Eye Optics and Refractive Errors

1
Eye Optics and Refractive Errors

• By John J. Beneck MSPA, PA-C

2
Case 1

• 14 year old boy comes to primary care office c/o
  inability to see the blackboard in school

3
Case 2

• 51 year old man presents c/o difficulty reading
  the news paper My arms are too short!

4
Case 3

• 6 year old girl presents with mom who states she
  squints when looking at anything more than 2 feet
  away.

5
Objectives

• Understand the optics of the eye
• Understand visual acuity assessment
• Understand common refractive errors
• Understand color perception assessment

6
Objectives (Cont.)

• Understand common refractive errors in terms of
• Etiology/pathology
• Clinical presentation
• Course and prognosis (when appropriate)
• Diagnosis
• Interventions/treatments

7
Abbreviations

• C/o complaining of or complains of

8
Visual Acuity

• Use Snellen chart
• Positioned 20 feet away
• Each Eye Alone, Then Together
• With Corrective Lenses (If indicated)

9
Snellen Charts
http//store6.yimg.com/I/sightmart-eye-care-produc
ts_1753_2381891 accessed 9/5/03
10
Visual Acuity

• Visual acuity is expressed as two numbers
• The first indicates the distance of the patient
  from the chart
• The second indicates the distance at which a
  normal eye can read the line of letters
• Ex 20/50

11
Visual Acuity

• 20/20
• ability to see letters of a given size at 20 feet
• 20/40
• what a normal person can see at 40 feet, this
  person must be at 20 feet to see.
• 20/200
• what a normal person can see at 200 feet, this
  person must be at 20 feet to see.

12
Further Acuity Assessment/Diagnosis

• Optometric examination
• Cornea
• Anterior chamber
• Posterior chamber
• Retinal examination and imaging

13
Image Reception

• Optics/Refraction
• Air anterior Cornea
• 2/3 of the refractive power of the eye
• Posterior Cornea aqueous humor
• Iris / pupil
• Variable aperture
• Aqueous humor anterior lens
• Posterior lens vitreous humor

14
Image Reception

• Convex refraction
• Refractive index
• Convergence
• Image reversal
• Perception
• Blind spot

15
Refractive Principles of a Lens

• Convex lens focuses light rays

Figure 49-2 Guyton and Hall
16
The Refractive Principles of a Lens
Figure 49-8 Guyton and Hall
17
Refractive Principles of a Lens

• Concave lens diverges light rays.

Figure 49-3 Guyton and Hall
18
Whats next?

• Emmetropia (normal vision)
• Myopia (near-sighted)
• Hyperopia (far-sighted)
• Inability of the lens to accommodate adequately
  for near vision
• Presbyopia
• Astigmatism

19
Myopia (Near-Sighted)

• The patient is able to focus on objects near but
  not far away
• Typical complaint is difficulty focusing on road
  signs or the black board
• The lens is unable to flatten enough to prevent
  conversion of images before reaching the retina
• The image comes into sharp focus in front of the
  retina
• Frequently squinting is compensatory mechanism

20
Errors of Refraction
Normal vision
Far sightedness
Near sightedness
Figure 49-12 Guyton and Hall
21
Myopia Correction

• Corrective concave lens use
• Glasses
• Contact lenses
• Surgical
• LASIK (greatest range of correction for myopia)
• Laser-Assisted In Situ Keratomileusis
• Epithelial flap cut and lifted
• Laser applied to deep layers of cornea
• Flap repositioned
• Squinting?

22
Correction of Myopic Vision
Myopia corrected with concave lens
Figure 49-13 Guyton and Hall
23
Depth of Focus
Effect of pupil size on focus in myopic patients
Note the difference in divergence of rays as they
reach the retinal surface
24
Hyperopia (Far-Sighted)

• The patient is able to focus on objects far away
  but not close up
• Typical complaint is difficulty reading
• The image comes into sharp focus behind the retina

25
Errors of Refraction
Normal vision
Far sightedness
Near sightedness
Figure 49-12 Guyton and Hall
26
Hyperopia Correction

• Corrective convex lens use
• Glasses
• Contact lenses
• Surgical
• LASIK
• Laser-Assisted In Situ Keratomileusis
• Epithelial flap cut and lifted
• Laser applied to deep layers of cornea
• Flap repositioned

27
Correction of Hyperopic Vision
Hyperopia corrected with convex lens
Figure 49-13 Guyton and Hall
28
Presbyopia The Inability to Accommodate

• Caused by progressive denaturation of the
  proteins of the lens.
• Makes the lens less elastic.
• Begins about 40-50 years of age.
• Near point of focus recedes beyond 22 cm (9
  inches).

29
Astigmatism

• Unequal focusing of light rays due to an oblong
  shape of the cornea
• Presents with relatively stable blurry vision
• Patient unable to focus on objects near or far
• Near vision is typically better

30
Astigmatism

• Vertical focal point different from
  Horizontal focal point
• Cornea lacks discoid continuity
• More curved in one plane than another
• Unable to correct with a single concavity or
  convexity index

31
Exaggerated Astigmatic Corneal Shape
Notice the difference in the degree of curve of
the cornea in 2 planes
Cornea face-on
32
Astigmatism Correction

• Cylindrical optical refractive correction
• Glasses
• Contact lenses
• Surgery
• LASIK
• Laser-assisted in situ keratomileusis

33
Cataracts

• Cataracts
• cloudy or opaque area of the lens
• caused by coagulation of lens proteins
• More to come

34
Cataract
35
Cataract Correction

• Surgical
• The lens is replaced
• Induces presbyopia
• Frequently dramatically improves far vision

36
Pigment Layer of Retina

• Pigment layer of the retina is very important
• Contains the black pigment melanin
• Prevents light reflection in the globe of the eye
• Without the pigment there is diffuse scattering
  of light rather than the normal contrast between
  dark and light.
• This is what happens in albinos
• poor visual acuity because of the scattering of
  light
• Best corrected vision is 20/100-20/200

37
Color Vision

• Color vision is the result of activation of
  cones.
• 3 types of cones
• blue cone
• green cone
• red cone
• The pigment portion of the photosensitive
  molecule is the same as in the rods, the protein
  portion is different for the pigment molecule in
  each of the cones.
• Makes each cone receptive to a particular
  wavelength of light

38
Each Cone is Receptive to a Particular Wavelength
of Light
Figure 50-7 Guyton Hall
39
Color Blindness

• lack of a particular type of cone
• genetic disorder passed along on the X chromosome
• occurs almost exclusively in males
• about 8 of women are color blindness carriers
• most color blindness results from lack of the red
  or green cones
• lack of a red cone, protanope.
• lack of a green cone, deuteranope.

40
Eyes Visual PathwaysIshihara Test for Color
Blindness
http//www.toledo-bend.com/colorblind/Ishihara.htm
l, 2001
The individual with normal color vision will see
a 5 revealed in the dot pattern. An individual
with Red/Green (the most common) color blindness
will see a 2 revealed in the dots.
41
Color Vision
Colorblind individuals should see the yellow
square. Color normal individuals should see the
yellow square and a "faint" brown circle.
42
How about those cases

• Case 1
• 14 year old boy comes to primary care office c/o
  inability to see the blackboard in school
• Case 2
• 51 year old man presents c/o difficulty reading
  the news paper My arms are too short!
• Case 3
• 6 year old girl presents with mom who states she
  squints when looking at anything more than 2 feet
  away.

43
Now, Do You See Things More Clearly???
