Title: VFD Lecture Part 3


1
VFD Lecture Part 3
2
Damato Campimeter
  • More precise, accurate
  • and reliable test with
  • better examiner control
  • Portable
  • Only measures central
  • visual field

3
Component Parts of the Campimeter
A test card B Side arm C Eye cover D Test
Grid E Stimulus window F Target stimulus G
Target arm and finger notches on the
arm and card
4
Test Procedure
  • Test materials
  • Damato Campimeter
  • Test form
  • Book stand (optional)
  • Eye patch or clip on occluder (optional)
  • Environment
  • Well lighted room light behind the patient and
    evenly illuminating the board
  • Room must be free from distractions

5
Test Instructions
  • Patient seated comfortably at a table with
    eyeglasses on if needed to see board
  • Instruct patient to hold the board upright on the
    table top unless a book stand is being used
  • EX is positioned in front of the patient so that
    the patients eyes can be observed
  • Instruct the patient to cover the eye using the
    eye cover folded inward (an eye patch can be used
    instead)
  • Make sure there are no shadows on the board and
    that the patients head is centered (not tilted
    sideways)

6
Correct examination position
Avoid tilting the head or the card
when administering the test
7
  • Adjust the card so it faces the client squarely,
    with the
  • board 13 inches from the eye
  • Tilt the care backward and forward until the
    client feels
  • comfortable
  • Make sure the window is blank
  • Instruct patient to focus on the window and to
    say now
  • when the black dot appears
  • Show the dot in the window repeat several
    times until
  • patient responds every time the dot is shown

8
  • PROCEED WITH TEST
  • Show the patient the number 1 on the grid
  • Instruct the patient to keep looking at the
    number 1 and to
  • say Now when the black dot appears
  • Watching the patients eye closely, move the dot
    into the
  • window. Avoid giving any clues (noise or sudden
    movement
  • of the hand
  • If there is any doubt about the validity of the
    patients response,
  • immediately retest that point before proceeding
    onto the next point
  • Record the patients response on the form
  • Return the window to a blank frame and instruct
    the patient to
  • read the next number out loud
  • Repeat until the patient has viewed all of the
    numbers

9
Modifications for Non Compliant Patients
  • The number can be highlighted to help maintain
    the patients attention/fixation
  • The number of test items can be reduced from 30
    to 15 for patients with limited attention and
    endurance
  • The patient can raise a finger or point to the
    target instead of giving a verbal response
  • The test can be broken down into short segments
    and given over several days

10
Scoring
If the patient does not see the black dot at the
test location, place a black mark at that
location on the test form When the test is
completed, connect the dots to indicate the area
of field loss NOTE the test form is held
one direction for scoring and the opposite
direction for interpretation
Results indicate a left Homonymous hemianopsia
11
Additional Assessments
12
Oculomotor Changes
  • Can be used to help confirm other observations
  • Patient is asked to gaze shift between targets
  • Patient often demonstrates searching saccade
    towards a target on the blind side
  • Makes several saccades toward the target instead
    of one smooth saccade
  • But makes a normal long smooth saccade towards
    the intact side

13
Insight into Visual Field Loss
  • Patient must have good insight in order to apply
    compensatory strategies
  • Patient often misunderstands diagnosis
  • Believes the deficit is in one eye only
  • Believes the deficit only affects peripheral
    field
  • Believes the deficit is in the eye not the brain
  • Patient is unable to describe strategies used to
    compensate for loss

14
Insight Can be Measured With a Simple Scale
  • 5 Demonstrates thorough understanding of
  • VFD understands that deficit is in both eyes
    and knows which side has been affected can
    describe how deficit has affected functional
    performance and safety able to verbalize
    strategy needed to compensate and consistently
    employs strategy
  • 4 Demonstrates understanding of VFD, understands
    that deficit is in both eyes and knows which side
    has been affected by deficit can describe how
    deficit affects function and safety able to
    verbalize strategy needed to compensate but does
    not consistently employ strategy

15
Insight rating
  • 3 demonstrates understanding of cause of VFD and
    which side has been affected by deficit
    minimizes affect of deficit on functional
    performance and safety and/or does not fully
    understand how deficit affects function and
    safety able to verbalize strategy needed to
    compensate but does not employ strategy
  • 2 realizes deficit is present knows which side
    is affected may not realize deficit is in both
    eyes not able to verbalize a compensatory
    strategy and/or cannot describe how deficit
    affects function and safety
  • 1 may be aware that vision has changed but is
    unaware of the visual field deficit

16
Assessment of Influence of VFD on Visual Search
  • Observational assessment
  • Questions to be answered
  • Does the VFD disrupt visual search?
  • How is the search pattern disrupted?
  • Does the patient initiate a compensatory
    strategy?
  • Assess two areas
  • Search in central visual field
  • Search in peripheral visual field

17
Visual Search Capability in the Central Visual
Field
  • Observe performance on cancellation tasks
  • Visual search subtests of Brain Injury Visual
    Assessment Battery for Adults (biVABA)

18
Normal Visual Search
  • Persons without visual impairment demonstrate
    specific characteristics of search patterns that
    make them effective in locating and identifying
    targets
  • Linear strategy
  • Left to right and top to bottom
  • Symmetrical search pattern
  • Predictable search pattern
  • Thorough and comprehensive
  • Resilient
  • Consistent accuracy

19
Four Normal Search Patterns
  • All strategies are left
  • to right and top to bottom
  • Use of these strategies
  • results in high degree
  • of accuracy

20
Characteristics of Ineffective Search Patterns
  • Abbreviated and incomplete
  • Asymmetrical
  • Initiated and confined to right side
  • Random-no predictable pattern
  • Inconsistent accuracy in target identification
  • Breaks down when challenged

21
Evaluating Search Effectiveness
  • Best evaluated by observing patient complete a
    search task
  • Identify strengths and weaknesses of the search
    pattern
  • Note accuracy
  • Note time needed to complete search

22
Observation of the Pattern
  • __Symmetrical horizontal left to right
  • __Symmetrical horizontal rectilinear
  • __Symmetrical vertical left to right
  • __Symmetrical vertical rectilinear
  • __Checks work for accuracy
  • __Abbreviated
  • __ right side __ left side
  • __Asymmetrical, right to left pattern
  • __Random, no predictable pattern

23
Cuing
  • Should be part of the evaluation
  • Physical
  • Verbal
  • Helps determine strengths and weaknesses
  • A necessary component of treatment planning
  • Example of documentation
  • __ verbal cue given___benefits___no benefit
  • __ physical cue give ___benefits___no benefit

24
Ineffective Search Strategies Used by Persons
with VFD Abbreviated Search
  • Abbreviates search towards blind side due to
    oculomotor disruption
  • Results in omissions on the blind side
  • Search pattern is organized
  • Person checks work for errors
  • Search is often time consuming
  • Person maintains attention throughout test

25
RVFD does not scan all the way over to the
right omissions on right side (black circles)
LVFD begins search a third of the way in from
the left side omissions on left side (black
circles)
26
Visual Search Capability in the Peripheral Visual
Field
  • Search of extrapersonal environment is often
    affected the most
  • To compensate for VFD, the patient must initiate
    a quick, efficient search of the blind side
  • Assessment determines whether patient
    demonstrates the essential components of a
    successful compensatory search strategy

27
Dynavision 2000
Computer driven light board displays random
pattern of interactive lights Person locates the
light and touches it Light beeps when it is
touched to verify contact and immediately a new
light appears in another area of the board 30,
60 sec or 4 minute run is completed Two Modes
Mode A Light stays on until it is touched Mode
B Light stays on for a pre-determined length
of time and then changes
28
Computer Analyzes Reaction Time in Each Quadrant
on Completion of a Run
Example of Print Out Analysis for Mode A Run
Completed on a Patient with a RVFD
Patient hit 28 lights during the 60 second
run The reaction times for the Left
quadrants(13) are 1.7 and 1.2 seconds The
reaction times for the right quadrants (24) are
2.2 and 2.9 seconds, confirming slower reaction
time towards VFD side
29
Flash Option Mode
1-7 numeric digits appear in the box every 6 sec
during the run or Mode A or B The patient must
read out the digit(s) while continuing to hit the
lights Enables evaluation of persons ability
and willingness to shift attention between the
central and peripheral areas of the board
30
Dynavision Performance
Deficient Performance
Good Performance
  • Searches good field first
  • Does not turn head or
  • doesnt turn head far
  • enough towards blind side
  • Uses a time consuming
  • strategy (often linear)
  • Focuses attention on one
  • side of the board
  • Looks to blind field first
  • Turns head to view periphery
  • of board
  • Uses an efficient circular
  • search strategy
  • Attends equally to both sides
  • of the board

31
If you dont have a Dynavision
  • Get one
  • At 7,000 falls into the expensive range making
    it difficult to get one through standard budget
    procedures
  • Look instead for a donor
  • Hospital auxiliary
  • Foundation supporting the hospital
  • Sorority or service club
  • Not that difficult as it represents a one time
    purchase of a unique piece of equipment that is
    plaque-able ( you can put a nice bronze
    donation plaque on it)
  • Cheap mans dynavision
  • Laser pointer-aim it at a white wall and have
    patient locate the red dot

32
Scan Course
  • Assesses integration of visual search with
    ambulation
  • Observe whether patient is willing to scan the
    environment during ambulation or uses the
    maladaptive strategy of fixating on the floor or
    staring straight ahead
  • Can be set up anywhere
  • Home or clinic

33
Scan Course
Use 3x5 inch note cards with black 1 inch stick
on letters or post it notes with letters written
on them in magic marker. Place in various
locations along a hallway, 10 on each
side Instruct patient to read out the letters
as h/she walks down the hallway Record the
number of errors made on each side of the
hallway. Provide feedback on error rate and have
the patient repeat,walking the opposite
direction
Yellow post it notes with letters on them are
arranged along a hallway in a pts home
34
Scan Course Performance
  • If the patient is unable to combine visual search
    with ambulation, h/she will miss letter targets
    on the blind side
  • The patient should always be given feedback on
    performance and then asked to repeat the test
    going the opposite direction
  • If performance improves on second attempt it
    indicates that the patient is able to benefit
    from feedback to improve compensation

35
Supplement Evaluation with Observation of
Behavior in Dynamic Environments
  • Hesitant, uncomfortable and anxious
  • Uses trailing or attempts to follow you
  • Comes very close to obstacles on blind side
  • Uncertain in responding to subtle features
    (curbs, support surface changes)
  • Stopping to search-unable to combine visual
    search with ambulation
  • Appears or complains of disorientation
Write a Comment
User Comments (0)
About PowerShow.com
