Title: Inflammatory Disorders


1
Inflammatory Disorders
  • By Nancy Jenkins
  • Updated Spring 2010 by John Nation

2
Overview of Todays Lecture
  • A P Review
  • Endocarditis- infection of the endocardial
    surface of the heart
  • Myocarditis- a focal or diffuse inflammation of
    the myocardium
  • Pericarditis- inflammation of the pericardial sac
    (the pericardium)

3
Layers of the Heart Muscle
4
Anatomy and Physiology!
  • How the heart works!

5
(No Transcript)
6
TISSUES SURROUNDING THE HEART
7
(No Transcript)
8
(No Transcript)
9
Anatomy and Physiology Review
  • Blood enters the right atrium and moves through
    the _______ into the right ventricle.
  • Blood then moves from the right ventricle into
    the pulmonary artery via the _________.

A- Aortic Valve B- Mitral Valve C- Pulmonary
Valve D- Tricuspid Valve
10
Anatamy and Physiology Review (Contd)
  • After entering the left atrium via the pulmonary
    veins, blood moves through the _____ into the
    left ventricle.
  • Finally, it travels through the _____ and out of
    the heart.

A- Aortic Valve B- Mitral Valve C- Pulmonary
Valve D- Tricuspid Valve
11
Infective Endocarditis
  • Infection of the inner layer of the heart
  • Usually affects the cardiac valves
  • Was almost always fatal until
  • development of penicillin
  • Around 15,000 cases diagnosed
  • annually in the U.S.

12
Causative Organisms
  • Causative organisms
  • Streptococcus viridans
  • Staphylococcus aureus
  • Viruses
  • Fungi

13
Etiology and Pathophysiology
  • Vegetation
  • Fibrin, leukocytes, platelets, and microbes
  • Adhere to the valve or endocardium
  • Embolization of portions of vegetation into
    circulation

14
Etiology and Pathophysiology
  • Occurs when blood turbulence within heart allows
    causative agent to infect previously damaged
    valves or other endothelial surfaces

15
Endocarditis
  • Infection of the innermost layers of the heart
  • May occur in people with congenital and valvular
    heart disease
  • May occur in people with a history of rheumatic
    heart disease
  • May occur in people with normal valves with
    increased amounts of bacteria

16
Etiology/Pathophysiology
  • Endocarditis
  • When valve damaged, blood is slowed down and
    forms a clot
  • Bacteria get into blood stream
  • Bacterial or fungal vegetative growths deposit on
    normal or abnormal heart valves

17
Classifications of Endocarditis
  • Acute Infective Endocarditis
  • Abrupt onset
  • Rapid course
  • Staph Aureus
  • Subacute Infective Endocarditis SBE
  • Gradual onset
  • Systemic manifestations
  • Prosthetic Valve Endocarditis

18
Bacterial Endocarditis of the Mitral Value
Fig. 37-2
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
Sequence of Events in Infective Endocarditis
Fig. 37-3
24
Risk Factors- endocarditis
  • Damaged heart valve
  • Prior history of endocarditis
  • Invasive procedures- (introduce bacteria into
    blood stream) (surgery, dental, etc)
  • Recent Dental Surgery
  • Permanent Central Venous Access
  • IV drug users
  • Valve replacements

25
Nursing Assessment
  • Subjective Data
  • History of valvular, congenital, or syphilitic
    cardiac disease
  • Previous endocarditis
  • Staph or strep infection
  • Immunosuppressive therapy
  • Recent surgeries and procedures

26
Nursing Assessment
  • Functional health patterns
  • IV drug abuse
  • Alcohol abuse
  • Weight changes
  • Chills

27
Nursing Assessment
  • Diaphoresis
  • Bloody urine
  • Exercise intolerance
  • Generalized weakness
  • Fatigue
  • Cough

28
Nursing Assessment
  • Dyspnea on exertion
  • Night sweats
  • Chest, back, abdominal pain

29
Collaborative Care
  • Fungal and prosthetic valve endocarditis
  • Responds poorly to antibiotics
  • Valve replacement is adjunct procedure

30
Assesment endocarditis
  • Infection and emboli
  • Emboli-spleen most often affected (splenectomy)
  • Oslers nodes- painful, red or purple pea-sized
    lesions on toes and fingertips
  • Splinter hemorrhages- black longitudinal streaks
    on nail beds
  • Janeway lesions- flat, painless, small, red spots
    on palms and soles
  • Roth spots- hemorrhagic retinal lesions
  • Murmur- 90 have murmurs
  • T above 101(blood cultures) and low-grade
  • Chills
  • Anorexia
  • Fatigue

31
Clinical Manifestations
  • Murmur in most patients
  • Heart failure in up to 80 with aortic valve
    endocarditis
  • Manifestations secondary to embolism
  • Heart Sounds Assessment Video

32
Auscultating Heart Sounds
  • The aortic area or right sternal border (RSB) is
    at the right 2nd intercostal space, just under
    and to the right of the angle of Louis (sternal
    angle)
  • The pulmonic area or left upper sternal border
    (LUSB) is at the left 2 nd intercostal space
  • The tricuspid area or left lower sternal border
    (LLSB) is at the left fourth intercostal space
  • The mitral area or apex is at the PMI -- the 5 th
    intercostal space in midclavicular line

33
(No Transcript)
34
Splinter hemorrhage
  • small areas of bleeding under the fingernails or
    toenails.
  • due to damage to capillaries by small clots

35
Janeway Lesions
  • flat, painless red spots on palms and soles

36
Oslers Nodes
  • Painful, pea-size, red or purple lesions
  • On finger tips or toes

Roth spots
Oslers nodes
37
Roths Spots
  • hemorrhagic retinal lesions

38
Diagnostic Tests
  • Blood Cultures-
  • Echocardiogram-TEE best- see vegetations
  • Other- WBC with differential, CBC,ESR, serum
    creatinine,CXR, and EKG

1) Vegetations on mitral valve 2) Vegetations on
aortic valve
39
Diagnostic Criteria
40
Diagnostic Criteria
41
Medications
  • Antibiotics
  • IV for 2-8 weeks
  • Monitor peaks and troughs of certain drugs
  • Monitor BUN and Creat.
  • Unclear success of oral antibiotics if not a good
    candidate for IV. Oral antibiotics are considered
    when dealing with endocarditis
  • Of the tricuspid valve
  • With a causative organism sensitive to oral
    agents
  • Long-term IV therapy difficult or impossible
  • Outpatient f/u can be arranged

42
Nursing Diagnoses
  • Risk for Imbalanced Body Temperature
  • Risk for Ineffective Tissue Perfusion-emboli
  • Ineffective Health Maintenance

43
Complications
  • Emboli (50 incidence)
  • Right side- pulmonary emboli (esp. with IV drug
    abuse- Why??)
  • Left side-brain, spleen, heart, limbs,etc
  • CHF-check edema, rales, VS
  • Arrhythmias- A-fib
  • Death
  • .

44
Prevention
  • Eliminate risk factors
  • Patient teaching

45
Risk Stratisfication for IE
  • High Risk-
  • Mechanical prosthetic heart valve
  • Natural prosthetic heart valve
  • Prior infective endocardititis
  • Valve repair with prosthetic material
  • Most congenital heart diseases
  • Moderate Risk-
  • Valve repair without prosthetic material
  • Hypertrophic cardiomyopathy
  • Mitral valve prolapse with regurgitation
  • Acquired valvular dysfunction
  • Low Risk-
  • Innocent heart murmurs
  • Mitral valve prolapse without regurgitation
  • Coronary artery disease
  • People with pacemakers/ defibrillators
  • Prophylactic antibiotics are generally
    recommended only for people in the High Risk
    category

46
Collaborative Care
  • Prophylactic treatment for patients having
  • Removal or drainage of infected tissue
  • Renal dialysis
  • Ventriculoatrial shunts
  • Dental, oral, or upper respiratory tract
    procedures

47
Video Review- Endocarditis
  • Livestrong Endocarditis Video

48
To diagnose the causative organism in
endocarditis, the nurse should anticipate the
doctor ordering which test?
  1. Chest x-ray
  2. Echocardiogram
  3. Blood cultures
  4. CBC

49
Which assessment finding is characteristic of
endocarditis?
  1. Peripheral edema
  2. Jaundice
  3. Bradycardia
  4. Heart Murmur

50
A common complication of endocarditis of the
mitral valve is pulmonary embolism.
  1. True
  2. False

51
Layers of the Heart Muscle
52
Myocarditis
  • Myocarditis is an uncommon inflammation of the
    heart muscle (myocardium). This inflammation can
    be caused by infectious agents, toxins, drugs or
    for unknown reasons. It may be localized to one
    area of the heart, or it may affect the entire
    heart.

53
Etiology/Pathophysiology
  • Myocarditis
  • Virus, toxin or autoimmune response causes
    necrosis of the myocardium
  • Most often caused by viral infection
  • Frequently caused by Coxsackie B virus
  • Frequently follows an upper respiratory infection
    or viral illness
  • Get decreased contractility
  • Can become chronic and lead to dilated
    cardiomyopathy- heart transplant or death

54
  • This is an infection in the muscles of the heart,
    most commonly caused by the Coxsackie B virus
    that follows upon a respiratory or viral illness,
    bacteria and other infectious agents.

55
Risk factor-myocarditis
  • Hx of upper respiratory infection
  • Toxic or chemical effects (radiation, alcohol)
  • Autoimmune or immunosuppresents- 10 HIV develop
    it
  • Metabolic-lupus
  • Heat stroke or hypothermia

56
Multiple Causes of Myocarditis
57
Assessment myocarditis
  • Infection and CHF
  • Fatigue,DOE
  • Tachycardia
  • Arrhythmias- PVCs, PACs, Atrial Tachycardias,
  • Chest pain
  • Signs of heart failure (S3, etc.)
  • Pericarditis frequently occurs with myocarditis-
    check friction rub

58
Diagnostic Tests
  • EKG- Non-specific T-wave abnormalities
  • CK-MB and Troponin may be elevated
  • Endomyocardial biopsy- there are risks and not
    used for every case but is definitive for
    myocarditis
  • Chest X-Ray- Variable (Normal to Cardiomegaly)
  • Echocardiogram
  • Cardiovascular Magnetic Resonance
  • A safe and sensitive noninvasive diagnostic test
    to confirm the diagnosis is not available

59
Chest X-Ray in Myocarditis
60
MRI in Acute Myocarditis
61
Endomyocardial Biopsy
62
Biopsy Video
  • Heart Biopsy Video

63
Possible Medications
  • Antibiotics (rarely)
  • Antiviral with interferon-a
  • IVIG- experimental trials
  • Corticosteroids or immunosuppressents
  • HF drugs- ACE, diuretics, beta blockers etc
  • Antiarrhythmics
  • Anticoagulants-

64
Other Treatments
  • Bedrest and activity restrictions- Why
    important??
  • Activities may be limited for 6 months- 1 yr.
  • O2

GOAL- Decrease workload of the heart so it can
heal
65
Nursing Diagnoses
  • Activity Intolerance
  • Decreased CO
  • Anxiety
  • Excess fluid Volume

66
Pericarditis
  • Pericarditis is an inflammation of the
    pericardium, the thin, fluid-filled sac
    surrounding the heart. It can cause severe chest
    pain (especially upon taking a deep breath) and
    shortness of breath.

67
(No Transcript)
68
(No Transcript)
69
Etiology/Pathophysiology
  • Pericarditis
  • bacterial, fungal or viral infection
  • Heart loses natural lubrication(10-30ccs) and
    layers roughen and rub
  • Inflammatory process causes lymphatic fluid
    build-up- if sudden may have cardiac tamponade
  • Pericardial Effusion- usually 250 ccs before
    show up on x-ray. Can have 1000ccs.

70
Risk Factors/pericarditis
  • Post MI (Dresslers syndrome)
  • Radiation
  • Infection
  • Trauma
  • Cancer
  • Drugs and toxins
  • Rheumatic diseases
  • Trauma or cardiac surgery
  • Can be chronic disorder-pericardium becomes rigid

71
Assessment pericarditis
  • Inflammation and pain
  • Pericardial friction rub-
  • diaphragm at LL sternal
  • border in knee chest
  • position
  • Fever
  • Substernal, sharp, pleuritic chest pain
  • Inc. with coughing, breathing,turning,lying flat
  • Decreases with sitting up and leaning forward
  • Referred to trapezius muscle
  • Dyspnea

72
Diagnostic Tests- to R/O
  • CBC-inc. WBC, ESR, and CRP
  • Cardiac Enzymes- elevated but not as much as with
    MI
  • EKG- ST elevation, PR changes
  • Echo- for wall movement
  • CXR
  • CT or MRI- for pericardial effusion
  • Pericardiocentesis fluid for analysis- attempt to
    determine cause

73
ECG in Pericarditis
74
Medications
  • ASA or tylenol
  • NSAIDS- ibuprofen
  • Corticosteroids

75
Pericarditis Video Review
  • Livestrong Pericarditis Video

76
Complications of Pericarditis
  • Pericardial Effusion- an accumulation of excess
    fluid in the pericardium
  • Cardiac Tamponade- an increase in intracardial
    pressure caused by pericardial effusion that
    results in compession of the heart

77
(No Transcript)
78
Pericardial Effusion
  • Can occur rapidly or slowly
  • Pulmonary compression-cough, dyspnea, and
    tachypnea
  • Phrenic nerve involvement- hiccups
  • Laryngeal nerve- hoarseness

79
Pericardial Effusion- EKGElectrical Alternans
  • Pericardial effusion with electrical alternans
  • The QRS axis alternates between beats. In this
    example it is best seen in the chest leads where
    the QRS points in different directions!
  • This is rarely seen and is due to the heart
    moving in the effusion.

80
Cardiac Tamponade
  • Compression of the heart
  • Can occur acutely (trauma) or sub-acutely
    (malignancy)
  • Symptoms- chest pain, confusion, anxious and
    restless
  • Later- tachypnea, tachycardia, and decreased CO,
    NVD (neck vein distention) and pulsus paradoxus
    present
  • With slow onset dyspnea may be only symptom

81
PERICARDIUM
CARDIAC TAMPONADE

Original heart size
Excess pericardial fluid
82
Definition- a decrease in systolic BP with
inspirations that is exaggerated in cardiac
tamponade
83
Determination of Pulsus Paradoxus
  • Place the patient in a position of comfort and
    take their systolic blood pressure during
    baseline respiration.
  • Raise sphygmomanometer pressure until Korotkoff
    sounds disappear.
  • Lower pressure slowly until first Korotkoff
    sounds are heard during early expiration with
    their disappearance during inspiration
  • Record this pressure.
  • Very slowly lower pressure (1mm at a time) until
    Korotkoff sounds are heard throughout the
    respiratory cycle with even intensity.
  • Record this pressure.
  • The difference between the two recorded pressures
    is the Pulsus Paradox.
  • Hemodynamically significant pulsus paradox is
    greater than or equal to 10 but we look at
    trends. People with COPD may have a paradox due
    to increased thoracic pressures.

84
Surgical/invasive Interventions
  • Pericardiocentesis
  • Hook needle to V lead- guided by EKG and echo
  • Look for ST elevation
  • Withdraw fluid
  • Afterward watch for cardiac tamponade (PP),
    arrhythmias, and pneumothorax
  • Pericardiectomy
  • Pericardial window
  • Sclerosing agent- tetracycline (Bonds layers
    together)

85
(No Transcript)
86
Pericardial Window
A procedure in which an opening is made in the
pericardium to drain fluid that has accumulated
around the heart. A pericardial window can be
made via a small incision below the end of the
breastbone (sternum) or via a small incision
between the ribs on the left side of the chest.
87
Cardiac Tamponade and treatment
You tube- Cardiac Tamponade
88
Chronic Constrictive Pericarditis
  • Starts with acute then scarring and fibrosis
    occur
  • See signs of HF and cor pulmonale most relate to
    decreased cardiac output
  • Most prominent finding is jugular vein distention
    (JVD)
  • Treatment of choice pericardectomy- with use of
    cardiopulmonary bypass

89
Nursing Diagnoses for Pericarditis
  • Acute Pain
  • Ineffective Breathing Pattern
  • Risk for Decreased Cardiac Output
  • Activity Intolerance

90
Specific Nursing Assessment
  • Paradoxical pulse
  • Murmur
  • Pericardial friction rub
  • Emboli
  • Chest pain
  • CHF

91
Comfort Measures
  • O2
  • Bedrest
  • Positioning
  • Prevent complications of immobility
  • Psychological support

92
Case study
  • http//www.austincc.edu/adnlev4/rnsg2331online/mod
    ule06/mr_a_case_study.htm
  • http//intmedweb.wfubmc.edu/grand_rounds/1999/tamp
    onade.html - CASE20PRESENTATION

93
The End!
Write a Comment
User Comments (0)
About PowerShow.com
