Introductory Chemistry, 2nd Edition Nivaldo Tro

1
Introductory Chemistry, 2nd EditionNivaldo Tro
Chapter 4 Atoms and Elements
2
Experiencing Atoms

• Atoms are very small they are building blocks of
  matter.
• Atom smallest particle of an element that
  retains its characteristics

3
Daltons Atomic Theory

• Elements are composed of tiny indivisible
  particles called atoms
• All atoms of an element are identical atoms of
  different elements are different
• every carbon atom is identical to every other
  carbon atom
• they have the same chemical and physical
  properties
• but carbon atoms are different from sulfur atoms
• they have different chemical and physical
  properties

John Dalton (1766-1844)
4
Daltons Atomic Theory

• Atoms combine in simple, whole-number ratios to
  form molecules of compounds
• each molecule of a compound contains the exact
  same types and numbers of atoms
• Law of Constant Composition or Definite
  Proportions
• Chemical Formulas

5
Daltons Atomic Theory

• In chemical reactions, atoms are not broken or
  changed into other atoms.
• atoms are not created or destroyed, just
  rearranged
• total mass will remain the same
• Law of Conservation of Mass
• atoms of one element do not change into atoms of
  another element in a chemical reaction
• cannot turn Lead into Gold by a chemical reaction

6
Daltons Atomic Theory

• Law of multiple proportions if two elements A
  and B combine to form more than one compound,
  masses of B which combine with mass of A, is a
  ratio of small whole numbers. Ex CO, (1.33 g
  O/1g C) CO2 (2.67 g O/g)
• The mass of O in CO2 is twice that in CO 2.67g O
  in CO2/1.33 g O in CO2 2.00
• Thus, when 2 elements combine to form 2 different
  compounds, they combine in different ratios or
  proportions
• CO, CO2 SO2, SO3

7
Modern Evidence for Atoms
Atoms can be seen through a special instrument
called the scanning tunneling microscope (STM)
8
Mass of Atoms

• Using compositions of compounds and assumed
  formulas, Dalton determined relative masses of
  atoms
• Dalton based his scale on H 1 amu
• we now base it on C-12 12 amu exactly
• unit atomic mass unit, amu

9
The Atom is Divisible!

• Work done by J.J. Thomson and others proved that
  the atom had particles called electrons
• Thomson found that electrons are much smaller
  than atoms and carry a negative charge
• The mass of the electron is 1/1836th the mass of
  a hydrogen atom

10
Rutherfords Experiment
Radioactive Sample
Lead Box
Fluorescent Screen
Gold Foil
11
Conclusions from Rutherfords Experiment

• Atom mostly empty space
• because most particles went through
• Atom contains a dense particle that was small in
  volume compared to the atom but large in mass
• because of the few particles that bounced back
• This dense particle was positively charged
• because of the large deflections of some of the
  particles

12
Rutherfords Interpretation the Nuclear Model

• Atom contains a tiny dense center called the
  nucleus
• The nucleus has essentially the entire mass of
  the atom
• the electrons weigh so little they give
  practically no mass to the atom
• The nucleus is positively charged
• the amount of positive charge balances the
  negative charge of the electrons
• The electrons move around in the empty space of
  the atom surrounding the nucleus

13
The Modern Atom

• Atoms are composed of three particles - protons,
  neutrons and electrons
• The nucleus contains protons and neutrons
• The electrons move outside the nucleus
• Neutral atom has same protons and electrons.

14
The Nuclear Atom
protons
Nucleus
neutrons


15
Subatomic Particles
Charge? Location?
neutrons (n) protons (p) electrons (e)
16
Subatomic Particles
17
Subatomic Particles
Mass (amu)
1 1 ? 0 (1/1837)
neutron proton electron
18
Elements

• Each element has a unique number of protons in
  its nucleus
• Number of protons in the nucleus of an atom is
  called the atomic number
• the elements are arranged on the Periodic Table
  in order of their atomic numbers
• Each element has a unique name and symbol
• symbol either one or two letters
• one capital letter or one capital letter one
  lower case

19
How many?

• protons depends on element
• neutrons variable for each element
• electrons same as protons

20
atomic number -

• The number of protons in one atom each element
  has a different atomic number
• The number on top of the element symbol in the
  periodic table

21
The Periodic Table of Elements
22
Review

• What is the atomic number of boron, B?
• What is the atomic mass of silicon, Si?
• How many protons does a chlorine atom have?
• How many electrons does a neutral neon atom have?

• Will an atom with 6 protons, 6 neutrons and 6
  electrons be electrically neutral?
• Will an atom with 27 protons, 32 neutrons and 27
  electrons be electrically neutral?
• Will a Na atom with 10 electrons be electrically
  neutral?

23
Review

• What is the atomic number of boron, B? 5
• What is the atomic mass of silicon, Si? 28.09
  amu
• How many protons does a chlorine atom have? 17
• How many electrons does a neutral neon atom have?
  10
• Will an atom with 6 protons, 6 neutrons and 6
  electrons be electrically neutral? Yes
• Will an atom with 27 protons, 32 neutrons and 27
  electrons be electrically neutral? Yes
• Will a Na atom with 10 electrons be electrically
  neutral? No

24
Three Types of Elements
Metal
Metalloid
Nonmetal
25
Metals

• Solids at room temperature, except Hg
• Shiny
• Conduct heat, electricity
• Malleable can be shaped
• Ductile drawn or pulled into wires
• Lose electrons and form cations ( charge) in
  reactions
• About 75 of the elements are metals

26
Nonmetals

• Found in all 3 states
• Poor conductors of heat electricity
• Solids are brittle
• Gain electrons in reactions to become anions (-
  charge)
• Only a few on the right of periodic table

27
Metalloids

• Show some properties of metals and some of
  nonmetals
• Also known as semiconductors

Properties of Silicon shiny conducts
electricity does not conduct heat well brittle
28
The Modern Periodic Table

• Elements with similar chemical and physical
  properties are in same column
• Columns are called Groups or Families
• designated by a number and letter at top
• Rows are called Periods
• Each period shows the pattern of properties
  repeated in the next period

29
The Modern Periodic Table

• Main Group Representative Elements A groups
• Transition Elements B groups
• all metals
• Bottom rows Inner Transition Elements Rare
  Earth Elements
• metals
• really belong in Period 6 7

30
Halogens
Lanthanides
Actinides
31
Important Groups - Hydrogen

• nonmetal
• colorless, diatomic gas
• very low melting point density
• reacts with nonmetals to form molecular compounds
• HCl is acidic gas
• H2O is a liquid
• reacts with metals to form hydrides
• metal hydrides react with water to form H2
• HX dissolves in water to form acids

32
Important Groups IA, Alkali Metals

• hydrogen usually placed here, though it doesnt
  belong
• soft, low melting points,low density
• very reactive, never find uncombined in nature
• tend to form water soluble compounds
• react with water to form basic (alkaline)
  solutions and H2 releasing a lot of heat

lithium
sodium
potassium
rubidium
cesium
33
Important Groups IIA, Alkali Earth Metals

• harder, higher melting, and denser than alkali
  metals
• reactive, but less than corresponding alkali
  metal
• form stable, insoluble oxides from which they are
  normally extracted
• oxides are basic alkaline earth

beryllium
magnesium
calcium
strontium
barium
34
Important Groups VIIA, Halogens

• nonmetals
• F2 Cl2 gases Br2 liquid I2 solid
• all diatomic
• very reactive
• react with metals to form ionic compounds
• HX all strong acids except HF

fluorine
chlorine
bromine
iodine
35
Important Groups VIIIA, Noble Gases

• all gases at room temperature,
• very low melting and boiling points
• very unreactive, practically inert
• very hard to remove electron from or give an
  electron to

36
Charged Atoms Ions

• Number of protons (atomic ) identifies the
  element!
• all sodium atoms have 11 protons in the nucleus
• In chemical change, number of protons in
  nucleus of atom doesnt change!
• Atoms can lose or gain electrons becoming
  electrically charged, these are called ions

37
Ions

• Atoms acquire a charge by gaining or losing
  electrons
• not protons!!
• Ion Charge protons electrons
• ions with a charge are called cations
• more protons than electrons
• form by losing electrons
• ions with a charge are called anions
• more electrons than protons
• form by gaining electrons

38
Atomic Structures of Ions

• Metals form cations
• For each positive charge the ion has 1 less
  electron than the neutral atom
• Na atom 11 p and 11 e-, Na ion 11 p and 10
  e-
• Ca atom 20 p and 20 e-, Ca2 ion 20 p and
  18 e-
• Cations are named the same as the metal
• sodium Na ? Na 1e- sodium ion
• calcium Ca ? Ca2 2e- calcium ion
• The charge on a cation can be determined from the
  Group number on the Periodic Table
• Group 1A ? 1, Group 2A ? 2, (Al, Ga, In) ? 3

39
Atomic Structures of Ions

• Nonmetals form anions
• For each negative charge the ion has 1 more
  electron than the neutral atom
• F 9 e-, F- 10 e-
• P 15 e-, P3- 18 e-
• Anions are named by changing the ending of the
  name to -ide
• fluorine F 1e- ? F- fluoride ion
• oxygen O 2e- ? O-2 oxide ion
• Charge on an anion can be determined by
  subtracting 8 from the Group number on the
  Periodic Table
• Group 7A ? 7- 8 -1 Group 6A ? 6 8 -2

40
Example 4.5 Determining the Number of Protons
and Electrons in an Ion
41

• Example
• Find the number of protons and electrons in the
  Ca2 ion.

42
ExampleFind the number of protons and electrons
in the Ca2 ion

• Write down the given quantity and its units.
• Given Ca2

43
ExampleFind the number of protons and electrons
in the Ca2 ion

• Information
• Given Ca2

• Write down the quantity to find and/or its units.

• Find p and e

44
ExampleFind the number of protons and electrons
in the Ca2 ion

• Information
• Given Ca2
• Find p and e

• Design a Solution Map.

ion symbol
and e
Ion charge p - e
45
ExampleFind the number of protons and electrons
in the Ca2 ion

• Information
• Given Ca2
• Find p and e
• Solution Map ion symbol ? element ? atomic
  number ? p ? e

• Apply the Solution Map.
• Determine the Name of the Element

Ca calcium
46
ExampleFind the number of protons and electrons
in the Ca2 ion

• Information
• Given Ca2 calcium
• Find p and e
• Solution Map ion symbol ? element ? atomic
  number ? p ? e

• Apply the Solution Map.
• Determine the Atomic Number of the Element

Ca calcium Atomic Number 20
47
ExampleFind the number of protons and electrons
in the Ca2 ion

• Information
• Given Ca2 calcium, Z 20
• Find p and e
• Solution Map ion symbol ? element ? atomic
  number ? p ? e

• Apply the Solution Map.
• Determine the Number of Protons in an Atom of the
  Element

Ca calcium Atomic Number 20 p atomic
number 20
48
ExampleFind the number of protons and electrons
in the Ca2 ion

• Information
• Given Ca2 calcium, Z 20
• Find p 20 and e
• Solution Map ion symbol ? element ? atomic
  number ? p ? e

• Apply the Solution Map.
• Determine the Number of Electrons in an Ion of
  the Element

Ion Charge p - e 2 20 - e -18 - e 18
e
Ca calcium Atomic Number 20 p atomic
number 20
49
Atomic Structures of Ions
50
Atomic Structures of Ions
51
Ion Charge the Periodic Table

• Charge on an ion can often be determined from an
  elements position on the Periodic Table
• Metals are always positive ions, nonmetals are
  negative ions
• For many main group metals, the charge the
  group number
• For nonmetals, the charge the group number - 8

52
Charges of Main Group Ions
IA
VIA
IIA
IIIA
VIIA
VA
Li1
Be2
O-2
F-1
N-3
Mg2
Na1
S-2
Cl-1
P-3
Al3
K1
Ca2
Se-2
Br-1
As-3
Ga3
Rb1
Sr2
Te-2
I-1
In3
Cs1
Ba2
53
Isotopes

• Isotopes atoms of an element that have same
  of protons but different of neutrons
• Isotopes of an element have different masses
• isotopes are identified by their
• mass numbers protons neutrons
• All isotopes of an element are chemically
  identical
• undergo the exact same chemical reactions

54
Isotopes

• Atomic Number
• Number of protons
• Z (symbol)
• Mass Number
• Protons Neutrons
• Whole number
• A (symbol)
• Abundance relative amount found in a sample

55
Neon
56
Isotope Symbols

• Cl-35 makes up about 75 of chlorine atoms in
  nature, and Cl-37 makes up the remaining 25
• Average atomic mass of Cl 35.45 amu
• Cl-35 has a mass number 35, 17 protons and 18
  neutrons (35 - 17)

or Cl-35
57
Example 4.8 Determining the Number of Protons
and Neutrons fromIsotope Symbols
58

• Example
• How many protons and neutrons in the chromium
  isotope

59
ExampleHow many protons and neutrons in the
chromium isotope

• Write down the given quantity and its units.
• Given

60
ExampleHow many protons and neutrons in the
chromium isotope

• Information
• Given

• Write down the quantity to find and/or its units.

• Find p and n

61
ExampleHow many protons and neutrons in the
chromium isotope

• Information
• Given
• Find p and n

• Design a Solution Map.

ion symbol
Mass p n
62
ExampleHow many protons and neutrons in the
chromium isotope

• Information
• Given
• Find p and n
• Solution Map ion symbol ? element ? atomic
  number ? p ? n

• Apply the Solution Map.
• Determine the Name of the Element

Cr chromium
63
ExampleHow many protons and neutrons in the
chromium isotope

• Information
• Given calcium
• Find p and n
• Solution Map ion symbol ? element ? atomic
  number ? p ? n

• Apply the Solution Map.
• Determine the Atomic Number of the Element

Cr chromium Atomic Number 24
64
ExampleHow many protons and neutrons in the
chromium isotope

• Information
• Given calcium
• Find p and n
• Solution Map ion symbol ? element ? atomic
  number ? p ? n

• Apply the Solution Map.
• Determine the Number of Protons in an Atom of the
  Element

Cr chromium Atomic Number 24 p atomic
number 24
65
ExampleHow many protons and neutrons in the
chromium isotope

• Information
• Given calcium
• Find p and n
• Solution Map ion symbol ? element ? atomic
  number ? p ? n

• Apply the Solution Map.
• Determine the Number of Neutrons in an Atom of
  the Element

Cr chromium Atomic Number 24 p atomic
number 24
Mass Number p n 52 24 n 28 n
66
Practice - Complete the following table
67
Practice - Complete the following table
68
Mass Number is Not the Sameas Atomic Mass

• The atomic mass is an experimental number
  determined from all naturally occurring isotopes
• The mass number refers to the number of protons
  neutrons in one isotope
• natural or man-made
