Title: ACL Injury Prevention Programs
1ACL Injury Prevention Programs
- Al T. Douex, Jr., MS, ATC
- Medical Aspects of Sports Conference
- University of Delaware
- 02/25/06
2Anatomy
- Anterior Cruciate Ligament
- Originates at posteromedial corner of lateral
femoral condyle - Inserts at anterolateral aspect of tibial spine
- Functions
- Prevents anterior translation of tibia on the
femur - Prevents hyperextension
- Secondary stabilizer to valgus and rotational
stress
3Mechanisms of Injury
- Common MOIs
- Slight knee flexion w/ tibial EROT/IROT at foot
strike - Excessive valgus, varus, hyperextension or
rotation - Guillotine
- Quads active
- Skiing
- Phantom Foot
- Knee Hyperextension in ski boot
- Valgus rotation
- Other Sports
- Sudden Deceleration
- Abrupt change of direction (fixed foot)
- Single leg landing
4Background
4 7x increased risk for ACL injury
500 900 increased female participation in
sports
Overall increased incidence of ACL injuries
5Healthcare Implications
- In U.S., estimated 38,000 Female ACL
injuries/year (athletics) - 200,000 ACL injuries/yr.
- 75,000 total ACL Reconstructions/yr.
- Estimated cost of 17K each
- Increased risk for OA
http//www.youcanbefit.com/ACL.html
6Intervention Programs Do Work!!!
Hewett et al. 1999
Mandalbaum et al. 2005
7Hewett et al. (2005)
- there appear to be 3 major etiological
contributions to the gender disparity observed in
ACL injury rates, namely, anatomical (in essence
nonmodifiable by nature), hormonal (extent to
which these can be modified remain unclear), and
neuromuscular. - Specifically, dynamic joint stabilization is
achieved via a combination of active muscle force
and passive ligament restraints.
8Training Perspectives
- Prophylactic training
- Comprehensive neuromuscular training
- ID at-risk athletes
- Sport/Position
- Age/Developmental stage
- Potentially dangerous maneuvers
- Address specific deficits
- Weakness
- Technique
- Endurance
- Neuromuscular Imbalances
9Neuromuscular Imbalances
- 3 typical traits in females
- Ligament Dominance
- Athlete allows ligaments to absorb GRF
- Quadriceps Dominance
- Athlete preferentially increases knee extensor
moments - Leg Dominance
- Athlete demonstrates side-to-side differences in
lower extremity measures
http//www.udel.edu/sportsinfo/womens_basketball
10 Neuromuscular Components
http//accelerationclinic.tripod.com/foursquare.jp
g
- Strength Training
- Resistance
- Plyometrics
- Proprioception
- Sport Specific
- Dynamic Training
- Education
11Address Landing Phenomenon
Hewett et al. 2002
12Strength Training
- Appropriate functional ratio between quadriceps
and hamstrings - Co-contraction, coordination timing
- Knee dynamic stabilizers
- Strength to control load vs. GRF
- ? peak landing forces, valgus/varus torques
- Incorporate plyometrics
13Proprioceptive Training
- ACL plays a significant role in normal
proprioception of the knee - Uninjured females inherently more stable than
males injured/reconstructed females less stable
and recover slower (SLS) - Learn to control loads in coronal plane
- Develop dynamic balance
14Proprioception - Athletic Position
Myer et al. 2004
15Proprioceptive Training
Soderman et al. 2000
Myer et al. 2004
16Sport-Specific Training
- Train Jump/Cut landings
- Control for Dynamic Valgus
- Land using a more bent-knee position
- Train deceleration
- Incorporate speed and agility drills
- ? muscle dominance, ? ligament dominance
Hewett et al. 2005
17Wall Jumps
Myer et al. 2004
18Tuck Jumps
Myer et al. 2004
19 Broad Jump Single Leg Hop Hold
Myer et al. 2004
Myer et al. 2004
20180 Jump
Myer et al. 2004
21Squat Jumps
Myer et al. 2004
22X Hops - Bounding
Myer et al. 2004
Myer et al. 2004
23Jump, Jump, Jump, Vertical Jump
Myer et al. 2004
24Education
- Emphasize awareness of dangerous positions,
MOIs, etc. - Vermont Ski Instructors
- Feedback/critical analysis of technique
- Partner training
http//www.skivermont.com/
25Continue to Emphasize Technique
- For jumps/cuts, 4 basic techniques should be
stressed - Correct posture throughout jump
- Alignment and distribution
- No excessive side-to-side or A/P movement
- Soft landings
- Toe-Heel rocking, knees bent, etc.
- Instant recoil
- Preparation for next jump
26Take Home
- We need to train athletes in such a way that they
develop feed-forward mechanisms designed to
protect them when presented with a
biomechanically dangerous and disadvantageous
position - Sell Performance Enhancement (not just Injury
Prevention)
27Thank You - Questions
- For more information on specific protocols, refer
to - Cincinnati Childrens Hospital, Sports Medicine
Biodynamics Center and Human Performance
Laboratory (Cincinnati, OH) - Santa Monica Orthopaedic and Sports Medicine
Research Foundation (Santa Monica, CA) - adouex_at_udel.edu
http//www.onlineathens.com/images/120300/women_ca
