AS Geography

1
AS Geography

• Atmosphere Weather
• Energy Budgets

2

• Meteorology is the study of the atmosphere.
• Weather is the short term conditions of the
  atmosphere.
• Climate is the longer-term average conditions in
  the atmosphere (temperature, humidity,
  precipitation).

Instrument Measures Unit
Thermometer Temperature Celsius/ Fahrenheit
Hygrometer Humidity
Barometer Air Pressure Mb (milibars)
Anemometer Wind Speed Km or Miles/hour
Weather Vane Wind Direction Compass directions
Rain Gauge Rainfall/precipitation mm
3
Structure of the atmosphere
4
Incoming Outgoing Energy

• Energy enters the atmosphere as short wave solar
  radiation (insolation).
• It may leave as
• Reflected solar radiation
• Outgoing long-wave (infra-red) radiation
• There is a balance between the energy arriving
  leaving.
• Positive heat balance at tropics
• Negative heat balance at polar regions

5
Energy Budgets

• Some parts of the earth receive a lot of solar
  energy (surplus), some receive less (deficit).
• In order to transfer this energy around, to
  create some sort of balance, the earth uses
  pressure belts, winds and ocean currents.
• The global energy budget is an account of the key
  transfers which affect the amount of energy gain
  or loss on the earths surface.
• The energy budget has a huge effect on weather
  and climate.

6
The six-factor day model
7
1. Incoming solar radiation

• Atmospheres main energy input
• Strongly influenced by cloud cover and latitude
• At the equator, the suns rays are more
  concentrated than at the poles.

8
2. Reflected solar radiation

• The proportion of reflected solar radiation
  varies greatly with the nature of the surface.
• The degree of reflection is expressed as either a
  fraction on a scale of 0 to 1, or as a
  percentage.
• This fraction is referred to as the albedo of the
  surface.

• Albedo
• This is simply the proportion of sunlight
  reflected from a surface.
• Fresh snow ice have the highest albedos,
  reflecting up to 95 of sunlight.
• Ocean surfaces absorb most sunlight, and so have
  low albedos.

9
Examples
Surface or object Albedo ( solar radiation reflected)
Fresh snow 75-95
Thick clouds 60-90
Thin clouds 30-50
Ice 30-40
Sand 15-45
Earth atmosphere 30
Mars (planet, not bar) 17
Grassy field 25
Dry, ploughed field 15
Water 10
Forest 10
Moon 7
10
3. Surface absorption

• Energy arriving at the surface has the potential
  to heat that surface
• The nature of the surface has an effect, e.g.
• If the surface can conduct heat rapidly into the
  lower layers of the soil its temperature will be
  low.
• If the heat is not carried away quickly it will
  be concentrated at the surface result in high
  temperatures there.

11
4. Latent heat (evaporation)

• The turning of liquid water into vapour consumes
  a considerable amount of energy.
• When water is present at the surface, a
  proportion of the incoming solar radiation will
  be used to evaporate it.
• Consequently, that energy will not be available
  to raise local energy levels and temperatures.

12
Energy transfers of state
13
5. Sensible heat transfer

• This term is used to describe the transfer of
  parcels of air to or from the point at which the
  energy budget is being assessed.
• If relatively cold air moves in, energy may be
  taken from the surface, creating an energy loss.
• If warm air rises from the surface to be replaced
  by cooler air, a loss will also occur.
• This process is best described as convective
  transfer, and during the day it is responsible
  for removing energy from the surface and passing
  it to the air.

14
6. Longwave radiation

• This is emitted by the surface, and passes into
  the atmosphere, and eventually into space.
• There is also a downward-directed stream of
  long-wave radiation from particles in the
  atmosphere
• The difference between the 2 streams is known as
  the net radiation balance.
• During the day, since the outgoing stream is
  greater than the incoming one, there is a net
  loss of energy from the surface.

15
Simple daytime energy budget equation

• Energy available at surface
• Solar radiation receipt
• (reflected solar radiation surface
  absorption latent heat sensible heat
  transfer longwave radiation)

16
The four-factor night model
17
1. Longwave radiation

• During a cloudless night, little longwave
  radiation arrives at the surface of the ground
  from the atmosphere
• Consequently, the outgoing stream is greater and
  there is a net loss of energy from the surface.
• Under cloudy conditions the loss is reduced
  because clouds return longwave radiation to the
  surface, acting like a blanket around the earth
• With clear skies, temperatures fall to lower
  levels at night.

18
2. Latent heat (condensation)

• At night, water vapour in the air close to the
  ground can condense to form dew because the air
  is cooled by the cold surface.
• The condensation process liberates latent heat,
  and supplies energy to the surface, resulting in
  a net gain of energy.
• However, it is possible for evaporation to occur
  at night. If this happens on a significant scale
  a net loss of energy might result.

19
3. Subsurface supply

• The heat stored in the soil and subsoil during
  the day can be transferred to the cooled surface
  during the night.
• This energy supply can offset overnight cooling,
  and reduce the size of the night-time temperature
  drop on the surface.

20
4. Sensible heat transfer

• Warm air moving to a given point will contribute
  energy and keep temperatures up.
• By contrast, if cold air moves in energy levels
  will fall, with a possible reduction in
  temperature.
