3-D RIPPLE PRINT

1
3-D RIPPLE PRINT TRANSPARENT PRINT
2
What is 3-D Ripple Print?3-dimensional
transparent print or Special embossed color print
on cellulosic goods

• Exclusive recipe by Permafin-PN..
• system
• Primarily for cellulosic goods
• Unique and exceptional print
• Fully creative finish

3
1. Additives for Transparent Ripple
PrintPermafin-PB-37, Permafin-PN-01Permafin-RPP,
Permafin-PN-119Crosslinker-UX,
Microderm-SKCAquarepel-XC/Conc,
Aquarepel-EX-001MTriplex-PTF, Altraplex-AW

• Recipe for Transparent and Ripple print
• Roller Print mangle padding for woven
• Rotary print for woven
• Rotary print for knit

4
Specification Additives
5
Additives

• Permafin- PN-37
• Permafin- PN-01
• Permafin- PN 119
• Urethane resin for transparent print and color
  print
• Excellent alkaline stability. No hydrolysis
  problem
• Prevent staining of dyes in washing process
• Good transparency and vivid print on goods
• Film with soft handle PN 119gtPN 37 gt PN-01
• Permafin- PN 119 provides more volume

6
Additives

• Permafin- RPP
• Urethane resin for transparent print and color
  print
• Excellent alkaline stability. No hydrolysis
  problem
• Prevent staining of dyes in washing process
• Good transparency and vivid print on goods
• Good volume feeling to the clothes and bed
  clothes
• Film with medium to stiff handle

7
Additives

• CROSSLINKER-UX
• Catalyst for urethane resin
• Promotes activation and fixation of Urethane
  resin
• Applying quantity 5 10 of urethane resin
• applied
• MICRODERM-SKC
• Specific softener for Ripple print only for
  knit
• Form film by itself without any bad influence on
• print
• Applying quantity 30 50 g/l

8
Additives

• AQUAREPEL-FC 1500
• Film protector for color Ripple print by
  reactive dyes
• Prevent color change/lost of dyes under strong
  alkalis
• Aquarepel-EX-001M
• Catalyst of FC 1500 in color ripple print
• Prevent drape property of fabrics
• Applying quantity ca. 20 of FC 1500 applied

9
Triplex-PTFThickener for viscosity
controlApplying quantity x for viscosity ca.
5000 cps
Additives

• Altraplex- AW
• Used in washing process after alkali ageing of
  Ripple Print
• Prevent yellowing of transparent print film after
  drying
• When neutralizing by Acid, used jointly in a bath
• Applying quantity 35 g/l

10
Application

• 1. Roller Print for Woven
• Recipe
• Permafin--RPP 95
• Crosslinker-UX 5
• Thickener Triplex-PTF x ca. 5000 cps of
  viscosity
• If softer handle is required, increase the
  quantity of Permafin- PN-01 or PN 37, PN 119,
  Microderm-SKC while reducing the quantity of
  Permafin--RPP
• Print condition Mangle padding Roller Print ?
  Setting 190ºC x 100 yd/mm ? Alkali treatment
  98 NaOH 32º 35º Be ? Rinsing neutralizing
  ? Tentering 170ºC x 70 yd/min

11
Application

• 2. Rotary print for woven
• Recipe
• Permafin- PN-01 70 or Permafin- PN 37, PN
  119
• Permafin- RPP 25
• Crosslinker-UX 5
• Thickener Triplex-PTF X ca. 5000 cps of
  viscosity
• Print condition
• Printing ? Curing 180ºC x 2 min ? Padding 98
  NaOH 320 350 g/l ? Rinsing neutralizing ?
  Tentering 180ºC x 90 sec

12
Application

• 3. Rotary print for knit
• Recipe
• Permafin- PN-01 55 or Permafin- PN 37, PN
  119
• Permafin- RPP 25
• Crosslinker-UX 5
• Microderm- SKC 15
• Thickener Triplex-PTF X ca. 5000 cps for
  viscosity
• Print condition
• Pre-treatment ? Printing ? Curing 180ºC x 2 min
  ? Padding 98 NaOH, 320350 g/l ? Rinsing
  neutralizing ? tentering 180ºC x 1 min 30 sec
