Medical Statistics: Hypothesis Testing

1
Medical Statistics Hypothesis Testing
Nimrod Lavi, MD Adhir Shroff, MD, MPH
2
Agenda

• Types of variables
• Descriptive statistics
• What is a hypothesis
• Definition of a p-value
• Sample vs. universe
• Comparative statistics
• T-tests
• Chi-square

3
Agenda

• Types of variables
• Descriptive statistics
• What is a hypothesis
• Definition of a p-value
• Sample vs. universe
• Comparative statistics
• T-tests
• Chi-square

4
Continuous variable

• One in which research participants differ in
  degree or amount.
• susceptible to infinite gradations (p. 176,
  Pedhazur Schmelkin, 1991)
• Examples height, weight, age

5
Categorical variable

• Participants belong to, or are assigned to,
  mutual exclusive groups
• Nominal
• Used to group subjects
• Numbers are arbitrary
• Examples sex, race, dead/alive, marital status
• Ordinal (rank)
• Given a numerical value in accordance to their
  rank on the variable
• Numerical values assigned to participants tells
  nothing of the distance between them
• Examples class rank, finishers in a race

6
Independent vs Dependent Variable

• Independent
• predictor variable
• Usually on the x axis
• Dependent
• outcome variable
• Usually on the y axis

• The independent variable (a treatment) leads to
  the dependent variable (outcome)
• Ultimately, we are interested in differences
  between dependent variables

Dependent
Independent
7
Agenda

• Types of variables
• Descriptive statistics
• What is a hypothesis
• Definition of a p-value
• Sample vs. universe
• Comparative statistics
• T-tests
• Chi-square

8
Descriptive Statistics

• These are measures or variables that summarize a
  data set
• 2 main questions
• Index of central tendency (ie. mean)
• Index of dispersion (ie. std deviation)

9
Descriptive Statistics

• Data set for ICD complications in 2005
• 14 patients
• Sex F, F, M, M, F, F, F, M, F, M, M, F, F, F
• Make G, S, G, G, G, M, S,S, G,G, M, S

• Central tendency is summarized by proportion or
  frequency
• Sex
• M 5/14 .36 or 36
• F 9/14 .64 or 64
• Make
• G 6/12 .5 or 50
• S 4/12 .33 or 33
• M 2/12 .17 or 17
• Dispersion not really used in categorical data

• Categorical data

10
Descriptive Statistics

• Data set SBP among a group of CHF pts in VA
  clinic
• 13 patients
• 100, 95, 98, 172, 74, 103, 97, 106, 100, 110,
  118, 91, 108

• Central Tendency
• Mean
• mathematical average of all the values
• S (xixiixn)/n
• Median
• value that occupies middle rank, when values are
  ordered from least to greatest
• Mode
• Most commonly observed value(s)

• Continuous variable

11
Descriptive Statistics

• Data set SBP among a group of CHF pts in VA
  clinic
• 13 patients
• 100, 95, 98, 172, 74, 103, 97, 106, 100, 110,
  118, 91, 108

• Central Tendency
• Mean
• mathematical average of all the values
• S (xixiixn)/n
• (100959817274103 97106100110118
  91108)/13 105.5

• Continuous variable

12
Descriptive Statistics

• Data set SBP among a group of CHF pts in VA
  clinic
• 13 patients
• 100, 95, 98, 172, 74, 103, 97, 106, 100, 110,
  118, 91, 108

• Central Tendency
• Median
• value that occupies middle rank, when values are
  ordered from least to greatest
• 74, 91, 95, 97, 98, 100, 100,
• 103, 106, 108, 110, 118,
• 172
• Useful if data is skewed or there are outliers

• Continuous variable

13
Descriptive Statistics

• Data set SBP among a group of CHF pts in VA
  clinic
• 100, 95, 98, 172, 74, 103, 97, 106, 100, 110,
  118, 91, 108

• Index of dispersion
• Standard deviation
• measure of spread around the mean
• Calculated by measuring the distance of each
  value from the mean, squaring these results (to
  account for negative values), add them up and
  take the sq root

• Continuous variable

14
Descriptive Statistics Normal
15
Descriptive Statistics Confidence Intervals

• Range of values which we can be confident
  includes the true value
• Defines the inner zone about the central index
  (mean, proportion or ration)
• Describes variability in the sample from the mean
  or center
• Will find CI used in describing the difference
  between means or proportions when doing
  comparisons between groups

Altman DG. Practical Statistics for Medical
Research 1999
16
Descriptive Statistics Confidence Intervals

• For example, a 95 CI indicates that we are 95
  confident that the population mean will fall
  within the range described
• Can be used similar to a p-value to determine
  significant differences
• CI is similar to a measure of spread, like SD
• As sample size increase or variability in the
  measurement decrease, the CI will become more
  narrow

17
Descriptive Statistics Confidence Intervals
L a n c e t 1999 3 5 4 7 0 8 1 5

• Prospective, randomized, multicenter trial of
  different management strategies for ACS
• 2500 pts enrolled in Europe with 6 month
  follow-up
• Primary endpoints Composite endpoint of death
  and myocardial infarction after 6 months

18
Descriptive Statistics Confidence Intervals
L a n c e t 1999 3 5 4 7 0 8 1 5
19
Descriptive Statistics Confidence Intervals
L a n c e t 1999 3 5 4 7 0 8 1 5
Risk ratio Riskinvasive / Risknoninvasive
When CI cross 1 or whatever designates
equivalency, the p-value not be significant.
20
Descriptive Statistics Confidence Intervals
L a n c e t 1999 3 5 4 7 0 8 1 5

• Review
• Calculate
• RRR, ARR, NNT

• RRR (12.1-9.4) / 12.1 22

ARR 12.1 - 9.4 2.7
NNT 100 / ARR 100 / 2.7 37
21
Agenda

• Types of variables
• Descriptive statistics
• What is a hypothesis
• Definition of a p-value
• Sample vs. universe
• Comparative statistics
• T-tests
• Chi-square

22
Hypothesis

• Statement about a population, where a certain
  parameter takes a particular numerical value or
  falls in a certain range of values.
• Examples
• A director of an HMO hypothesizes that LOS p AMI
  is longer than for CHF exacerbation
• An investigator states that a new therapy is 10
  better than the current therapy
• Bivalirudin is not-inferior to heparin/eptifibitid
  e for coronary PCI

23
Null Hypothesis (Ho)

• Innocent until proven guilty
• Null hypothesis (Ho) usually states that no
  difference between test groups really exists
• Fundamental concept in research is the concept of
  either rejecting or conceding the Ho
• State the Ho

• A director of an HMO hypothesizes that LOS p AMI
  is longer than for CHF exacerbation
• An investigator states that a new therapy is 10
  better than the current therapy
• Bivalirudin is not-inferior to heparin/eptifibitid
  e for PCI

24
Null Hypothesis (Ho) Courtroom Analogy

• The null hypothesis is that the defendant is
  innocent.
• The alternative is that the defendant is guilty.
• If the jury acquits the defendant, this does not
  mean that it accepts the defendants claim of
  innocence.
• It merely means that innocence is plausible
  because guilt has not been established beyond a
  reasonable doubt.

Graduate Workshop in Statistics Session 4.
Hamidieh K. 2006 Univ of Michigan
25
Agenda

• Types of variables
• Descriptive statistics
• What is a hypothesis
• Definition of a p-value
• Sample vs. universe
• Comparative statistics
• T-tests
• Chi-square

26
Extrapolation of Research Findings

• Sample population vs. the world
• If your study shows that treatment A is better
  than treatment B
• You cannot conclude that treatment A is ALWAYS
  better than treatment B
• You only sampled a small portion of the entire
  population, so there is always a chance that your
  observation was a chance event

27
Extrapolation of Research Findings

• At what point are we comfortable concluding that
  there is a difference between the groups in our
  sample
• In other words, what is the false-positive rate
  that we are willing to accept
• What is this called in statistical terms?

28
Agenda

• Types of variables
• Descriptive statistics
• What is a hypothesis
• Definition of a p-value
• Sample vs. universe
• Comparative statistics
• T-tests
• Chi-square

29
Definition of p-value

• With any research study, there is a possibility
  that the observed differences were a chance event
• The only way to know that a difference is really
  present with certainty, the entire population
  would need to be studied
• The research community and statisticians had to
  pick a level of uncertainty at which they could
  live

30
Definition of p-value

• This level of uncertainty is called type 1 error
  or a false-positive rate

31
Two Types of Errors
Trt has no effect
Trt has an effect
Graduate Workshop in Statistics Session 4.
Hamidieh K. 2006 Univ of Michigan
32
Definition of p-value

• This level of uncertainty is called type 1 error
  or a false-positive rate (a)
• More commonly called a p-value
• Statistical significance will be recognized if
  p 0.05 (can be set lower if one wishes)

33
Trade-Off in Probability for Two Errors
There is an inverse relationship between the
probabilities of the two types of
errors. Increase probability of a type I error
? decrease in probability of a type II error
.05
.01
Graduate Workshop in Statistics Session 4.
Hamidieh K. 2006 Univ of Michigan
34
Definition of p-value

• This level of uncertainty is called type 1 error
  or a false-positive rate (a)
• More commonly called a p-value
• In general, p 0.05 is the agreed upon level
• In other words, the probability that the
  difference that we observed in our sample
  occurred by chance is less than 5
• Therefore we can reject the Ho

35
Definition of p-value
Stating the Conclusions of our Results

• When the p-value is small, we reject the null
  hypothesis or, equivalently, we accept the
  alternative hypothesis.
• Small is defined as a p-value ? a, where a
  acceptable false () rate (usually 0.05).
• When the p-value is not small, we conclude that
  we cannot reject the null hypothesis or,
  equivalently, there is not enough evidence to
  reject the null hypothesis.
• Not small is defined as a p-value gt a, where a
  acceptable false () rate (usually 0.05).

Graduate Workshop in Statistics Session 4.
Hamidieh K. 2006 Univ of Michigan
36
Agenda

• Types of variables
• Descriptive statistics
• What is a hypothesis
• Definition of a p-value
• Sample vs. universe
• Comparative statistics
• t-tests
• Chi-square

37
(No Transcript)
38
Two Sample Tests Continuous Variable

• t-test
• Comparing two groups, statistical significance is
  determined by
• Magnitude of the observed difference
• Bigger differences are more likely to be
  significant
• Spread, or variability, of the data
• Larger spread will make the differences not
  significant

39
Two Sample Tests Continuous Variable
40
Two Sample Tests Continuous Variable

• t-test
• Comparing two groups, statistical significance is
  determined by
• Magnitude of the observed difference
• Bigger differences are more likely to be
  significant
• Spread, or variability, of the data
• Larger spread will make the differences not be
  significant
• Key is to compare the difference between groups
  with the variability within each group

41
Two Sample Tests Continuous Variable

• Types t-tests
• Student t-test or two sample t-test
• Used if independent variables are unpaired
• Example
• A randomized trial to high dose statin versus
  placebo post AMI
• Paired t-test
• Used if independent variables are paired
• Each person is measured twice under different
  conditions
• Similar individuals are paired prior to an
  experiment
• Each receives a different trt, same response is
  measured
• Example
• A study of ejection fraction in patients before
  and after Bi-V pacing

42
Two Sample Tests Continuous Variable

• t-test
• Tails
• Two-tailed
• Most commonly used in clinical research studies
• Means that the treatment group can be better or
  worse than the control group
• One-tailed
• Used only if the groups can only differ in one
  direction

43
Example t-test

• What type of test should be run?
• How are the data related or are they?

• Data entered into a statistical program
• p value 0.2329, not significant

44
Agenda

• Types of variables
• Descriptive statistics
• What is a hypothesis
• Definition of a p-value
• Sample vs. universe
• Comparative statistics
• T-tests
• Chi-square

45
Two Sample Tests Categorical Variables

• Chi square (?2) analysis
• Data that is organized into frequency, generate
  proportions
• Based on comparing what values are expected from
  the null hypothesis to what is actually observed
• Greater the difference between the observed and
  expected, the more likely the result will be
  significant

46
Chi square (?2) analysis
Outcome
Therapy
Totals
abcd

• Null hypothesis states that outcomes of therapy
  A and B are equally successful
• This is how the expected outcomes are determined

47
Chi square (?2) analysis
Outcome
Therapy
Totals
abcd

• Next the actual observed values are then
  recorded
• With this information the ?2 value can be
  calculated and a p-value will be generated

48
Example ?2 analysis

• Arrange data into a 2x2 table
• Treatment groups along the vertical axis,
  Outcomes alone the horizontal axis

49
Example ?2 analysis

• Data entered into a statistical program

• P-value 0.6392
• Not a significant difference

50
Example Ear Infections and Xylitol
Experiment n 533 children randomized to 3
groups Group 1 Placebo Gum Group 2
Xylitol Gum Group 3 Xylitol
Lozenge Response Did child have an ear
infection?
Group Infection Count 1 placebo Y
49 2 gum N 150 3 lozenge
Y 39 4 placebo N 129 5 gum
Y 29 6 lozenge N 137
Graduate Workshop in Statistics Session 5.
Hamidieh K. 2006 Univ of Michigan
51
Two Sample Tests Categorical Variables
Outcome
Therapy
52
Example Ear Infections and Xylitol
Compute expected count for each cell Expected
count (Row total) ? (Column total) / Total n
Example 39.1 (178 117) / 533 Or
intuitively, calculate overall infection rate
total number infected / total number
117/533 .2195 Now, assuming no difference
between treatments, the infection rate will be
the same in each group .2195 x total for each
group .2195 x 178 39.1
Graduate Workshop in Statistics Session 5.
Hamidieh K. 2006 Univ of Michigan
53
Example Ear Infections and Xylitol
? From a table, p 0.035
Graduate Workshop in Statistics Session 5.
Hamidieh K. 2006 Univ of Michigan
54
Conclusion

• There are many ways to describe ones data
• P-values are the maximum acceptable false
  positive rate
• Remember the Courtroom Analogy when it comes to
  the Null hypothesis
• Choice of statistical test depends on type of
  variable and number of comparison groups

55
References

• Neely JG, et al.
• Laryngoscope, 11212491255, 2002
• Laryngoscope, 11315341540, 2003
• Laryngoscope, 1131719 1724, 2003
• Guyatt G, et al. Basic Statistics for Clinicians.
  CMAJ. 1/1/95
• http//www-personal.umich.edu/khamidie/?MA
• Altman, DG. Practical Statistics for Medical
  Research. 1999.

56

• Thank you
