OUR ISO CERTIFICATIONS
3
CE Certification for our Leading Products
4
Qualities on which we stand

• 1. All Steel fabricated.
• 2. Steel Casted Chamber in Single Pcs.
• 3. Tripple reduction helical gear box fitted with
  Graded Steel Casted Gears
  Alloy steel Pinion.
• 4. Cake thickness can be adjusted on running
  machine.
• 5. Best Quality of oil cake.
• 6. Maintence Free Press.
• 7. Less Electrical Motor Require.
• 9. Minimum Space Require.
• 10. Hard Faced worms Cages.
• 11. Water Cooling arrangement in Main worm Shaft
  to maintain the temprature.
• 12. Main Worm Shaft can be withdrawn without
  disturbing the Gear Box.
• 13. Chambers are Vertically hinged,easy to open.
• 14. The Pressing worms, Cone,Discharge Ring
  Compression Rings are Hard Faced upto 3MM
  Thickness to have Better life.
• 15. Main Shaft is manufactured out of Carbon
  Steel EN-8.The best recommended steel for Shafts
  Axles.
• 16. All the Gears in Gear Box are of Graded Steel
  Castings Pinion Shafts are of EN-24, 55-65
  Carbon Steel.
• 17. The Worms Cages are made from EN8/EN9
• 18. All Gears Pinions are running in the Oil
  bath Bearings are also
• Lubricated with Splash Lubrication.

5
GOYUM 1500- LEADING THE REVOLUTION IN EXPELLERS
6
HIGH CAPACITY- 140 - 150 Tonne in
Pre-Pressing 50 -60 Tonne in single and
Final Crushing

• 1. This model has been designed in a Simple and
  Symmetrical shape.
• 2. Triple reduction Gear Box with Helical Gear of
  Cast Steel and Pinion Shaft of Special Steel.
• 3. Gear Box is aligned with all the bodies on a
  single Fabricated Base.
• 4. This expeller has three chambers of cast
  steel, vertically hinged. Each of 36 long.
• 5. Cake thickness can be adjusted on running
  machine.
• 6. Worm assembly, discharge ring, Sliding ring,
  all are hard faced welded.
• 7. Main Worm shaft can be withdrawn without
  disturbing the Gear Box. The shaft is water
  cooled.
• 8. Crammer shaft for Extra cramming of the seed
  or cake is fitted on the feed body. The crammer
  shaft is driven by Geared motor of 3 H.P.
• 9. Base and Bodies are fabricated from Mild
  Steel.
• 10. Superior Quality of Oil Cake.
• 11. Low Maintenance.
• 12. Low Power Consumption.

7
FOR ACCURATE COOKING OF SEED

• 1. This Cooker is supportedly separately on a
  fabricated Steel Structure.
• 2. This Cooker is divided in five stages using
  66Diameter Steam Jackets for efficient cooking
  of the seeds, nut or meal.
• 3. Pipe fitting contains safety valve, steam
  spray pipe.
• 4.Aspiration system is also provided to extract
  excess steam or moisture from the cooking
  chambers.
• 5. Doors or openings are provided in each section
  for cleaning and fitting of agitators.
• 6. Indicatiors are fitted to indicate the level
  of the seed or meal in all the sections.
• 7. Gear Box - Worm Reduction Gear Box of
  Vertical Type.
• 8. Power Consumption- 3 Phase 25 H.P motor of
  1440 RPM.

8
MOST COMPETITIVE

• 1. Steel Fabricated Base Body.
• 2. Double reduction Gear Box with helical gears
  of Cast Steel.
• 3. Cast Steel chamber of 45X 7.5 Dia. Of Four
  sections is vertically hinged.
• 4. Cake thickness can be adjusted on running
  machine.
• 5. Case hardened worm assembly assembly with hard
  faced discharge ring compression ring.
• 6. Main worm shaft can be withdrawn without
  disturbing the gear box.
• 7.Crammer Shaft gives extra cramming of the seed
  or cake in the feed body.
• 8. Low Power Consumption.
• 9. Maintenance Free.
• 10. Superior Quality of oil cake.
• 11. High Capacity

9
MOST ECONOMICAL

• 1. Our oldest and economical model.
• 2. Double reduction Gear Box of Cast Iron Body
  and Mild Steel fabricated Gears.
• 3. The machine has to be stopped for adjusting
  the cake thickness.
• 4. Case hardened worm assembly and cone point.
• 5. Main Worm Shaft can be withdrawn without
  disturbing the Gear Box.
• 6. Crammer Shaft gives extra cramming of the Seed
  or Cake in the Feed Body.
• 7.Superior quality of Oil Cake.
• 8.Low Maintenance.
• 9. Steel Fabricated base.
• 10. Chamber is made from Mild Steel plates.
• 11. Low Power Consumption.

10
COMPACT AND STURDY

• The whole body is fabricated from Mild steel
  material.
• Steel Casted Chamber.
• The Screw Press is directly coupled with Geared
  Motor.
• Cake thickness can be adjusted on the running
  machine.
• Best Quality of Oil Cake.
• Low maintenance required.
• Power Consumption 7.5 H.P Motor of 1440 r.p.m.
• Less space requirement.
• Hard faced worm assembly.
• CE Certified.

11
FILTER PRESSES- For filteration of Oils,
Chemicals, Paints, Varnishes, Pottery Clay and
other Liquids.

• Two flat Side Bars are provided on which filter
  plates rest to stand extra pressure.
• Heavy types steel screw nut is fixed in the screw
  plate and best quality steel screw rod is
  provided with pressure pulley.
• Cast Iron jam nuts and petcocks of special design
  are provided for better filteration.
• The casting is heavier and carefully machined
  and each plate is grinded to avoid leakage.

12
SINGLE AND DUPLEX FILTER PUMP-Heavy type
plunger pumps serves two fold purpose,
filteration as well as delivery.
13
FEATURES OF OUR SPARES- HIGH
QUALITY COMPLETE ACCURACY LONG LIFE
DURABILITY
14
MATERIAL HANDLING EQUIPMENT- SCREW
CONVEYORS ELEVATORS
15
GOYUM BOILERS-FOR ACCURATE STEAM PRESSURE
FOR SEED PREPARATION
16
SEED PREPARATORY EQUIPMENT

• HAMMER MILL

• SEED CLEANER

17
SEED PREPARATORY EQUIPMENT

• SOYA CRACKER

• SEED CLEANER

18
MEAL COOLING SYSTEM FOR LARGE OIL EXTRACTION
PLANTS
