Statistics in Medical Research RCTs and Cohort

1
Statistics in Medical ResearchRCTs and Cohort

• Jemila Hamid
• Clinical Epidemiology Biostatistics
• Pathology Molecular Medicine
• McMaster University
• jhamid_at_mcmaster.ca
• July 21, 2011

2
Outline

• I. Introduction
• II. Group comparison
• Paper I Edwards et al., submitted
• III. Survival Analysis
• Paper II Krag et al, Lancet oncol, 2010
• Paper III Weaver et al., NEJM, 2011.
• IV. Design Issues sample size
• V. Summary

3
I. Introduction

• Study types are classified into two broad
  categories
• Experimental researcher investigates the
  effects of intervention
• They are prospective studies and are usually
  comparative in nature, longitudinal or cross
  sectional, parallel vs crossover designs eg.
  clinical trials Krag et al., Lancet oncol
• Observational researcher doesnt influence
  events
• Case-control (retrospective and cross sectional
  in general) or cohort (prospective and mostly
  longitudinal), Surveys (cross sectional) eg.
  epidemiology, diagnostic testing, public health
  Weaver et al., NEJM

4
Statistical Question?

• Estimation? Estimating prevalence of disease,
  treatment effect, risk, hazard, accuracy etc.
• Comparative? Comparing treatment effect with a
  constant (single sample)? Comparing a new
  diagnostic test with a gold standard? Comparing
  two or more treatments? Comparing before and
  after an intervention?
• Association and regression? Relationship between
  two variables? Effect of one variable on another?
  Effect of multiple variables on an outcome?
• Prediction? Predict (classify into) disease
  subtype? predict an outcome based on risk
  factors?

5

• Paper II Krag et al.
• Comparing survival and disease free survival
  between two surgical procedures
  Sentinel-lymph-node resection and
  axillary-lymph-node dissection
• Paper III Weaver al al.
• Comparison of disease recurrence and survival
  between two groups of patients those with occult
  lymph-node metastases and those in whom no occult
  metastases was detected
• In both Papers, estimation and confidence
  intervals are also a part of the statistical
  question - eg. estimate overall survival,
  disease free survival, hazard ratio etc.

6
Outcome Measures?

• Continuous - mean, standard deviation, mean
  difference
• Normal distribution is often assumed
• Transformations, non-parametric approaches
• Binary risk, odds, relative risk, risk
  difference, odds ratio, sensitivity, specificity,
  classification accuracy, AUC
• Logistic regression
• Binomial distribution
• Count - mean count, proportions, rates
• Poisson regression
• Negative binomial
• Survival hazard, hazard ratio, time to event
• Cox regression
• Weibull, lognormal and generalized Gamma
  distributions

7
Statistical Analysis

• Descriptive Table 1 of medical articles
• Summarizing and evaluating data using
  graphical, tabular
• This can be done using boxplots, histograms,
  normal probability plots
• Gives a good feel of data
• Assess distributions normal? need
  transformation?
• Outliers? What are we going to do about them?
• Missing values? Why are they missing? What are we
  going to do about them?

8
Paper II
9
Paper III
10
Estimation and Confidence Intervals

• Estimator parameter of interest could be mean,
  response rate, proportion etc
• Confidence interval (CI) quantifies imprecision
  or uncertainty associated with an estimate
• the reader can assess whether a result is
  estimated precisely or not, definitive or not
• presenting CI has been widely promoted in the
  literature

11
Interpretation of 95 CI

• If we repeated the experiment many many times,
  95 of the time the TRUE parameter value would be
  in the interval
• Before performing the experiment, the probability
  that the interval would contain the true
  parameter value was 0.95

12
Set of 95 C.I.s from samples of size n12 drawn
from a normal distribution with ? 211 and s2
46.
13
95 CI for continuous outcome

•

14

•

15
95 CI for proportions

•

16

•

17
Examples from Papers II and III

• Paper II
• 8 year overall survival were 91.8 (95 CI
  90.4-93.4) for group 1 and 90.3 (95
  CI88.8-91.8) in group 2
• HR 1.05 (95 CI 0.90-1.22)
• Paper III
• Occult metastases were detected in 15.9 of the
  patients (95CI 14.7-17.1)
• Adjusted hazard ratio HR 1.40 (95 CI
  1.05-1.86)

18
Hypothesis Testing

•

19
Examples from papers I-III

• Papers I III, overall and disease free survival
  were compared among the groups considered eg
  paper II, HR1.2,p value 0.12 paper III,
  HR1.40, p-value0.03
• Paper I
• Statistical Question - Comparison of clinical
  characteristics of B-Cell lymphoma unclassifiable
  (BCLU) with that of Burkitt Lymphoma (BL) and
  Diffuse Large B-Cell Lymphoma (DLBL)
• Several clinical variables were considered some
  binary and some categorical eg. Researchers
  compared DLBL and BCLU with respect to Gender
  (P-value0.51), CNS involved (p-value0.01)

20
Analysis of variance (ANOVA)

•

21

• ANOVA table

Source df SS MS F P- value
Between Groups k-1
Within Groups n-k
Total n-1
22
Example for ANOVA

• In paper I, if the researches were to compare all
  the three tumor types DLBL, DCLU and BL with
  respect to the a continuous clinical
  characteristics, Aanova would be appropriate
• For the other non-continous characteristics,
  one can apply an appropriate transformation
  before applying anova
• If they dont use anova and opt to use pairwise
  comparisons, there will be an issue of multiple
  comparison

23
Example Anova

• E.g. (Altman, 1991) Twenty two patients
  undergoing cardiac bypass surgery were randomized
  to one of three ventilation groups
• 50 nitrous oxide and 50 oxygen mixture for 24
  hours
• Same as 1, but received received treatment
  during the operation
• No nitrous oxide but received 35-50 oxygen for
  24 hours
• Compare if three groups have the same red
  cell folate (RCL)
• levels

24
Summary of RCL levels Summary of RCL levels Summary of RCL levels
Group Mean Std Dev Freq.
I 316.6 58.7 s1 8 n1
II 256.4 37.1 s2 9 n2
II 278.0 33.8 s3 5 n3
Total 283.2 22 n
25
ANOVA table
Source df SS MS F P-value
Between Groups 2 15515.9 7757.9 3.71 0.04
Within Groups 19 39716.1 2090.3
Total 21 55232 2510.5
At the 5 level, there is evidence to suggest
there is a significant difference in RCL levels
among the three groups.
26
Regression Methods

• So far we considered estimation, confidence
  intervals and comparisons. Some of these can be
  framed as a simple regression model
• Anova can, for example, be framed as a regression
  model where the treatment groups are independent
  variables
• Estimation is a big part of regression methods
• But, will present regression models in general
  and talk about special cases eg. Cox regression

27
Regression Methods

• A method for analyzing relationship between two
  or more variables
• There is a causal direction investigator seeks
  to ascertain the causal effect of one variable
  upon another
• Otherwise, it will be association or correlation
  analysis no causal relationship, here one needs
  to measure the strength of association between
  variables without assuming any causal
  relationship

28

• Two kinds of variables outcome (dependent
  variable) and predictor (independent variable)
• Predictors are sometimes called risk factors,
  exposure variables, prognostic factors depending
  on the nature of data
• Simple linear regression
• Y a ß1X1 ß2X2 ßpXp
• Depending on the distribution of the outcome
  variable, we have different types of regression
  Anova (MD), logistic regression (RR and OR), Cox
  regression (HR)

29
Example

• E.g. (Altman, 1991) Twenty two patients
  undergoing cardiac bypass surgery were randomized
  to one of three ventilation groups
• 50 nitrous oxide and 50 oxygen mixture for 24
  hours
• Same as 1, but received received treatment
  during the operation
• No nitrous oxide but received 35-50 oxygen for
  24 hours
• Compare if three groups have the same red
  cell folate (RCL)
• levels

30
Examples

• Study of biomarkers Kazu et al., work in
  progress
• Evaluate the diagnostic ability of a panel of
  five immunohistochemical markers in
  distinguishing between Endometrioid
  Adenocarcinoma (EC) and Serous Carcinoma (SC)
• Study the relative contribution of each of the
  five markers towards predicting the two
  histologic types.
• Clinical covariates such as age, body mass index
  (BMI), stage, and history of hormone replacement
  therapy
• Multiple logistic regression and ROC analysis was
  performed to estimate odds ratio and construct a
  predictive model

31
Examples

• Paper II
• Cox regression is used to estimate hazard ratio,
  model and compare survival between the two
  surgical procedures
• Here outcome (dependent variable) is survival and
  disease free survival, predictor variable is
  surgical groups, other covariates are also
  included in the model to estimate adjusted HR
• Paper III
• Again, Cox regression is used to model and
  compare survival between the two group of
  patients
• Outcome variables overall survival, disease free
  survival and distant-disease free interval.
  Predictor variable is two groups of patients,
  other covariates are also included here

32
Other Methods

• Diagnostic testing
• Agreement studies
• Multivariate methods cluster analysis,
  discriminant analysis, factor analysis, PCA, CCA
• Meta analysis combining data from different
  studies
• Methods for correlated data - longitudinal and
  repeated measures data
• Methods for high-dimensional data genomics and
  genetics

33
II. Group Comparison

• We will talk about Paper I
• We will focus only on the comparative aspect of
  the paper
• Talk about group comparison, multiple comparison
  using same data

34
Paper I

• Statistical Question - Comparison of clinical
  characteristics of B-Cell lymphoma unclassifiable
  (BCLU) and Diffuse Large B-Cell Lymphoma (DLBL)
• Several clinical variables were considered some
  binary and some categorical eg. Researchers
  compared DLBL and BCLU with respect to the
  clinical variables
• Survival is also considered in this paper but
  we will focus on the comparative aspect of the
  paper here

35
Materials and methods Paper I

• A ten-year retrospective examination of the
  clinical characteristics, survival, treatment
  response and molecular profile of BCLU (n34)
  compared to DLBL (n97)
• Variables considered include Gender, age at
  diagnosis, International Prognostic Index (IPI),
  Eastern Cooperative Oncology Group (EGOC)
  performance status, Ann Arbour stage, presence of
  B-symptoms, bone marrow (BM) and central nervous
  system (CNS) involvement, extranodal and bulky
  disease
• Chi-square and one way Analysis of Variance were
  used respectively for categorical and continuous
  data to compare the baseline characteristics
  between groups

36
Results paper I
Table 2. Clinical characteristics at diagnosis
and treatment regimes.
Variable DLBL n () DLBL n () DLBL n () BCLU n () BCLU n () P-value
Male Gender 45 (46) 18 18 (53) 0.51
B symptoms 37 (41) 12 12 (40) 0.95
Positive BM 21 (26) 5 5 (19) 0.46
CNS involved 4 (5) 6 6 (20) 0.01
Bulky disease 18 (20) 12 12 (40) 0.03
Extranodal disease 35 (39) 14 14 (47) 0.43
IPI Score 0 1 2 3 4 5   6 16 19 18 11 14   (7) (19) (23) (21) (13) (17)   3 5 8 6 7 0   3 5 8 6 7 0   (10) (17) (28) (21) (24) (0) 0.22
EGOC 0 1 2 3 4   31 27 12 15 6   (34) (30) (13) (17) (7)   11 10 6 1 2   11 10 6 1 2   (37) (33) (20) (3) (7) 0.43
Ann Arbour stage 1 2 3 4   18 18 14 41   (20) (20) (15) (45)   8 5 8 9   8 5 8 9   (27) (17) (27) (30) 0.33
Treatment regime BL-like DLBL-like Palliative No treatment   4 74 13 6   (4) (76) (13) (6)   4 24 1 5   4 24 1 5   (12) (71) (3) (15)

37
II. Survival Analysis

• Focus on statistical methods used Papers II and
  III
• We will discuss
• Study type and design
• Materials and Methods
• Statistical Analysis
• Results

38
Paper II
39
Paper III
40
Study type - Paper II

• Randomized controlled phase 3 trial done at 80
  centers across Canada and the USA
• Women with invasive breast cancer were randomly
  assigned to two surgical procedures
• Sentinel-lymph-node resection (SLN) plus
  axillary-lymph-node dissection (ALND)
• SLN alone with ALND only if the SLNs were
  positive
• Randomization was stratified by age ( 49, 50),
  tumor size and surgical plan (lumpectomy,
  mastectomy)
• Primary outcome was overall survival but other
  secondary outcomes were considered

41
(No Transcript)
42
Study type - Paper III

• Retrospective and observational study from
  previously conducted RCT
• Paraffin-embedded tissue blocks of sentinel lymph
  nodes obtained from patients with pathologically
  negative SLNs were centrally evaluated for occult
  metastases
• Objective is estimate proportion of patients
  with occult metastases and compare survival
  between group of patients with and without occult
  metasetases

43
(No Transcript)
44
Methods, survival analysis

• In both papers, the primary outcome is overall
  survival secondary outcome disease free
  survival, regional control
• Both papers used the log rank test and Cox
  proportional hazard models
• Kaplan-Meier corves were used in both papers
• In both papers, HRs and adjusted HRs with 95 CIs
  were provided

45
Survival analysis

• Survival analysis is used to analyze time to
  event data arises in both clinical and cohort
  studies
• Event Death, disease occurrence, disease
  recurrence, recovery, or other experience of
  interest
• Time The time from the beginning of an
  observation period (e.g., surgery) to (a) an
  event, or (b) end of the study, or (c) loss of
  contact or withdrawal from the study
• We almost never observe the event of interest in
  all subjects for these patients, we dont know
  their survival time

46
Survival analysis

• Censoring/censored observation
• When a subject does not have an event during the
  observation time, they are described as censored,
  meaning that we cannot observe what has happened
  to them subsequently.
• A censored subject may or may not have an event
  after the end of observation time
• Such survival times are called censored.

47
Survival analysis

•

48
Survival analysis.

• Median survival- time point at which 50 of the
  population survives
• Mean survival the average survival time (not
  commonly used) calculated as the number if
  years survived by all patients divide by the
  number of deaths
• 5 year survival proportion of patients that
  survive 5 years ( it can be 1 year, 2 years, 5
  years or 10 years depending on the nature of the
  event)

Time to event
49
Paper II
50
Paper III
51
Paper III
52
Paper I
53
Comparing survival curves

• One use KM curves is to compare survival between
  two or more groups
• We can visually compare median survival, mean
  survival, 5 year survival etc.
• We need more objective way of comparing long
  rank test

Remission time for acute myelogenous leukemia.
Group 1 received maintenance chemo, group 2,
didnt
54
Log rank test
Alive Dead Total
Group 1 a1 d1 n1
Group 2 a2 d2 n2
Total a d n

55
Cox proportional hazard model

•

56
Results from paper II

• Comparison of survival between group 1 (SLR
  ALND) and group 2 (SLN alone) resulted in
  unadjusted HR 1.20 (95CI 0.86-1.50,
  p-value0.12)
• 8 year KM estimates for overall survival were
  91.8 (95CI 90.4-93.3) for group 1 and 90.3
  (95CI88.8-91.8) for group 2
• Comparison for disease free survival resulted in
  HR of 1.05 (95CI0.90-1.22,p-value0.54)
• 8 year KM estimates for disease free survival
  were 82.4 (95CI 80.5-84.4) for group 1 and
  81.5 (95CI79.6-83.4) for group 2

57
Results from Paper III

• Occult metastases were detected in 15.9 (95CI
  14.7 -17.1) of the patients
• A significant difference in overall survival
  (p-value0.03), disease free survival
  (p-value0.02) and distant disease free survival
  (p-value0.04) between the two groups of patients
• The 5 year KM survival estimates for group 1 (in
  whom occult metastases was detected were 94.6,
  86.4, 89.7 for overall, disease free and
  distant disease free survival, respectively.
• For group 2, the estimates are 95.8, 89.2, and
  92.5, respectively

58
(No Transcript)
59
IV. Design Issues sample size

• Determining the sample size for a study is a
  crucial component of study design
• Small sample size leads to imprecise estimates
  and the study will be under powered to detect
  differences, in particular when the effect size
  is very small
• Using too many subjects may result in
  statistically significant conclusions and clear
  future study directions however, the same
  answer could have been obtained with fewer
  subjects studies are over powered and lead to
  wasted resources
• Some treatments are also invasive

60

• Important to choose primary outcome
• There are important parameters needed for sample
  size calculations desired power (1-type II
  error), level of the test (Type one error or a),
  variance (or standard deviation) and effect size
  (the minimum difference to be detected)
• Eg. comparing two means 80 power, 0.05 level,
  range of sd, range of MD

• N102 (50 for each group is needed to achieve 80
  power when 3.5 and sd3
• Only N9 (3 for each group is needed to achieve
  80 power when 1 and sd1

61

• Multiple logistic regression we need to chose
  the primary predictor variable
• Provide parameter values based on this primary
  predictor
• Consider the correlation between these predictor
  with other predictors or covariates
• When correlation is high, we need larger sample
  size

62
Summary

• Statistical question, outcome variable, primary
  and secondary outcomes
• Estimation, CI, hypothesis testing
• Multiple comparison
• Survival analysis and linear regression
  (comparison between two or more groups)
• Design issues sample size
