FORCED VIBRATION

1
FORCED VIBRATION DAMPING
2
Damping

• a process whereby energy is taken from the
  vibrating system and is being absorbed by the
  surroundings.
• Examples of damping forces
• internal forces of a spring,
• viscous force in a fluid,
• electromagnetic damping in galvanometers,
• shock absorber in a car.

3
Free Vibration

• Vibrate in the absence of damping and external
  force
• Characteristics
• the system oscillates with constant frequency and
  amplitude
• the system oscillates with its natural frequency
• the total energy of the oscillator remains
  constant

4
Damped Vibration (1)

• The oscillating system is opposed by dissipative
  forces.
• The system does positive work on the
  surroundings.
• Examples
• a mass oscillates under water
• oscillation of a metal plate in the magnetic field

5
Damped Vibration (2)

• Total energy of the oscillator decreases with
  time
• The rate of loss of energy depends on the
  instantaneous velocity
• Resistive force ? instantaneous velocity
• i.e. F -bv where b damping coefficient
• Frequency of damped vibration lt Frequency of
  undamped vibration

6
Types of Damped Oscillations (1)

• Slight damping (underdamping)
• Characteristics
• - oscillations with reducing amplitudes
• - amplitude decays exponentially with time
• - period is slightly longer
• - Figure
• -

7
Types of Damped Oscillations (2)

• Critical damping
• No real oscillation
• Time taken for the displacement to become
  effective zero is a minimum
• Figure

8
Types of Damped Oscillations (3)

• Heavy damping (Overdamping)
• Resistive forces exceed those of critical damping
• The system returns very slowly to the equilibrium
  position
• Figure
• Computer simulation

9
Example moving coil galvanometer (1)

• the deflection of the pointer is critically damped

10
Example moving coil galvanometer (2)

• Damping is due to induced currents flowing in the
  metal frame
• The opposing couple setting up causes the coil to
  come to rest quickly

11
Forced Oscillation

• The system is made to oscillate by periodic
  impulses from an external driving agent
• Experimental setup

12
Characteristics of Forced Oscillation (1)

• Same frequency as the driver system
• Constant amplitude
• Transient oscillations at the beginning which
  eventually settle down to vibrate with a constant
  amplitude (steady state)

13
Characteristics of Forced Oscillation (2)

• In steady state, the system vibrates at the
  frequency of the driving force

14
Energy

• Amplitude of vibration is fixed for a specific
  driving frequency
• Driving force does work on the system at the same
  rate as the system loses energy by doing work
  against dissipative forces
• Power of the driver is controlled by damping

15
Amplitude

• Amplitude of vibration depends on
• the relative values of the natural frequency of
  free oscillation
• the frequency of the driving force
• the extent to which the system is damped
• Figure

16
Effects of Damping

• Driving frequency for maximum amplitude becomes
  slightly less than the natural frequency
• Reduces the response of the forced system
• Figure

17
Phase (1)

• The forced vibration takes on the frequency of
  the driving force with its phase lagging behind
• If F F0 cos ?t, then
• x A cos (?t - ?)
• where ? is the phase lag of x behind F

18
Phase (2)

• Figure
• 1. As f ? 0, ? ? 0
• 2. As f ? ?, ? ? ?
• 3. As f ? f0, ? ? ?/2
• Explanation
• When x 0, it has no tendency to move. ?maximum
  force should be applied to the oscillator

19
Phase (3)

• When oscillator moves away from the centre, the
  driving force should be reduced gradually so that
  the oscillator can decelerate under its own
  restoring force
• At the maximum displacement, the driving force
  becomes zero so that the oscillator is not pushed
  any further
• Thereafter, F reverses in direction so that the
  oscillator is pushed back to the centre

20
Phase (4)

• On reaching the centre, F is a maximum in the
  opposite direction
• Hence, if F is applied 1/4 cycle earlier than x,
  energy is supplied to the oscillator at the
  correct moment. The oscillator then responds
  with maximum amplitude.

21
Bartons Pendulum (1)

• The paper cones vibrate with nearly the same
  frequency which is the same as that of the
  driving bob
• Cones vibrate with different amplitudes

22
Bartons Pendulum (2)

• Cone 3 shows the greatest amplitude of swing
  because its natural frequency is the same as that
  of the driving bob
• Cone 3 is almost 1/4 of cycle behind D. (Phase
  difference ?/2 )
• Cone 1 is nearly in phase with D. (Phase
  difference 0)
• Cone 6 is roughly 1/2 of a cycle behind D. (Phase
  difference ?)

Previous page
23
Hacksaw Blade Oscillator (1)
24
Hacksaw Blade Oscillator (2)

• Damped vibration
• The card is positioned in such a way as to
  produce maximum damping
• The blade is then bent to one side. The initial
  position of the pointer is read from the attached
  scale
• The blade is then released and the amplitude of
  the successive oscillation is noted
• Repeat the experiment several times
• Results

25
Forced Vibration (1)

• Adjust the position of the load on the driving
  pendulum so that it oscillates exactly at a
  frequency of 1 Hz
• Couple the oscillator to the driving pendulum by
  the given elastic cord
• Set the driving pendulum going and note the
  response of the blade

26
Forced Vibration (2)

• In steady state, measure the amplitude of forced
  vibration
• Measure the time taken for the blade to perform
  10 free oscillations
• Adjust the position of the tuning mass to change
  the natural frequency of free vibration and
  repeat the experiment

27
Forced Vibration (3)

• Plot a graph of the amplitude of vibration at
  different natural frequencies of the oscillator
• Change the magnitude of damping by rotating the
  card through different angles
• Plot a series of resonance curves

28
Resonance (1)

• Resonance occurs when an oscillator is acted upon
  by a second driving oscillator whose frequency
  equals the natural frequency of the system
• The amplitude of reaches a maximum
• The energy of the system becomes a maximum
• The phase of the displacement of the driver leads
  that of the oscillator by 90?

29
Resonance (2)

• Examples
• Mechanics
• Oscillations of a childs swing
• Destruction of the Tacoma Bridge
• Sound
• An opera singer shatters a wine glass
• Resonance tube
• Kundts tube

30
Resonance (3)

• Electricity
• Radio tuning
• Light
• Maximum absorption of infrared waves by a NaCl
  crystal

31
Resonant System

• There is only one value of the driving frequency
  for resonance, e.g. spring-mass system
• There are several driving frequencies which give
  resonance, e.g. resonance tube

32
Resonance undesirable

• The body of an aircraft should not resonate with
  the propeller
• The springs supporting the body of a car should
  not resonate with the engine

33
Demonstration of Resonance (1)

• Resonance tube
• Place a vibrating tuning fork above the mouth of
  the measuring cylinder
• Vary the length of the air column by pouring
  water into the cylinder until a loud sound is
  heard
• The resonant frequency of the air column is then
  equal to the frequency of the tuning fork

34
Demonstration of Resonance (2)

• Sonometer
• Press the stem of a vibrating tuning fork against
  the bridge of a sonometer wire
• Adjust the length of the wire until a strong
  vibration is set up in it
• The vibration is great enough to throw off paper
  riders mounted along its length

35
EXAMPLES
36
Oscillation of a metal plate in the magnetic field
37
Slight Damping
38
Critical Damping
39
Heavy Damping
40
Amplitude
41
Phase
42
Bartons Pendulum
43
Damped Vibration
44
Resonance Curves
45
Swing
46
Tacoma Bridge
Video
47
Resonance Tube
A glass tube has a variable water level and a
speaker at its upper end
48
Kundts Tube
49
Sonometer
