Kinect H4x

1
Kinect H4x

• Gesture Recognition and Playback Tools
  (Inspiration)

2
SDK Version 1.0 - Out TODAYWhat's New?

• Ability to control which user(s) are under full
  skeletal tracking.
• "Near mode" enables interaction as close as 40cm
  from the device. Includes "too far" and "too
  close"
• depth indicators
• Better everything
• Mother of All Kinect Demos - Kinect Explorer
  sample app shows off all features (camera tilt,
  audio beam angles, etc).

3
Gesture Recognition Dynamic Time Warping

• A sequence matching algorithm that can adapt to
  sequences that vary in speed and time. (think
  Levenshtein distances, but generalized to
  matching any sort of input to stored data)
• It measures the similarity between two sequences
  based on a cost function of how much it needs to
  "warp" the points forward/backward in time to
  have them line up.
• In Kinect-land, this means an algorithm that can
  take streaming joint data and quickly find the
  closest match to a gesture 'on record'.

4
There's an App for that -- DEMO
5
But how does it work?And how can I work into my
own project?

• Three classes
• Skeleton2DDataExtract.cs -- Takes in Kinect SDK
  joint data, spits out normalized 2d skeleton
  points.
• Skeleton2DdataCoordEventArgs.cs -- Defines the
  event args that get emitted from the
  Skeleton2DDataExtract event handler once
  processed.
• DtwGestureRecognizer.cs - Parse the 2d skeleton
  data and call Recognize() to match against loaded
  gestures (see code for loading/saving example).

6
Recognizing A Gesture -- Code
7
Really Advanced Hacks
The DtwGestureRecognizer can flexibly match any
vectorized data stream. We happened to use
skeleton data in our example, but it should be
fairly simple to incorporate a depth stream or
color stream. Just ensure that each of the
sequence objects you pass into AddOrUpdate and
Recognize is an array of doubles (e.g. double
observationPoint).
8
Working on P4 CollaborativelyRecording and
Replaying Skeleton Data

• In light of the fact that many teams share a
  single Kinect, it might be of use to you to be
  able to record a sequence of skeleton data, write
  it to a file, and replay it back through a dummy
  nui.SkeletonFrameReady handler.
• Fortunately, the Kinect Toolbox (not to be
  confused with the Coding4Fun Kinect Toolkit),
  allows us to do just that.
• Get it at http//kinecttoolbox.codeplex.com/

9
Demo -- Sample Code Walkthrough -- Saving and
Playing Back Gestures
10
Candescent NUI (Demo)

• The Cool News Hand Finger Tracking!
• The Bad News Behemoth, undocumented code library
• Project available at http//candescentnui.codeplex
  .com
• Kinect SDK only provides depth values from 800mm
  out. The finger tracking code only works in the
  range of .8 - 1m, so using this project in
  conjunction with the Kinect SDK will prove
  difficult.
• UPDATE NEW SDK 1.0 provides depth values from
  400mm out!
• Compatible With Candescent Alternative OpenNI
  NITE uses the raw point cloud to make best-guess
  tracking estimates lt 800mm away. Good community,
  documentation at OpenNI.org / OpenKinect.org

11
Anant - Shape Game Walkthrough
12
Inspirational Project

• Deixis Application To Children's Education Games
• Main Idea Ask children to point and verbally
  identify ("this one!") a subset of objects
  (numbers, colors, animals).
• Description Video
• http//www.cs.utoronto.ca/uzmakhan/HCIProject.htm
  l

13
Inspirational Hacks

• Gesture Enabled Garden Hose
• Main Idea Use servos (simple motors) in
  conjunction with netduinos (network-enabled
  microcontrollers) to control the servo via Kinect
  gestures
• http//channel9.msdn.com/coding4fun/kinect/Kinect-
  to-Netduino-Cross-post
• In Practice http//channel9.msdn.com/coding4fun/k
  inect/A-Kinect--Netduino-controlled-squirt-gun
• http//www.youtube.com/watch?vFWINsKcP8oQ

14
Inspirational Hacks Pt. 2

• Gesture Based Electronic Music Performance
• http//vimeo.com/channels/pulseproject30301433

15
Inspirational Hacks Pt. 3

• EDEN Interactive Ecosystem Simulation Software
• http//vimeo.com/31940579
• Main Idea Create a topographical landscape on
  the iPad, fill it with (simulated) water, project
  it onto a sandscape via depth data with an
  overhead Kinect projector. Play with the sand
  to change the climate and topography to terraform
  your own sandscape.

16
More

• Kinect Telepresence - http//www.youtube.com/watch
  ?vecMOX8_GeRY
• Home Security Camera - http//www.youtube.com/watc
  h?vUfGOR1Eg_qQ
• Living Paintings - http//www.youtube.com/watch?v
  UjDaHMKwQl4
• Visually Impaired Navigation Tool- http//www.yout
  ube.com/watch?vl6QY-eb6NoQ
• ZigFu Single bundle install NITE, OpenNI,
  PrimeSense Sensor, everything you need to work
  outside of the official SDK http//zigfu.com/devt
  ools.html
