OGSA-DQP

• Steven Lynden
• University of Manchester

2
Introduction

• OGSA-DQP is a service based distributed query
  processor
• It evaluates queries over distributed data
  sources wrapped by OGSA-DAI
• It is built using OGSA-DAI extensibility points
• People involved
• University of Manchester
• Tasos Gounaris, Steven Lynden, Alvaro Fernandes,
  Rizos Sakellariou, Norman Paton
• University of Newcastle
• Jim Smith, Arijit Mukherjee, Paul Watson
• OGSA-DAI
• Prototype release 3.0 available from the OGSA-DAI
  website

3
OGSA-DQP high-level overview

• OGSA-DQP uses a middleware approach.
• It can be seen as a mediator over OGSA-DAI
  wrappers.
• Usability use it as an OGSA-DAI data service.
• DQP is capable of planning, scheduling and
  executing in parallel the distributed queries
• Calls to analysis (Web) services can be declared
  within queries and invoked by DQP.

Query
Results
OGSA-DQP
OGSA-DAI
OGSA-DAI
DBMS
DBMS
data
data
4
OGSA-DQP architecture
Evaluator
QE
DQP activities installed
OGSA-DAI data service
Evaluator
perform
QE
Evaluator
QE
The OGSA-DQP service, Grid Distributed Query
Service (GDQS) AKA Coordinator
AKA Grid Query Evaluation Service (GQES)
5
OGSA-DQP architecture

• DQP evaluator services
• Are plain Web services
• Implement the QueryEvaluation port type
• evaluate the input is a query plan partition
  which is subsequently executed
• receiveData allows the evaluator to receive
  data from other evaluators
• OGSA-DAI extensions
• DQP resource a resource which encapsulates a
  distributed query infrastructure DQP evaluator
  services, OGSA-DAI data services etc. Implemented
  as a data resource accessor.
• OQL query statement activity enables the
  submission of a query in Object Query Language
  (OQL)
• DQP factory activity enables the creation and
  configuration of DQP resources.

6
Example query

• Given two DBMSs and one analysis tool (i.e., a
  Web service)
• goTerm a table in a GO Gene Ontology database
  running as a remote mySQL DB, exposed by an
  OGSA-DAI data service
• protein a table in a protein sequence DB,
  exposed by an OGSA-DAI data service
• Blast (sequence alignment scoring Web service)
• We want to obtain alignment scores for a sequence
  against proteins of a certain kind
• The user submits a single query referencing data
  stored at multiple sites.
• The author of the query need not be aware of
  how/where data is stored.
• Queries are written in Object Query Language
  (OQL)

select p.proteinId, Blast(p.sequence) from
protein p, goTerm t where t.termId GO0005942
and p.proteinIdt.proteinId
7
Client interaction with OGSA-DQP

• Two kinds of client/server interactions
• Configuration the client sends a perform
  document requesting the service to create a DQP
  data service resource
• Query submission the client sends a perform
  document requesting the service to execute an
  Object Query Language (OQL) query, using a DQP
  data service resource created in (1)
• The data service resource created in (1)
  encapsulates the distributed query infrastructure
  used to execute queries. Differs from the typical
  OGSA-DAI data service resources e.g. relational
  data service resource

8
DQP configuration
ltperformgt ltDQPFactorygt Evaluator URLs OGSA-DAI
data service resources Web service
URLs lt/DQPFactorygt lt/performgt
OGSA-DAI data service
GetRP
OGSA-DAI data service
OGSA-DAI data service
GetRP
perform
DQP factory activity
Result resource ID of created DSR
creates
DQP DSR

• Global schema of imported DBs analysis
  services
• Set of evaluators that can be used
• Physical DB metadata (used to optimise queries)

9
DQP query evaluation
ltperformgt ltOQLQueryStatementgt ltexpressiongt OQL
query lt/expressiongt lt/OQLQueryStatementgt
lt/performgt
OGSA-DAI data service
Evaluator
perform
QE
OGSA-DAI data service
Analysis service
Evaluator
transport
perform
. . .
QE
OQLQueryStatement
DQP DSR
OGSA-DAI data service
Evaluator
perform
QE
Result WebRowSet XML Stream
10
OQL Query Statement activity detail
query
single-node optimiser
logical optimiser
physical optimiser
parser
evaluators
partitioner
scheduler
multi-node optimiser
query results
11
Logical optimisation

• Consider the query
• select p.proteinId, Blast(p.sequence)
• from protein p, goTerm t
• where t.termId GO0005942 and
• p.proteinId t.proteinId
• Plan is expressed as a logical algebra
• Multiple equivalent plans are generated

reduce
op_call (Blast)
join (proteinId)
reduce
reduce
scan termIdGO0005942 (goTerm)
scan (protein)
12
Physical optimisation

• Plan is expressed as a physical algebra
• Plan is chosen by cost-ranking of equivalent plans

reduce
op_call (Blast)
hash_join (proteinId)
reduce
reduce
table_scan termIdGO0005942 (goTerm)
table_scan (protein)
13
Query partitioning

• Plan is transformed into a parallel algebra
  (physical operators data exchange)
• Exchange operators are placed where data exchange
  must take place

reduce
op_call (Blast)
exchange
hash_join (proteinId)
exchange
exchange
reduce
reduce
table_scan termIdGO0005942 (goTerm)
table_scan (protein)
14
Query scheduling

• Allocate operators to evaluator nodes

partitioned parallelism
pipelined parallelism
select p.proteinId, Blast(p.sequence) from
protein p, goTerm t where t.termId
GO0005942 and p.proteinId t.proteinId
15
Conclusion

• OGSA-DQP is a service based distributed query
  processor that is
• Exposed as a service
• Implemented as an orchestration of services
• Benefits
• Queries are executed in parallel
• OGSA-DAI OGSA-DQP can take advantage of the host
  of delivery options provided by OGSA-DAI
• Web services can be invoked during query
  execution, merging data access with data analysis
