

37
Periodicallyfully-awake-interval

• Two types of beacon interval
• Low power intervals
• AW is reduced to the minimum
• PS host send out its beacon to inform others its
  existence
• Fully awake intervals
• AW is extended to the maximum
• Arrives periodically every T intervals
• PS hosts discover who are in its neighborhood,
  and can predict when its neighboring host will
  wake up.

38
Quorum-based

• PS host only picks 2n-1 intervals (one column and
  one row) out of the n x n quorum
• Quorum interval
• Beacon MTIM, AW BI
• Non quorum intervals
• Start with an MTIM window, after that, host may
  go to sleep mode, AWMW

39
Asynchronous Wakeup FormalizedZheng03

• Formalize the asynchronous wakeup schedule as a
  block design problem in combinatorics
• Give theoretical analysis and an optimal design
• Three components
• neighbor discovery
• neighbor prediction
• neighbor reservation

40
Slot Assignments
124
235
346
457
561
672
713
SLOTS
1
2
3
4
5
6
7
Slot assignment for (7,3,1) design The schedule
repeats after 7 slots, has three ON slots, and
any two schedules overlap at least 1 slot.
41
MAC for Directional Antenna

• Benefits of Directional Antenna
• More spatial reuse
• With omni-directional antenna, packets intended
  to one neighbor reaches all neighbors as well
• Increase range, keeping transmit power constant
• Reduce transmit power, keeping range comparable
  with omni mode
• Reduces interference, potentially increasing
  spatial reuse

42
More Spatial Reuse
Omni-directional antenna
Directional antenna
A
B
A
B
C
D
C
D
Both A and C can transmit simultaneously
While A is transmitting to B, C cannot transmit
to D
43
Antenna Model

• 2 Operation Modes Omni and Directional

A node may operate in any one mode at any given
time
44
Antenna Model

• In Omni Mode
• Nodes receive signals with gain Go
• While idle a node stays in omni mode
• In Directional Mode
• Capable of beamforming in specified direction
• Directional Gain Gd (Gd gt Go)
• Symmetry Transmit gain Receive gain

45
Directional Packet Transmission

B
A
D-O transmission
Bs omni receive range
D-D transmission
A
B
Bs directional receive beam
46
MAC Designs for Directional Antenna

• Most proposals use RTS/CTS dialog
• They differ in how RTS/CTS are transmitted
• Omni-directional transmit ORTS, OCTS
• Directional transmit DRTS, DCTS
• Current proposals
• ORTS/OCTS Nasipuri00
• DRTS/OCTS Ko00
• DRTS/DCTS Choudhury02

47
ORTS/OCTS

• Sender sends omni-directional RTS
• Receiver sends omni-directional CTS
• Receiver also records direction of sender by
  determining the antenna on which the RTS signal
  was received with highest power level
• Similarly, the sender, on receiving CTS, records
  the direction of the receiver
• All nodes overhearing RTS/CTS defer transmissions
• Sender then sends DATA directionally to the
  receiver
• Receiver sends directional ACK

48
ORTS/OCTS cont.

• Protocol takes advantage of reduction in
  interference due to directional
  transmission/reception of DATA
• All neighbors of sender/receiver defer
  transmission on receiving omni-directional
  RTS/CTS
• ? spatial reuse benefit not realized

49
D-MAC

• Uses directional antenna for sending RTS, DATA
  and ACK in a particular direction, whereas CTS
  sent omni-directionally
• Directional RTS (DRTS) andOmni-directional CTS
  (OCTS)

50
DMAC DRTS/OCTS
A
B
C
E
D
DRTS(B)
OCTS(B,C)
OCTS(B,C)
DRTS(D)
OCTS(D,E)
DATA

DATA
ACK
ACK
51
DMAC Pros and Cons

• Benefit Can allow more simultaneous
  transmissions by improving spatial reuse
• Disadvantage Can increase ACK collisions

52
Directional NAV

• Physical carrier sensing still omni-directional
• Virtual carrier sensing be directional
  directional NAV
• When RTS/CTS received from a particular
  direction, record the direction of arrival and
  duration of proposed transfer
• Channel assumed to be busy in the direction from
  which RTS/CTS received

53
Directional NAV (DNAV)

• Nodes overhearing RTS or CTS set up directional
  NAV (DNAV) for that Direction of Arrival (DoA)

D
CTS
C
X
Y
54
Directional NAV (DNAV)

• Nodes overhearing RTS or CTS set up directional
  NAV (DNAV) for that Direction of Arrival (DoA)

D
C
DNAV
X
Y
55
Directional NAV (DNAV)

• New transmission initiated only if direction of
  transmission does not overlap with DNAV, i.e.,
  if (? gt 0)

B
D
DNAV
?
A
C
RTS
56
Routing in Ad Hoc Networks

• Unicast
• Source node to destination node
• Single or multiple hops
• Multicast
• Source node to multiple destination nodes
• Varied number of hops
• Members could join and leave

57
Issues in MANET Routing

• Factors affecting the routing of packets in
  MANETs
• Bandwidth limitation
• Power limitation
• Node heterogeneity
• Multi-hops
• Mobility

58
Classification of Unicast Routing Protocols

• Flooding-based Routing
• Precomputed (proactive) Routing
• On-demand (reactive) Routing
• Location or Position-Based Routing
• Hybrid Routing
• Power/Energy-Aware Routing

59
Flooding-Based Routing
D
S
60
Proactive Routing

• Nodes maintain global state information
• Consistent routing information are stored in
  tabular form at all the nodes
• Changes in network topology are propagated to
  all the nodes and the corresponding state
  information are updated
• Routing state maintenance could be flat or
  hierarchical

61
Examples of Proactive Routing

• Destination Sequenced Distance Vector (DSDV)
• Wireless Routing Protocol (WRP)
• Hierarchical State Routing Scheme

62
Destination Sequenced Distant Vector (DSDV)
Routing Perkins94

• Table-Driven algorithm based on Bellman-Ford
  routing mechanism
• Every node maintains a routing table that records
  the number of hops to every destination
• Each entry is marked with a sequence number to
  distinguish stale routes and avoiding routing
  loops
• Routes labeled with most recent sequence numbers
  is always used
• Routing updates can be incremental or full dumps

63
Wireless Routing Protocol (WRP) Murthy96

• Table-based protocol
• Each node is responsible for maintaining four
  tables
• distance table,
• routing table,
• link-cost table, and
• message retransmission list (MRL) table

64
WRP - Continued

• The mobile nodes inform each other of link
  changes through the use of update messages
• Update messages are sent only between neighboring
  nodes, which modify their tables and send updates
  to their neighbors
• The existence and status of the neighboring nodes
  is determined through ACKs of messages or
  periodic hello messages

65
Hierarchical Routing Schemes

• Cluster Gateway Source Routing (CGSR)
• Nodes are divided into clusters each cluster has
  a cluster-head (uses a distributed cluster-head
  selection algorithm)
• Uses DSDV for cluster-head-to-gateway routing

66
CGSR Chiang97
67
On-demand (Reactive) Routing

• A path is computed only when the source needs to
  communicate with a destination
• The source node initiates a Route Discovery
  Process in the network
• After a route is discovered, the path is
  established and maintained until it is broken or
  is no longer desired

68
Ad hoc On-demand Distance Vector (AODV) Routing
Perking99

• AODV builds on the DSDV algorithm
• Creates route on a demand basis and maintains
  only as long as they are necessary
• Loop freedom is routing is achieved through the
  maintenance of sequence numbers
• AODV uses routing table to store routing
  information the routing table contains the
  destination and the next-hop IP addresses
• AODV is able to provide both unicast and
  multicast ability

69
AODV Route Discovery

• When a source desires to send a message to any
  destination, and if the routing table does not
  have a corresponding entry, it initiates a route
  discovery process.
• The source broadcasts a route request (RREQ)
  packet to its neighbors, which in turn, forwards
  it to their neighbors, and so on, until either
  the destination node or an intermediate node with
  a valid route to the destination is located.
• The intermediate nodes set of a reverse route
  entry for the source node in their routing table.

• The reverse route entry is used for forwarding a
  route reply (RREP) message back to the source.
• An intermediate node while forwarding the RREP to
  the source, sets up a forward path to the
  destination

70
AODV
F ?
C
A
E
S
I am F
D
B
F
71
AODV
To F, Next-hop is B
C
A
E
S
D
B
F
72
Dynamic Source Routing (DSR) Johnson96

• On-demand source-based routing approach
• Packet routing is loop-free
• Avoids the need for up-to-date route information
  in intermediate nodes
• Nodes that are forwarding or overhearing, cache
  routing information for future use
• Two phases Route Discovery and Route Maintenance

73
DSR Route Discovery

• Route discovery is initiated if the source node
  does not have the routing information in its
  cache
• The source node broadcasts a route request packet
  that contains destination address, source
  address, and a unique ID
• Intermediate nodes that do not have a valid
  cached route, add their own address to the route
  record of the packet and forwards the packet
  along its outgoing links

74
DSR Route Reply

• Route reply is generated by the destination or a
  node that has a valid cached route
• The route record obtained from the route request
  is included in the route reply
• The route is sent via the path in the route
  record, or from a cached entry, or is discovered
  through a route request
• Route maintenance is accomplished through route
  error packets and acknowledgments

75
DSR
I am F Route1 SACEF Route2 SBDF
F ?
C
A
E
S
D
B
F
To F, route is SBDF
Choose Route2
76
Zone Routing Protocol (ZRP) Haas97

• ZRP is a hybrid of reactive/proactive protocol
• A routing zone is defined for each node, which
  includes nodes whose minimum distance in terms of
  number of hops is less than a predefined number
• A proactive routing approach is used for
  intra-zone communication and a reactive approach
  is used for inter-zone communication
• For intra-zone route discovery, bordercasting
  technique is used

77
ZRP-Example
F
M
E
G
D
H
A
L
B
K
I
J
Border nodes
BoarderCast efficiently deliver route request to
all boarder nodes.

• Routing Zone of A (Zone radius 2)
• IARP Intra-zone routing protocol
• IARP runs at the center of each zone
• IARP uses proactive routing method
• Each node has its own zone

78
ZRP-Example
F
M
E
Q
V
G
N
D
H
A
P
R
W
L
B
K
O
U
S
I
J
T
Center of zone
Source/Destination node
IERP Inter-zone routing, uses reactive routing
method
79
ZRP-Example
F
M
E
Q
V
G
N
D
H
A
P
R
W
L
B
K
O
U
S
I
J
T
Center of zone
Source/Destination node
IERP Inter-zone routing, uses reactive routing
method
80
ZRP-Example
F
M
E
Q
V
G
N
D
H
A
P
R
W
L
B
K
O
U
S
I
J
T
Center of zone
Source/Destination node
IERP Inter-zone routing, uses reactive routing
method
81
Location Informed Protocols for MANET

• Location informed approach assume each mobile
  node is aware of its location, for example, by
  means of GPS
• This approach is practical with the development
  of low-cost GPS receiving device
• Categorization
• Location aided routing (route discovery)
• LAR, LAKER, PANDA, ...
• Position based routing (packet forwarding)
• DREAM, GPSR, GRA, ...

82
Location Aided Route Discovery

• Example Location aided routing (LAR) protocol
  Ko98

D
S
Network area
83
Position Based Packet Forwarding

• Examples geodesic forwarding (in GPSR)

84
Position Based Packet Forwarding Void Area

• Difficulty in geodesic forwarding void area

A
B
S
D
C

85
LAKER Knowledge Guided Route Discovery Li03

• Even more limited search space compared to LAR

86
LAKER Dealing With Void Area

• Bypassing void area smartly

87
Multicasting in MANETs

• Ad hoc multicasting should
• Guarantee message delivery to all interested
  members
• Minimize control messages in order not to
  interfere with data transmission
• Maintain membership information as nodes join and
  leave at will
• Repair broken links because of topology change

88
Route structure consideration

• Tree structured protocols
• More optimal route
• More suitable for high load
• More expensive to maintain
• Mesh structured protocols
• More resilient to topology change
• More likely to repair link breakage locally
• Link redundancy

Multicast source Multicast receiver Forwarding
node Group neighbor node
89
Taxonomy of current protocols
90
Hierarchical Multicasting
91
Relation to Underlying Unicast Protocol

• Closely coupled MCEDARSinha99
• Unicast-independent AMRoute Liu99
• Double role serve both using one protocol
• MAODV Royer99
• ODMRP Lee99

92
Tree-Structured Routing MAODV Royer99

• MAODVMulticast operation of Ad hoc On-demand
  Distance Vector
• Multicast tree shared by the group.

93
MAODV- Route Request
Step 1 Flooding of Join Request
1
Multicast group member Multicast tree
member Non-Tree nodes Multicast Tree
Link ROUTE_REQ Message
2
4
3
7
5
f
6
b
e
c
d
a
94
MAODV- Route Request
Step 2 Join Reply trace back to source
1
Multicast group member Multicast tree
member Non-Tree nodes Multicast Tree
Link ROUTE_REP Message
2
4
3
7
5
f
b
6
e
c
d
a
95
MAODV- Route Request
Step 3Route Activation
1
Multicast group member Multicast tree
member Non-Tree nodes Multicast Tree
Link ROUTE_ACT Message
2
4
3
7
5
f
b
6
e
c
d
a
96
MAODV- Route Request
Step 4 Tree branch addition
Multicast group member Multicast tree
member Non-Tree nodes Multicast Tree Link
97
MAODV--Repairing

• Link break detection
• Periodical hello messages between neighbors
• Hello message time_out
• hello_interval?(1allowed_hello_loss)

98
MAODV--Repairing

• Down-stream node of the broken link is
  responsible of repairing
• Route Request is first given small TTL to hope
  the local operation

99
Mesh-based Routing ODMRP Lee99

• On-Demand Multicast Routing
• Source-based mesh
• Membership information is maintained by the source

100
ODMRMesh setup
Step 1 Source periodically flood JOIN DATA packet
JOIN DATA packet Receiver Source
4
3
2
1
6
5
7
8
9
10
101
ODMR Mesh setup
Step 2 Receiver broadcasts JOIN TABLE
4
3
2
1
6
5
7
8
9
10
Finally, forwarding group is set to be 2,3,5,8
102
TCP in Ad hoc Networks

• TCP is tuned for wired networks, in which
• Low BER
• Loss is mainly due to congestion
• Route is relatively fixed during a connection
  life time
• However, in wireless ad hoc networks
• High BER
• Route Changes
• Network Partitions
• Multi-path Routing

103
Effect of High BER

• Bit errors cause packets to get corrupted and
  dropped
• result in losses of TCP data segments or ACKs
• Either fast retransmit or Retransmission Time-Out
  (RTO) is triggered

104
Effect of Route Changes

• Discovering a new route may take significantly
  longer than TCP sender RTO
• Route change may cause packets to arrive
  out-of-order

105
Effect of Network Partitions

• If the sender and the receiver of a TCP
  connection lie in different partitions
• Multiple consecutive timeouts
• Inactivity for up to 1 or 2 minutes after
  partitions get connected

106
Effect of Multi-path Routing

• Routes are short-lived due to frequent link
  breaks
• To reduce delay due to route re-computation, some
  routing protocols (such as TORA) maintain
  multiple routes between a source-destination pair

107
Effect of Multi-path Routing

• Multi-path routing can result in packet arrival
  out-of-order

108
Consequences

• TCP sender misinterprets losses as congestion
• Retransmits unACKed segments
• Invokes congestion control
• Enters slow start recovery
• These are undesirable because
• Why retransmit when there is no route
• Throughput is always low as a result of frequent
  slow start recovery
• Why use TCP at all in such cases?
• For seamless portability to applications like
  file transfer, e-mail and browsers which use
  standard TCP

109
Approaches to Improve TCP

• Hide error losses from the sender
• So the sender will not reduce congestion window
• Let the sender know, or determine, cause of
  packet loss
• If due to errors, it will not reduce congestion
  window

110
Where to Do Modifications?

• At the sender only
• ATCP Liu01
• At the receiver only
• At intermediate node(s) only
• Combinations of the above

111
ATCP Approach

• ATCP utilizes network layer feedback (from the
  intermediate nodes) to take appropriate actions
• Network feedback is
• ICMP The Destination Unreachable ICMP message
  indicates route disruption
• ECN Indicates network congestion
• With ECN enabled, time out and 3 dup ACKs are
  assumed to no longer be due to congestion

112
ATCP in the TCP/IP Stack
Sender
Receiver
TCP
TCP
A-TCP
IP
IP
Link layer
Link layer
Note from now on, the terms ATCP and TCP are
referred to as ATCP sender and TCP sender,
respectively
113
Adapt to Ad-hoc Environment

• High BER
• Retransmits lost segments without shrinking the
  congestion window.
• Delays due to route change and partition
• Stops transmitting and resumes when a new route
  is found.
• Multi-path routing
• On receipt of duplicate ACKs, TCP sender should
  not invoke congestion control, because multi-path
  routing shuffles the order in which segments are
  received.

114
TCP/ATCP Behavior

• RTO or 3rd dup ACK
• Retransmits unACKed segments
• ACK with ECN flag
• Invokes congestion control
• Destination Unreachable ICMP message
• Stops transmission
• Wait until a new route is found ? resume
  transmission
• ATCP monitors TCP state and spoofs TCP in such a
  way to achieve the above behaviors

115
ATCP states

• Normal (when a connection is opened)
• Congested
• Disconnected
• Loss

• During operation, ATCP transits from one state to
  another and put TCP in Persist mode when
  appropriate

116
TCP Persist Mode

• Triggered by an ACK carrying zero advertised
  window size from TCP receiver
• Parameters are frozen
• Persist timer is started
• TCP sender sends a probe segment each time
  persist timer expire
• When TCP sender receives an ACK carrying non-zero
  advertised window size from TCP receiver
• ? TCP sender resumes transmission

117
Advantages of ATCP

• ATCP improves TCP performance
• Maintains high throughput since TCPs unnecessary
  congestion control is avoided
• Saves network resources by reducing number of
  unnecessary re-transmissions
• End-to-End TCP semantics are maintained
• ATCP is transparent
• Nodes with and without ATCP can set up TCP
  connections normally

118
Overarching Issues

• Power Aware Communication
• Quality of Service (QoS)
• Security

119
Power Aware Routing

• Aka Energy efficient, Maximum Battery lifetime,

• Minimum transmission power multiple small hops
  instead of single hop transmission
• Residual battery capacity attempt balance
  traffic among different nodes
• Geographical Adaptive Fidelity (GAF) Routing
• Consider other factors e.g. link quality and
  retransmission

120
Quality of Service (QoS)

• QoS A set of service requirements that are met
  by the network while transferring a packet stream
  from a source to a destination
• QoS metrics could be defined in terms of one or a
  set of parameters
• Examples delay, bandwidth, packet loss,
  delay-jitter, etc.

121
QoS in MANETs Mohapatra03

• The use of QoS-aware applications are evolving in
  the wireless environments
• Resource limitations and variations adds to the
  need for QoS provisioning
• Use of MANETs in critical and delay sensitive
  applications demands service differentiation

122
Compromising Principles

• Soft QoS
• After the connection set-up, there may exist
  transient periods of time when QoS specification
  is not honored
• The level QoS satisfaction is quantified by the
  fraction of total disruption
• QoS Adaptation
• As available resources change, the network can
  readjust allocations within the reservation range
  (dynamic QoS)
• Applications can also adapt to the re-allocations

123
QoS Support in Physical Channels

• Since wireless channel is time varying, the SNR
  in channels fluctuates with time
• Adaptive modulation which can tune many possible
  parameters according to current channel state is
  necessary to derive better performance
• Major challenge channel estimation accurate
  channel estimation at the receiver and then the
  reliable feedback to the transmitter
• Wireless channel coding needs to address the
  problems introduced by channel or multipath
  fading and mobility
• Cross-layer issue Joint source-channel coding
  takes both source characteristics and channel
  conditions into account

124
QoS Provisioning at the MAC Layer

• For providing QoS guarantee for real-time traffic
  support in wireless networks, several MAC
  protocols based on centralized control have been
  proposed
• For multihop networks
• The MAC protocol must be distributed in nature
• It should solve the hidden and exposed terminal
  problems

125
QoS Support using IEEE 802.11 DCF

• IEEE 802.11 DCF is a best-effort type control
  algorithm
• The duration of backoff is decided by a random
  number between 0 and the contention window (CW).
• Service differentiation can be achieved by using
  different values of CW
• When packets collide, the ones with smaller CW is
  more likely to occupy the medium earlier

126
MACA/PR Lin97

• Multihop Access Collision Avoidance with
  Piggyback Reservation provides guaranteed
  bandwidth support for real-time traffic
• The first packet in a real-time stream uses
  RTS/CTS dialogs to make reservations in the path
• The sender schedules the next transmission after
  the current data transmission and piggybacks the
  reservation in the current data packet
• Upon receiving the data packet correctly, the
  receiver updates its reservation table and sends
  an ACK
• ACK serves for the renewal of reservation, not
  for recovering from packet losses

127
QoS-aware Routing at the Network Layer

• Types of MANET routing protocols
• Proactive, table-based routing schemes
• Reactive, on-demand routing schemes
• Constraint-based routing schemes
• These algorithms are based on the discovery of
  shortest paths
• QoS-aware routing protocol should find a path
  that satisfies the QoS requirements in the path
  from source to the destination

128
CEDAR Singha99

• Core Extraction Distributed Ad hoc Routing scheme
  dynamically establishes the core of the network,
  and then incrementally propagates the link states
  of stable high-bandwidth links to the core nodes
• The route computation is on demand basis
• Components of CEDAR
• Core extraction
• Link-state propagation
• Route computation

129
Integrating QoS in Flooding-Based Route Discovery

• Ticket-based probing algorithm Chen99
• During the QoS-satisfying path search, each
  probing message is provided a limited number of
  tickets to reduce the scope of flooding
• When one or more probes arrive at the
  destination, the path and delay/bandwidth
  information is used to perform reservation for
  the QoS-satisfying path
• A simple imprecise model is used for the
  algorithm

130
PANDA Approach Li03

• Positional Attributes based Next hop
  Determination Approach (PANDA) discriminates the
  next hop based on the desired QoS metric
• Instead of using a random rebroadcast delay, the
  receiver opts for a delay proportional to its
  ability in meeting the QoS demands
• The decisions at the receivers are made based on
  a predetermined set of thresholds

131
QoS Support using Bandwidth Calculations Lin99

• The end-to-end bandwidth can be calculated and
  allocated during the admission control phase
• Using TDMA, time is divided into slots, which in
  turn are grouped into frames
• Each frame contains two phases control and data.

• During the control phase, each node takes turns
  to broadcast its information to all the neighbors
  in a predetermined slot.
• At the end of control phase, each node knows
  about the free slots between itself and its
  neighbors
• Thus bandwidth calculation and allocation can be
  done in a distributed manner

132
Multi-path QoS Routing Liao01

• The algorithms searches for multiple paths
  between the source and the destination that
  collectively satisfies the QoS requirements
• Suitable for ad hoc networks with limited
  bandwidth
• A ticket based probing scheme is adopted for the
  path searching process

133
Transport Layer Issues for QoS Provisioning

• TCP performs poorly in terms of end-to-end
  throughput in MANETs
• The assumption used in Internet that packet
  losses are due to congestion is not valid in
  MANET environments
• TCP performance improvement in wireless networks
• Local retransmissions
• Split-TCP connections
• Forward error corrections (FEC)
• Explicit feedback mechanisms to distinguish
  between losses due to errors and congestion is
  necessary for QoS provisioning in MANETs
• Efficient techniques for resource management is
  necessary for QoS provisioning

134
Application Layer Issues

• Application level QoS adaptation belong to
  adaptive strategies that play a vital role in
  supporting QoS
• Flexible user interfaces, dynamic QoS ranges,
  adaptive compression algorithms, joint
  source-channel coding, joint source-network
  coding schemes
• Adaptive real-time audio/video streaming support
  can be provided by enhancing
• Compression algorithms, layered encoding, rate
  shaping, adaptive error control, and bandwidth
  smoothing

135
Inter-Layer Design Approaches

• Efficient intercommunication protocols need to
  conserve scarce resources something difficult
  to achieve following the strict separation of the
  protocol layer functionalities
• Inter-layer or cross-layer issues needs to be
  examined
• Examples INSIGNIA and iMAQ

136
Security Issues

• Environments and Philosophies
• Closed vs. open world assumption
• Prevention vs. Detection
• Malicious vs. Selfish behavior

137
Vulnerabilities

• Wireless links vulnerable to jamming
• Inherent broadcast nature facilitates
  eavesdropping
• Tradeoffs between resource constraints and
  security
• Mobility/dynamics make it difficult to detect
  anomalies such as bogus routes
• Self organization is inherent, cannot have
  central authorities/infrastructures, such as for
  key management

138
Attacks

• Motivation
• Better service
• Monetary benefits
• Gaining confidential information
• Power saving
• Preventing someone else from getting proper
  service

139
Attacks Indications

• Create routing loops
• Black holes
• Misrouting along sub-optimal paths
• Incorrect forwarding acknowledge ROUTE REQUEST,
  and do not forward it at all
• Bogus routing information advertise a
  non-existent route
• Choose a very short reply time, so the route will
  be prioritized and stays in cache longer
• Do not send error messages in order to prevent
  other nodes from looking for alternative routes
• Use promiscuous mode to listen in on traffic and
  gather information
• Cause DoS attack caused by overload, by sending
  route updates at short intervals

140
Solutions

• Authentication by imprinting (closed world)
• Incentives to cooperate per hop payment in
  every packet/counters embedded in nodes
• Localized certification based on Public Key
  Infrastructure
• ARIADNE Secure on-demand routing protocol which
  prevents attackers from tampering
• SEAD One way hash functions used to add security
  to DSDV (adds latency)

141
Detection

• Intrusion detection techniques
• Distributed and cooperative
• Using statistical anomaly detection approaches
• Cooperate with other network layers
• Majority voting to classify behavior
• Watchdog and Pathrater
• CONFIDANT

142
Nodes bearing Grudges Buchegger02

• Give the nodes incentive for cooperation
• Nodes must behave in a manner that is best both
  for them and the group
• Punish the non cooperating nodes

• (A beautiful mind !!)

143
Selfish Gene Dawkins76

• In many schemes, the malicious nodes are relieved
  of carrying traffic for others, while their
  traffic is still transferred
• Looks more like encouragement
• Biological example
• Suckers
• Cheats
• Grudgers

144
From Birds to Network Nodes

• The Monitor
• Trust Manager
• Reputation System
• Path Manager

145
Components

• The Monitor
• Neighborhood watch
• Look out for deviations no forwarding, route
  salvaging, unusually frequent route updates
• Trust Manager (Distributed and adaptive)
• Trust function to calculate trust levels
• Forwarding of ALARM messages
• Filtering ALARMs based on trust level of
  reporting node

146
Components

• Reputation System
• Own experience greatest weight
• Observations smaller weight
• Reported experience weight function according to
  trust level
• Path Manager
• Remove malicious nodes from routes between well
  behaved nodes
• Educate nodes to not provide paths between
  malicious nodes

147
ARIADNE Hu02

• Aims to create a secure on-demand routing
  protocol
• Uses TESLA, an authentication scheme that
  requires loose time synchronization
• Incorporate security features into DSR
• Focuses on active attackers

148
Attacker Model

• Passive versus Active
• Passive only eavesdrops
• Threats against privacy/anonymity
• Active injects packets as well as eavesdrops
• Active-n-m attacker
• Compromises n good nodes and owns m nodes in the
  network
• Attacker have all keys of compromised nodes and
  distributes it among all its nodes
• Active-VC attacker
• Owns all nodes on a vertex cut

149
Overview of TESLA

• Broadcast authentication protocol
• Authenticate routing messages
• Only one MAC(Message Authentication Code)
• Secure authentication in point-to-point
  communication
• Asymmetric primitive by clock synchronization and
  delayed key disclosure
• One-way key chain
• Each sender chooses random initial key KN,
  generates one-way key chain as Ki HN-i (KN)
• Schedule for disclosing keys
• Each sender pre-determines the schedule
• For example, disclose Ki at Ti T0 i ? t

150
Overview of TESLA

• Receiver can determine which key is disclosed
• Based on loose time synchronization(?)
• Sender picks Ki which will not be disclosed until
  ? 2? time passes and add MAC using Ki
• Discard the packet if security condition fails
• TESLA security condition
• Ki used to authenticate a packet cannot have been
  disclosed yet
• tr ? t0 i ? t - ? implies Ki is not disclosed
  yet
• ? is small ? may discard some packets? is large
  ? long delay for authentication? does not affect
  security

151
ARIADNE Route Discovery

• Target authenticates Route Requests
• Initiator includes a MAC with KSD
• Data Authentications
• Initiator authenticates nodes in Route Reply
• Target authenticates nodes in Route Request and
  return only legitimate paths
• TESLA, digital signatures, standard MACs
• Per-hop hashing
• One-way hash functions to verify that no hop was
  omitted

152
References

• Bharghavan94 V. Bharghavan, A. Demers, S.
  Shenker and L. Zhang, MACAW a media access
  protocol for wireless LANs, SIGCOMM94.
• Braginsky02 David Braginsky and Deborah Estrin.
  Rumor Routing Algorithm For Sensor Networks. In
  Proceedings of the First Workshop on Sensor
  Networks and Applications (WSNA), September 28
  2002, Atlanta, GA.
• Buchegger02 S. Buchegger and J. L. Boudec,
  Nodes Bearing Grudges Towards Routing Security,
  Fairness, and Robustness in Mobile Ad Hoc
  networks, Euromicro Workshop on Parallel,
  Distributed, and Network-Based Processing, 2002.
• Bulusu01 N. Bulusu, John Heidemann and Deborah
  Estrin. Adaptive Beacon Placement. In Proceedings
  of the Twenty First International Conference on
  Distributed Computing Systems (ICDCS-21), April,
  2001.
• Bulusu02 N. Bulusu. Self-Configuring
  Localization Systems, Ph.D Thesis, University of
  California at Los Angeles, October 2002.
• Bulusu00 N. Bulusu, John Heidemann and Deborah
  Estrin. GPS-less Low Cost Outdoor Localization
  for Very Small Devices. IEEE Personal
  Communications Magazine, Vol. 7, No. 5, pp.
  28-34. October, 2000.
• Bulusu03 N. Bulusu, J. Heidemann, D. Estrin,
  and T. Tran. Self-configuring Localization
  Systems Design and Experimental Evaluation. ACM
  Transactions on Embedded Computing Systems(TECS),
  Special Issue on Networked Embedded Computing,
  May 2003.
• Campbell01 A. Veres, A.T. Campbell, M. Barry,
  and L.H. Sun, Supporting service differentiation
  in wireless packet networks using distributed
  control, IEEE J. SAC, Oct, 2001.
• Chen99 S. Chen and K. Nahrstedt, "Distributed
  Quality-of-Service Routing in Ad-Hoc Networks,"
  IEEE Journal of Selected Areas on Communications,
  vol. 17, No. 8, August 1999.

153

• Chiang97 C.-C. Chiang, Routing in Clustered
  Multihop, Mobile Wireless Networks with Fading
  Channel, IEEE SICON (Singapore International
  Conference on Networks) , Apr, 1997
• Choudhury02 R. R. Choudhury, X. Yang, N.
  Vaidya, R. Ramanathan, Using directional
  antennas for medium access control in ad hoc
  networks, Mobicom, 2002.
• Dawkins76 R. Dawkins, The Selfish Gene, Oxford
  University Press, 1989 Edition, 1976.
• Getting93 I. A. Getting, "The Global
  Positioning Systems," IEEE Spectrum, pp. 36--47,
  December 1993.
• Haas97Z.J. Haas, "A New Routing Protocol for
  the Reconfigurable Wireless Networks", IEEE Intl.
  Conf. on Universal Personal Comm. (ICUPC'97), San
  Diego, Oct. 1997.
• He03 T. He, C. Huang, B. M. Blum, J. A.
  Stankovic,and T. F. Abdelzaher. Range-Free
  Localization Schemes in Large Scale Sensor
  Networks, the Ninth Annual International
  Conference on Mobile Computing and Networking
  (MobiCom 2003), San Diego, CA, September 2003.
• Heinzelman99 W. Heinzelman, J. Kulik, and H.
  Balakrishnan, Adaptive Protocols for
  Information Dissemination in Wireless Sensor
  Networks,'' Proc. 5th ACM/IEEE Mobicom Conference
  (MobiCom '99), Seattle, WA, August, 1999.
• Heinzelman00 Wendi Heinzelman, Anantha
  Chandrakasan, and Hari Balakrishnan,
  Energy-Efficient Communication Protocols for
  Wireless Microsensor Networks, Proc. Hawaaian
  Int'l Conf. on Systems Science, January 2000.
•  Intanagonwiwat00 C. Intanagonwiwat, R.
  Govindan and D. Estrin. Directed Diffusion A
  Scalable and Robust Communication Paradigm for
  Sensor Networks. In Proceedings of MobiCOM 2000,
  August 2000, Boston, Massachusetts.
• Johnson96 D.B. Johnson, and D.A. Maltz,
  Dynamic Source Routing in Ad-Hoc Wireless
  Networks, Mobile Computing, T. Imielinkski and
  H. Korth, Eds., Kluwer, 1996, pp 153-181.

154

• Karn90 P. Karn, MACA a new channel access
  method for packet radio, Amateur Radio 9th
  Computer Networking Conference, 1990.
• Kleinrock75 L.Kleinrock and F.A.Tagobi,
  Packet switching in radio channels Part-II The
  hidden terminal problem in carrier sense
  multiple-access modes and the busy tone
  solution, IEEE Trans. Comm. Vol 23, no 12, 1975
• Ko00 Y.-B. Ko, V. Shankarkumar, N. Vaidya,
  Medium Access Control Protocols using
  Directional Antennas in Ad Hoc Networks, Infocom
  2000
• Ko98 Y. B. Ko and N. H. Vaidya,
  Location-Aided Routing (LAR) in Mobile Ad Hoc
  Networks, Mobicom, 1998.
• Lai02 B.C. Lai, S. Kim, I. Verbauwhede.
  Scalable session key construction protocol for
  wireless sensor networks. IEEE Workshop on Large
  Scale Real-Time and Embedded Systems (LARTES).
  December 2002
• Lee99S.J. Lee, M. Gerla, and C.C. Chiang,
  On-Demand Multicast Routing Protocol, IEEE
  WCNC, 1999.
• Lee98 S. Lee and A. T. Campbell "INSIGNIA
  In-band signaling support for QOS in mobile ad
  hoc networks", Proc of 5thInternational Workshop
  on Mobile Multimedia Communications (MoMuC,98) ,
  Berlin,Germany, October 1998.
• Li03 J. Li and P. Mohapatra, LAKER Location
  Aided Knowledge Extraction Routing for Mobile Ad
  Hoc Netwoks, WCNC 2003.
• Li03 Jian Li, and Prasant Mohapatra. "A Novel
  Mechanism for Flooding Based Route Discovery in
  Ad Hoc Networks," IEEE GlobeCom 2003 .
• Liao01 Wen-Hwa Liao, Yu-Chee Tseng, Shu-Ling
  Wang, Jang-Ping Sheu A Multi-path QoS Routing
  Protocol in a Wireless Mobile ad Hoc Network. ICN
  (2) 2001 158-167.

155

• Lin97 C.R. Lin, and M. Gerla, MACA/PR An
  Asynchronous Multimedia Multihop Wireless
  Network, IEEE INFOCOM, 1997
• Lin99 C. R. Lin and J. S. Liu, QoS routing in
  Ad hoc Wireless Networks", IEEE Journal on
  Selected Areas in Communications, August 1999.
• Liu01J. Liu, and S. Singh, ATCP TCP for
  mobile ad hoc networks, IEEE J-SAC, July, 2001
• Liu99M. Liu, R.R. Talpade, A. McAuley, and E.
  Bommaiah, AMRoute Adhoc Multicast Routing
  Protocol, Computer Science Dept. U. Maryland,
  TR-99-8
• Mohapatra03 P. Mohapatra, J. Li, and C. Gui,
  QoS in Mobile Ad Hoc Networks, IEEE Wireless
  Communications, June 2003.
• Murthy96 S. Murthy and J.J. Garcia-Luna-Aceves,
  An Efficient Routing Protocol for Wireless
  Networks, ACM MONET, Oct, 1996, pp 183-197
• Nasipuri00 A. S. Nasipuri, S. Ye, and R. E.
  Hiromoto, "A MAC Protocol for Mobile Ad Hoc
  Networks Using Directional Antennas", WCNC 2000
• Niculescu01 D. Niculescu and B. Nath, "Ad hoc
  Positioning System (APS)", GLOBECOM 2001, San
  Antonio, Nov 2001.
• Niculescu03 D. Niculescu and B. Nath, "Ad hoc
  Positioning System (APS) using AoA", INFOCOM 2003.

156

• Perkins94C. Perkins, Highly Dynamic
  Destination-Sequenced Distance-Vector Routing
  (DSDV) for Mobile Computers, ACM SIGCOMM, 1994
• Perkins99 C.E. Perkins, and E.M. Royer,
  Ad-hoc On-Demand Distance Vector Routing, IEEE
  Workshop on Mobile Computing Systems and
  Applications, Feb, 1999
• Perrig01 A. Perrig, R. Szewczyk, V. Wen, D.
  Culler, and J. Tygar. SPINS Security Protocols
  for Sensor Networks. In Seventh Annual ACM
  International Conference on Mobile Computing and
  Networks(Mobicom) 2001.
• Royer99E. Royer, and C.E. Perkins, Multicast
  operations of the ad-hoc on-demand distance
  vector routing protocol, ACM MOBICOM, 1999
• Sawide01 A. Savvides, C.C. Han and M. B.
  Srivastava, Dynamic Fine Grained Localization in
  Ad-Hoc Sensor Networks, Proceedings of the Fifth
  International Conference on Mobile Computing and
  Networking, Mobicom 2001, pp. 166-179, Rome,
  Italy, July 2001
• Schurgers02C. Schurgers, V. Tsiatsis, S.
  Ganeriwal, and M. Srivastava, Optimizing Sensor
  Networks in the Energy-Latency-Density Design
  Space, IEEE Tran. Mobile Comp. Vol. 1, No. 1,
  Jan-Mar, 2002
• Shah01 Samarth H. Shah, Kai Chen, Klara
  Nahrstedt, Cross Layer Design for Data
  Accessibility in Mobile Ad Hoc Networks, in Proc.
  of 5th World Multiconference on Systemics,
  Cybernetics and Informatics (SCI 2001), Orlando,
  Florida, July, 2001.
• Shih01 Eugene Shih, Seong-Hwan Cho, Nathan
  Ickes, Rex Min, Amit Sinha, Alice Wang, and
  Anantha Chandrakasan. Physical Layer Driven
  Algorithm and Protocol Design for Energy-Ecient
  Wireless Sensor Networks. In Proceedings of
  MOBICOM 2001

157

• Singh98 S. Singh and C.S. Raghavendra, PAMAS
  power aware multi-access protocol with
  signaling for ad hoc networks, ACM SIGCOMM, 1998
• Sinha99a P. Sinha, R. Sivakumar, and V.
  Bharghavan, CEDAR A core extraction distributed
  ad hoc routing algorithm. In Proc. of IEEE
  Infocom, 1999.
• Sinha99bP. Sinha, R. Sivakumar and V.
  Bharghavan, MCEDAR Multicast extensions to
  Core-Extraction Distributed Ad hoc Routing
  algorithm'', IEEE WCNC, 1999
• SmartDust http//robotics.eecs.berkeley.edu/pis
  ter/SmartDust/
• Sobrinho99 J.L. Sobrinho, and A.S.
  Hrishnakumar, Quality-of-Service in Ad Hoc
  carrier sense multiple access wireless networks,
  IEEE J. SAC, Aug, 1999
• Sohrabi00 K. Sohrabi, J. Gao, V. Ailawadhi,
  and G.J. Pottie. Protocols for self-organization
  of a wireless sensornetwork. IEEE Personal
  Communications, 7(5)1627, October 2000.
• Tseng02Y.-C. Tseng, C.-S. Hsu, and T.-Y.
  Hsieh, Power-Saving Protocols for IEEE
  802.11-Based Multi-Hop Ad Hoc Networks, IEEE
  INFOCOM, 2002
• Woo01 A. Woo, D. Culler, A Transmission
  Control Scheme for Media Access in Sensor
  Networks, Mobicom 2001.
• Ye02 W. Ye, J. Heidemann and D. Estrin. "An
  Energy-Efficient MAC Protocol for Wireless Sensor
  Networks," In Proceedings of the 21st
  International Annual Joint Conference of the IEEE
  Computer and Communications Societies (INFOCOM
  '02), New York, June 2002.
• Zheng03R. Zheng, J. Hou, and L. Sha,
  Asynchronous Wakeup for Power Management in Ad
  Hoc Networks, ACM MOBIHOC, 2003
