LASER GUIDED SYSTEMS

1
Laser Guided Systems
Laser Guided Training Round (LGTR)
Laser Guided Bomb (LGB)
Mission Readiness Test Set (MRTS)
Dual Mode Guided Bomb (DMGB)
Missiles and Fire Control Archbald, Pennsylvania
M/PP/DL/LGS Pres Rev2
2
LM Paveway II LGB Qualified Proven

• USAF USN qualification completed
• Meets all form, fit function Paveway II
  requirements
• GBU-10, GBU-12, GBU-16 kits in production
• Over 12,000 units delivered to US
• International customers

Airfoil Group (AFG)

• Deployable rear wings
• Canard control surfaces
• Field assembly to MK series bombs

Computer Control Group (CCG)

• Semi active laser seeker
• Bang-bang pneumatic control actuator
• Pursuit guidance navigator

Lockheed Martins Low Cost Design Meets Or
Exceeds Mission Requirements
3
Mission Readiness Test Set (MRTS)

• Designed to replace TTU-373, TTU-392, TTU-394
• TTU-550 and TTU-555 test sets

• Efficiently tests MAU-169 and MAU-209 Computer
  Control Group (CCG)
• Lightweight design (45 lbs.) provides one-man
  portability
• User friendly fully automated operation provides
  go/no go test capability
• Capable of operating from multiple power sources
• Upgradeable for future systems

The MRTS Provides A Low Cost, Efficient, Light
Weight Test Capability
4
Laser Guided Training Round (LGTR)

• Permits live-fire training at a fraction of the
  cost
• Emulates the LGB
• Release envelope
• Flight characteristics
• Guidance and control functions
• Target designation requirements
• Accuracy

• Qualified and in production for over 11 years
• Produced over 30,000 units for US Navy and
  International customers
• COTS proven design provides reliability at an
  extremely low cost
• Cleared on F-16, A-6, F-14, F/A-18 and Mirage
  F-1
• Demonstrated on A-7, F-4, Mirage 2000 and Jaguar
• Design compatible on Tornado, Eurofighter, AMX
  and AV-8

Conserves LGB Inventory While Providing A Low
Cost Training Solution
5
Dual Mode Guided Bomb (DMGB) All Weather
Capability

• COMBINES proven Paveway II laser terminal
• guidance with GPS/INS
• Fire Forget
• Utilizes MIL-STD-1760 interface to aircraft
• Incorporates anti-jam technology
• DMGB provides increased accuracy with reduced
• Collateral damage and number of sorties to
• Accomplish mission requirements

GPS Satellites generate RF signals
Warheads Carriage and Release Envelopes Target
Types Guidance Methods Employment Modes Impact
Accuracy Aircraft Compatibility Fire Control
Interface Mission Planning Weapons Logistics
(storage, handling, assembly, test)
MK 82 (500lb) (Future MK83, MK84)
GBU-12 (Future GBU-10, GBU-16)
High priority fixed and relocatable, and mobile
targets
DMGB uses INS data with GPS updates to align
flight path with ballistic path to the target
Semi-Active Laser (SAL) terminal guidance GPS
aided inertial (All weather)
Reflected laser energy from autonomous buddy
aircraft, or ground designator leads to target
position
Laser only, all weather only, dual mode
Laser 30 foot CEP Performance Spec. All-weather
13 meter SEP (goal). Dual w/terminal laser 15ft
CEP (goal)
After laser acquisition, DMGB performs as an LGB
and aligns its flight path with the reflected
laser energy
F/A-18, F-16, F-15, F-117 and others
Emulate JDAM (goal no changes to aircraft
software)
Laser Spot
Similar to existing LGB and JDAM planning methods
and tools
If no laser energy is detected, DMGB continues to
target using INS data with GPS updates
Fixed or moving target
Maximize compatibility with Paveway II logistics.
Exceptions TTU-373/MRTS replaced by CMBRE BIT
added
Dual Mode Effectively Combines Technology At A
Low Cost
6
Laser Guided Systems

• Lockheed Martin The One Company that Provides
  an End-to-End System

• Aircraft
• Laser Designators
• Training Bombs
• Warheads
• LGBs
• LGB Tester
• LongShot TM

F-16 LANTIRN, Pantera LGTR BLU-109, 116 GBU-10,
12 16 MRTS XR Wing Kit

• Business Development Points of Contact

Name
Phone
Email
Title

• Keith Rayborn
• Joe Garcia
• David Landis

[phone] [phone] [phone]
keith.r.rayborn_at_lmco.com fred.n.garcia_at_lmco.com da
vid.c.landis_at_lmco.com
Director, Business Development Manager, Business
Development Sr. Manager, Business Development
