GRASP Patterns

1
GRASP Patterns
2
Challenge

• Old-school advice on OOD
• After identifying your requirements and creating
  a domain model, then add methods to the
  appropriate classes, and define the messages
  between the objects to fulfill the requirements.
• New-school advice there are consequences to
• where we place methods
• they way objects interact in our design
• specific principles can help us make these
  decisions
• Note This is not UML!
• UML is a notation
• Larman The critical design tool for software
  development is a mind well educated in design
  principles.

3
Recall The big picture

• Object design is part of the larger modeling
  effort
• some inputs to modeling
• Whats been done?
• How do things relate?
• How much design modeling to do, and how?
• What is the output?
• Domain models, SDDs
• some outputs from modeling
• object design (UML diagrams interaction, class,
  package)
• UI sketches and prototypes
• database models
• sketches of reports and prototypes

4
Design of objects

• Responsibility-driven design (RDD)
• What are an objects responsibilities?
• What are an objects roles?
• What are an objects collaborations?
• The term is important
• We are initially trained to think objects in
  terms of data structures and algorithms
  (attributes and operations)
• RDD shifts this by treating objects as having
  roles and responsibilities
• Objects then become
• service providers
• information holders
• coordinators, controllers
• interfaces, etc.

5
What is an object responsibility?

• Doing
• doing something itself (creating an object
  performing a calculation)
• initiating action in other objects
• controlling and coordinating activities in other
  objects
• Knowing
• knowing about private encapsulated data
• knowing about related objects
• knowing about things it can derive or calculate
• Responsibilities vary in granularity
• big (hundreds of classes) example provide
  access to relational databases
• small (one method) example create an instance
  of Sale

6
What is an object collaboration?

• Assumption
• responsibilities are implemented by means of
  methods
• the larger the granularity of responsibility, the
  larger the number of methods
• this may entail an object interacting with itself
  or with other objects
• Therefore
• fulfilling responsibilities requires
  collaborations amongst different methods and
  objects
• Low representational gap
• RDD is a metaphor
• Objects are modeled as similar to persons /
  systems with responsibilities
• Community of collaborating responsible objects

7
A couple of parenthetical comments

• Responsibility here implies non-interference
• This is idealized (i.e., in the real world this
  is not necessarily true in boundary cases)
• However it is suitable enough for object design
• Suitable for programming-in-the-large
• As opposed to programming-in-the-small
• This is a qualitative difference
• mass of details
• amount of communication
• this become overwhelming
• Practical as opposed to theoretical

8
GRASP

• Craig Larmans methodical approach to OO design
• In essence
• a tool to help apply responsibilities to OOD
  design
• designed (and meant to be used as) methodical,
  rational, explainable techniques
• They are patterns of assigning responsibilities
• Note the use of pattern here is slightly
  different from some that intended by the GoF book
• Recognizes that responsibility assignment is
  something already do
• UML interaction diagrams are about assigning
  responsibilities

9
A bit more about pattern terminology

• Patterns as applied to architecture
• invented by Christopher Alexander
• context that of a pattern language for
  designing spaces used by humans
• Classic design patterns for software
• invented by the Gang of Four (GoF) (Gamma,
  Johnson, Helm, Vlissides)
• Patterns is now a rather loose term
• Conferences exist to look at patterns
• http//hillside.net/plop/2005/
• Larman has a special meaning for his GRASP
  patterns

10
What is a GRASP pattern?

• A named and well-known problem/solution pair
• General enough to be applied to new contexts
• Specific enough to give advice on how to apply it
• Especially important for novel situations
• Also comes with a discussion of
• trade-offs
• implementations
• variations

11
Specifically GRASP

• Defines nine basic OO principles
• basic building blocks for OO designs
• Meant to be pragmatic
• Meant to be a learning aid
• aids naming the group of ideas
• aids in presenting insight of ideas
• aids in remembering basic, classic design ideas
• Also intended for combination with
• a development process (UP)
• an organizational metaphor (RDD)
• a visual modeling notation (UML)

12
The Nine GRASP Patterns

• Creator
• Information Expert
• Low Coupling
• Controller
• High Cohesion

• Polymorphism
• Pure Fabrication
• Indirection
• Protected Variations

13
1. GRASP Creator
Problem Who should be responsible for creating a
new instance of some class? Example Who is
responsible for creating SalesLineItem?

• Object creation is one of the most common OO
  activities
• (However, set aside for now such concerns as
  Factory Method vs. Abstract Factory)
• Creator principle is meant to help us achieve
• low coupling
• increased clarity
• increased encapsulation
• increased reusability

Recall We also have a Register class floating
about.
14
Jargon alert terms and definitions
coupling the degree to which each program module
relies on other modules
cohesion a measure of how well the operations in
a module work together to provide a specific
piece of functionality
encapsulation synonym for information hiding
reusability likelihood a segment of structured
code can be used again to add new functionality
with slight or no modification
15
1. GRASP Creator

• Problem statement
• Who should be responsible for creating a new
  instance of some class?
• Solution
• Assign class B the responsibility to create an
  instance of class A if one of these is true (
  the more the better)
• B contains or compositely aggregates A.
• B records A
• B closely uses A.
• B has initializing data for A (i.e., B is an
  Expert with respect to creating A).

16
1. GRASP Creator
Who is responsible for creating SalesLineItem?

• Sale will contain many SalesLineItem objects
• Creator GRASP pattern suggests Sale is one object
  that could fulfill this responsibility.
• Consequences
• makeLineItem becomes a method in Sale.
• we capture this decision in our UML design-model
  diagrams

17
GRASP patterns give you more

• Each of these patterns comes with
• a discussion section
• a contraindication section
• a benefits section
• a related patterns or principles section
• Important!
• these patterns provide advice on assignment of
  responsibilities
• patterns may conflict in their advice
• there we must exercise some judgment in applying
  these patterns
• the extra sections help us with thi
• This is not mechanical work!

18
1. GRASP Creator

• Discussion
• intent is to support low coupling (i.e., creator
  is found that already needs to be connected to
  created object)
• initializing data is sometimes an indicator of a
  good Creator
• some object constructors have complex signatures
• which objects have the information needed to
  supply parameter values for such constructors?
• Contraindications
• creation can be complex (recycled instances,
  creating an instance from a family of similar
  classes)
• may wish to use Factory Method or Abstract
  Factory instead in these cases

19
1. GRASP Creator

• Benefits
• low coupling has already been mentioned
• why is this good?
• Related patterns or principles
• Low Coupling
• Factory Method and Abstract Factory
• Whole-Part pattern defines aggregate objects
  that support encapsulation of components

20
Reality Check
21
2. GRASP Information Expert

• Problem statement What is a general principle of
  assigning responsibilities to objects?
• Recall design model may end up very large
  (hundreds of classes and methods)
• If assignment of responsibilities is well chosen,
  result is an easy to understand system
• Solution
• Assign a responsibility to the information expert
• This expert is the class that has the information
  needed to fulfill the responsibility

22
Key idea
(Clear Statement Rule) Start assigning
responsibilities by clearly stating the
responsibility.
23
2. GRASP Information Expert

• NextGEN POS will end up with lots of
  functionality
• One small part of this is class that knows the
  grand total of a sale
• Clear Statement rule could transform this into
• Who should be responsible for knowing the grand
  total of a sale?
• Which class of objects has the information needed
  to determine the total?

If there are relevant classes in the design
model, then look there first for classes
otherwise look into the Domain Model in order
to us or expand its representations to suggest
the creation of appropriate classes
24
2. GRASP Information Expert
new method
new method
25
2. GRASP Information Expert
new method
26
Comment

• Notice how the initial assignment of
  responsibilities drove the design
• Result is the identification of several new
  methods
• Interaction diagram helped us capture the result
• Class model entities are also modified
• Also notice the degree of delegation
• getSubtotal (vs. getPrice and getQuantity
  to supply a multiplication operation)

27
2. GRASP Information Expert

• Read text for full details on patterns
• Discussion
• Contraindications (important!)
• Benefits
• Information encapsulation
• low coupling
• behavior is distributed across classes (i.e.,
  high cohesion)
• Related Patterns
• Low coupling
• High cohesion

28
3. GRASP Low Coupling

• Problem
• How can our design support
• low dependency?
• low change impact?
• increased reuse?
• Solution
• Assign a responsibility so that coupling remains
  low.
• Use this principle to evaluate alternative
  assignment of responsibilities.

29
Key idea
Coupling affects global understanding, but
decisions about placing responsibility must be
made more locally, usually by choosing from
amongst alternatives.
30
Example

• NextGen POS dealing with Payments
• What object should be responsible for
  associating Payments with Sales?
• Three objects appear to be involved
• Real-world domain Register records a Payment
  (Creator?)
• Also in real-world A Register also records
  Sales.

31
Example

• Suppose we apply our two previous GRASP patterns
  like so
• (Creator) Suggests Register as a candidate for
  creating Payments.
• (Information Expert) Register knows about
  Payments, and therefore associates these with
  Sales
• Resulting interaction diagram appears below

32
Example

• Recall Our GRASP pattern is to be applied to
  alternatives.
• Another approach
• (Creator) Suggests Sales creates Payments

33
Evaluating Alternatives
Which design choice results in lower coupling?
34
Kinds of Coupling

• Often applied to types or classes
• Class X has an attribute referring to Class Y
  instance
• Class X objects call on the services of a Class Y
  object
• Class X has methods referencing instances of
  Class Y (i.e., parameters, local variables of
  Class Y)
• Class X is a direct or indirect subclass of Class
  Y
• Y is an interface, and Class X implements it
• Note
• All of these are needed at some point
• We are not trying to eliminate coupling, but
  rather make careful choices

35
Important contra-indicator

• There is a least one set of objects and classes
  to which we must allow our code to be
  highly-coupled
• Java libraries (i.e., javax.swing, java.util)
  etc.
• C libraries
• .NET libraries
• Key features permitting this
• these are stable
• they are widespread

36
4. GRASP Controller

• Problem
• What first object beyond the UI layer receives
  and coordinates (controls) a system operation?
• Solution
• Assign responsibility to a class based on one of
  the following
• class is root object for overall system (or
  major subsystem)
• a new class based on use case name

37
Context

• This usually is applied to the actions recorded
  in our SSDs
• system events generated by some GUI
• we do not write to the GUI just yet, but assume
  some UI layer
• Therefore we do not have window, view or
  document classes
• Be very careful here as we are so tied to GUIs
  when visualizing applications
• GUI is meant to delegate tasks to system

38
Example (NextGen POS)
Which class of object should be responsible for
receiving the enterItem() system event message?
Register? POSSystem? These represent overall
system, root object, device, or subsystem.
ProcessSaleHandler?ProcessSaleSession?(these
would be new) These represent a receive or
handler of all system events of a use case
scenario.
39
Example NextGen POS
Here are the two basic alternatives.
(And how do we choose from amongst them?)
40
Caveats

• A balance must be striked between having too many
  controllers and too few
• More common problem too few (i.e., bloated
  controllers)
• Example
• single controller classes for all events (façade)
• controller performs many of the events itself
  rather than delegate work
• controller maintain a lot of state about the
  system (e.g., variables and attributes)

41
5. GRASP High Cohesion

• Problem
• How can we keep objects in our design
• focused?
• understandable?
• manageable?
• Solution
• Assign a responsibility so that cohesion remains
  high.
• As with low coupling, use this evaluate
  alternatives to placing responsibilities in
  objects

42
Signs of Low Cohesion

• Classes that do too many unrelated things or
  which too too much work
• Such classes are
• hard to comprehend
• hard to reuse
• hard to maintain
• delicate in that any change elsewhere in the
  system requires many changes in this class
• In general
• the greater the granularity of classes, the lower
  the cohesion
• but we do not want to go to the other extreme
  (i.e., lots and lots of classes, each doing one
  trivial thing)

43
Compare and contrast
(Yet again) What class should be responsible for
creating and class instance and associating it
with a Sale?
We have two options. Which shows both high
cohesion and low coupling?
44
Contra-indicators

• Simple people-management issues
• Large class maintained by a single programmer
• Performance
• Distributed systems
• Any place where the overhead of invoking an
  operation is a significant proportion of
  performing the operation

45
6. GRASP Polymorphism

• Problem
• How can we handle alternatives based on type?
• How can we create pluggable software components?
• Alternatives based on type
• Old style conditional variation (if-then-else,
  examination of tags, type testing)
• Pluggable software components
• Usually applied to client-server relationships
• How can we replace one server component with
  another and not need to rewrite the client?

46
6. GRASP Polymorphism

• Solution
• Use object type to declare alternative behavior.
• Then use polymorphic operations to define the
  alternative behavior
• Insight We no longer need to test for object
  type, instead allowing compiler run-time system
  to do this work for us.
• We have seen one important flavour of this
  already
• Always program to an interface and not to a
  concrete instance.

47
NextGen POS example taxes

• A NextGen POS use case specifies multiple
  external third-party tax calculators
• Tax-Master
• Good-As-Gold Tax Pro
• others as yet unknown
• Intent is to have system integrate with each of
  these
• Each tax calculator, however, has a different
  interface
• Solution?

48
Polymorphism via Adapter
49
Polymorphism slight detour

• Parametric polymorphism
• What we obtain using generics
• Example
• Creating a list of integers vs. a list of
  instances of class B
• List operations are not re-written for different
  types
• Impossible to insert an integer onto a list for
  class B instances
• Range of possible types usable is infinite
• Ad-hoc polymorphism
• What we obtain via subclassing
• Range of possible types usable is finite
• (Also this is what we get with overloading)

50
Polymorphism interfaces

• Single-inheritance languages
• Java, C Class may have only one superclass
• Difficult to mix in behaviors or capabilities
• Multiple-inheritance languages
• C, Eiffel
• May now mix in behaviors, but this can have
  unintended consequences
• Interfaces
• Provides the mix in capability of multiple
  inheritance
• but without some of the major problems with
  multiple inheritnace.

51
6. GRASP Polymorphism

• Contraindicators
• May not need to future proof the code (or at
  least not as much as we think)
• Cute
• Novice developers tend toward brittle designs
• intermediate developers tend toward overly
  fancy and flexible, generalized ones
• and expert designers choose with insights
  perhaps a simple and brittle design whose cost of
  change is balance against likelihood of change

52
7. GRASP Pure Fabrication

• Problem
• What object should have the responsibility, when
  you do not want to violate High Cohesion and Low
  Coupling, or other goals
• yet solutions offered by Expert or other GRASP
  patterns are not appropriate
• Insight here
• low representational gap aids design
• but this can lead to serious problems later if
  applied without enough thought

53
7. GRASP Pure Fabrication

• Solution
• Create an artificial or convenience class
• and assign a highly cohesive set of
  responsibilities to it.
• This class is literally a fabrication (i.e.,
  made out of whole cloth)
• As we have total freedom in creating such a
  class, we get much of what we want by way of
  cohesion and coupling

54
Example NextGen POS

• Sales we need to save them in a relational
  database
• Where do we place this functionality?
• Beware
• Such a task may require use of a lot of database
  operations which, of course, have nothing to do
  with sales
• Sale class would be coupled with a database API
• Saving data is actually a very general task are
  we willing to duplicate this functionality across
  our design?
• Solution PersistentStorage class

55
PersistentStorage

• This solves several design problems
• Sale remains well designed, with high cohesion
  and low coupling
• PersistentStorage class is itself relatively
  cohesive (i.e., sole purpose is storing or
  inserting objects in some persistent storage
  medium)
• PersistentStorage is generic and may be used by
  other classes
• Note emphasis is on where responsibility should
  be placed

56
Decomposition

• Representational decomposition
• Use to achieve a low representational gap
• Objects in the software system have rough
  analogues in the domain
• Example Sale
• Behavioral decomposition
• Use when we want to assign responsibilities by
  grouping behaviors or by grouping algorithms
• Example PersistentStorage
• Pure Fabrications are (mostly) function centric
  or behavior based
• That said, GoF patterns are Pure Fabrications

57
7. GRASP Pure Fabrication

• Contraindications
• Pure Fabrication tends to be preferred by novice
  designers
• Also preferred by those new to object-oriented
  programming
• Example all functions simply become objects
• Overuse of Pure Fabrication could lead to too
  many behavioral objects

58
8. GRASP Indirection

• Problem
• Where do we assign a responsibility such that we
  avoid direct coupling between two or more things?
• Recall
• Coupling is necessary in systems
• But too much coupling results in brittleness
• When we are aware of possible brittleness, how do
  we deal with it?

59
8. GRASP Indirection

• Solution
• Assign responsibility to an intermediate object.
• This object mediates between other components
  or services.
• Therefore object and services are not directly
  coupled
• Classic example use of Adapter GoF pattern
• Another example PersistentStorage from previous
  GRASP pattern
• Practically every one of the GoF patterns
  involves indirection
• Most problems in computer science can be solved
  with an additional level of indirection.

60
9. GRASP Protected Variations

• Problem
• How can we design
• objects
• subsystems
• and systems
• such that the variations in these do not have
  an undesirable impact on other elements in the
  system?
• Solution
• Identify points of predicted variation or
  instability
• Assign responsibilities to create a stable
  interface around them.
• This principle is simply the source of most
  software engineering wisdom.

61
Protected Variations mechanisms

• Core mechanisms
• data encapsulation
• interfaces
• polymorphism
• indirection
• standards
• Data-Driven designs
• Service Lookup
• Interpreter-Driven Designs
• Reflective / Meta-level Designs

62
Protected Variations mechanisms

• Uniform Access
• Standard Languages
• Liskov Substitution Principle (formalism)

63
Law of Demeter

• Also called Dont Talk to Strangers by Larman
• Law states that, within a method, message
  should only be sent to the following objects
• The this object
• A parameter of the method.
• An attribute of this
• An element of a collection which is an attribute
  of this
• An object created within the method

64
Law of Demeter violations
class Register private Sale sale
public void slightlyFragileMethod()
Money amount sale.getPayment().getTenderedAmo
unt() // //
public void moreFragileMethod()
AccountHolder holder
sale.getPayment().getAccount().getAccountHolder()

public void poison() F someF
foo.getA().getB().getC().getD().getE().getF()
65
Motivation behind Demeter

• Traversing path of object connections ? talking
  to a distant stranger
• Design impact
• code is now coupled to a specific structure of
  object connections
• the farther along the path a program traverses,
  the more fragile the code is
• In some situations, long traversals are not
  necessarily bad
• i.e., standard libraries (Java, STL)

66
Protected Variations

• Two other ways of stating this
• information hiding (Parnas)
• open-closed principle (Meyer)
• Protection at variation and evolution points.

67
The Nine GRASP Patterns

• Creator
• Information Expert
• Low Coupling
• Controller
• High Cohesion

• Polymorphism
• Pure Fabrication
• Indirection
• Protected Variations
