Cardiovascular Anatomy, Physiology and Pathophysiology Review

1
CardiovascularAnatomy, Physiology and
PathophysiologyReview

• Jeffrey Groom, MS, CRNA, ARNP
• Principles of Anesthesia III - Cardiothoracic
  Anesthesia
• FIU Anesthesiology Nursing Program

2
Cardiac Anatomy

• Pumbing
• Electrical
• Mechanical

3
Heart
4
1. Left anterior descending
2.Diagonal
3.Septal
4.Circumflex
5.Circumflex marginal
6.Right 7.Acute
marginal
8.Posterior descending
5
(No Transcript)
6
ECG and Coronary Anatomy
Anatomic Site ECG Leads Artery
Inferior II, III, aVF Right
Lateral I, aVL, V5, V6 L Circumflex
Anterior V3-V4 (I, aVL) Left
Anteroseptal V1-V2 LAD
7
Ionic Basis of Cardiac Action Potentials
4 Resting Potential (- 70 to - 90 mV)
primarily due to iK PUSHED TO THRESHOLD 0
Depolarization Increased iNa decreased iK 1
Early Repolarization Voltage-dependent
decrease in iNa, increase in iK (transient)
iCl 2 Plateau Slow (L-type) Ca channels
open iCa 3 RepolarizationiK increases slow
Ca channels close 4 Resting Potential
8
(No Transcript)
9
Spontaneous Depolarization and Automaticity

• Automaticity
• fastest rate sets the pace
• non-neurally mediated neurally modified
• Methods of modifying the rate and automaticity
• 1o Change the rate of spontaneous
  depolarization
• Acetylcholine increases K current - slows rate
  of spontaneous depolarization
• Epinephrine increases Ca current (calcium
  channel blockers have an opposite effect)
• Change the resting potential
• Acetylcholine increased K current causes cell
  to reach more negative value upon repolarization

10
iCa (T-type)
Time (msec)
11
Ionic Basis of Nodal Action Potentials

• Unstable Resting Potential
• -60 mV
• Ion Currents
• K current present, but declining
• increasing Na and Ca (T-type) currents
• SPONTANEOUS DEPOLARIZATION
• Membrane potential reaches threshold ( - 40 mV)
• further, rapid increase in T-type Ca current
• transient fall in iK, then increases again early
  in depolarization
• cell reaches 0 to 5 mV
• Repolarization Increase in iK decrease in iCa

12
ECG and Action Potential
13
Heart Muscle Mechanics

• TENSION (force) -
• Elements contributing
• Contractile element
• gt Active tension
• Elastic element (functional, not anatomic)
• gt Resting tension

14
Heart Muscle Mechanics

• 2) LENGTH of muscle fibers influences Tension
• Starling's relationship (Tension (active
  resting) vs Length)
• Performance-wise this is PRELOAD

15
(No Transcript)
16
Heart Muscle Mechanics
17
Heart Muscle Mechanics

• 3) VELOCITY is influenced by Length and Tension
• Calcium activation
• Total calcium released
• Sarcomere length alters calcium sensitivity

18
Cardiac Performance

• Cardiac output HR x Stroke volume
• Stroke Volume affected by
• Preload
• After load
• Contractility
• Law of La Place relates ventricular pressure and
  wall tension
• T Pr
• 2h

19
LAPLACEs LAW

• Tension Pressure Gradient X Radius

Tension Radius balance required to overcome
Critical closing pressure
20
LAPLACEs LAW
Tension Pressure Gradient X Radius
Aortic Aneurysm Rupture R P T
21
LAPLACEs LAW
Tension Pressure Gradient X Radius
Left Ventricle - filling gt wall pressure
22
Cardiac Cycle

• Isovolumetric ventricular contraction
• Rapid ejection phase
• Reduced ejection phase
• Isovolumetric relaxation
• Rapid filling phase
• Slow filling period
• (Atrial contribution (20-30 in failing heart))

23
Cardiac Cycle
24
(No Transcript)
25
Determinants of Myocardial Function

• Preload
• Afterload
• Contractility
• Heart Rate

26
Preload

• Normal heart - increased venous return results in
  increased cardiac output
• Failing heart - sarcomere length is already
  maximal cardiac output increase requires
  increased contractility or heart rate

27
Preload

• 1. Preload is the pressure applied to fill the
  heart and is represented by the "passive"
  pressure-volume curve - clinically the end
  diastolic pressure is the preload
• 2. Typical values for LVEDP are 4-5 mmHg.
• 3. A sudden increase in Filling Pressure
  (increased preload)
• a. EDV increases
• b. Heart contracts more forcefully due to
  enhanced thick and thin filament overlap,
  contracts to the same ESV -Starlings Law of the
  Heart
• c. SV, CO and PA are increased

28
Afterload

• Afterload is the pressure in the aorta throughout
  the ejection phase - estimate of which is
  arterial pressure
• 2. An sudden increase in mean arterial pressure
  causes 3 things to happen
• a. pressure in the ventricle must rise to a
  higher level during the isovolumetric contraction
  phase before the aortic valve will open
• b. ejected volume goes down
• c. SV and CO will decrease

29
Afterload

• 3. A sustained increase in mean arterial
  pressure
• a. the increased ESV plus normal venous return
  volume leads to increased EDV
• b. due to the increased EDV the heart
  contracts more forcefully (Starlings Law of the
  Heart)
• c. SV, CO and PA are increased
• d. at steady state, the pressure volume curve
  is shifted to the right, reserve is diminished

30
Contractility

• 1. Altered contractile force due to change in the
  rate or quantity of calcium delivered to the
  myofilaments, or a change in the affinity of the
  filaments for calcium.
• 2. A sudden increase in contractility causes
• a. the heart to contract more forcefully from
  any initial length
• b. the heart to contract more forcefully
  during the ejection phase, leading to a reduced
  ESV and increased SV
• c. increased SV increases CO and PA

31
Contractility

• 3. Effect of a sustained increase in
  contractility
• a. the reduced ESV plus normal venous return
  volume leads to a reduced EDV
• b. the heart contracts less forcefully due to
  the reduced EDV
• c. at steady sate, the pressure volume curve
  is shifted to the left, heterometric reserve is
  enhanced

32
Cardiac Cycle and Pressure Volume Loops
33
(No Transcript)
34
Phases of the Cardiac Cycle

• Diastole
• Isovolumic relaxation
• Filling
• Atrial kick
• Systole
• Isovolumic contraction
• Ejection
• Rapid and reduced ejection

35
(No Transcript)
36
Cardiac Pressure-Volume Loop

• Filling Phase (A-B) radius increases at constant
  filling pressure causing increased wall tension

37
Cardiac Pressure-Volume Loop

• Isovolumetric ContractionPhase (B-C) Tension
  increases at constant radius causing increased
  pressure.

38
Cardiac Pressure-Volume Loop

• Ejection Phase (C-D) Radius decreases at
  constant tension causing further increase in
  pressure

39
Cardiac Pressure-Volume Loop

• Isovolumetric Relaxation Phase (D-A) Tension
  decreases at constant radius causing decreased
  pressure.

40
Cardiac Pressure-Volume Loop

• 1. Filling phase AV valve opens, ventricular
  volume increases to its maximum - EDV, pressure
  rises only slightly to EDP.
• 2. Isovolumetric contraction phase Mitral valve
  closes, ventricular pressure rises dramatically
  without change in volume.
• 3. Ejection phase When ventricular pressure
  exceeds aortic pressure aortic valve opens, and
  ejection begins (volume decreases). Initially
  pressure continues to rise then begins to fall.
• 4. Isovolumetric relaxation phase Aortic valve
  closes, volume in ventricle is end systolic
  volume. Pressure in ventricle falls until AV
  valve opens (back to step 1)

41
PV Loop RV vs LV
42
Effects of Changing Preload on Stroke Volume
Ç Increase
ä Decrease
43
Effects of Changing Afterload on Stroke Volume
Cycle 1
Cycle 2
Cycle 3
44
Nitroglycerin (Decreased Preload in Ischemic
Heart)
45
Factors Affecting Cardiac Output

• RATE
• RHYTHM
• PRELOAD
• AFTERLOAD
• CONTRACTILITY

46
Cardiac Output

• CO is the product of heart rate (HR) and stroke
  volume (SV) HR X SV CO
• SV is the difference between end diastolic
  volume and end systolic volume
• Ejection fraction is the amount of blood ejected
  in each beat, SV, divided by end diastolic volume
  (EDV)
• Typical ejection fraction is 60-65, lt40
  indicative of severe cardiac disease

47
Control of Stroke Volume

• As ventricular volume increases, ventricular
  circumference increases and lengths of individual
  cells increases
• At constant volume, increased intraventricular
  pressure causes increased tension in the
  individual cells of the ventricular muscle
• As ventricular volume increases, a larger force
  from each muscle cell is required to produce any
  given intraventricular pressure
• Pressure (P) 2 x tension (T) x Wall thickness
  (H) intraventricular radius (r)

48
Control of Cardiac Output

• Intrinsic Control rapidly compensate for
  changing conditions and equalize R L outputs
• Heart rate
• Stroke volume Starlings Law of the Heart
• Extrinsic Control Changes in contractility
  (inotropic state)
• inotropic state the relative capability to
  generate tension at a given preload

49
Frank-Starling Curve
50
Ventricular Performance
End-Diastolic Volume
51
Factors Influencing Myocardial Oxygen Consumption

• A. Stroke work is the area within the pressure
  volume loop approximated by SV x PA
• B. Cardiac efficiency is defined as SW divided by
  oxygen consumption (QO2)
• C. Cardiac efficiency is typically between 5-15,
  most energy is dissipated as heat in
  isovolumetric contraction.

52
Factors Influencing Myocardial Oxygen Consumption

• D. Factors causing increased oxygen consumption
• 1. increased afterload or contractility
• 2. dilation of the ventricular chamber
• 3. increased heart rate
• 4. increased stroke volume the least
  expensive way to increase CO

53
Determinants of Mean Arterial Pressure

• A. The product of cardiac output (CO) and total
  peripheral resistance (TPR) determines MAP
• B. Pressure difference between beginning (aorta)
  and end (right atrium) of the systemic
  circulation must be sufficient to overcome
  resistance of the vessels for flow (cardiac
  output) to occur
• C. CO is proportional to pressure difference
  between aorta and right atrium
• D. CO is inversely proportional to resistance of
  the circulatory system

54
Intrinsic Regulation of Myocardial Function
55
Indicators of Cardiac Performance

• Cardiac index CO / BSA
• LVEDP (or approximation)
• mean left atrial pressure
• mean pulmonary wedge pressure
• pulmonary artery diastolic pressure
• CI and LVEDP together are better indicators of
  contractility than either alone
• Ejection fraction SV / EDV

56
QUESTIONS
57
Cardiac Function Alterations
EDV ESV LV SV MAP SVR PCWP HR
ÇPL
ÈPL
ÇAL
ÈAL
ÇCT
ÈCT
58
Explain the phases of a Pressure-Volume Loop
59
mmHg
Pressure Afterload
ml
