Traumatic Brain Injury Diagnostic Challenges & Emerging Tools

1
Traumatic Brain Injury Diagnostic Challenges
Emerging Tools

• Julie C. Chapman, PsyD

2
VA/DOD Definition of TBI

• A traumatically induced structural injury AND/OR
• physiologic disruption of brain function
• as a result of an external force
• that is indicated by new onset or worsening of
• at least one of the following clinical signs
• immediately following the event

3
VA/DOD Definition of TBI

• At least one of the following clinical signs
  immediately following the event
• Any period of loss of consciousness
• Any loss of memory for events immediately before
  or after injury
• Any alteration in mental state at the time of
  injury
• Neurologic deficits
• Intracranial lesion

4
How is TBI Diagnosed?

• 2nd Level TBI Evaluation
• Interview
• Physical Examination
• Neurobehavioral Symptom Inventory
• TBI is often retrospectively diagnosed

5
Severity of Injury

• Three main indices
• Duration of Loss of Consciousness (LOC) or
  Alteration of Consciousness (AOC)
• Post-Traumatic Amnesia (PTA)
• Glasgow Coma Scale (GCS)

6
Severity of Injury (VA/DOD)
7
Diagnostic Challenges

• Diagnostic criteria is based largely upon patient
  self-report, particularly in mild TBI.
• Possible threats to diagnostic accuracy
• Recall bias
• Cognitive difficulties
• Other factors

8
Diagnostic Challenges

• Overlap of symptoms in co-morbid conditions
• Hoge et al. Study
• Schneiderman et al. Study
• RAND Study

9
Symptom Overlap

• TBI

• PTSD

• Insomnia
• Memory Problems
• Poor concentration
• Depression
• Anxiety
• Irritability
• Headache
• Dizziness
• Fatigue
• Noise/light intolerance

• Insomnia
• Memory problems
• Poor concentration
• Depression
• Anxiety
• Irritability
• Re-experiencing
• Avoidance
• Emotional numbing

10
Seeking Objective Markers

• Biomarkers
• Brain Imaging
• Neurobehavioral Measures

11
Biomarkers

• S-100B
• Calcium binding protein found in astroglial and
  Schwann cells
• Sensitive but not specific for brain injury
• Others
• GFAP Glial Fibrillary Acidic Protein
• MBP Myelin Basic Protein
• NSE Neuron Specific Enolase

12
Diffusion Tensor Imaging

• Measures the movement of water molecules in
  neurons.
• Diffusion is an intrinsic physical process
  independent of the MR effect magnetic field.
• White matter tracts can be visualized and
  estimated in vivo.

13
Diffusion Tensor Imaging

• Lipton et al. 2009 - 20 pts (2 wks post mTBI), 20
  matched controls. Reduced FA in frontal WM
  correlated with executive function tests
  (IntegNeuro CPT EMT).
• Niogi et al. 2008 - 43 patients (16.9 mths post
  mTBI) and 23 controls. Attentional control
  correlated with FA in L corona radiata. Memory
  performance correlated with FA in uncinate
  fasciculus.
• Rutgers et al. 2008 - 21 patients (5.5 mths post
  mTBI) and 11 controls. mTBI had reduced FA in
  cerebral lobar WM, cingulum and corpus callosum.

14
Blast Injury Outcomes (BIO) Study

• Sample of OEF/OIF Veterans and Controls with
• No prior TBI (even mild)
• No current or recent or chronic substance abuse
  or dependence
• All OEF/OIF Veterans have
• Mild TBI from blast exposure and/or
• Combat-related PTSD

15
Blast Injury Outcomes (BIO) Study - Chapman
16
Blast Injury Outcomes (BIO) Study-Chapman
17
Neurobehavioral Measures

• Heitger et al. 2009 Antisaccades and visual
  tracking more impaired in patients with
  post-concussive syndrome at avg of 140 days
  post-injury than controls
• Wortzel et al. 2009 Presence of frontal release
  signs plus paratonia predicted cognitive and
  functional impairment in a acute TBI.
• Chapman et al. 2010 Presence of visual tracking,
  frontal release signs and antisaccades predicted
  mTBI versus No TBI group.

18
Integrative Diagnostics

• Patient Self-Report

Objective Diagnostic Markers
GESTALT
19
All Hands on Deck
Epidemiology
Laboratory Science
Clinical Science
20
Integrative Diagnostics
Clinical Algorithms
21
Markers for the Identification, Norming
Differentiation (MIND) of TBI and PTSD

• Principal Investigator Julie C. Chapman, PsyD
• Study Chair and Co-PI Aaron Schneiderman, PhD
• Tri-WRIISC Study (DC, East Orange, Palo Alto)
• Clinical Research Evaluation of OEF/OIF Veterans
  from the Epidemiological Study

22
Markers for the Identification, Norming
Differentiation of TBI and PTSD (MIND)

• Four groups of OEF/OIF Veterans studied (total
  n800)
• Veterans with TBI
• Veterans with PTSD
• Veterans with both TBI and PTSD
• Veterans with neither TBI nor PTSD

23
Phase One AimsMIND Study

• Aim 1 To validate the prevalence estimate of TBI
  and PTSD in OEF/OIF Veterans from the
  Epidemiological Study.
• Aim 2 To assess the effectiveness of VHA
  screening instruments for TBI and PTSD in OEF/OIF
  Veterans.

24
Phase Two AimsMIND Study

• Aim 1 To identify sensitive specific markers
  for both conditions from each measurement
  modality.
• Aim 2 To develop prediction models for both
  conditions using multi-system, objective measures
  and patient self-report.
• Measures include
• Cognitive
• Sensorimotor
• Advanced Neuroimaging
• Sleep

25
Phase Three AimsMIND Study

• Aim 1 To identify sensitive specific markers
  for TBI from each measurement modality.
• Aim 2 To develop prediction models for TBI
  using multi-system, objective measures and
  patient self-report.
• Measures include
• Neuroendocrine
• Sleep Medicine

26
Contact Us

• ADDRESS
• Veterans Affairs Medical Center
• MS 127
• Washington, DC 20422
• PHONE [phone]
• EMAIL Julie.Chapman_at_va.gov
• VISIT OUR WEBSITE
• www.warrelatedillness.va.gov/dc/
