The NESPOLE Interchange Format IF

1
The NESPOLE Interchange Format (IF)

• Lori Levin, Emanuele Pianta, Donna Gates, Kay
  Peterson, Dorcas Wallace, Herve Blanchon, Roldano
  Cattoni, Jean-Philippe Gibaud, Chad Langley, Alon
  Lavie, Nadia Mana, Fabio Pianesi

2
Outline

• Approaches to MT Interlingua, Transfer, Direct.
• The NESPOLE! Interlingua.
• Overview and motivation
• Linguistic coverage
• Tools and resources.
• Evaluating an interlingua
• Coverage how do we measure coverage of the
  domain
• Reliability so that an analyzer written by one
  person in Italy can work with a generator written
  by someone he has never met in Korea.
• Scalability move to broader semantic domains
  without a constant increase in the amount of work.

3
Outline

• Approaches to MT Interlingua, Transfer, Direct.
• The NESPOLE! Interlingua.
• Overview and motivation
• Linguistic coverage
• Tools and resources.
• Evaluating an interlingua
• Coverage
• Reliability
• Scalability

4
What is an interlingua?

• Representation of meaning or speaker intention.
• Sentences that are equivalent for the translation
  task have the same interlingua representation.
• The room costs 100 Euros per night.
• The room is 100 Euros per night.
• The price of the room is 100 Euros per night.

5
Interlingua
Give-informationpersonal-data (namealex_waibel)
Vaquois MT Triangle
s vp accusative_pronoun chiamare proper_name
s np possessive_pronoun name vp be
proper_name
Transfer
Mi chiamo Alex Waibel
My name is Alex Waibel.
Direct
6
Other Approaches to Machine Translation

• Direct
• Very little analysis of the source language.
• Transfer
• Analysis of the source language.
• The structure of the source language input may
  not be the same as the structure of the target
  language sentence.
• Transfer rules relate source language structures
  to target language structures.

7
Note

• Some transfer systems may produce a more detailed
  meaning representation than some interlingua
  systems.
• The difference is whether translation equivalents
  in the source and target languages are related by
  a single canonical representation.

8
Multilingual Translation with an Interlingua
Chinese (input sentence) San1 tian1 qian2, wo3
kai1 shi3 jue2 de2 tong4
French
Italian
Analyzers
Japanese
English
German
Korean
Catalan
give-informationonsetbody-state
(body-state-specpain, time(interval3d,
relativebefore))
Spanish
Arabic
Interlingua
Arabic
Spanish
Korean
Catalan
Chinese (paraphrase) wo3 yi3 jin1 tong4 le4 san1
tian1
French
Italian
Generators
Japanese
English (output sentence) The pain started three
days ago.
German
9
Multilingual translation with transfer

• Transfer-rules-1 Arabic-Catalan
• Transfer-rules-2 Catalan-Arabic
• Transfer-rules-3 Arabic-Chinese
• Transfer-rules-4 Chinese-Arabic
• Transfer-rules-5 Arabic-English
• Transfer-rules-6 English-Arabic
• Etc.

10
Advantages of Interlingua

• Add a new language easily
• get all-ways translation to all previous
  languages by adding one grammar for analysis and
  one grammar for generation
• Mono-lingual development teams.
• Paraphrase
• Generate a new source language sentence from the
  interlingua so that the user can confirm the
  meaning

11
Disadvantages of Interlingua

• Meaning is arbitrarily deep.
• What level of detail do you stop at?
• If it is too simple, meaning will be lost in
  translation.
• If it is too complex, analysis and generation
  will be too difficult.
• Should be applicable to all languages.
• Human development time.

12
Interlingual MT Systems

• University of Maryland Lexical Conceptual
  Structure (Dorr)
• Carnegie Mellon
• Kantoo (Mitamura and Nyberg)
• Nespole/C-STAR (Waibel, Levin, Lavie)
• UNL (Universal Networking Language)
• Microcosmos (Nirenburg)
• Verbmobil Domain actions (Block)

13
Outline

• Approaches to MT Interlingua, Transfer, Direct.
• The NESPOLE! Interlingua.
• Overview and motivation
• Linguistic coverage
• Tools and resources.
• Evaluating an interlingua
• Reliability
• Coverage

14
A Travel DialogueTranslated from Italian

• A Albergo Gabbia DOro. Good evening.
• B My name is Anna Maria DeGasperi. Im calling
  from Rome. I wish to book two single rooms.
• A Yes.
• B From Monday to Friday the 18th, Im sorry, to
  Monday the 21st.
• A Friday the 18th of June.
• B The 18th of July. Im sorry.
• A Friday the 18th of July to, you were saying,
  Sunday.
• B No. Through Monday the 21st.

15
A Travel Dialogue(Continued)

• B So with departure on Tuesday the 22nd.
• A Then leaving on the 22nd. Yes. We have two
  singles certainly.
• B Yes.
• A Would you like breakfast?
• B Is it possible to have all meals?
• A No. We serve meals only in the evening.
• B Ok. If you can do breakfast and dinner.
• A Ok.
• B Do you need a deposit?

16
A Travel Dialogue(Continued)

• A You can give me your credit card number.
• B Ok. Just a moment. Ok. My name is Anna
  Maria DeGaperi. The card is 005792005792.
• A Good.
• B Expiration 2002.
• A 2002. Good. Thank you. We need a
  confirmation on the 18th of July before 6pm.
• B Goodbye.
• A Thanks. Goodbye.
• B Thanks. Goodbye.

17
A Non-Task-Oriented Dialogue(We cant translate
this.)

• A Are you cooking?
• B My father is cooking. Im cleaning. I just
  finished cleaning the bathroom.
• A Look. What do you know about Monica?
• B I dont know anything. Look. I dont know
  anything.
• A You dont know anything? I wrote her three
  weeks ago, but if she hasnt received the letter,
  they would have returned it. I hope she received
  it.
• B Because Celia told me that the address that
  Monica had given us was wrong. She said that if
  I was going to write to her, well, .

From the Spanish CallHome corpus unlimited
conversation between family members.
18
The Ideal MT System

• Fully automatic
• High quality
• Domain independent (any topic)
• .isnt within the current state-of-the-art.

19
Design Principles of the Interchange Format

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

• Suitable for task oriented dialogue
• Based on speakers intent, not literal meaning
• Can you pass the salt is represented only as a
  request for the hearer to perform an action, not
  as a question about the hearers ability.
• Abstract away from the peculiarities of any
  particular language
• resolve translation mismatches.

20
Translation Mismatches

• Sentences that are translation-equivalents in two
  languages do not have the same syntactic
  structure or predicate-argument structure.
  (Unitrans Eurotra)
• I like to swim.
• I swam across the river.
• Sue met with Sam/Sue met Sam.

21
Design Principles (continued)

• Domain independent framework with domain-specific
  parts
• Simple and reliable enough to use
• at multiple research sites with high intercoder
  agreement.
• with widely varying type of parsers and
  generators.
• Allow robust language engines
• Underspeicification must be possible.
• Fragments must be represented.

22
Speech ActsSpeaker intention vs literal meaning

• Can you pass the salt?
• Literal meaning The speaker asks for information
  about the hearers ability.
• Speaker intention The speaker requests the
  hearer to perform an action.

23
Remember this term Domain Action
24
Domain Actions Extended, Domain-Specific Speech
Acts

• give-informationexistencebody-state
• It hurts.
• give-informationonsetbody-object
• The rash started three days ago.
• request-informationavailabilityroom
• Are there any rooms available?
• request-informationpersonal-data
• What is your name?

25
Domain ActionsExtended, Domain-Specific Speech
Acts

• In domain.
• I sprained my ankle yesterday.
• When did the headache start?
• Out of domain
• Yesterday I slipped in the driveway on my way to
  the garage.
• The headache started after my boss noticed that I
  deleted the file.

26
Formulaic Utterances

• Good night.
• tisbaH cala xEr
• waking up on good
• Romanization of Arabic from CallHome Egypt

27
Same intention, different syntax

• rigly bitiwgacny
• my leg hurts
• candy wagac fE rigly
• I have pain in my leg
• rigly bitiClimny
• my leg hurts
• fE wagac fE rigly
• there is pain in my leg
• rigly bitinqaH calya
• my leg bothers on me
• Romanization of Arabic from CallHome Egypt.

28
Language Neutrality

• Comes from representing speaker intention rather
  than literal meaning for formulaic and
  task-oriented sentences.
• How about suggestion
• Why dont you suggestion
• Could you tell me request info.
• I was wondering request
  info.

29
Domain Action Interlingua and Lexical Semantic
Interlingua

• and how will you be paying for this
• Domain Action representation
• arequest-informationpayment (methodquestion)
• Lexical Semantic representation
• predicate pay
• time future
• agent hearer
• product distance proximate, type
  demonstrative
• manner question

30
Complementary Approaches

• Domain actions limited to task oriented
  sentences
• Lexical Semantics less appropriate for formulaic
  speech acts that should not be translated
  literally

31
Components of the Interchange Format

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

• speaker a (agent)
• speech act give-information
• concept availabilityroom
• argument (room-type(single double),

• timemd12)

32
Components of IFas of February 2002

• 61 speech acts give-information
• domain independent,
• 20 are dialog managing
• 108 concepts availability,
  accommodation
• mostly domain dependent
• 304 arguments room-type, time
• domain dependent and independent
• 7,652 values single,
  double, 12th

33
Examples

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

• no thats not necessary
• cnegate
• yes I am
• caffirm
• my name is alex waibel
• cgive-informationpersonal-data
  (person-name(given-namealex, family-namewaibel)
  )
• and how will you be paying for this
• arequest-informationpayment (methodquestion)
• I have a mastercard
• cgive-informationpayment (methodmastercard)

34
Outline

• Approaches to MT Interlingua, Transfer, Direct.
• The NESPOLE! Interlingua.
• Overview and motivation
• Linguistic coverage
• Tools and resources.
• Evaluating an interlingua
• Reliability
• Coverage
• Scalability

35
Conventional Speec Acts

• thank you. cthank
• can I help you ?aofferhelp (whoi,
  to-whomyou)
• ltuhgt my name is Chadcgive-informationpersonal-d
  ata (person-name(given-namechad))

36
Fragments ellipsis

• ltBgt and ltuhgt lthmgt in a restaurant.
  agive-informationconcept
  (conjunctiondiscourse, location(restaurant,
  identifiabilityno))
• ltuhgt which town? crequest-informationconcept
  (concept-spec(town, identifiabilityquestion))

37
Fragments abandoned

• You should
• a suggestconcept (whoyou)
• What should I
• c request-suggestionconcept (whoI)

38
Coordination of Sentences

• I want to go to France and I would prefer to
  leave today.
• cgive-informationdispositiontrip
  (destination(object-namefrance),
  disposition(whoi, desire))
• cgive-informationdispositiondeparture
  (conjunctiondiscourse, time(relative-timetoday)
  , disposition(whoi, preference))

39
Coordination of sentences, reduced

• I want to leave Pittsburgh at 2 and return from
  Rome at 5.
• cgive-informationdispositiondeparture
  (conjunctiondiscourse, origin(object-namepittsb
  urgh), disposition(whoi, desire),
  time(clock(hours2)))
• cgive-informationtrip (conjunctiondiscourse,
  factualityunspecified, trip-specreturn,
  origin(object-namerome), time(clock(hours5)))


40
Conjunctive Set

• I like festivals and plays.
• cgive-informationdispositionevent (...
  event-spec(operatorconjunct, (festival,
  quantityplural), (play, quantityplural)))

41
Conjunction of modifiers

• I prefer red and blue cars.
• cgive-informationdispositionvehicle (...
  vehicle-spec(car, quantityplural,
  color(operatorconjunct, red, blue)))

42
Disjunctive Sets

• I prefer hotels or cabins.
• cgive-informationdispositionaccommodation (...
  accommodation-spec(operatordisjunct, (hotel,
  quantityplural), (cabin, quantityplural)))

43
Contrastive Set

• I like hotels but not cabins.
• cgive-informationdispositionaccommodation (...
  accommodation-spec(operatorcontrast, (hotel,
  quantityplural), (polaritynegative, cabin,
  quantityplural)))

44
Attitudes often a source of mismatches

• Disposition
• Eventuality
• Evidentiality
• Feasibility
• Knowledge
• Obligation
• Main verbs in English that occur in other
  languages as affixes, adverbs, or other
  construtions that are not clearly bi-clausal.

45
Disposition

• ltuhmgt ltPgt and I would like to arrive ltPgt around
  September ninth.cgive-informationdispositionar
  rival (disposition(whoi, desire),
  / attitude / conjunctiondiscour
  se, / rhetorical
  information / time(exactnessapproximate,
  month9, md9)) / time /

46
Disposition

• I would like to stay in a hotel.
• Dispositiondesire
• I hate mushroom picking.
• Dispositiondislike
• I am waiting to see the circle.
• Dispositionexpectation
• But wouldnt matter.
• Dispositionindifferent
• When do you plan on arriving in Pittsburgh?
• Dispositionintention

47
Eventuality

• It is possible I may be arriving earlier.
• give-informationeventualityarrival
• (eventualitypossible)
• Im sure that they will arrive tomorrow.
• Maybe there is something beautiful to see.
• It is not impossible.

48
Evidentiality Source of information

• Apparently there are many castles.
• Give-informationevidentialityattraction
• I heard there are many castles.
• I noticed there is a winter package available.
• Ive been told I must leave before ten.

49
Feasibility

• You can rent skis at the resort.
• Give-informationfeasibilityrentequipment
• (feasibilityfeasible.)

50
Knowledge

• I didnt know that Trento has lakes.
• Give-informationnegationknowledgecontainattrac
  tion
• (knowledge(whoI, polaritynegative),
  contain(lake, quantityplural),
  attraction-specname-trento)
• I know the location of the hotel.

51
Obligation

• You must make a reservation.
• Give-informationobligationreservation
  (obligationrequired.)
• You may cancel at any time.
• We require that you cancel 24 hours in advance.

52
Negation with limited facilities for
representing scope

• Of conventional speech act
• I didnt hear.
• Negate-dialogue-hear
• Of main predication
• I did not make a reservation.
• Give-informationnegationreserveaccommodation
  (polaritynegative)
• Of attitude
• I dont know if its all right.
• Give-informationnegationknowledgefeatureobject

• (knowledge(whoI, polaritynegative),
  object-specpronoun, feature(modifieracceptable)
  )

53
Negation

• I didnt promise I would not come.
• Negate-promisenegationaction
• Of a concept
• There is no downhill skiiing?
• Request-informationexistenceactivity
• (activity-spec(polaritynegative,
  downhill_skiing)

54
Relative Clauses

• Broken into two IFs.
• I want the hotel that you suggested.
• Give-informationdispositionaccommodation
• (disposition(desire, whoI),
• accommodation-spec(hotel, identifiabilityyes))
• Give-informationrecommendationobject
• (object-specrelative, whoyou, e-timeprevious)
• Sentence internal relative clauses (e.g.,
  modifying the subject) are not handled very well.
• The only hotel that I can show you is a four star
  hotel.
• No long-distance gaps.
• They are rare anyway.

55
Some simple relative clauses arent broken

• The hotel that is in Cavalese
• give-informationconcept
• (accommodation-spec(hotel,
  identifiabilityyes, locationname-cavalese))

56
Yes-No Questions

• Conventional speech act
• Do you hear me?
• Dialog-request-hear
• Does the flight leave at 200?
• Tell me if the flight leaves at 200.
• request-informationdeparture
• (transportation-spec(flight,
  identifiabilityyes), time(clock(hours2)))

57
Wh-questions

• Who is traveling?
• request-informationtrip (whoquestion)
• When are you traveling?
• What date are you traveling?
• How quiet is the hotel?
• Where are you traveling to?
• How are you traveling?
• What are you doing?
• No long distance gaps.

58
Rhetorical Relations

• Therefore I arrived late.
• give-informationarrival
• (causediscourse, whoI)
• I arrived late because of the snow
• give-informationarrival
• (whoI, causesnow, e-timeprevious, timelate)

59
Rhetorical Relations

• because I was tired.
• give-informationfeatureperson
• (rhetoricalcause, )
• Other relations after, before, besides,
  co-occurrence, concessive, condition,
  contrastive, dependency, purpose, related-to,
  restrictive-result, result, while

60
Outline

• Approaches to MT Interlingua, Transfer, Direct.
• The NESPOLE! Interlingua.
• Overview and motivation
• Linguistic coverage
• Tools and resources.
• Evaluating an interlingua
• Reliability
• Coverage
• Scalability

61
The Interchange Format Database
d.u.sdu olang X lang Y Prv Z sdu in language
Y on one line d.u.sdu olang X lang Z Prv Z sdu
in language Z on one line d.u.sdu
IF Prv Z IF on-one-line d.u. sdu
comments your comments d.u. sdu comments go
here
61.2.3 olang I lang I Prv IRST telefono per
prenotare delle stanze per quattro
colleghi 61.2.3 olang I lang E Prv IRST Im
calling to book some rooms for four
colleagues 61.2.3 IF Prv
IRST crequest-actionreservation featuresroom
(for-whom(associate, quantity4)) 61.2.3
comments dial-oo5-spkB-roca0-02-3
62
NESPOLE! Database

• Annotated turns (end 2001)
• English 815 (235 distinct DAs)
• German 2,873 (367)
• Italian 1,286 (233)
• French 234 (94)
• Total distinct DAs 610
• Annotated turns (end 2002) 30/40 more

63
Tools and Resources

• IF specifications (available on the web)
• http//www.is.cs.cmu.edu/nespole/db/index.html
• IF discussion board
• http//peace.is.cs.cmu.edu/ISL/get/if.html
• C-STAR and NESPOLE! Data Bases
• http//www.is.cs.cmu.edu/nespole/db/index.html
• IF Checker (web interface)
• http//tcc.itc.it/projects/xig/xig-on-line.html
• IF test suite
• http//tcc.itc.it/projects/xig/xig-ts.html
• IF emacs mode

64
The C-STAR Interchange Format Database
English Dialogues English Sentences Korean
Dialogues Korean Sentences Italian
Dialogues Italian Sentences Japanese
Dialogues Japanese Utterances Distinct Dialogue
Acts
36 2466 70 1142 5 233 124 5887 554 (310 agent,
244 client)
65
Outline

• Approaches to MT Interlingua, Transfer, Direct.
• The NESPOLE! Interlingua.
• Overview and motivation
• Linguistic coverage
• Tools and resources.
• Evaluating an interlingua
• Reliability
• Coverage
• Scalability

66
Comparison of two interlinguas

• I would like to make a reservation for the fourth
  through the seventh of July.
• IF-1 (C-STAR II, 1997-1999)
• crequest-actionreservationtemporalhotel
• (time(start-timemd4, end-time(md7,july)))
• IF-2 (NESPOLE, 2000-2002)
• cgive-informationdispositionreservation
• accommodation
• (disposition(whoI, desire),
• reservation-spec(reservation,
• identifiabilityno),
• accommodation-spechotel,
• object-time(start-time(md4),
• end-time(md7, month7,
• incl-exclinclusive)))


67
Comparison of four databases(travel domain, role
playing, spontaneous speech)
Same data, different interlingua

• DB-1 C-STAR II English database tagged with IF-1
• 2278 sentences
• DB-2 C-STAR II English database tagged with IF-2
• 2564 sentences
• DB-3 NESPOLE English database tagged with IF-2
• 1446 sentences
• Only about 50 of the vocabulary overlaps with
  the C-STAR database.
• DB-4 Combined database tagged with IF-2
• 4010 sentences

Significantly larger domain
68
Outline

• Approaches to MT Interlingua, Transfer, Direct.
• The NESPOLE! Interlingua.
• Overview and motivation
• Linguistic coverage
• Tools and resources.
• Evaluating an interlingua
• Reliability
• Coverage
• Scalability

69
Measuring Coverage

• No-tag rate
• Can a human expert assign an interlingua
  representation to each sentence?
• C-STAR II no-tag rate 7.3
• NESPOLE no-tag rate 2.4
• 300 more sentences were covered in the C-STAR
  English database
• End-to-end translation performance Measures
  recognizer, analyzer, and generator performance
  in combination with interlingua coverage.

70
Outline

• Approaches to MT Interlingua, Transfer, Direct.
• The NESPOLE! Interlingua.
• Overview and motivation
• Linguistic coverage
• Tools and resources.
• Evaluating an interlingua
• Reliability
• Coverage
• Scalability

71
Example of failure of reliability

• Input 300, right?
• Interlingua verify (time300)
• Poor choice of speech act name does it mean
  that the speaker is confirming the time or
  requesting verification from the user?
• Output 300 is right.

72
Measuring Reliability Cross-site evaluations

• Compare performance of
• Analyzer ? interlingua ? generator
• Where the analyzer and generator are built at the
  same site (or by the same person)
• Where the analyzer and generator are built at
  different sites (or by different people who may
  not know each other)
• C-STAR II interlingua comparable end-to-end
  performance within sites and across sites.
• around 60 acceptable translations from speech
  recognizer output.
• NESPOLE interlingua cross-site end-to-end
  performance is lower (but not clearly because of
  the IF).

73
Intercoder agreement average of percent
agreeent pairwise

74
Workshop on InterlinguaReliabilitySIG-IL

• Association for Machine Translation in the
  Americas
• October 8, 2002
• Tiburon, California
• Intent to participate in coding experiment
  (dependency representation)
• (email to lsl_at_cs.cmu.edu)

75
Outline

• Approaches to MT Interlingua, Transfer, Direct.
• The NESPOLE! Interlingua.
• Overview and motivation
• Linguistic coverage
• Tools and resources.
• Evaluating an interlingua
• Reliability
• Coverage
• Scalability

76
Comparison of four databases(travel domain, role
playing, spontaneous speech)
Same data, different interlingua

• DB-1 C-STAR II English database tagged with IF-1
• 2278 sentences
• DB-2 C-STAR II English database tagged with IF-2
• 2564 sentences
• DB-3 NESPOLE English database tagged with IF-2
• 1446 sentences
• Only about 50 of the vocabulary overlaps with
  the C-STAR database.
• DB-4 Combined database tagged with IF-2
• 4010 sentences

Significantly larger domain
77
Measuring Scalability Coverage Rate

• What percent of the database is covered by the
  top n most frequent domain actions?

78
Measuring Scalability Number of domain actions
as a function of database size

• Sample size from 100 to 3000 sentences in
  increments of 25.
• Average number of unique domain actions over ten
  random samples for each sample size.
• Each sample includes a random selection of
  frequent and infrequent domain actions.

79
(No Transcript)
80
Comparison of four databases(travel domain, role
playing, spontaneous speech)
Same data, different interlingua

• English database 1 tagged with interlingua 1
  2278 sentences
• English database 1 tagged with interlingua 2
  2564 sentences
• English database 2 tagged with interlingua 2
  1446 sentences
• Only about 50 of the vocabulary overlaps with
  the English database 1.
• Combined databases tagged with interlingua 2
  4010 sentences

Significantly larger domain
81
Conclusions

• An interlingua based on domain actions is
  suitable for task-oriented dialogue
• Reliable
• Good coverage
• Scalable without explosion of domain actions
• It is possible to evaluate an interlingua for
• Realiability
• Expressivity
• Scalability

82
How to have success with an interlingua in a
multi-site project

• Keep it simple.
• Periodically check for intercoder agreement.
• Good documentation
• Discussion board for developers
• Know your language typology.
