Influenza Hemagglutinin

1
Influenza Hemagglutinin

• Jodi Ann Hadden
• BCMB 8010
• University of Georgia

2
Introduction

• Type I integral membrane glycoprotein
• Imbedded in surface of Influenza A virus
• Two roles
• Viral attachment
• Membrane fusion

Figure created from PDB ID 1RVT 11 using VMD
53.
3
Structure

• Homotrimer
• Monomers
• HA0 ? HA1 HA2
• HA1
• Globular head domain
• Jelly rolls of 8 antiparallel b-strands (116
  261)
• HA2
• Transmembrane domain
• 3 fold to form central a-helical coiled coil

Figure created from PDB ID 1RUZ 11 using VMD
53.
4
Binding Site

• Sides
• 190 helix (190 198)
• 130 loop (135 138)
• 220 loop (221 228)
• Base
• Y 98
• W 158
• H 183
• Y 195

Figures created from PDB ID 1RUZ 11 using VMD
53.
5
Binding Site
Figures created from PDB ID 1RUY 11 using VMD
53.
6
Binding Site

• Sides
• 190 helix (190 198)
• 130 loop (135 138)
• 220 loop (221 228)
• Base
• Y 98
• W 158
• H 183
• Y 195

Figures created from PDB ID 1RVT 11 using VMD
53.
7
Binding Site

• Sides
• 190 helix (190 198)
• 130 loop (135 138)
• 220 loop (221 228)
• Base
• Y 98
• W 158
• H 183
• Y 195

Figures created from PDB ID 1RVT 11 using VMD
53.
8
Spring-Loaded Mechanism

• Globular heads dissociate
• Destabilized by low pH
• Loop ? helix (55-75)
• Propels fusion peptide to membrane insertion
• HA tilts on its side
• Juxtaposes membranes and fusion pore forms
• Helix ? loop (105-112)
• Enlarges fusion pore

Figure created from PDB ID 1RUZ 11 using VMD
53.
9
References (1-8)

• Barbey-Martin, C., et al., An Antibody That
  Prevents the Hemagglutinin Low pH Fusogenic
  Transition. Virology, 2002. 294(1) p. 70-74.
• Carr, C.M., C. Chaudhry, and P.S. Kim, Influenza
  hemagglutinin is spring-loaded by a metastable
  native conformation. Proceedings of the National
  Academy of Sciences of the United States of
  America, 1997. 94(26) p. 14306-14313.
• Carr, C.M. and P.S. Kim, A spring-loaded
  mechanism for the conformational change of
  influenza hemagglutinin. Cell (Cambridge, MA,
  United States), 1993. 73(4) p. 823-32.
• Cherfils, J., et al., Rigid-body docking with
  mutant constraints of influenza hemagglutinin
  with antibody HC19. Proteins Structure,
  Function, and Genetics, 1994. 18(1) p. 8-18.
• Chernomordik, L.V. and M.M. Kozlov, Membrane
  hemifusion Crossing a chasm in two leaps. Cell
  (Cambridge, MA, United States), 2005. 123(3) p.
  375-382.
• de Ona, M., et al., Isolation of influenza virus
  in human lung embryonated fibroblast cells
  (MRC-5) from clinical samples. Journal of
  clinical microbiology, 1995. 33(7) p. 1948-9.
• Doms, R.W., A. Helenius, and J. White, Membrane
  fusion activity of the influenza virus
  hemagglutinin. The low pH-induced conformational
  change. Journal of Biological Chemistry, 1985.
  260(5) p. 2973-81.
• Eckert, D.M. and P.S. Kim, Mechanisms of viral
  membrane fusion and its inhibition. Annual Review
  of Biochemistry, 2001. 70 p. 777-810.

10
References (9-16)

• Fields, B.N., et al., Fields Virology Volume 2.
  1995. 1445 pp.
• Fouchier, R.A.M., et al., Characterization of a
  novel influenza A virus hemagglutinin subtype
  (H16) obtained from black-headed gulls. Journal
  of Virology, 2005. 79(5) p. 2814-2822.
• Gamblin, S.J., et al., The structure and receptor
  binding properties of the 1918 influenza
  hemagglutinin. Science (Washington, DC, United
  States), 2004. 303(5665) p. 1838-1842.
• Glaser, L., et al., A single amino acid
  substitution in 1918 influenza virus
  hemagglutinin changes receptor binding
  specificity. Journal of Virology, 2005. 79(17)
  p. 11533-11536.
• Gray, C. and L.K. Tamm, Structural studies on
  membrane-embedded influenza hemagglutinin and its
  fragments. Protein Science, 1997. 6(9) p.
  1993-2006.
• Harter, C., et al., Hydrophobic binding of the
  ectodomain of influenza hemagglutinin to
  membranes occurs through the "fusion peptide".
  Journal of Biological Chemistry, 1989. 264(11)
  p. 6459-64.
• Huang, Q., et al., Protonation and stability of
  the globular domain of influenza virus
  hemagglutinin. Biophysical Journal, 2002. 82(2)
  p. 1050-1058.
• Huang, R.T., R. Rott, and H.D. Klenk, Influenza
  viruses cause hemolysis and fusion of cells.
  Virology, 1981. 110(1) p. 243-7.

11
References (17-24)

• Isin, B., P. Doruker, and I. Bahar, Functional
  motions of influenza virus hemagglutinin a
  structure-based analytical approach. Biophysical
  Journal, 2002. 82(2) p. 569-581.
• Kielian, M. and F.A. Rey, Virus membrane-fusion
  proteins more than one way to make a hairpin.
  Nature Reviews Microbiology, 2006. 4(1) p.
  67-76.
• Killian, M.L., Hemagglutination assay for the
  avian influenza virus. Methods in Molecular
  Biology (Totowa, NJ, United States), 2008.
  436(Avian Influenza Virus) p. 47-52.
• Klenk, H.D., et al., Activation of influenza A
  viruses by trypsin treatment. Virology, 1975.
  68(2) p. 426-39.
• Lazarowitz, S.G. and P.W. Choppin, Enhancement of
  the infectivity of influenza A and B viruses by
  proteolytic cleavage of the hemagglutinin
  polypeptide. Virology, 1975. 68(2) p. 440-54.
• Lemon Stanley, M. and A.F. Mahmoud Adel, The
  threat of pandemic influenza are we ready?
  Biosecurity and bioterrorism biodefense
  strategy, practice, and science, 2005. 3(1) p.
  70-3.
• Madhusoodanan, M. and T. Lazaridis, Investigation
  of pathways for the low-pH conformational
  transition in influenza hemagglutinin.
  Biophysical Journal, 2003. 84(3) p. 1926-1939.
• Maeno, K., et al., Isolation of hemagglutinin and
  neuraminidase subunits of hemagglutinating virus
  of Japan. Journal of Virology, 1970. 6(4) p.
  492-9.

12
References (25-32)

• Marinina, V.P., et al., The effect of losing
  glycosylation sites near the receptor-binding
  region on the receptor phenotype of the human
  influenza virus H1N1. Molecular Biology (Moscow,
  Russian Federation, English Edition) (Translation
  of Molekulyarnaya Biologiya), 2003. 37(3) p.
  468-472.
• Markovic, I., et al., Synchronized activation and
  refolding of influenza hemagglutinin in
  multimeric fusion machines. Journal of Cell
  Biology, 2001. 155(5) p. 833-843.
• Mir-Shekari, S.Y., et al., The glycosylation of
  the influenza A virus hemagglutinin by mammalian
  cells. A site-specific study. Journal of
  Biological Chemistry, 1997. 272(7) p. 4027-4036.
• Neumann, G., et al., Generation of influenza A
  viruses entirely from cloned cDNAs. Proceedings
  of the National Academy of Sciences of the United
  States of America, 1999. 96(16) p. 9345-9350.
• Ohuchi, M., et al., Regulation of receptor
  binding affinity of influenza virus hemagglutinin
  by its carbohydrate moiety. Journal of Virology,
  1997. 71(11) p. 8377-8384.
• Overman, J.R., Friedewald, W.F., Cold
  Hemagglutination Reactions with Influenza Virus.
  The Journal of Immunology, 1949. 62 p. 415-424.
• Oxford, J.S., Influenza A pandemics of the 20th
  century with special reference to 1918 virology,
  pathology and epidemiology. Reviews in medical
  virology, 2000. 10(2) p. 119-33.
• Pedroso de Lima, M.C., et al., Target cell
  membrane sialic acid modulates both binding and
  fusion activity of influenza virus. Biochimica et
  Biophysica Acta, Biomembranes, 1995. 1236(2) p.
  323-30.

13
References (33-40)

• Ramalho-Santos, J. and M.C. Pedroso de Lima, The
  influenza virus hemagglutinin a model protein in
  the study of membrane fusion. Biochimica et
  Biophysica Acta, Reviews on Biomembranes, 1998.
  1376(1) p. 147-154.
• Reid, A.H., et al., Origin and evolution of the
  1918 "Spanish" influenza virus hemagglutinin
  gene. Proceedings of the National Academy of
  Sciences of the United States of America, 1999.
  96(4) p. 1651-1656.
• Roberts, A., et al., Vaccination with a
  recombinant vesicular stomatitis virus expressing
  an influenza virus hemagglutinin provides
  complete protection from influenza virus
  challenge. Journal of Virology, 1998. 72(6) p.
  4704-4711.
• Skehel, J.J., et al., Changes in the conformation
  of influenza virus hemagglutinin at the pH
  optimum of virus-mediated membrane fusion.
  Proceedings of the National Academy of Sciences
  of the United States of America, 1982. 79(4) p.
  968-72.
• Skehel, J.J. and D.C. Wiley, Receptor binding and
  membrane fusion in virus entry the influenza
  hemagglutinin. Annual Review of Biochemistry,
  2000. 69 p. 531-569.
• Smith, W., C. H. Andrews, and P.P. Laidlaw, A
  virus obtained from influenza patients. Lancet,
  1933. ii66.
• Stegmann, T., I. Bartoldus, and J. Zumbrunn,
  Influenza Hemagglutinin-Mediated Membrane Fusion
  Influence of Receptor Binding on the Lag Phase
  Preceding Fusion. Biochemistry, 1995. 34(6) p.
  1825-32.
• Stegmann, T., F.P. Booy, and J. Wilschut, Effects
  of low pH on influenza virus. Activation and
  inactivation of the membrane fusion capacity of
  the hemagglutinin. Journal of Biological
  Chemistry, 1987. 262(36) p. 17744-9.

14
References (41-48)

• Stegmann, T., J.M. White, and A. Helenius,
  Intermediates in influenza induced membrane
  fusion. EMBO Journal, 1990. 9(13) p. 4231-41.
• Stevens, J., et al., Glycan Microarray Analysis
  of the Hemagglutinins from Modern and Pandemic
  Influenza Viruses Reveals Different Receptor
  Specificities. Journal of Molecular Biology,
  2006. 355(5) p. 1143-1155.
• Stevens, J., et al., Structure and receptor
  specificity of the hemagglutinin from an H5N1
  influenza virus. Science (Washington, DC, United
  States), 2006. 312(5772) p. 404-410.
• Tumpey, T.M., et al., A two-amino acid change in
  the hemagglutinin of the 1918 influenza virus
  abolishes transmission. Science (Washington, DC,
  United States), 2007. 315(5812) p. 655-659.
• Weber, T., et al., Evidence for H()-induced
  insertion of influenza hemagglutinin HA2
  N-terminal segment into viral membrane. The
  Journal of biological chemistry, 1994. 269(28)
  p. 18353-8.
• Webster, R.G., et al., Evolution and ecology of
  influenza A viruses. Microbiological reviews,
  1992. 56(1) p. 152-79.
• Wharton, S.A., et al., Electron microscopy of
  antibody complexes of influenza virus
  hemagglutinin in the fusion pH conformation. EMBO
  Journal, 1995. 14(2) p. 240-6.
• White, J., A. Helenius, and M.J. Gething,
  Hemagglutinin of influenza virus expressed from a
  cloned gene promotes membrane fusion. Nature
  (London, United Kingdom), 1982. 300(5893) p.
  658-9.

15
References (49-53)

• White, J., J. Kartenbeck, and A. Helenius,
  Membrane fusion activity of influenza virus. EMBO
  Journal, 1982. 1(2) p. 217-22.
• Wilkinson, B.E., Recombinant Hemagglutinin
  Subunit Vaccine Produced in a Baculovirus
  Expression Vector System. Avian Diseases, 2003.
  47(Special Issue, Fourth International Symposium
  on Avian Influenza) p. 253-262.
• Wilson, I.A., J.J. Skehel, and D.C. Wiley,
  Structure of the hemagglutinin membrane
  glycoprotein of influenza virus at 3 .ANG.
  resolution. Nature (London, United Kingdom),
  1981. 289(5796) p. 366-73.
• Yamada, S., et al., Haemagglutinin mutations
  responsible for the binding of H5N1 influenza A
  viruses to human-type receptors. Nature (London,
  United Kingdom), 2006. 444(7117) p. 378-382.
• Humphrey, W., Dalke, A., and Schulten, K., VMD
  Visual Molecular Dynamics, J. Molec. Graphics,
  1996, vol. 14, pp. 33-58.
• Full paper and references at http//jodih.myweb.ug
  a.edu/bcmb8010/InfluenzaHemagglutinin.pdf
