• Context-Sensitive Domain-Independent
• Algorithm Composition and Selection
• Troy A. Johnson and Rudi Eigenmann
• Purdue University

2
Motivation

• Increasing programmer productivity
• Typical language approach increase abstraction
• do more with less code
• reduce development and maintenance costs
• Domain-specific languages / libraries (DSLs)
  provide a high level of abstraction
• e.g., a domain is biology, chemistry, physics
• But, typically a sequence of library calls is
  needed

3
A Library Designer's Problem

• Consider two useful library procedures A and B
• reluctant to include a third procedure C that
  simply calls A and B (i.e., has composite
  behavior)
• though convenient, C is redundant
• including only C prevents reuse of A and B
• including all three, for all such procedures,
  greatly increases library size and complexity
• Library user is expected to compose sequences of
  fundamental calls

4
A Library User's Problem

• Novice users don't know these call sequences
• procedures documented independently
• tutorials provide a few example call sequences
• not an exhaustive list
• may need adjusted for each calling context
• User knows what they want to do, but not how to
  do it.
• Can the compiler let them specify a goal, and
  insert an appropriate call sequence? Yes!

5
Our Solution

• Add an abstract algorithm (AA) construct to the
  programming language
• named and defined (once) by the programmer
• definition is the programmer's goal
• called like a procedure (any number of times)
• compiler replaces each AA call w/ a library call
  sequence
• How does the compiler do this?
• short answer it uses a domain-independent
  planner that accepts procedure specifications as
  operators

6
Our Major Contributions

• Explain how composition of DSL procedures can be
  implemented as a language feature
• First compiler to use a planner to insert a
  sequence of library calls, while considering the
  calling context
• A novel application of planning that motivates
  research in planning theory
• Support incomplete, abstract procedure
  specifications that can be written for many
  domains
• use programmer-compiler interaction to clarify
  ambiguity

7
Outline

• Example The BioPerl DSL for Bioinformatics
• Brief Introduction to Planning
• Mapping Composition onto Planning
• Related Work (very abbreviated see paper)
• Conclusions Future Work

8
A Common BioPerl Call Sequence

• Query a remote database and save the result to
  local storage

Query q bio_db_query_genbank_new(nucleotide,
ArabidopsisORGN AND topoisomeraseTITL AND
03000SLEN) DB db bio_db_genbank_new(
) Stream stream get_stream_by_query(db,
q) SeqIO seqio bio_seqio_new(gtsequence.fasta,
fasta) Seq seq next_seq(stream) write_seq(s
eqio, seq)
5 data types, 6 procedure calls
Type Procedure
Example adapted from http//www.bioperl.org/wiki/H
OWTOBeginners
9
Describing the Library User's Goal

• Library author provides a domain glossary
• query_result(result, db, query) result is the
  outcome of sending query to the database db
• contains(filename, data) file named filename
  contains data
• in_format(filename, format) file named filename
  is in format format
• Glossary terms are properties (facts), whereas
  procedure calls are actions
• Library user lists properties of their goal

10
Defining and Calling an AA

• AA (goal) defined using the glossary...

algorithm save_query_result_locally(db_name,
query_string, filename, format) gt
query_result(result, db_name, query_string),
contains(filename, result),
in_format(filename, format)
Order does not matter. These are not procedure
calls.

• ...and called like a procedure

Seq seq save_query_result_locally(nucleotide,
ArabidopsisORGN AND topoisomeraseTITL AND
03000SLEN, gtsequence.fasta, fasta)
1 data type, 1 AA call
Type Property AA
11
Call-Sequence Selection

• Compilers planner may find multiple sequences
• programmer can select a sequence
• or the compiler can select one heuristically
• by using library annotations as a guide may
  require knowing typical program values to compare
  sequences
• by selecting sequence with fewest calls
• Incomplete specifications may cause undesirable
  sequences to be suggested
• incompleteness will occur in practice
• cannot eliminate the option for programmer-review

12
Making Interaction Unobtrusive

• Compilation normally non-interactive
• what programmers expect
• interaction should be minimized
• Cache programmers responses
• most code does not change between compiles
• avoids repeatedly selecting same sequence
• compiler flag to clear or ignore cache

13
Advantages of Our AA approach

• The following can remain unknown
• library procedure names
• order of calls
• intermediate variables
• Can teach library users call sequences
• AA calls adapt under different calling contexts

14
Why Calling Context Matters

• save_query_result_locally replaced with library
  calls
• In general, would use the 6-call sequence
• creates 5 data objects
• What if some objects already exist?
• suppose there is a live DB object
• then DB db bio_db_genbank_new( ) is
  unnecessary
• What if the goal is already satisfied?
• then the AA call does not generate any code

15
Composing a Call Sequence

• A planner discovers a sequence of instantiated
  operators (actions calls), known as a plan
• Given
• initial state lt calling context, from compiler
• goal state lt AA definition, from programmer
• operator set lt library procedure specifications,
  from librarian

16
Greatly-Simplified View of Planning
(Compiler)
(Executable)
Plan User
World
(Library Specs.)
Operators
Planner
Actions
Plan
(Call Context)
Initial State
(AA Definition)
Goal State
A Domain-INDEPENDENT Planner
A Domain-Dependent Planner

• World is composed of objects
• Actions modify objects' properties and
  relationships
• Planner deals with a symbolic model

17
Why Planning Is Difficult

• Operators define a state-transition system
• precondition when an operator can be used
• effects what an operator does
• Planner finds a path through the system from the
  initial state to the goal state
• What's difficult?
• typically too many states to enumerate
• search intelligently using reasonable time
  space
• danger that planner may not terminate

18
Is planning necessary for composition?

• Many possible actions
• libraries contain 10s 100s procedures
  (operators)
• each procedure has several parameters
• 10s 100s live variables (objects) at a call
  site
• many ways to bind variables to parameters
• Ex 128 procs, 2 params each, 8 objs, 4 calls
• assume all objects params have the same type
• (128 82)4 (27 26)4 2(134) 252
  potential plans

19
Overall System Challenges
Plan
(Challenge 4)
Procedure Specifications
Domain-Specific Library
Operators
DIPACS Planner
DIPACS Compiler
(Challenge 1)
Goal State
Initial State
Application Code
(Challenge 3)
(Challenge 2)
C Code
Run-Time Program State (World)
Binary (Actions)
gcc
00101010 01000010
1. Ontological Engineering choosing a glossary
for the domain
2. Determine Initial Goal States requires
flow analysis translation to a planning language
3. Object Creation most planners assume a fixed
set of objects
4. Merge the Plan into the Program destructive
vs. non-destructive plans
DIPACS Domain-Independent Planned Algorithm
Composition and Selection
20
Related Work

• Languages and Compilers
• Jungloids
• David Mandlin et al. Jungloid Mining Helping to
  Navigate the API Jungle. PLDI, June 2005.
• Broadway
• Samuel Z. Guyer and Calvin Lin. Broadway A
  Compiler for Exploiting the Domain-Specific
  Semantics of Software Libraries. Proceedings of
  the IEEE, 93(2)342357, February 2005.
• Speckle
• Mark T. Vandevoorde. Exploiting Specifications to
  Improve Program Performance. PhD thesis,
  Massachusetts Institute of Technology, 1994.

21
Related Work (continued)

• Automatic Programming
• Robert Balzer. A 15-year Perspective on Automatic
  Programming. IEEE Transactions on Software
  Engineering, 11(11)12571268, November 1985.
• David R. Barstow. Domain-Specific Automatic
  Programming. IEEE Transactions on Software
  Engineering, 11(11)13211336, November 1985.
• Charles Rich and Richard C. Waters. Automatic
  Programming Myths and Prospects. IEEE Computer,
  21(8)4051, August 1988.
• Automated (AI) Planning
• Keith Golden. A Domain Description Language for
  Data Processing. Proc. of the International
  Conf. on Automated Planning and Scheduling, 2003.
• M. Stickel et al. Deductive Composition of
  Astronomical Software from Subroutine Libraries.
  Proc. of the International Conf. on Automated
  Deduction, 1994.
• Other work at NASA Ames

22
Conclusions Future Work

• A DSL compiler can use a planner to implement a
  useful language feature
• We provide an example using a real DSL
• Identified implementation challenges in this talk
• for detailed solutions see paper
• Future work
• call sequences that include branches and loops
• develop examples using additional domains

23
