Kishore P.

1
Invasive Mechanical Ventilation
2

• Ventilate is derived from
• Latin word ventus meaning wind

3
Mask based device
Negative pressure ventilators The Iron Lung
4
Why ventilate?

• Improve oxygenation
• Increase/maintain minute ventilation and help CO2
  clearance
• Decrease work of breathing
• Protect airway

5
Common indications for ventilation

• Hypoxemic respiratory failure 66
• Acute exacerbation of COPD 13
• Neuromuscular disorders - 10
• Coma - 10

Data from Americas and Europe
Am. J. Respir. Crit. Care Med., Volume 161,
Number 5, May 2000, 1450-1458
6
Key concepts

• Determinants of Oxygenation
• - Ventilator factors
• FiO2 ( fraction of oxygen in inspired air)
• Mean airway pressure
• PEEP ( positive end expiratory pressure)
• - Patient factors
• V/Q (ventilation/ perfusion) mismatch
• Shunt
• Diffusion defect
• Reduced mixed venous oxygen

7
Key concepts

• Determinants of CO2 clearance
• - Ventilator factors
• Rate
• Tidal volume
• Anatomical dead space
• - Patient factors
• Physiological dead space
• CO2 production

Alveolar minute ventilation
8

• Adjust FiO2 and PEEP according to PaO2 and SpO2
• Adjust TV and rate according to PCO2 and pH

9
Modes of ventilationVolume controlled

• Machine delivers a set volume irrespective of the
  pressure generated within the system
• Adv.
• - predefined minute volume is guaranteed
• Disadv.
• - changes in mechanical properties of lungs
  (resistance or compliance) can lead to high
  pressures
• - Patient is unable to adjust breathing pattern
  to changes in ventilatory demand

10
Modes of ventilationPressure controlled

• Ventilator applies a predefined target pressure
  to the airway during inspiration
• Adv.
• - decreased risk of barotrauma
• Disadv.
• - with decreasing compliance or increasing
  resistance, tidal volume and minute ventilation
  fall

11
Volume control
Pressure control

• TV, inspiratory flow, IE ratio
• Tidal volume
• Airway pressure

• Peak inspiratory pressure, inspiratory time,
• Maximum inspiratory pressure
• Tidal volume

Settings
Constant
Variable
12
Patient system interaction
CPAP
PEEP
Spontaneous
SIMV
IMV
Assist control
Assisted-pressure support
Controlled MV
13
Continuous mandatory ventilation (CMV)

• Also known as controlled mechanical ventilation
• Rate, IE ratio, volume determined entirely by
  machine and cannot be altered by patient effort
• Used in paralyzed patients only

14
Intermittent mandatory ventilation (IMV)

• Patient is allowed to take spontaneous breaths in
  between preset timed ventilator breaths
• The ventilator does not offer any assistance to
  the spontaneous breaths
• Stacking of breaths may occur

15
(No Transcript)
16
Assist control (A/C)

• In addition to a preset number of mandatory
  breaths, the ventilator delivers additional full
  breaths whenever the patient has a spontaneous
  respiratory effort
• Sensitivity of trigger important

17
(No Transcript)
18
Synchronized intermittent mandatory ventilation
(SIMV)

• The ventilator attempts to synchronize the set
  number of mandatory breaths with the patients
  respiratory efforts
• The ventilator waits for a patient effort during
  a sensitive peroid before every breath. In its
  absence, it gives a controlled breath
• Spontaneous breaths outside of this sensitive
  period are unsupported
• Commonly used mode

19
(No Transcript)
20
Pressure support

• Delivers a breath to a preset airway pressure
  when the patient makes an inspiratory effort
• Cycles into expiration when inspiratory flow
  falls toward end of inspiration
• Used along with SIMV
• Useful for weaning

21
Newer modes

• Hype
• Add to cost
• No reliable evidence for better outcomes in terms
  of mortality, duration of ventilation

22
Adaptive support ventilation (ASV)

• A weight based minimum minute ventilation is set.
• the machine decides how to achieve that MV with
  the least work of breathing-fixes an appropriate
  TV and rate
• Decreases the need for frequent reassessment and
  changes in ventilator settings
• No outcome difference

23
Proportional assist ventilation (PAV)

• Useful weaning mode
• The proportion of work of breathing to be
  contributed by the ventilator is set
• Each breath gets a different degree of support
  from the ventilator depending on patient effort.
• Theoretically smooth offloading

24
Others

• Airway pressure release ventilation (APRV)
• Pressure controlled inverse ratio ventilation

25
Patient system interaction
CPAP
PEEP
Spontaneous
SIMV
IMV
Assist control
Assisted-pressure support
Controlled MV
26

• One of the key goals of mechanical ventilation is
  to decrease work of breathing
• Improper ventilator settings can however increase
  work of breathing, increasing patient distress
  and worsening hemodynamics and metabolic
  parameters

27
Remember

• Ventilation is not an end in itself, it is only a
  form of organ support
• The nuances of ventilation should not take away
  from the primary goal of treating the underlying
  condition

28
Whos Watching the Patient?
Pierson, IN Tobin, Principles and Practice of
Critical Care Monitoring
29
Default settings

• TV-6-8ml/kg
• Rate 15/min
• FiO2 100
• PEEP 5cmH2O
• Pressure support 15cmH2O
• Ti 1.0 sec
• Pramp 50msec

30
Monitor and re-adjust

• FiO2-
• based on PaO2 and SpO2. maintain PaO2 60-90mmHg
• Aim to reduce FiO2 below 60
• PEEP-
• based on PaO2 and SpO2.
• Aim to reduce FiO2 below 60.
• Can increase rapidly but can be reduced very
  gradually

31
Monitor and re-adjust

• Rate
• To keep CO2 in normal range-30 to 50 mmHg
• Exceptions ?ICP, acute phase of MACD
• Pressure support
• Spontaneous breaths should have at least 80 of
  set TV
• Tidal volume
• Adjust so that peak pressure lt 30cm H2O
• Ti
• clinical and graphical synchrony
• Pramp
• increase only in obstructed airways

32
Adjuncts

• Tracheobronchial hygiene
• Sedation and analgesia
• Stress ulcer prophylaxis
• DVT prophylaxis
• Eye care

33
Considerations while buying a new ventilator

• Advanced modes are expensive-do you really need
  them
• Must have NIV
• Cost must include humidifier, nebulizer,
  compressor
• Find out cost of replacables-flow sensors
• Service back up
• Try out for a week in the ICU-hands on
• Bargain, bargain, bargain..
