THINGS BIG

1
THINGS BIG SMALL

• Dhiman Chakraborty
• (dhiman_at_fnal.gov)

2
Outline Part 2

• Up to the grandest the Universe at large
• Big Bang Cosmology a brief overview
• The three tests of BB cosmology
• Cosmic Microwave Background (CMB) ? Flat Universe
• Large Scale Structure (LSS) ? Dark matter
• Expansion of the Universe Supernova 1a (SN1a) ?
  Dark E
• Recent/current/proposed experimental programs
  using ground- and space-based telescopes
• CMB COBE, WMAP, Planck
• LSS HST, SDSS, LSST, Chandra, XMM-Newton,
• SN1a HZSNT, SCP, SNAP
• Summary of planned HEP cosmology projects
• Outlook

3
Up to the grandest
4
Big Bang cosmology

• t0 the beginning of time space represents an
  essential singularity with infinite matter-energy
  density (r) and temperature (T).
• An expansion ensues, governed primarily by GTR.
• T r fall as the universe expands.

5
Epochs dominant components

• ? lt10-43 s string (?)
• Inflation 10-38 s vacuum (inflaton driven?)
• Quantum fluctuations imprinted on metric, to be
  seen later as anisotropies in cosmic microwave
  background.
• Baryogenesis 10-36 s radiation/matter(?)
• WIMP decoupling
• Big Bang Nucleosynthesis (BBN) 1 s radiation
• neutrino decoupling. Best tested part, nB/ng
  only parameter.
• Cosmic Microwave Background (CMB) 1012 s matter
• photon decoupling ? transition to
  matter-dominated era.
• Present 5?1017 s vacuum
• Dark energy drives the universe into
  accelerated expansion.

6
Evolution of the Universe
7
Evolution of the Universe
8
Pillars of the Big Bang theory

• Cosmic microwave background
• Abundance of the light elements
• Evidence of cosmic expansion
• Observationally, these measurements are
  completely independent of each other. They must
  provide even support for the theory to hold water.

9
Hubbles law

• Based on experimental observation (1929)
• On average, all galaxies are moving away from
• each other with speed proportional to distance.
• Corollary on large scales, the universe is
  homogeneous and isotropic- it looks the same in
  all directions and in all parts theres no
  center nor edge.
• Metric for a homogeneous isotropic universe
• R(t) scale factor (dimensionless)

10
The Friedman equation
where ,

• governs the expansion of a uniform gas-filled
  universe
• r Energy density (matterradiationvacuum)
• z ? t (large z ? small t, present ? R R0 ?
  z0 ).
• H0 ? 60 km/s/Megaparsec (1 Mpc ? 3.26
  light-year)

critical density (? k0, flat universe)
Red shift (Doppler effect)
11
The density components
In general,
equation of state parameter
In a flat universe dominated by

• density parameter (inormal matter, neutrino,
  dark matter, dark energy, )

12
Geometry of the Universe
Current data ? ? 1
13
Structure formation

• Jeans instability in self-gravitating systems
  cause formation of structures.
• Needs initial seed density fluctuations.
• Density fluctuations grow little in a radiation-
  or vacuum-dominated universe.
• Density fluctuations grow linearly in a matter
  -dominated universe.
• Baryonic matter alone falls far short of
  explaining the level of structure seen today.

14
Theoretical arguments for dark matter

• Spiral galaxies made of bulgedisk unstable as a
  self-gravitating system ? need a (nearly)
  spherical halo.
• With only baryons as matter, structure forma-tion
  starts too late for us to exist at this time
• Matter-radiation equality achieved too late,
• Baryon density fluct. cant grow until
  decoupling,
• Need larger electrically neutral component.

15
Size-evolution of the universe
16
Observational verification

• A Standard Model of cosmology emerges from
  extensive surveys of
• Anisotropy in cosmic microwave background
  (earliest structures visible, z ? 3000) CMB
• Large-scale structures (e.g. Galaxies, clusters,
  grav. lensing, z ? 5, ? dark matter,) LSS
• Type 1a supernova brightness redshift (std.
  candles, z ? 0.5, ? dark energy) SN1a
• Each gives a linear equation in ?M, ?? ? any two
  of these determine ?M, ?? the 3rd serves as a
  cross-check.

17
CMB Peeking into the universes infancy
with the Wilkinson Microwave Anisotropy Probe
18
WMAP talk about thermal resolution!
19
WMAP talk about spatial resolution!
20
LSS Surveying galaxies clusters with normal
(HST, SDSS) x-ray (Chandra, XMM-Newton) vision

• The XMM-Newton x-ray observatory

21
LSS Dark matter in galaxy clusters

• Galaxies form clusters bound in a gravitational
  well.
• Hydrogen gas in the well gets heated, emits
  x-ray.
• Allows us to determine the baryon fraction of the
  cluster.

22
LSS Chandra discovers "Rivers Of Gravity" that
define the cosmic landscape
Four independent teams of scientists have
detected intergalactic gas with temperatures in
the range 300,000 to 5 million degrees Celsius by
observing quasars with the Chandra X-ray
Observatory. An artist's rendering illustrates
how X-rays from a distant quasar dim as they pass
through a cloud of the intergalactic gas. By
measuring the amount of dimming due to oxygen and
other elements in the cloud - see the spectrum of
the quasar PKS 2155-304 in the inset -
astronomers were able to estimate the
temperature, density and mass of the absorbing
gas cloud.
23
LSS Chandra discovers "Rivers Of Gravity" that
define the cosmic landscape
24
LSS Surveying galaxies clusters with normal
(HST, SDSS) x-ray (Chandra, XMM-Newton) vision

• The sky is not so dark in x-ray HST (L), Chandra
  (R)

25
Sloan Digital Sky Survey (SDSS)
26
LSS
The M78 nebula, a nursery of stars, as seen by
SDSS

• It is extremely important to know how the mass
  and energy, most of it dark, is distributed
  throughout the universe. A particle theory that
  contradicts cosmological observations will not be
  viable.

27
LSS CMB surveys agree
28
SN1a measuring the rate of cosmic expansion
using high-z supernovae 1a as standard candles

• Nuclear chain reaction in stars with M?2Msun
  (more complex - binaries etc.)
• As bright as host galaxy
• Brightness not const, but related to fall-off
  rate.
• Apparent brightness gives distance.
• Red shift (z) gives relative radial velocity.

29
SN1a Clear evidence of accelerated expansion

• By SCPHZSNT using HST ground-based telescopes.
• The cosmological constant fits the bill.
• Can in principle be something else with ve p.
• Generally called Dark Energy.

30
Expansion history of the universe
31
SN1a Next step the Joint Dark Energy Mission
The proposed Supernova/ Acceleration Probe (SNAP)
32
The cosmic concordance

• CMB ? ?1? flat universe.
• LSS ?M ? 0.3
• SN1a ?L-2?M ? 0.1

• Remarkable agreement
• Dark Matter 23 4
• Dark Energy 73 4
• (Baryons 4 0.4, Neutrinos 0.5)
• Remarkable precision (10)
• Remarkable results

33
Cosmology summary

• The current state of knowledge
• The Universe is geometrically flat,
• It is expanding with increasing speed,
• Dark energy dominates matter,
• Dark matter dominates baryonic matter,
• Baryonic matter dominates baryonic antimatter.

34
Outstanding questions

• Dark Matter What is it? How is it distributed?
• Dark Energy What is it? Why not WL 10120?
  Why not WL 0? Does it evolve?
• Baryons Why not WB 0?
• Ultra-High-Energy Cosmic Rays What are they?
  Where do they come from?
• What tools do we need to address these?

35
Particle dark matter

• Suppose an elementary particle constitutes DM
• WIMP (Weakly Interacting Massive Particle).
• Heavy but stable, neutral, produced in early
  Universe.
• Left over from near-complete annihilation.
• No such candidate in the SM, must be new physics!

• TeV is the right energy scale.
• SUSY the lightest supersymmetric particle (LSP)
  is a superpartner of a gauge boson in most
  models the bino is a perfect candidate for a
  WIMP.
• There are other possibilities (axino, gravitino,
  axion, technibaryons, axion, Kaluza-Klein
  particles, )
• In any case, we should be able to produce such
  WIMPs at colliders of the next generation (LHC,
  ILC).

36
Neutralino dark matter
37
The enigma of dark energy

• A naïve estimate of the cosmological constant in
  quantum field theory ? rL ? MPlanck4?10120 times
  the onserved value.
• The worst prediction in theoretical physics!
• People had argued that there must be some
  mechanism to set it to zero.
• But now it seems finite!!!
• Quintessence?
• A scalar field slowly rolling down the potential
  hill.
• Will set L to 0 when it reaches the minimum?
• Must be extremely light O(10-42 GeV) !!!

38
Particle physics at the energy frontier
39
The many connections
40
Conclusions

• Theres mounting evidence for non-baryonic dark
  matter and dark energy.
• These immediately imply physics beyond the SM.
• Dark matter is likely to be at TeV scale.
• Search for dark matter using
• Collider experiments (LHC, ILC)
• Direct searches (CDMS-II)
• Indirect searches (ICECUBE)
• Dark energy best investigated by JDEM (SNAP?).

41
The larger US efforts
From the report of the Quantum Universe
subcommittee commissioned by HEPAP (DOE/NSF)
42
The smaller US efforts
From the report of the Quantum Universe
subcommittee commissioned by HEPAP (DOE/NSF)
43
HEPAP recommendation to DOE/NSF
(by subpanel on Long Range Planning for U.S. HEP)
44
Outlook

• A large number of particle physics, astrophysics,
  and cosmology projects both theoretical and
  experimental are underway. They complement
  each other toward a common goal to solve the
  most fundamental mysteries of nature.
• It is a truly INTERNATIONAL effort.
• We are living through a revolution in our
  understanding of the Universe on both the
  smallest and the largest scales.
• The next decade or two will usher us into a new
  era of observation and comprehension.

45
THANK YOU!

• Feel free to contact the speaker
• for more information
• dhiman_at_fnal.gov
