Title: Integrated Plasma Fuel Cell Process (IPFC)


1
Integrated Plasma Fuel Cell Process (IPFC)
  • Process/Technology Briefing
  • Presented by
  • James Jordan, President and CEO
  • Louis Ventre, Jr. Executive VP and General
    Counsel
  • Meyer Steinberg, VP and Chief Scientist,
  • Archer Haskins, VP Marketing
  • HCE, LLC
  • www.hceco.com

2
Integrated Plasma Fuel Cell Process (IPFC)
A Highly Efficient Process for Producing
Electricity, Hydrogen, Gasoline and Diesel Fuels
from Coal, Petroleum, Natural Gas and
Biomass with Low Greenhouse Gas Emissions
Greening Fossil Energy
3
Agenda
  • Describe the Integrated Plasma Fuel Cell (IPFC)
    Process
  • Compare the Potential of this Process with the
    Other Fossil Fuel Conversion Technologies
  • Describe the key components
  • Discuss Proposed Development and
    Commercialization Strategy

4
HCE, LLC Seeks Support to Develop a Highly
Efficient and Clean Process for Conversion of
Fossil Fuel to Electricity, Hydrogen and
Synthetic Fuels
  • The process is a breakthrough
  • The process is more efficient than any other
    fossil fuel conversion process
  • The process can be demonstrated at a pilot scale
    in 3 years at a cost of about 18 million
  • The estimated cost of a follow-on full scale
    demonstration plant is about 57 million

5
IPFC Process Flowsheet
6
IPFC Fischer-Tropsch Synfuel Flowsheet
7
The IPFC Process Integrates Two
TechnologiesHydrogen Plasma Black Reactor
HPBRwith Direct Carbon Fuel Cell DCFC
  • Lower Production Cost Resulting from
  • High Efficiency
  • Lower Capital Investment
  • Low Pollution Discharges
  • Half CO2 in concentrated form
  • 5 to 10X less pollution (NOx and SOx than
    conventional power plant
  • Varied Applications Resulting from
  • Adaptability of Process
  • Scalability of Process

8
Lower Production Cost
9
Lower Production Cost
10
Highest Powerplant Thermal Efficiency
  • When compared to other systems, the IPFC promises
    the highest powerplant thermal efficiencies ---
    ranging from a low of 70 to a high of 92!
    (Values vary depending upon the type of fuel, the
    amount of hydrogen produced in relation to the
    amount of electricity, and the heating value of
    the fuel.)
  • Natural Gas Combined Cycle powerplants typically
    achieve 60 thermal efficiency for electricity
    production.
  • Integrated Gasification Combined Cycle plants
    typically achieve 50 - 55 thermal efficiency for
    electricity production.
  • Current fossil powerplants (Rankine Cycle)
    generate electricity in a range of 35 - 40
    thermal efficiency.

11
Comparison of IPFC Process with Rankine Plants
and the Advanced IGCC Plant for Likely Fuel Types
12
Higher Thermal Efficiency Than IGCC for Variety
of Feedstocks
13
Lower CO2 Emissions than IGCC
14
Lower Capital Investment
15
Lower Production Cost
16
Adaptable and Scalable to a Variety of
Feedstocks and Applications
  • Feedstock Fuels Natural gas, petroleum, coals,
    lignite, bitumen biomass
  • Basic Unit Produces Electricity and Hydrogen
  • HPBR Hydrogen Plasma Black Reactor coupled
    with
  • DCFC Direct Carbon Fuel Cell
  • For Electric Power and Transportation Fuels
    (gasoline and diesel)
  • Add Water Gas Shift Reactor (WGS) and
    Fischer-Tropsch Reactor
  • For Electric Power Production Alone
  • Add WGS and SOFC Solid oxide fuel cell
  • For Hydrogen Alone
  • Add WGS and water electrolyzer
  • Scalable
  • Residential to Large Multi-Megawatt Power Plant

17
  • HYDROGEN PLASMA BLACK REACTOR
  • HPBR

18
HPBR How It Works
IPFC Process
19
IPFC Process Electric Arc Hydrogen Plasma Black
Reactor
20
IPFC Process Electric Arc Hydrogen Plasma Black
Reactor
21
Benefits of HPBR
IPFC Process
  • Continuously cracks oil and natural gas.
  • Proofs needed for continuously cracking coal and
    biomass to carbon, hydrogen and carbon monoxide.
  • The carbon is in a fine particulate form.
  • The fine particulate pure carbon is ideal for the
    Direct Carbon Fuel Cell
  • The Hydrogen generated by the HPBR is in a
    concentrated form readily usable in other
    processes, such as upgrading petroleum refining,
    or as a feed stock for synfuels production or for
    sale in the commercial market

22
  • DIRECT CARBON FUEL CELL
  • DCFC

23
Fuel Cells Overview
24
Direct Carbon Fuel CellHow It Works
  • Carbon flows into the Direct Carbon Fuel Cell
    carried by a molten carbonate electrolyte.
  • The carbon then combines with oxygen from the
    atmosphere, producing electricity and
    concentrated carbon dioxide.

25
Small-scale Experimental Work at LLNL has
confirmed Proof of Principle of Direct Carbon
Fuel Cell
  • A laboratory-scale Direct Carbon Fuel Cell is
    shown in the photograph.
  • It is a fully functional 60 square centimeters
    Direct Carbon Fuel Cell.
  • Lab scale thermal efficiencies achieved up to
    90 at 1 kW/m2 and efficiencies of 80 proved
    at 2 kW/ m2

26
Direct Carbon Fuel Cell
  • Inside the barrel shell of the Direct Carbon Fuel
    Cell, there is an electrode assembly as shown in
    the schematic illustration.

27
A Concept for an Industrial-Scale Direct Carbon
Fuel Cell
28
Direct Carbon Fuel Cell
(DCFC) Reduces Pollution
  • Emission is nearly pure CO2
  • Ten-fold Reduction in offgas volume per MWH
  • 5X---no nitrogen in flue gas
  • 2X---80 efficiency cuts all flue gas in half
    per ton of coal
  • Reduces costs of sulfur removal
  • DCFC retains regulated emissions in molten salt
    (e.g., mercury, vanadium, thorium)

29
Direct Carbon Fuel Cell
Economics
  • Preliminary costs of stacked cells 250/kW at
    2kW/m 2
  • Estimated 5-year life of cell (graphite corrosion
    at 50µm/year

30
  • IPFC-FT
  • ELECTRICITY AND TRANSPORTATION FUELS

31
Integrated Plasma Fuel Cell Process SynFuels
Plant IPFC-FT
  • Electric Power and Transportation Fuel Production
  • HHV Thermal Efficiency and CO2 Emission Reduction
  • __________________________________________________
    _______
  • Product Ratio Thermal CO2
    Emission
  • Electric Power Efficiency
    Reduction
  • Fuel Gasoline
    from IGCC
  • __________________________________________________
    _______
  • Natural Gas 0.53 74.5 31.2
  • Petroleum 1.82 82.8 19.0
  • N. Dakota Lignite 1.82 82.0 26.5
  • Coal
  • Kentucky Bituminous 2.76 79.8 25.2
  • Coal
  • Biomass 0.20 70.4 -
  • __________________________________________________
    ___________________
  • Single Conventional Plants CO2 Reduction by
    IPFC
  • Rankine Cycle Electricity -
    38 76.4
  • Coal Gasification Gasoline - 65
    36.4

32
Integrated Plasma Fuel Cell Power Plant (IPFC-FT)
  • Electric Power and Transportation Fuel Production
  • HHV Thermal Efficiency
  • __________________________________________________
    _______
  • Gasoline and Total
  • Fuel Electric Power Diesel
    Efficiency
  • __________________________________________________
    _______
  • Natural Gas 25.7 48.8 74.5
  • Petroleum 53.4 29.4 82.8
  • N. Dakota Lignite 52.9 29.1 82.0
  • Coal
  • Kentucky Bituminous 58.6 21.2 79.8
  • Coal
  • Biomass 11.9 58.5
    70.4
  • Equivalent IGCC coal plant
    60
  • __________________________________________________
    ___________________

33
Preliminary Cost Estimate IPFC-FT
PlantElectricity and Gasoline Production
  • Plant Electricity
    Gasoline Equivalent
  • Fuel Capital Cost Prod. Cost Prod.
    Cost Crude Oil Cost
  • Cost Kw Mills/Kwh
    /gal /Bbl
  • __________________________________________________
    ___________________
  • Natural Gas
  • 6.00/MMBTU 690 50.15 1.76
    55.60
  • 4.00/MMBTU 690 40.99
    1.44 45.50
  • 4.00/MMBTU 690 50.00 1.06
    33.50
  • __________________________________________________
    ___________________
  • N. Dakota Lignite
  • 12.40/ton MF 775 28.50 1.00
    31.50
  • 0.73/MMBTU 775 44.18 0.00
    10.50
  • __________________________________________________
    ___________________
  • Cost of a barrel of crude oil to refinery to
    produce gasoline equivalent to
  • listed IPFC gasoline cost.
  • Selling price of electricity raised from
    production cost but not to exceed
  • conventional price of 50 mills/Kwh(e).
  • It costs 0.25/gal to refine crude oil. For
    zero production cost, equivalent

34
Integration of DCFC in the IPFC Process
  • The IPFC process development project will
    scale-up the DCFC for industrial application and
    integrate it with a continuously circulating
    carbon-black-laden molten carbonate stream
  • The IPFC process project will design, fabricate
    and test an off-gas system to collect the
    concentrated stream of CO2 for various
    applications
  • The IPFC Project will test performance of the
    DCFC with various ranks of fossil fuels

35
Design Fabricate Appropriately Scaled Hydrogen
Plasma Black Reactor (HPBR)
  • Design a Test Program for Various Ranks of U.S.
    and Chinese Coal
  • Set up an instrumented experimental unit at
    Norwegian University of Science and Technology
    develop off-gas and processing data to determine
    systems design information for off-gas processing
    system, molten carbonate system, and a scaled
    design for the IPFC pilot plant

36
Hydrogen Plasma Black Reactor (HPBR) at Norwegian
University of Science and Technology, Trondheim,
Norway
37
Major Level 3 WBS Tasks of Systems Requirements
Definition Task (SRD 1.01)
  • Complete Conceptual Design Report
  • Scale-Up of Direct Carbon Fuel Cell (DCFC)
  • Design Fabricate Appropriately Scaled Hydrogen
    Plasma Black Reactor (HPBR)
  • Design Fabricate Appropriately Scaled Molten
    Salt Carbon Transfer System
  • Design Fabricate Appropriately Scaled Off-Gas
    Collection Systems for HPBR and DCFC Components
  • Testing of Various Ranks of Fossil Fuels in Above
    Systems
  • Perform Trade Studies for Coal Prep and De-Ashing
    Systems
  • Perform Complete Preliminary Conceptual Design
  • Perform Complete Analytical Systems Model
  • Perform Complete Preliminary Life Cycle Cost
    Analysis

38
List of IPFC Process Pilot Plant Project
Deliverables
  • Complete Pilot Plant TE Report
  • Complete Construction of Pilot Plant
  • Complete Final E,SH Report
  • Complete Final Design of Pilot Plant
  • Complete Preliminary Design of Pilot Plant
  • Complete Conceptual Design Report for 1 MW Pilot
    Plant
  • Design, Construct TE a full-scale DCFC Module
  • Design, Construct TE a multiple module gas
    collection system
  • Design, Construct TE a multiple module molten
    carbonate transfer system
  • Design, Construct TE an appropriately scaled
    HPBR
  • Design, Construct TE an appropriately scaled
    fuel prep system

39
Greening Fossil Energywww.hceco.com
Thank You
