Wireless Networking

1
Wireless Networking

• TGIF, April 18th, 2003
• Alvin Chew (alchew_at_stanford.edu)
• Kent Reuber (reuber_at_stanford.edu)

2
Outline

• Wireless technology overview
• ITSS Wireless Net
• Department wireless nets
• Home wireless nets
• Questions

3
Wireless Technology Overview
4
Why Wireless?

• () No wires. Convenience, flexible. But
• (-) Relatively slow speeds, typically 5 Mbps with
  802.11b. Nowhere near the 100 Mbps of typical
  wired connection.
• (-) Wireless access points are hubs, not
  switches. Bandwidth is shared among wireless
  users. Think of it as phone party lines.
• (-) Data is freely available in the air.
• Traffic is easily sniffed.
• Data is not encrypted unless the protocol is
  encrypted (e.g., SSL and Kerberos).
• Stanford does not use WEP, because it can be
  cracked.

5
Wireless Terms

• Access Point (or AP) device that sends and
  receives wireless signals. Usually directly
  connected to the wired net.
• ITSS uses Cisco Aironet 350 APs.
• SSID the network name that Access Points
  broadcast.
• ITSS uses Stanford.
• Departments and home users may want to use other
  names.
• Users can roam between access points with the
  same SSID.
• Channel radio frequency used by APs.
• APs near one another should use different
  channels to minimize noise.
• 802.11b Channels 1, 6, and 11 dont overlap.
  Channels 1, 4, 8, and 11 have only a little bit
  of overlap

6
Wireless Alphabet Soup

• 802.11b
• Most common wireless protocol. Uses 2.4GHz
  frequency, with 11 Mbps bandwidth. (5 Mbps is
  more typical). ITSS wireless net and most other
  campus wireless is based on this.
• 802.11a
• Uses 5.5GHz range, 54 Mbps bandwidth (20 Mbps is
  typical performance). Produces to much radio
  power to be certified in medical areas. Unlikely
  to become a standard at Stanford.
• 802.11g
• Uses 2.4GHz band and is compatible with 802.11b.
  Also 54 Mbps bandwidth (20 Mbps typical). An
  emerging standard, but likely to grow in the
  future.

7
ITSS Wireless Net
8
ITSS Wireless NetOverview

• Coverage map at http//wirelessnet.stanford.edu
• Wireless net uses separate physical and logical
  network. (Separate switches, fiber, and address
  space.)
• Prevents layer 2 attacks (e.g., broadcasts,
  IP/MAC spoofing) on wired net
• Prevents wired broadcasts/multicasts from
  saturating wireless bandwidth
• Dont have to dedicate department roaming IPs
  for wireless users
• You still have to register wireless cards in
  NetDB.
• provide the hardware address of the wireless card

• enable DHCP and roaming.
• Wireless card recommendations
• Recommend Cisco and Apple cards which are
  available at the Bookstore.
• Any WiFi certified card should work.

9
ITSS Wireless NetSecurity

• Wireless networks are inherently insecure
• Even with encryption, the data between client and
  APs are available for anyone to capture.
• Most corporate wireless nets lie outside of
  firewalls.
• ITSS Wireless doesnt use WEP
• Consumes client resources
• Well-known security vulnerabilities
• Other methods of wireless encryption are
  vendor-specific.
• Stanford uses wireless authentication to protect
  campus resources.

10
ITSS Wireless NetAuthentication

• Protects the institution, not the user
• S/ident integration
• If you have PC/Mac-Leland, youre all set
• First net activity should bring up PC/Mac-Leland
  automatically
• Web-based authentication backup
• First web page you get is the authentication page
• Automatically redirects you to your requested
  page after login
• Future Guest Login feature
• Any SUNet ID user will be able to sponsor a guest
  wireless account

11
Department Wireless
12
My Department Wants Wireless!

• Net-to-jack clients are eligible for 1 AP for
  every 16 wired ports.
• Wireless net-to-jack For non-net-to-jack
  clients, ITSS will do a survey, install, monitor,
  maintain, and upgrade your wireless network.
  Price is 31/month per AP.
• Or.

13
Do-It-Yourself Options

• Option 1 ITSS can place a wireless entrance
  switch in your building and that carries the ITSS
  Wireless net.
• Option 2 Departments can put their wireless
  devices on their existing building net.
• Both options require departments to purchase APs
  and switches. ITSS can recommend equipment, but
  departments will need to do their own survey and
  place access points.

14
Department Wireless Setup

• ITSS Wireless net always uses Stanford as the
  SSID.
• APs plugged into the building net shouldnt use
  Stanford
• This has caused problems when users roam between
  access points.
• Putting the department/group/lab name as the SSID
  makes it clear to users who to call in case of
  trouble.

15
Recommended Cards and APs

• 802.11b cards
• Apple Airport card, Cisco Aironet 350 PC Card
• In principle, any card that adhere to the WiFi
  certification should work.
• Access Points
• Cisco Aironet 350 APs for departments.

16
Home Wireless Nets
17
Keeping Your Neighbors Out

• The range of wireless means that its very
  possible that your neighbors can use your
  wireless net too. And see all your traffic
• Precautions
• Most APs have MAC address filters so that only
  specific cards can associate. This is the most
  important thing to enable!
• Most APs can also be set to not broadcast the
  SSID. (e.g., Apple Airports call this Create a
  closed network) That way, people have to know
  the name of your network in order to join.
• Definitely want to use encrypted protocols
  whenever possible.
• If available, consider turning down the power of
  your AP to restrict the range.

18
Setup 1 Stanford DSL and Stanford West

• In both cases, you can request multiple IP
  addresses for home machines. You dont need a
  DSL router.
• We suggest that you purchase access points that
  do bridging, where traffic is simply forwarded
  between the wired and wireless sides of the
  access point without alteration.
• Examples Cisco Aironet 350, Linksys WAP11,
  Apple Airport.
• Weve seen a number of people on the campus or
  Stanford West who have installed Airport base
  stations with DHCP enabled on the Ethernet side,
  disrupting DHCP service.
• Breaks DHCP for other users.
• We shut down their connections

19
Setup 2 Non-Stanford DSL or Cable Modem

• In many cases, you only get one IP address.
• Network Address Translation (NAT -- often
  provided by DSL/wireless routers) can be used
  to hide a network behind a single IP address
• Some wireless units do this by default. E.g.,
  Apple Airport.
• Note that NAT disrupts some Stanford services,
  especially WebAuth.
• Also interferes with some VPN setups.

20
Questions???
