Test1 Solutions

1
Test1 Solutions

• Web 2.0 and Rich Internet Applications

2
1. a. What is Web 2.0 ?

• Web 2.0 as a term was first coined during a
  brainstorming session at a conference on Internet
  Technology.
• Before year 200, Websites were well insulated
  entities that executed entirely within the
  browser and well within their own sphere of
  influence.
• Users were important but no one would dare
  venture so far as to suggest that users specify
  what they wanted.
• After 2000, Web 2.0 provides rich user
  interaction. Web 2.0 like art, has no real
  definition.

3
1.b. Briefly describe iterative development.

• Rather than use a forklift approach to getting
  functionality out of door, web 2.0 companies
  operate in a very short cycles of design,
  develop, launch, get feedback, repeat.
• This means time-to-market is reduced.
• Companies purposefully leave features out to
  achieve shorter cycle times.
• Rather than guess at what the users want, its
  better to launch a small subset of functionality
  and then take real-world users feedback.
• The feedback is then used to drive feature
  definition in subsequent cycles.

4
1. c. What are Folksonomies?

• The term folksonomy refers to the process whereby
  a group of people collaborate to organize
  information using an impromptu vocabulary.
• A common example in the corporate world is team
  building excercises, whereby a group of
  individuals rearrange flash cards on the floor or
  stickers on a white board. By getting a large
  group of peoples input, you have a higher
  probability of getting an appropriate
  classification of the information in question.

5
1.c. How do Folksonomies apply to web 2.0?

• In the web 2.0, there is a huge amount of
  information and its updated constantly.
• It would be naïve to think that any one company
  could categorize that information so accurately
  that classification would make sense to everyone.
• Who better to categorize data than the people
  closest to it?
• For example Amazon allows users to tag products
  with key words. Over time, this will evolve into
  its own folksonomy where the users are adding
  value for other users simply by using amazon
  site.

6
2.a. Is Internet different from World Wide Web?

• The internet is a collection of computers and
  other devices connected by equipment that allows
  them to communicate with each other.
• The web is a collection of software and protocols
  that has been installed on most if not all of the
  computers on the internet.
• The internet was quite useful before the web was
  developed, and it is still useful without it.
• However, it is now the case that most users of
  the internet use web.

7
2.b. Briefly describe HTTP Protocol.

• Application level, client-server protocol
• Primarily for distributed hypermedia systems
• Flexible - thus has many other uses - e.g.
• Nameservers
• Distributed collaborative document management
  systems
• HTTP is small and fast
• Minimal performance overhead
• Easy to implement
• HTTP is a stateless protocol
• Each request is an independent transaction -
  unrelated to any previous requests (unlike
  session-based protocols, e.g. FTP)
• Advantage
• Simplifies server design - information about
  previous transactions does not need to be stored
• Disadvantage
• More information must be included in each request

8
HTTP Operation

• On the Internet HTTP usually uses TCP/IP
  connections
• TCP Port 80 is the default (though others can be
  specified)
• HTTP uses a Request/Response paradigm
• Client establishes a connection to the server,
  and sends it a request
• Server responds to the request by generating a
  response (which may or may not contain content)

9
HTTP Request

• Delivered from a client to a server containing
  instructions for the server
• Contains
• the method to be applied to the data resource
• the identifier of the resource
• the protocol version in use
• Most commonly used methods
• GET - Fetch a document
• HEAD - Fetch just the header of the document
• POST - Execute the document, using the data in
  body
• PUT - Store a new document on the server
• DELETE - Remove a document from the server

10
Request message
General request message structure
METHOD /path-to-resource HTTP/version-number Hea
der-Name-1 value Header-Name-2 value optional
request body
Example
GET /index.html HTTP/1.1 Host
www.cs.nott.ac.uk Accept text/ User-Agent
Mozilla/2.02Gold (WinNT I)
11
HTTP Response

• Message generated by a server after receiving and
  interpreting a request
• Responses contain
• Status line with the protocol version, a status
  code, and a reason phrase
• Response-Header (containing information about the
  server)
• Entity Header (meta-information)
• Entity Body (data)

12
Response message
General response message structure
HTTP/version-number status-code message
Response-Header-Name-1 value Response-Header-Nam
e-2 value Entity-Header-Name-1
value Entity-Header-Name-2 value optional
entity body
Example
HTTP/1.1 200 OK Server Apache
(Red-Hat/Linux) Content-Type text/html Content-Le
ngth 9934 ltHTMLgt ltHEADgt ltTITLEgtSchool of
Computer Sciencelt/TITLEgt
13
2.c. What is a hyperlink?

• A hypertext link in an XHTML document is called
  Hyperlink acts as a pointer to some resource.
  That resource can be an XHTML document anywhere
  on the web.

14
3.a What is the task of the Domain Name Server?

• The Domain name servers convert domain names into
  IP addresses.
• Name servers serve a collection of machines on
  the internet and are operated by organizations
  that are responsible for the part of internet to
  which those machines are connected.
• All document requests from browsers are routed to
  the nearest name servers.

15
3.b. What are the differences between IPv4 and
IPv6?

• IPv4 supports 32 bit IP addresses
• IPv6 supports 128 bit IP addresses
• ( with this every grain of sand on earth can be
  IP addressable!)
• New type of addresses called anycast apart from
  unicast and multicast.
• Fragmentation and Reassembly IPv6 does not allow
  for fragmentation and reassembly at intermediate
  routers.
• Header Checksum As with IPv4, due to fast
  processing requirements, this has been removed in
  IPv6
• Options An option field is no longer a part of
  the standard IP header. The removal of the
  options field results in a fixed-length, 40-byte
  IP header.
• IPv6 has an elusive definition of a flow state
  that allows labeling of packets belonging to
  particular flows.

16
3.c. Why is TCP/IP referred to as network
friendly protocol?

• TCP/IP uses slow start and helps congestion
  control.
• Whenver the network becomes congested, it will
  slow down packet transmission such that network
  can recover quickly.

17
4.a. Briefly describe MIME

• Problems with international languages
• Languages with accents (French, German).
• Languages in non-Latin alphabets (Hebrew,
  Russian).
• Languages without alphabets (Chinese, Japanese).
• Messages not containing text at all (audio or
  images).
• Multipurpose Internet Mail Extensions

18
MIME (2)

• The MIME types and subtypes defined in RFC 2045.

19
4. b. What is a plug-in?
20
4. c. What is the important capability lacking in
a markup language?

• Uniformity while being rendered by different
  browsers.
• User interaction, dynamism, control loops,
  programming language constructs.

21
5.a. Why is HTTP 1.0 considered as a stateless
protocol?

• Each request is an independent transaction -
  unrelated to any previous requests (unlike
  session-based protocols, e.g. FTP)

22
5.b. What are use of cookies?

• Cookies provide general approach to storing
  information about sessions on the browser system
  itself.
• A cookie is a small object of information
  consisting of a name and a textual value.
• A cookie is created by some software system on
  the server such as a CGI program.

23
5.c. What is a proxy server?

• A web cache also called proxy server is a network
  entity that satisfies HTTP requests on the behalf
  of an origin server.
• The web cache has its own disk storage and keeps
  in this storage copies of recently requested
  objects.
• A users browser can be configured so that all
  the users HTTP requests are first directed to
  the web cache.

24
6.a. What are the differences between HTML and
XHTML?

• HTML has lax syntax rules, leading to sloppy
  and sometime ambiguous documents
• XHTML syntax is much more strict, leading
  to clean and clear documents in a standard
  form
• HTML processors do not even enforce the few
  syntax rules that do exist in HTML
• The syntactic correctness of XHTML documents can
  be validated

25
6.b. What is the application of XHTML document
Validation?

• W3C HTML Validation Service
• http//validator.w3.org/file-upload.html

26
6.c. What is the use of meta element?

• The meta element is used to provide additional
  information about a document.
• It has no content rather all of the provided
  information is specified through attributes.
• ltmeta name Keywords contentbinary tree /gt
• Web search engines use the info provided with the
  meta element to categorize web documents in their
  indices.

27
7.a. What are the XHTML tags useful for designing
a Table?

• A table is a matrix of cells
• The cells can include almost any element
• Some cells have row or column labels and some
  have data
• A table is specified as the content of a lttablegt
  tag
• Each row of a table is specified as the content
  of a lttrgt tag
• The row headings are specified as the content of
  a ltthgt tag
• Each data cell of a row is specified as the
  content of a lttdgt tag

28
7.b. Creat an XHTML document that has a form with
following controls. ( A text box to collect
users name. Four checkboxes and 3 radio buttons.)
29
An example

• lt?xml version "1.0" encoding "utf-8"?gt
• lt!DOCTYPE html PUBLIC "-//w3c//DTD XHTML 1.1//EN"
• "http//www.w3.org/TR/xhtml11/DTD/xhtml11.dtd"gt
• lt!-- popcorn.html
• This describes popcorn sales form page
• --gt
• lthtml xmlns "http//www.w3.org/1999/xhtml"gt
• ltheadgt lttitlegt Popcorn Sales Form lt/titlegt
• lt/headgt
• ltbodygt
• ltform action "http//marian.cs.nott.ac.uk/b
  nk/cgi-bin/popcorn.pl" method "post"gt
• lth2gt Welcome to Millennium Gymnastics
  Booster Club Popcorn Sales lt/h2gt
• lt!-- A borderless table of text widgets for name
  and address --gt
• lttablegt
• lttrgt
• lttdgt Name lt/tdgt

30
contd

• lt!-- A bordered table for item orders --gt
• lttable border "border"gt
• lt!-- First, the column headings --gt
• lttrgt
• ltthgt Product Name lt/thgt
• ltthgt Price lt/thgt
• ltthgt Quantity lt/thgt
• lt/trgt
• lt!-- Now, the table data entries --gt
• lttrgt
• ltthgt Unpopped Popcorn (1 lb.) lt/thgt
• lttdgt 3.00 lt/tdgt
• lttdgt ltinput type "text" name "unpop"
  size "2" /gt lt/tdgt
• lt/trgt

31
contd

• lt!-- The radio buttons for the payment method --gt
• lth3gt Payment Method lt/h3gt
• ltpgt
• ltinput type "radio" name "payment" value
  "visa" checked "checked" /gt Visa
• ltinput type "radio" name "payment" value
  "mc" /gt Master Card
• ltinput type "radio" name "payment" value
  "discover" /gt Discover
• ltinput type "radio" name "payment" value
  "check" /gt Check ltbr/gt
• lt/pgt
• lt!-- The submit and reset buttons --gt
• ltpgt
• ltinput type "submit" value "Submit
  Order" /gt
• ltinput type "reset" value "Clear
  Order Form" /gt
• lt/pgt
• lt/formgt
• lt/bodygt
• lt/htmlgt

32
Result
33
8.a. Write a short note on CSS

• CSS provides the means to control and change
  presentation of XHTML documents
• Style sheets allow you to impose a standard style
  on a whole document, or even a whole collection
  of documents
• CSS1 specification was developed in 1996
• CSS level 2 revision 1 (CSS 2.1) - 2004, is a
  Candidate W3C Recommendation
• CSS3 is under development

34
Levels of Style Sheets

• There are three levels of style sheets
• Inline - specified for a specific occurrence of a
  tag and apply only to that tag
• This is fine-grain style, which defeats the
  purpose of style sheets - uniform style
• Document-level style sheets - apply to the whole
  document in which they appear
• External style sheets - can be applied to any
  number of documents
• When more than one style sheet applies to a
  specific tag in a document, the lowest level
  style sheet has precedence

35
Levels of Style Sheets

• Inline style sheets appear in the tag itself
• Document-level style sheets appear in the head of
  the document
• External style sheets are in separate files,
  potentially on any server on the Internet
• Written as text files with the MIME type text/css
• A ltlinkgt tag is used to specify that the browser
  is to fetch and use an external style sheet file
• ltlink rel "stylesheet" type "text/css"
• href "http//www.wherever.org/example.css"gt
• lt/linkgt

36
8.b. Write a short note on Web servers

• Apache, IIS
• Webroot
• Port number
• Webpages
• TCP/IP connection

37
Webserver
