Solid State ChemistryChem 331
  • Dr. Bailey
  • Stratton 219
  • x3286
  • cbailey_at_wells.edu

Koloman Moser
2
Wall decorations in the Sala del Reposo, Alhambra.
3
Mauritis C. Escher
4
Introduction to the Solid State
  • There are 20,000,000 known chemical substances.
  • 95 are molecular (predominantly containing C).
  • 4 are inorganic molecular.
  • 1 are non-molecular extended structures (e.g.
    solid salts and most elements).

5
Single Element Packing
Square Lattice
first layer
second layer (directly above first)
Simple Cubic Lattice Packing used by e.g. Po.
6
Single Element Packing
Square Lattice
first layer
second layer (sitting in indentations)
BCC Lattice Packing used by e.g. Li, K, V, Fe,
W, etc.
third layer (directly above first)
7
Single Element Packing
first layer
Closest Packed Lattice
A A A
second layer (over any indentation)
B B B
  • Two types of indentations
  • Directly over first layer.
  • Over first layer indentation.
  • So, two different places to start third layer!

8
Single Element Packing
first layer
Closest Packed Lattice
A A A
second layer (over any indentation)
  • Two types of indentations
  • Directly over first layer.
  • Over first layer indentation.
  • So, two different places to start third layer!

IF directly over A, get ABAB packing, also known
as hexagonal closest packed (hcp). Used by Mg,
Ca, Co, Zn, etc.
9
Single Element Packing
first layer
Closest Packed Lattice
second layer (over any indentation)
  • Two types of indentations
  • Directly over first layer.
  • Over first layer indentation.
  • So, two different places to start third layer!

IF third layer directly over B, get ABCABC
packing, also known as face centered cubic
(fcc). Used by Al, Cu, Ni, Ag, Au etc.
10
Lattice Packing
  • Elemental Cu and Ni each uses fcc packing and
    both have very similar lattice parameters (e.g.
    internuclear distances).
  • If we heat the two elements to melting and then
    mix together and cool slowly, the fcc packing is
    retained, but with a random placement of the two
    elements.
  • Known as a solid solution alloy.

11
Lattice Packing
  • Elemental Cu and Au each uses fcc packing but
    have very different lattice parameters (Au gtgt
    Cu).
  • Upon reaction (melt and cool) yields a
    specifically ordered arrangement an
    intermetallic compound, which may not conform to
    oxidation state rules.

12
Binary Compounds (MX)
  • Which elements do we need to be concerned about?
  • ignore noble gases no known extended structures.
  • ignore radioactive elements.
  • this leaves about 80 elements of possible
    interest.
  • mathematically, this results in 3,160 possible
    binary elemental combinations (not taking into
    account various stoichiometries, AB, AB2, A2.3B3,
    etcetera).
  • 90 of known binary compounds have simple
    stoichiometries MX, MX2, MX3, M3X5, etcetera.
  • For MX there are 20 common structure types (well
    look at 3).
  • For MX2 there are 26 common structure types
    (well look at 2).
  • Each of these structural types can be thought of
    as starting from single element packing lattices.

13
Most Common MX Structures
NaCl structure Na in fcc lattice Cl- in Oh
holes
CsCl structure Cl- in simple cubic lattice Cs
in cubic hole
Zinc blende (ZnS) structure S-2 in fcc
lattice Zn2 in alternating Td holes
14
Most Common MX2 Structures
Fluorite (CaF2) structure Ca2 in fcc
lattice F- in all Td holes
Rutile (TiO2) structure Ti2 in body centered
cubic lattice Oxygens in lower symmetry array.
15
Ternary Compounds (ABC)
  • 82,160 potential combinations 20,000 known.
  • 700 structural types known (so far and growing
    fast) very few examples of each type.
  • Synthesis grind together and heat Li2O and MoO3,
    for example. Reacts before melting.
  • Forms one of three compounds, depending on ratio
    on mixing
  • 1 Li2O 1 MoO3 ? Li2MoO4 100yield
  • 1 Li2O 4 MoO3 ? Li2Mo4O13 100yield
  • 2 Li2O 5 MoO3 ? Li4Mo5O17 100yield
  • If react with other ratios, get mixtures of these
    3 plus startting material.
  • If use Na2O instead of Li2O, get entirely
    different compounds.

16
Pseudoternary Compounds.
  • Both sodium chloride and silver chloride utilize
    NaCl structure.
  • If react (melt and re-cool) non-stoichiometric
    amounts, get solid solution of NaCl structure
    type, but with random occupation of Na/Ag sites.
  • Called pseudoternary because it contains 3 types
    of elements, but still adopts binary-type
    structure.

(1-x) NaCl xAgCl ? Na1-xAgxCl
17
Future? Why Do We Care?
  • Consider superconductors (a metal that, when
    cooled to a low enough temperature, Tc, will
    carry a charge with no resistance).
  • best single element superconductor is Nb, Tc 9
    K.
  • best binary superconductor is Nb3Ge, Tc 20 K.
  • best ternary superconductor is La2CuO4, Tc 40
    K.
  • best quarternary superconductor is Ba2YCu3O4, Tc
    92 K above N2(l).
  • best superconductor is Tl2Ba2Ga2Cu3O10, Tc 135
    K.
  • to extrapolate out to room temperature, would
    need 8 elements, which means 2.90 x 1010
    possible combinations before stoichiometry!
  • what are the most complicated compounds in
    nature (max cations in different
    crystallographic environments)?
  • Asbecaite Cu3TiAs6Be2Si2O30
  • Mordite LaSrNa3ZnSi6O17

18
Synthesis of Non-Molecular Solids
  • Typically start with powdered reactants, mix
    together, press together, heat, and then let cool
    (aka shake and bake).
  • See West Ch 9 for specifics of many methods.
  • By convention, high temp 800oC low temp
    200-600oC.
  • Dont want material to react with container, so
    common to use fused quartz (up to 1200oC), but do
    use other materials.
  • Often start with oxides that are stable in air.
  • 3CuO 2BaO2 Y(OH)3
  • mix well and press into a pellet heat in
    aluminum oxide container 920oC for 24 hours.
  • yields YBa2Cu3O6, which when reacted with 3/2H2O
    5/2O2 and annealed below 500oC in O2 produces
    YBa2Cu3O4 (superconductor).

19
Nucleation and Diffusion
  • These solid state reactions occur in two steps
    first nucleation, where product forms within a
    few nm of where the reactants contact one
    another, then product growth through diffusion.
  • The reason the material is pressed is to get
    points of contact (on the molecular scale) as the
    reaction only occurs when contact occurs.
  • Very little is known about nucleation, but
    diffusion is reasonably well understood.
  • Different atoms diffuse at different rates, but
    typically D 10-10 to 10-12 cm2/sec at 2/3Tm (in
    K).
  • Therefore, it would take 320 years to move 1cm
    in a solid. But, they ARE moving! Atomic scale on
    order of ?.
  • Atoms can also diffuse (migrate) in crystalline
    solids because of defects (more later).

d v D t
time
diffusion distance
diffusion constant
20
Melting Points
  • Compounds may melt congruently (Tm) , with a
    single melting point. Changes from solid to
    liquid of same composition.
  • e.g. H2O(s) ? H2O(l) all elements melt
    congruently.
  • Some compounds melt incongruently (Tin),
    decomposing on heating to components with
    different composition.
  • e.g. solid ? solid and liquid of different
    composition.
  • e.g. YBa2Cu3O4 melts incongruently.
