Decision Making with Uncertainty and Data Mining

1
Decision Making with Uncertainty and Data Mining

• David L. Olson University of Nebraska
• Desheng Wu University of Science Technology
  of China
• ADMA05 Wuhan, China, 22-24 July 2005

2
Decision Making under Uncertainty

• Uncertainty exists in data
• Imprecise data
• Missing data
• Human subjectivity
• Fuzzy set theory
• A means to reflect uncertainty
• Grey related analysis (interval vague)
• A type of fuzzy set data

3
Monte Carlo Simulation

• Analytic models preferred
• But simulation needed if
• High levels of uncertainty make analytic models
  too messy to calculate
• High levels of complexity make analytic models
  intractable

4
Fuzzy Simulation

• Fuzzy input often expressed in trapezoidal form
• Minimum, range of most likely, maximum
• Triangular, interval special cases
• Can be analyzed through Monte Carlo

5
Fuzzy Distribution Forms

• Trapezoidal

• Triangular

• Interval

6
Grey Related Analysis

• Deng 1982
• Means to incorporate uncertainty
• Incomplete or unknown elements
• Interval numbers
• Standardize through norms
• Transform index values through product operations
• Minimize distance to ideal, max from nadir
• Simple, practical
• Dont require large sample sizes, nonparametric

7
Demonstration MCDM

• MultiCriteria Decision Making
• Modern decision making complex
• Need to balance tradeoffs among conflicting
  criteria (attributes objectives goals)
• Fuzzy MCDM
• Alternative scores on each criterion uncertain
• Measures of weights vary across group members

8
Implementations of Fuzzy Multiattribute Idea

• Fuzzy theory
• DuBois Prade 1980
• Rough sets
• Pawlak 1982
• Grey sets
• Interval analysis Moore 1966 1979
• Deng 1982
• Vague sets Gau Buehrer 1993
• Probability theory
• Pearl 1988

9
PROMETHEE

• J.P. Brans, P. Vincke, B. Mareschal (Belgium)
• basically a workable ELECTRE
• PROMETHEE I partial order
• PROMETHEE II full ranking
• GAIA graphical (concordance analysis)

10
criteria scales

• I -0 if indifferent or worse, 1 if better
• II -0 if not better by parameter q, 1 if
• III -d is degree better than alternative
• 0 if not better by parameter q
• d/p if between q p, 1 if dgtp
• IV -step 0 if dltq .5 if qltdltp 1 if dgtp
• V - slope
• VI - normal

11
Promethee Criteria

• II INTERVAL
• III TRIANGULAR
• V TRAPEZOIDAL
• Promethee doesnt use value function
• But demonstrates the incorporation of fuzzy input
  into MCDM

12
Demo Model

• Group Decision
• Conservative, Liberal, Business
• Energy Options
• S1 Nuclear
• S2 Coal
• S3 Conservation
• S4 Import
• Criteria
• C1 Cost (minimize)
• C2 Pollution (miniimize)
• C3 Risk of catastrophe (minimize)
• C4 Energy Independence (maximize)

13
Weights for each group memberTrapezoidal (grey
related)
14
Cost Scores for each group memberTrapezoidal
15
MethodWu, Olson, Liang

• Use grey related analysis
• Inputs are uncertain
• Use alpha-cut method to convert trapezoidal into
  interval
• Simulate
• Very complex preference model
• Know distribution of uncertainty
• Possibility that different alternatives may turn
  out to be preferred

16
Simulation Output
17
Monte Carlo Simulation of Grey Related Data

• Given interval data
• Draw uniform random number
• Assume value that proportion from minimum to
  maximum
• Do this for every interval number
• These become crisp numbers for this sample
• Calculate outcomes
• Value
• Get probabilistic picture of outcomes in complex
  system involving uncertainty (grey related
  intervals)

18
DemonstrationOlson Wu

• Hiring decision
• Multiple criteria, Six applicants
• Criteria
• C1 Experience in business
• C2 Experience in function
• C3 Education
• C4 Leadership
• C5 Adaptability
• C6 Age
• C7 Aptitude for Teamwork

19
Alternative Performance Matrix
20
Grey Related Weights
21
Grey Related data

• Weights interval
• Scores interval
• Used Grey Related model to identify best for each
  simulation run
• Best average weighted distance to reference point
• Reflect both min to ideal, max from nadir
• Ran 1,000 replications for each of 10 seeds

22
Probabilities of Best
23
Implications

• Crisp Grey Related
• Isabel is the best choice
• Antonio very close
• Alberto, Fernando not far back
• SIMULATION
• Isabels probability of being best is 0.41
• Antonio 0.35, Alberto 0.19, Fernando 0.05
• Fabio Rafaela never won
• Simulation provides better picture

24
Simulation of Grey Related Data in Data Mining

• Decision tree analysis (PolyAnalyst)
• Real credit card data
• 1,000 observations (900 train 100 test)
• 140 default, 860 no problem
• 65 available explanatory variables (used 26)
• Due to imbalance, initial models degenerate
• Called all test cases OK
• Differential cost models also degenerate
• Called all test cases default

25
Fuzzified Data

• Of 26 explanatory variables
• 5 binary
• 1 categorical
• 20 continuous
• Fuzzified into 3 categories each
• Case by case, roughly equally sized categories

26
Decision Tree Models

• Minimum support minimum of 1
• PolyAnalyst allowed
• Optimistic split of criteria
• Pessimistic split of criteria
• Different decision tree model each run

27
Continuous Data Output

• Varied degree of perturbation (uncertainty)
• Continuous Data
• Many models overlapping
• Three unique decision trees
• Used a total of 8 explanatory variables
• Categorical Data
• Four unique decision trees
• Used a total of 7 explanatory variables

28
Continuous Model 1

• Bal/Pay ratio lt 6.44 NO
• Bal/Pay ratio 6.44
• Utilization lt 1.54 Default
• Utilization 1.54
• AvgPayment lt 3.91 NO
• AvgPayment 3.91 Default

29
Continuous Model 2

• Bal/Pay ratio lt 6.44 NO
• Bal/Pay ratio 6.44 Default

30
Continuous Model 3

• Bal/Pay ratio lt 6.44 NO
• Bal/Pay ratio 6.44
• Utilization lt 1.54 Default
• Utilization 1.54
• AvgRevolvePay lt 2.28 Default
• AvgRevolvePay 2.28 NO

31
Categorical Model 1

• Bal/Pay ratio high
• CreditLine high
• CalcIntRate I mid NO
• CalcIntRate I NOT mid Default
• CreditLine NOT high Default
• Bal/Pay ratio NOT high NO

32
Categorical Model 2

• Bal/Pay ratio high
• CreditLine low
• ChangeLine mid
• PurchBal low Default
• PurchBal NOT low NO
• ChangeLine low NO
• ChangeLine high Default
• CreditLine high
• CalcIntRate I mid NO
• CalcIntRate I NOT mid Default
• CreditLine mid Default
• Bal/Pay ratio NOT high NO

33
Categorical Model 3

• Bal/Pay ratio high Default
• Bal/Pay ratio NOT high NO

34
Categorical Model 4

• Bal/Pay ratio high
• CreditLine low
• ChangeLine mid
• PurchBal low Default
• PurchBal NOT low NO
• ChangeLine low NO
• Residence 0 Default
• Residence 1 or 2 NO
• ChangeLine high Default
• CreditLine high
• CalcIntRate I mid NO
• CalcIntRate I NOT mid Default
• CreditLine mid Default
• Bal/Pay ratio NOT high NO

35
Continuous 1 Coincidence matrix
36
Simulation Output Continuous 1(Crystal Ball
test set accuracy)
37
Continuous 1

• Simulation accuracy of 100 observations, 1000
  simulation runs
• perturbation -0.25,0.25 0.67-0.73
• perturbation -0.50,0.50 0.65-0.74
• perturbation -1,1 0.62-0.75
• perturbation -2,2 0.58-0.74
• perturbation -3,3 0.57-0.74
• perturbation -4,4 0.56-0.75

38
Mean Model AccuracyMeasured on Test Set
39
Inferences

• Continuous models declined in accuracy more than
  categorical
• Categorizing data one basic form of fuzziness

40
Applying to Data Mining

• Easiest way to apply fuzzy concepts to data
  mining
• CATEGORIZE DATA
• Simulation a way to deal with fuzzy data
• Application of Simulation to fuzzy data mining
  not as simple
• Large scale data sets
• Create additional columns
• Still very promising research area

41
Conclusions

• Interesting research directions
• Simulation in data mining
• Fuzzy data is probabilistic, so simulation seems
  appropriate
• Simulation involves a lot more work than closed
  form (CRISP) simplifications
• Group preference aggregation
• Fuzzy data may be fuzzy due to different group
  member opinions
• Interesting ways to aggregate
