Romeo Nuzziello

1
SerVaas Factories Intl
910 MT Press Extrusion Line
Technical Specifications


Romeo Nuzziello Paul SerVaas
Prepared by
2
SerVaas Factories Intl
Introducing
3
SerVaas Factories Intl Douglas, British Isles
We have been in business for over 50 years and
have excellent credit and business references. We
will consider deals in any country, but have
particular experience in North and South
America, Europe, Russia and China. We are former
factory owners who have often bought and sold
factory equipment as events dictated.
We can finance our own purchase from you, or if
the equipment is still in production, we can pay
you for an option to buy it at a later
date. Our associates speak English, Spanish,
German, Portuguese, Italian, Russian and Mandarin
Chinese.
SerVaas Inc. 1000 Waterway Boulevard Indianapolis,
Indiana 46202 Tel [phone] Fax
001-317-633-8805 www.SerVaasFactories.com
910 MT Aluminum Extrusion Press Line Never Used
Available Immediately
4
910 MT Press Extrusion Line
Technical Specifications


5
910 MT Press Extrusion Line
PRESS DESCRIPTION 910 metric ton
horizontal, self-contained, oil-hydraulic
extrusion press using a three tie rod
construction. This press is a transverse
die-slide type, and was designed for the
extrusion of soft aluminum alloys. The press is
suitable for direct extrusion by means of a fixed
dummy block.
6
910 MT Press Extrusion Line

• THE PRESS MAINLY CONSISTS OF
• A basic press mounted on a single-piece,
  structural frame.
• An oil-hydraulically operated, container-shifting
  device.
• A traverse die-slide, complete with aligning
  devices. (The slide is made of several parts.
  One part is provided with a clearance hole for
  billet sticker removal, and two parts are used
  for die holders, one of which is situated inside
  the press, and the other is in the die changing
  device.)
• A quick die-changing device (from one side of the
  press only).
• A vertical, oil-hydraulically operated butt-shear
  (for cutting off the butt end).
• An oil-hydraulically operated horizontal shear
  (for cutting extrusions behind the die stack).
  The shear cylinder serves to shift die slide.

7
910 MT Press Extrusion Line

• THE PRESS MAINLY CONSISTS OF (continued)
• An oil-hydraulically operated (automatic pivot
  arm) billet loader.
• An automatic control system (which will stop the
  press without damage should the butt not fall
  free at the completion of the main shear
  operation).
• A chute for ejecting butt end.
• The oil-hydraulic pumps, solenoid-operated
  control valves, and the connecting piping.
• A self-supported oil tank situated over the main
  cylinder.
• A free-standing, main operating pulpit with all
  necessary controls for manual press operation,
  and for automatic sequencing, with cycle
  selectors, gauges, and motor controls.
• An auxiliary control panel located on the press
  in the proximity of the
• platen egress hole.

8
910 MT Press Extrusion Line

• THE PRESS MAINLY CONSISTS OF (continued)
• An adjustable extrusion-speed PLC (instantaneous)
  for automatic press control.
• Adjustable limit-switches (for automatic
  sequencing, and for safety
• interlocks).
• An electric container heater with automatic
  temperature control.
• An oil filtering and cooling system.
• A manually operated lubricating system with
  connecting lines to all main sliding surfaces.
• A billet lubricating system (necessary for
  working with a
• fixed dummy-block).

9
910 MT Press Extrusion Line
910 MT Press Extrusion Line

• PRESS TECHNICAL DATA
• Press capacity 910 M.T.
• Operating pressure max 210 kg/sq. cm
• Capacity of auxiliaries
• Side cylinders forward 113 M.T.
• Side cylinders return 62 M.T.
• Container stripping 84 M.T.
• Container sealing 63 M.T.
• Main shear 27 M.T.
• Auxiliary shear 16/8 M.T.
• Stroke
• Main ram 1395 mm
• Container 290 mm
• Main shear 450 mm
• Auxiliary shear(for die slide shifting) 1130 mm
• Auxiliary shear(for extrusion cutting) 550 mm

10
910 MT Press Extrusion Line
910 MT Press Extrusion Line

• PRESS TECHNICAL DATA (continued)
• Operating speeds
• Fast advance 465 mm/s
• Extrusion (max. delivery 600 1/min.) 23 mm/s
• Return 415 mm/s
• Range of round billet diameter 115-145 mm
• Max. length of cold billet 650 mm
• Container length 690 mm
• Platen bore 165 mm
• Hydraulic system
• Output of main pumps 730 l/min
• Output of auxiliary pump 108 l/min
• Output of sealing pump 17 l/min
• No. and type of main pumps One double-pump
• (with piston at variable delivery)

11
910 MT Press Extrusion Line
910 MT Press Extrusion Line

• PRESS TECHNICAL DATA (continued)
• Main pump motor 200 KW _at_1500 RPM
• Container heating system electric resistance
  type
• Dead cycle time 12 sec. (approximate)

12
910 MT Press Extrusion Line
Press Construction Details and Description
13
910 MT Press Extrusion Line
MACHINE DESIGN The press is a three-column type
with a transverse die-slide. It utilizes one
billet container that is shifted by means of
hydraulic cylinders. It also includes all other
devices necessary for aluminum billet extrusion
(see list of relevant alloys). The press
comes complete with adjustment devices necessary
for the exact alignment of the press components.
They are designed to assure continuous alignment
during operation. The above mentioned devices
are particularly useful for the container, the
container holder, and the die slide, which are
heated components, and are free to expand without
causing any distortion or misalignment. Special
care has been taken in the design to guarantee
both a long press life, and ease of maintenance.
Wear-parts are self adjusting, so even after many
years of operation, no mechanical machining or
replacements are necessary.
14
910 MT Press Extrusion Line
MAIN CYLINDER RAM The main cylinder is made of
forged steel (single piece) with welded
extensions. It has been thoroughly tested,
including a pressure test to 150 of the rated
pressure. The cylinder is equipped with long,
bronze bushings so that the ram is properly and
precisely guided. The main cylinder is fixed
at the baseframe end. Concerning the extensions,
either the three main columns, or the two main
ram-advancing and returning hydraulic cylinders,
are fixed. The ram is made of wear-resistant
cast iron. Its surface is accurately lapped.
15
910 MT Press Extrusion Line
AUXILIARY CYLINDERS (for the rapid advance and
return of the main ram) Two forged-steel side
cylinders are provided for rapid advance and
return of the main ram. These cylinders are of
the double-acting type. Cylinders and piston
rods are made of a forged-steel integral
construction, with a wear-resistant bronze
face. The two stems are fixed, and they work on
the moving crosshead. In order to obtain the
presss rated capacity, the auxiliary cylinders
and the main cylinder must work at the same time.
16
910 MT Press Extrusion Line
PLATEN The extrusion platen is made of a
quality, high-grade steel. The platen bore is
wide enough to provide access to the extrusions
coming out of the die, and to ease the discharge
of partially extruded billets. The platen is
mounted on the baseframe in such a way that it is
longitudinally adjustable in order to assure
its correct positioning under pressure. A
high-strength pressure plate exists on the
internal face of the platen. This plate reacts
against the die tooling set, and the horizontal
shear load.
17
910 MT Press Extrusion Line
MAIN COLUMNS AND NUTS The main columns are made
of forged steel. They are designed to assure a
very high stiffness between the main cylinder and
the platen. Special split-nuts allow for the
pre-stressing of the columns position, and makes
possible the permanent locking of tie rods and
nuts during the final assembly of the
press. Thread design is of special type, and
the entire design is carefully worked out to
minimize stress concentrations and fatigue
conditions.
18
910 MT Press Extrusion Line
BASEFRAME AND GUIDES The heavy-duty baseframe
is a rigid, uni-body steel structure. It was
stress relieved before machining. All the guides
for the press members are carefully and
accurately finished to close dimensional
tolerances. The guides are of a reverse V
type and are provided with hard, renewable, and
adjustable wear plates.
19
910 MT Press Extrusion Line
MOVING CROSSHEAD The moving crosshead is
designed in such a way to assure a lasting
alignment of the extrusion stem with the press
centerline. The press columns support and
guide the crosshead using bronze plates. The
crosshead is stiffly fixed to the main ram, and
to the auxiliary cylinders.
20
910 MT Press Extrusion Line
EXTRUSION STEM The extrusion stem is centered
(and stiffly fixed) on the moving crosshead using
bolts. The heavy heat-treated alloy-steel
bolster is inserted between the bottom extrusion
stem and the moving crosshead.
21
910 MT Press Extrusion Line
DIE SLIDE The die slide is a transverse-type,
and is shifted by means of an oil-hydraulic
cylinder. It consists of two detachable
die-carriers. The first one is used as die
holder. The second one is provided with a
clearance hole for billet-sticker removal. This
hole contains a tempered-steel ring. A
tooling set (with the die included) is located in
the die-slide housing. The included pressure
rings are designed to take up, and transmit, the
extrusion force to the extrusion plate. The die
slide does not experience the extrusion force.
The die-slide shifts on a sturdy guide. It
bears on bronze wear-surfaces, which can be
easily replaced. The guide assures an effective
support, so as to prevent misalignment of the
tooling set, which is subjected to the cutting
loads of the main shear, and to the opening and
closing of the container.
22
910 MT Press Extrusion Line
DIE SLIDE The main shifting slide oil-hydraulic
cylinder is used to drive the auxiliary shear
for cutting the extrusion behind the die. The
tooling set is bearing against a sturdy
forged-steel bolster, which is fixed in the
reaction plate hole. The die assembly can be
aligned and centered in the press by adjusting of
the die slide. This can be realized vertically
by utilizing a wedge, and horizontally by means
of an adjustable positioning stop, which limits
the die shift stroke. The die slide consists of
a rugged unit, which is well guided and easy to
adjust. It is therefore possible to compensate
readily for both wear and temperature
differences, and perfectly centerline the die.
Positioning is simple, and deflections are
minimized, which results in optimum conditions
for long tool life, and for high quality of the
extrusion.
23
910 MT Press Extrusion Line
DIE CHANGING DEVICE The die-changing device is
composed of two housing shuttles situated on the
side of the press and driven by an oil-hydraulic
cylinder. Such a device allows for die changing
only from one side of the press. When such
changing is requested, the die slide shifts
laterally in such a way as to position the die
set over the empty shuttle housing. The used
die set detaches from the die slide by means of
the shifting shuttle, while the new one (which
is in the other housing) is prepared. During
the die-change operation, the die slide shifts
laterally until the die is positioned at the
center of the press. Two jig locaters are used
in order to assure the centering of the die at
the press centerline.
24
910 MT Press Extrusion Line
CONTAINER The container is centered in its
housing on the three keys located on the
vertical and horizontal centerlines of the
press. Uniform expansion under the influence of
heat is thus assured. The container is thus
automatically aligned by proper adjusting of the
housing. The container is held within the
housing by means of a split-hinged ring. The
ring is equipped with pull handles for fast
unlocking and relocking of the container, thus
permitting its rapid removal from its housing by
the main moving crosshead.
25
910 MT Press Extrusion Line
CONTAINER HOLDER The container holder is made
of a steel casting. Its design is such that it
will be as symmetrical as possible in order to
permit uniform radial expansion under the
influence of heat. The container holder is
supported and guided by two lateral prismatic
guides, which are part of the baseframe, and
lined with replaceable steel wear plates. In the
extrusion position, the container is sealed
firmly and squarely against the tool stack to
prevent flashing of material.
26
910 MT Press Extrusion Line
CONTAINER SHIFTING CYLINDERS The container is
operated by means of two shifting cylinders,
located symmetrically about the machine center.
The construction of these cylinders is similar
to that one of rapid advance and return
cylinders. The traveling stroke is controlled at
low pressure by means of a special interlock
circuit this prevents, in the event of any
obstruction of container path, the developing of
forces which could cause cocking or tilting of
the container or even bending the cylinder
rods. While the container is closed against the
die slide, a small volume and high pressure pump
assures a tight and effective sealing at the die
end.
27
910 MT Press Extrusion Line
VERTICAL BUTT SHEAR A heavy oil-hydraulically
operated shear is located above the press and is
mounted on the platen by means of a rigid
structure. Its function is to separate the butt
end from the extrusion. The shear cylinder is a
double-acting type. The sliding carrier of
the shear operates in a heavy housing and is
accurately guided in bronze wear liners, assuring
straight line, non-deflecting operation when
shearing.
28
910 MT Press Extrusion Line
HORIZONTAL AUXILIARY SHEAR The die slide
shifting cylinder has sufficient capacity to
function as a shearing device for cutting
extrusions behind the die, by transverse
movement of the die slide. The platen insert,
which acts as a shearing face, is adequately
hardened to withstand the shearing action.
29
910 MT Press Extrusion Line
BILLET LOADER The billet is charged into the
centerline of the machine by means of a loader
(of the pivoted swinging type) and pushed into
the container by the advancing pressing-stem.
The billet loader is composed of two
oil-hydraulically operated arms. Because they
are moving out of the way separately, one after
the other, as pressing-stem pushes a billet into
the container, the result is better flexibility.
The loader cradle can be easily adjusted when
changing billet diameters. Ample loading space
is provided between stem and the container, thus
assuring safe and rapid loading.
30
910 MT Press Extrusion Line
BUTT-END HANDLING SYSTEM The butt-end handling
system consists of a chute for directing the
butt- end to the outside of the press, onto a
suitable conveyor. The conveyor throws the
butt-end into a scrap box (of your supply) to be
located on the floor level.
31
910 MT Press Extrusion Line
CONTAINER HEATING SYSTEM The container holder
is designed to permit the symmetrical arrangement
of tubular resistance heaters within the annular
space between the container and the container
holder. The system includes a control board for
automatic temperature control.
32
910 MT Press Extrusion Line
LIMIT SWITCHES Interlocks and press movement
starts and stops are, in most cases, controlled
by limit-switches, though in some cases timer and
pressure switches may be utilized. Where
necessary, adjustable cams are furnished so that
the switches can be actuated. Example to preset
a desired value of butt length, etc..
33
910 MT Press Extrusion Line
MAIN PRESS CONTROL BOARD A press control board
is provided with pushbuttons and selectors to
initiate the various automatic and manual
cycles. The control board contains pressure
gauges and potentiometers for speed control, and
temperature gauges and regulators for the
container. It also has start-and-stop push
buttons for the motors, signal lamps etc It
also incorporates an auxiliary control panel
located on the press near the platen egress
hole. Programmable logic control, electronic
operational facilities, and speed control devices
for press movements (particularly for extrusion)
are located in separate metal cabinets.
34
910 MT Press Extrusion Line
OPERATING CYCLES The presss sequence cycle
control system includes methods for presetting
(and immediate regulation of) the extrusion speed
for any cycle. The oil-hydraulic circuit
includes a slip-compensation system to provide
constantly controlled speed for the main,
regardless of the pressure variance during the
extrusion portion of the stroke. Controlling
the speed of upset, and filling of the die, is
accomplished using pressure-switches and timers,
and can be part of any cycle. The press is
supplied with the following automatic operating
cycles -conventional cycle for open and
porthole dies -normal bridge die cycle -burp
cycle
35
910 MT Press Extrusion Line
HYDRAULIC SYSTEM The main hydraulic system
consists of two pumps of variable delivery, which
allows for stepless volume adjustment. The
entire pumping system (including the main pump)
is mounted over the oil tank, which is in turn
mounted over the main cylinder of press. An
auxiliary, low pressure pump is also provided to
power the cylinders actuating the loading,
handling, and transfer devices. A separate
sealing pump maintains constant sealing pressure
between the container and the die face,
throughout the extrusion stroke. Amply sized
heat exchangers are provided to prevent
overheating of the oil by keeping it below 50C.
Oil filters guarantee adequate oil cleaning.
36
910 MT Press Extrusion Line
OIL TANK The oil tank is mounted over the main
cylinder of the press. The oil tank is of
adequate size and is baffled to prevent foaming
at the maximum press speed. Oil level and oil
temperature gauges will be mounted in such a way
as to be visible from the main operating
pulpit. The entire system is easily accessible
via catwalks and stairways.
37
910 MT Press Extrusion Line
HYDRAULIC PIPING Hydraulic piping is accurately
pre-formed pickled and annealed and pickled
before installation to assure a piping system
free from strains. High pressure piping is of
seamless steel and designed with long gradual
radius bends and with welded flange connections
and O ring seals. Wherever needed, rigid
supports for piping are used. A stop valve is
provided for servicing the pre-fill valve. All
cylinders, valves and piping, where required, can
be serviced without draining of the tank.
38
910 MT Press Extrusion Line

• TOOLINGS
• This press includes two complete extrusion
  tooling sets (billet diameter 120 mm and 145 mm)
  for working with fixed dummy block. Each
  diameter includes
• A complete containers with liner.
• A fixed dummies block.
• A pressing stems.

39
910 MT Press Extrusion Line
EXTRUDING DIE One die set to produce a tube of
8 mm diameter and of 1 mm thickness. This die
has been production tested. One die set to
produce a tube of 12 mm diameter and of 1 mm
thickness. This die has not been production
tested.
40
910 MT Press Extrusion Line
41
910 MT Press Extrusion Line
42
910 MT Press Extrusion Line
43
(No Transcript)
44
(No Transcript)
45
910 MT Press Extrusion Line
46
910 MT Press Extrusion LineAfter and before
Press Equipment
EXTRUSION EQUIPMENT
47
910 MT Press Extrusion Line
Billet Loading Table -billet
diameter 115 to 145 mm -billet max.
length 6000 mm -table width 3000
mm -load capacity 16 billets It consists
of a heavy duty, sloping steel table, onto which
billet packs are loaded. The billets roll down
against a stop bar, where a transfer device
loads the billets, one at a time, onto a conveyor
behind the furnace. Billets are then pushed into
the furnace by a hydraulic cylinder.
48
910 MT Press Extrusion Line
Continuous Gas Furnace for Rapid Heating of
Aluminum Billet with Recuperator -billet
diameter 115 to 145 mm -billet max.
length 6000 mm -length of heating
area 3000 mm -length of preheating
area 2000 mm -billet max. length 650
mm -production rate max. 1200 kg/h -working
temperature range 400 to 480C -self-regulated
areas 3 -thermal power installed 275.000
Kcal/h
49
910 MT Press Extrusion Line
Continuous Gas Furnace for Rapid Heating of
Aluminum Billet with Recuperator
-fuel propane/butane gas P.C.I.
11000 Kcal/kg -electric power installed 40
KW -feeding voltage 380 V _at_ 50
Hz 3-phase neutral -compressed
air 6 bar -gas consumption with
working 16,5 kg/tons of material furnace at
max. production of billets at 480C
50
910 MT Press Extrusion Line

• Continuous Gas Furnace for Rapid Heating of
  Aluminum Billet with Recuperator
• The furnace consists of a sturdy framework of
  steel beams and welded plates which contain
  insulating material. The heat insulation has
  been obtained by a series of three thermal
  barriers of high insulating capacity. Burnt gas
  is sucked by a centrifugal fan and forced to pass
  through the billet preheating area.
• A billet conveyor is formed using idle rollers
  and cast iron bearing supports designed to work
  in a high temperature environment.
• Temperature control is performed using three
  thermocouples of type K, which get into the
  furnace intermittently via pneumatic cylinders.
  A vertical sliding door, operated by a pneumatic
  cylinder, shuts the unloading area. The heating
  assembly is formed by a set of main burners
  controlled by pilot burners with electric
  lightening, flame detectors, and electronic
  programming panels for combustion control,
  locking valves, pressure switch, and a
  centrifugal electric fan for burnt gas.
  Temperature control is by thermo-regulators PID
  action and three modulating valves, with alarm
  for minimum and maximum temperature.

51
910 MT Press Extrusion Line
Hot Shear for Billet Cutting -billet
diameter 115 to 145 mm -billet
length 400-650 mm -max. force of shear
cylinder 50 M.T. -max. force for log back 5
M.T. -max. force to eject sheared billet 1,5
M.T. -installed power 30 KW All movements
are automatically actuated and synchronized with
the billet call signal from the press. During
the machine set-up, each operational step may be
accomplished separately from the others via
proper switches and pushbuttons. Billet length
is determined by a motor-reducer which moves the
measuring unit constituted by three photocell
switches. The cutting is performed by the
sliding movement of the movable container head
against the fixed container head. This sliding
movement is accomplished using a hydraulic
cylinder.
52
910 MT Press Extrusion Line
Hot Shear for Billet Cutting (continued)
A set of auxiliary hydraulic cylinders pushes
the log back into the furnace and removes the hot
billet from the cutting area. A shuttle then
transfers the billet onto the press loader. Its
steel frame is of a heavy-duty design, and was
stress relieved before machining. The
containers are made of tempered, forged steel,
and are design for hot working. Different sized
containers can be mounted according to the billet
diameter used. Both containers are divided into
two parts one fixed and the other movable (via
a hydraulic cylinder) in order to have a correct
introduction of the billet, and to assure the
billet is held during the cutting phase. The
movable container slides upon guides made of
bronze. An adjustable, forged steel gib is used
to move the containers. This gib can be used to
provide the exact clearance necessary between the
containers two cutting surfaces. On the shears
fixed part (on the furnace side) a holder and a
cradle have been installed, which permit the
temporary parking of a billet in case of a double
cut.
53
910 MT Press Extrusion Line
Hot Shear for Billet Cutting
(continued) A sensor checks the length of the
remaining billet on the upper part of the cutting
line after each cut. If the length is such that
the next billet will have a crop-end measuring
less than the specified minimum length, the
system will decide to perform a double cut so as
to avoid this. The patented double cut
system guarantees the ability to extrude a whole
billet, without rejects and without crop-ends of
a length smaller than the minimum
specified. With our plant, extrusion rejects
are reduced to a minimum by -eliminating
length standardization problems, -reducing the
need for stocking different diameters and length,
and -eliminating the need to cut with a
circular saw.
54
910 MT Press Extrusion Line
Hot Shear for Billet Cutting (continued)
With our plant, total rejection of the
extrusion process is reduced to a minimum
by -our ability to extrude only the length
desired -our ability to link the hot shear
with the puller via a computer to get an
automatic optimization of the profile and billet
length. -our ability to work with pre-cut
billets, by using a short billet cycle. Hot
shear is supplied with -a hydraulic unit
complete with safety and check valves, filters, a
heat exchanger for oil cooling, and various
fittings, all assembled on a base oil
tank. -the hydraulic unit also includes various
solenoid valves for the control of the
synchronized movements.
55
910 MT Press Extrusion Line
Hot Shear for Billet Cutting
(continued) Hot shear is supplied complete
with -electric control board -control panel
with push-buttons and selectors for manual
operations and warning lights for the
control of automatic cycles.
56
910 MT Press Extrusion Line
Hot Billet Conveyor to the Extrusion Press
It consists of transfer equipment which
transfers the billet to the press loading
arm. The billet conveyor is electrically or
hydraulically actuated and is designed to handle
billets with a double cut.
57
910 MT Press Extrusion Line

• Run-out Table Technical Data
• -run-out table width 400 mm
• -conveyor-stretcher distance 4000 mm between
  axes
• -stretcher-cutting line distance 2100 mm
• -working length (approximate) 50 m
• -stretcher capacity 15 M.T.
• -jaw stretcher width 250 mm
• -jaw max. opening 130 mm
• -feeding voltage 380 V 3-phase neutral
• -compressed air 6 bars
• -total electric power installed approximately
  100 KW
• -total air capacity 18 m3/h (6 bars)

58
910 MT Press Extrusion Line

• Exit Table with Overhead cooling device
• -total length (approximate) 6 m
• -width 300 mm
• -length of top cooling device 3 m
• -total electric power 4.5 KW
• The exit table is a fabricated steel frame
  adjustable up and down by hand.
• It is covered by graphite coated slats onto
  which the extruded profiles run.
• The cooling device (located on top of the
  table) allows for the cooling of aluminum
  profiles at the output of the press with air
  only, or with water, or with both.

59
910 MT Press Extrusion Line

• Puller
• -jaw max. width 300 mm
• -jaw max. opening 130 mm
• -max. working length 60 m
• -min. seizing distance from the
• front plate of the press 2 m
• -pulling force 20 to 150 kg
• -puller working speed 70 m/min.
• -puller backing speed 300 m/min.
• -dead time (approximate) 30 sec.
• -electric power installed 20 KW

60
910 MT Press Extrusion Line

• Puller (continued)
• The puller is composed of the following
  elements
• -A sliding way (on which is also located the
  trolley race for the electric wires). The
  sliding way can be positioned either at the side,
  or at the top, of the roller
• conveyor. The movement of the
  puller-saddle takes place by means of a chain or
  rope moved by a gear-motor unit. The snub pulley
  is provided with a
• tensioning system.
• -A draft saddle provided with slide wheels on
  bearings.
• -A profile-seizing jaw operated (hydraulically
  or pneumatically) with relevant air accumulator.
  The jaw is provided with clamps so as to fit the
  various shapes of the extruded profiles.

61
910 MT Press Extrusion Line
Puller (continued) The puller is
also composed of the following elements -A
motor unit, which is comprised of a base, a
constant torque, direct current motor, coupled
with an encoder for the measurement of the puller
movements. - A reduction gear, and a
pneumatic or electromagnetic safety
brake. -Electric control panel for the
regulation of the direct current motor, power
control panel, push-button panel to set and
visualize puller speed, profile length,
profile positioning status, number of extrusions
per billet (in case of low extrusion ratio) and
number of billets per extrusion (in case of high
extrusion ration), and selectors to choose the
various working modalities.
62
910 MT Press Extrusion Line
Puller (continued) The following
puller working modalities can be selected a)
Stopped by Puller commanded by the press with
subsequent profile cutting, profile run away by
means of the puller, then return for the new
cycle. b) Stopped by Press commanded by the
puller when the selected extrusion length has
been obtained.
63
910 MT Press Extrusion Line
Hot Section Sawing Machine -saw blade
diameter 400 mm -electric power 5 KW -cut
positioning, minimum 2.5 m maximum 4.5
m -The sawing unit rests on a carriage,
positioned on the guide placed on the extrusion
run-out table. -The sawing unit is
transversal. -The blade penetration is
adjustable via a hand-wheel. -The longitudinal
position of the saw is obtained through gear and
rack motorized unit. -The sawing unit is
complete with a profile hold-down device.

64
910 MT Press Extrusion Line
Run-Out Table -length, maximum 50
m -width 400 mm It consists of a set of
fixed sleepers, covered with graphite.
65
910 MT Press Extrusion Line
Transfer Arms -arms span 800
mm -lifting 50 mm The transfer arms speed
is adjustable, and is pneumatically controlled.
The lifting and sliding system is operated by
three sets of cylinders using speed control
devices, and is slowed down at the end of the
stroke using an alignment and compensation
device.
66
910 MT Press Extrusion Line
Walking Beam Cooling Table -working length
(approximate) 50 m -conveyor-stretcher
distance between centers 4 m -distance between
fixed bar 800 m -distance between movable
bar 1200 mm -pitch 60 mm The frame is
made from welded steel tubes and shaped profiles.
The frame is connected to the supporting beams
of the run-out conveyor. The supporting beams
carry the fixed cross bars, the shaft supports,
and the walking bar guides. The shafts are
operated by a central gear-motor (3 phase), with
programmable cycles. The walking bar cams are
secured to the supporting shafts by self-locking
bushings.
67
910 MT Press Extrusion Line
Air Cooling Unit -Number of axial-fans 24
-electric total power 6 KW The 24 fans are
controlled by three group switches. This allows
for flexible cooling based on the shape of the
profile.
68
910 MT Press Extrusion Line
Transfer Arms to the Stretcher -arms
span 800 mm -working speed 150
mm/sec. -tape width 80 mm -motor
power 2 KW -compressed air 6 bar -air
consumption 6 Nm3/h The movable arms consist
of transverse belt conveyors sliding on bearing
guides. Each arm is swinging upward (via a
pneumatic cylinder) to allow for easy unloading
of the profiles from the exit table. The sliding
system is operated by pneumatic cylinders. The
belt conveyors are operated by a gear motor
drive.
69
910 MT Press Extrusion Line
Stretcher -working length
(approximate) 50 m -nominal stretching
capacity 15 tons -positioning speed 170
mm/sec. -stretching stroke 1600 mm -jaw
opening 0 to 130 mm -jaw width 250
mm -installed power on fixed head 15
KW -installed power on movable head 2
KW -total oil tank capacity for hydraulic
units 200 liters It is substantially a welded
construction formed by two steel beams connected
to each other. This structure is provided with
suitable supports fixed to the floor.
70
910 MT Press Extrusion Line
Stretcher (continued) The fixed
head can only be moved for the stretching
stroke. It is made in welded construction and
formed by a body, a stationary jaw, a movable
jaw, and hydraulic unit which serves for all the
movements of the head. These movements are
controlled manually by means of an oil-hydraulic
distributor. The whole head is connected to a
hydraulic cylinder. Controls are mounted on
the panel of this head for -stretching -cooli
ng table -arms for transferring sections onto
the stretching line -stretched profile
table The movable head is similar to the fixed
head, but it has the capacity to move along the
whole beam structure. This movement is obtained
by a gear-motor.
71
910 MT Press Extrusion Line

• Stretched Profile Table and Transfer to Profile
  Cutting Roller line
• -distance between conveyor 800 mm
• -conveyor length (approximate) 1400 mm
• Consisting of belt conveyors hinged on one side
  to the steel base of the stretcher, while on the
  other side, they are supported by cams that are
  connected together to a torque-shaft driven by
  hydraulic cylinders. The hydraulic cams lift the
  belt conveyors, so the profiles are discharged
  onto the cutting roller line.

72
910 MT Press Extrusion Line

• Roller Cutting Line
• -width (approximate) 1000 mm
• -length (approximate) 50 m
• -It consists of a base supporting the rollers
  and the drive system.
• -Motorized rollers alternate with idle rollers.
• -All rollers are made up of highly resistant
  plastic tubes, and are idling on ball bearings.
• -A side-rail prevents profiles from falling
  down, and guarantees their smooth movement to the
  sawing machine.
• -All operations are interlocked with the cutting
  operation.

73
910 MT Press Extrusion Line
Sawing Machine -cutting width
(approximate) 1000 mm -blade diameter 500
mm -electric power 8 KW -adjustable working
speed 0-15 m/min. -A cast-iron table from
which the disc protrudes during the cutting
stroke. -The disc re-enters automatically during
the reversal stroke. -The disc is fully
protected by a liftable profile-holding device,
shaped to be used also as a screen
against noise, and as a suction cap. -The disc
is mounted on independent supports with
hydraulic lifting and is connected to the motor
through a toothed belt.
74
910 MT Press Extrusion Line
Sawing Machine (continued) -The cutting speed
is adjustable. -The feeding is controlled by a
hydraulic cylinder, and a relevant flow-rate
selector. -The sliding guides (made of hardened
steel with anti-wear pads and continuously
lubricated) allow high precision cutting, and
long life. The guides are protected from chips
and dust by a movable screen.
75
910 MT Press Extrusion Line
Cut to Length Table -cutting length
adjustable up to 7000 mm -cutting
width 800 mm -width of removal zone 800
mm The cut-to-length table consists of a steel
support frame for rollers and belts, a table with
motorized rollers for profile evacuation
synchronized with the cutting roller line,
transverse and liftable belt conveyors for
transferring the shapes to the control and
unloading zone, and a movable stop, complete with
a slow down device and shock absorber, all used
so as to determine the cut length. All
movements are fully synchronized with the cutting
operations. The stop movement is
motorized.
76
910 MT Press Extrusion Line
Profile Stacking Unit -maximum length of
the profiles 7000 mm -maximum width of the
layer of profiles to be stacked 800
mm The system is designed to stack in layers
(into proper baskets supplied by customer) the
extruded profiles coming off the cut-to-length
table.
77
910 MT Press Extrusion Line

• Electric Control Panel
• -Equipped with push-buttons, general switches,
  thermal relays for the electric motor, and a PLC
  processor for the logical functions.
• -The panel is located in a cabinet with a
  front-opening door.
• -The movements of the puller, and the transfer
  arms to the walking beam are automatic and
  synchronized with the production flow of the
  extrusion press.
• -The control panel has push-button control and a
  warning light for all functions.
• -This control panel is set up near the the
  control panel of the press. It contains
  programmer and digital displays (for the profile
  length check), controls for the lateral transfer
  of extruded profiles, and a pulling capacity
  indicator.
• -The back-speed puller can be set on the
  electronic control panel of the direct current
  motor.

78
910 MT Press Extrusion Line

• Electric Furnace-Hot Air Circulation for Die
  Heating
• -number of heating chambers 1
• -inner sizes of heating chamber 600 mm width
• 500 mm height
• 1000 mm length
• -air recycling fan power 2,5 KW
• -thermic installed power about 30 KW
• -voltage 380 V 50 Hz
• 3-phase neutral
• -maximum loading weight about 450 kg

79
910 MT Press Extrusion Line

• Electric Furnace-Hot Air Circulation for Die
  Heating (continued)
• -The furnace consists of a sturdy, fabricated
  steel frame, which provides the housing for the
  insulation material. The heat insulation is
  obtained by using various layers of insulating
  bricks.
• -Re-circulating air system is complete with
  electric motor.
• -Shutting door of high stiffness structure and
  insulating material.
• -Door opening is accomplished using a pneumatic
  cylinder.
• -Furnace heating is accomplished using stainless
  steel electric resistors.
• -Control board is equipped with a main switch,
  push buttons, warning lights, thermocouples, and
  safety pyrometers. This panel is located in a
  cabinet with a front-opening door.

80
910 MT Press Extrusion Line

• Ageing Oven for Extruded Profiles
• The charge is formed by stacked baskets, and is
  distributed by means of suitable spacers. Furnace
  is two carriage-type, with two motorized doors.
• Specifications
• -maximum length profiles 7000 mm
• -basket sizes 900 x 400 mm
• -number of baskets 6 or 8
• -working temperature 180/250C
• -propane/butane gas PCI 11000 Kcal/kg
• -maximum thermal capacity 420000 Kcal/h
• -consumption 152 Kwh/1000 kg
• -time 7 10 h
• -loading in the furnace 5000 kg Al 1500 kg
  Fe

81
910 MT Press Extrusion Line
ALUMINUM TUBE PRODUCTION EQUIPMENT
One complete line for the production of aluminum
tubes over recyclable spools
82
910 MT Press Extrusion Line
Spooling Equipment Dimensions -overall length
(approximate) 40 m -overall width
(approximate) 4.5 m -hot tube conveying
system in combination with the hot slat
conveyor of the press first section length
(approximate) 3500 mm second section length
(approximate) 3500 mm third section length
(approximate) 4500 mm -loop control section
length (approximate) 7500 mm -cooling and
drying section length (approximate) 9000 mm

83
910 MT Press Extrusion Line
Spooling Equipment Dimensions (continued)
-spoolers size length (approximate) 1700
mm width (approximate) 2800 mm height
(approximate) 1300 mm Spool
Dimensions -aluminum tube outside diameter
minimum 5 mm maximum 12 mm -inside
diameter of coil 500 mm -outside diameter of
coil (approximate) 1200 mm -width,
maximum 680 mm -net weight of coil
(approximate) 150 kg
84
910 MT Press Extrusion Line

• Spool Specifications
• -weight of empty spool fabricated
• out of aluminum 38 kg
• -total weight of coil and spool,
  approximate 200 kg
• Spooling Capacity
• -coil weight per spool 10 billets
• -size 120 diameter x 500 mm
• -billet cycle time, approximate 130 sec
• -total spooling time, approximate 1300 sec

85
910 MT Press Extrusion Line
Spooling Equipment Utility
Data -electrical supply 380 V 50
Hz -compressed air pressure at least 6
bar -tube cooling water (approximate) 6
m³/hour -installed power (approximate) 10 KVA
each spooler
86
910 MT Press Extrusion Line
Spooling Equipment Technical Description The
spooler is made as follows -One self-contained
basement to allow for a balanced lifting of the
machine, -The upper frame part which will
contain the fixed mechanisms and the sliding
parts -The sliding part is mounted on rails and
is pivoting, two combined cylinders lift the
frame to allow the spool to be loaded. -The
fixed frame contains the gear motor, moving
mechanism, and the rotating shaft allowing also
for pressurization of the tube being
spooled. -The mobile part supports the idle
container shaft with independent regulation, the
same keeps the spool into the correct position
during take up.
87
910 MT Press Extrusion Line
Spooling Equipment Technical Description
(continued) -The two combined cylinders lift
the spool (to be clamped between the rotating
shafts) releasing the full spool onto a frame
mounted on wheels. This action facilitates the
unloading of the spooled coil. -On the spool
supporting frame, two proximity switches are
mounted that control the reversing of the
spooling direction. -The tube pre-straightener
(with 7 idle and independent rolls) is mounted on
an endless screw, which is rigidly connected
to the main frame of the spooler. -The three
roll section is fixed, the four roll section is
movable. This facilitate the tube
introduction.
88
910 MT Press Extrusion Line

• Spooling Equipment Technical Description
  (continued)
• -The pre-straightener connected to the spooler
  mechanism can control
• a) the cycle starting position
• b) the incremental speed of every subsequent
  layout of coils
• -The take up speed will be regulated and
  displayed from 0 to 250 m/min
• -The spool will stop at full load within 180
  rotation.

89
910 MT Press Extrusion Line
CONSUMPTION OF UTILITIES (approximate)
Press After and Before
Press

Equipment -Electric power
450 KVA 380
KVA -Propane/butane gas -
100 Kg/h
-Compressed air -
75 m³/h -Water
12 m³/h 23 m³/h
-Electric power required 380 V 3 phase
50 Hz -Propane/butane gas specs. AB 11.000
Kcal/kg net caloric value -Compressed air
required 6 bar -Water pressure/
temperature 2.5 bar temperature
20-30C
90
910 MT Press Extrusion Line

• TECHNICAL DOCUMENTATION AVAILABLE
• Lay-out
• 910 MT Press
• Before and After Press

91
910 MT Press Extrusion Line

• EQUIPMENT AVAILABLE FOR SALE IN THIS
  TECHNICAL SPECIFICATION
• One 910 M.T. horizontal extrusion press,
  manufactured by a famous Italian Aluminum
  Extrusion Press Manufacturer. Built in 1990.
• Extrusion equipment, upstream and downstream of
  the press, for the production both of traditional
  profiles and small diameter tube (8 mm in
  diameter and thickness 1 mm). Manufactured by
  Sottri (Italy). Built in 1990.
• One die for tube 8 mm in diameter, 1 mm thick.
• Oil-hydraulic (REXROTH) and electric (SIEMENS)
  equipment for the entire line.
• One set of spare parts for the entire plant for a
  two-year production period (250 working days per
  year and 20 working hours per day).
• Piping and electrical wiring for machine board
  and up to the electrical panel.
• Two complete spoolers for alternatively taking up
  the aluminum tube onto self-contained spools,
  pre-straightener and control units, control and
  operating electrical cabinets.

92
910 MT Press Extrusion Line

• EXCLUSIONS
• External electric connections from the cabinets
  to the supply mains
• Connecting piping to the feeding points
• Oil and grease for first-filling
• Bottle and piping for feeding billet lubricating
  system
• Tooling (except for what is specified)
• Foundation and masonry works
• Concrete foundation drawings
• Covers around the press and facilities
• Erection staff and rigging equipment
• Gas, air, water and electric power utilities
• The fume exhaust ducts
• Spools and the ageing racks in sufficient
  quantity
• In general, anything else not clearly described
  in our technical specifications.

93
910 MT Press Extrusion Line
SERVICES WE CAN PROVIDE Financing

Transportation

Installation

Start-up Of Complete 910 MT
Press Extrusion Line Equipment
94
910 MT Press Extrusion Line

• GENERAL INFORMATION
• All extrusion line equipment is stored inside our
  warehouse in Italy.
• The address is
•
  SerVaas Factories Intl

•
  Via Fratelli Cervo No. 6

•
  20017 Mazzo di Rho ( Milan )

•
  Italy
• Phone [phone]
• Fax [phone]
• Cell 39-340-852-1974

• All crates are stored at our warehouse. Some
  crates are open and ready
• for inspection.

95
(No Transcript)
96
More information's Please Contact As
SerVaas Factories International 1000 Waterway
Boulevard Indianapolis, Indiana 46202 USA Dr.
George Pendygraft Chief Operating Officer Tel
001 - 317 - 633 - 2022 Fax 001 - 317 - 633 -
8805 Cell 001 - 317 - 590 - 3398 E-mail
gwp_at_SerVaasFactories.com Web Site
www.SerVaasFactories.com
