Title: Cluster analysis for microarray data


1
Cluster analysis for microarray data
  • Anja von Heydebreck

2
Aim of clustering Group objects according to
their similarity
Cluster a set of objects that are similar to
each other and separated from the
other objects. Example green/ red data
points were generated from two different normal
distributions
3
Clustering microarray data
gene expression data matrix
  • Genes and experiments/samples are given as the
    row and column vectors of a gene expression data
    matrix.
  • Clustering may be applied either to genes or
    experiments (regarded as vectors in Rp or Rn).

n experiments
p genes
4
Why cluster genes?
  • Identify groups of possibly co-regulated genes
    (e.g. in conjunction with sequence data).
  • Identify typical temporal or spatial gene
    expression patterns (e.g. cell cycle data).
  • Arrange a set of genes in a linear order that is
    at least not totally meaningless.

5
Why cluster experiments/samples?
  • Quality control Detect experimental
    artifacts/bad hybridizations
  • Check whether samples are grouped according to
    known categories (though this might be better
    addressed using a supervised approach
    statistical tests, classification)
  • Identify new classes of biological samples (e.g.
    tumor subtypes)

6
Alizadeh et al., Nature 403503-11, 2000
7
Cluster analysis
  • Generally, cluster analysis is based on two
    ingredients
  • Distance measure Quantification of
    (dis-)similarity of objects.
  • Cluster algorithm A procedure to group objects.
    Aim small within-cluster distances, large
    between-cluster distances.

8
Some distance measures
  • Given vectors x (x1, , xn), y (y1, , yn)
  • Euclidean distance
  • Manhattan distance
  • Correlation
  • distance

9
Which distance measure to use?
  • The choice of distance measure should be based
    on the application area. What sort of
    similarities would you like to detect?
  • Correlation distance dc measures trends/relative
    differences
  • dc(x, y) dc(axb, y) if a gt 0.

x (1, 1, 1.5, 1.5) y (2.5, 2.5, 3.5, 3.5)
2x 0.5 z (1.5, 1.5, 1, 1)
dc(x, y) 0, dc(x, z) 2. dE(x, z) 1, dE(x,
y) 3.54.
10
Which distance measure to use?
  • Euclidean and Manhattan distance both measure
    absolute differences between vectors. Manhattan
    distance is more robust against outliers.
  • May apply standardization to the observations
  • Subtract mean and divide by standard
    deviation
  • After standardization, Euclidean and correlation
    distance are equivalent

11
K-means clustering
  • Input N objects given as data points in Rp
  • Specify the number k of clusters.
  • Initialize k cluster centers. Iterate until
    convergence
  • - Assign each object to the cluster with the
    closest center (wrt Euclidean distance).
  • - The centroids/mean vectors of the obtained
    clusters are taken as new cluster centers.
  • K-means can be seen as an optimization problem
  • Minimize the sum of squared within-cluster
    distances,
  • Results depend on the initialization. Use several
    starting points and choose the best solution
    (with minimal W(C)).

12
K-means/PAM How to choose K (the number of
clusters)?
  • There is no easy answer.
  • Many heuristic approaches try to compare the
    quality of clustering results for different
    values of K (for an overview see Dudoit/Fridlyand
    2002).
  • The problem can be better addressed in
    model-based clustering, where each cluster
    represents a probability distribution, and a
    likelihood-based framework can be used.

13
Hierarchical clustering
  • Similarity of objects is represented in a tree
    structure (dendrogram).
  • Advantage no need to specify the number of
    clusters in advance. Nested clusters can be
    represented.

Golub data different types of leukemia.
Clustering based on the 150 genes with highest
variance across all samples.
14
Agglomerative hierarchical clustering
  • Bottom-up algorithm (top-down (divisive) methods
    are less common).
  • Start with the objects as clusters.
  • In each iteration, merge the two clusters with
    the minimal distance from each other - until you
    are left with a single cluster comprising all
    objects.
  • But what is the distance between two clusters?

15
Distances between clusters used for hierarchical
clustering
  • Calculation of the distance between two
    clusters is based on the pairwise distances
    between members of the clusters.
  • Complete linkage largest distance
  • Average linkage average distance
  • Single linkage smallest distance

Complete linkage gives preference to
compact/spherical clusters. Single linkage can
produce long stretched clusters.
16
Hierarchical clustering
  • The height of a node in the dendrogram represents
    the distance of the two children clusters.
  • Loss of information n objects have n(n-1)/2
    pairwise distances, tree has n-1 inner nodes.
  • The ordering of the leaves is not uniquely
    defined by the dendrogram 2n-2 possible choices.

Golub data different types of leukemia.
Clustering based on the 150 genes with highest
variance across all samples.
17
Alternative direct visualization of
similarity/distance matrices
Useful if one wants to investigate a specific
factor (advantage no loss of information). Sort
experiments according to that factor.
18
Clustering of time course data
  • Suppose we have expression data from different
    time points t1, , tn, and want to identify
    typical temporal expression profiles by
    clustering the genes.
  • Usual clustering methods/distance measures dont
    take the ordering of the time points into account
    the result would be the same if the time points
    were permuted.
  • Simple modification Consider the difference
    xi(j1) xij between consecutive timepoints as
    an additional observation yij. Then apply a
    clustering algorithm such as K-means to the
    augmented data matrix.

19
Biclustering
  • Usual clustering algorithms are based on global
    similarities of rows or columns of an expression
    data matrix.
  • But the similarity of the expression profiles of
    a group of genes may be restricted to certain
    experimental conditions.
  • Goal of biclustering identify homogeneous
    submatrices.
  • Difficulties computational complexity, assessing
    the statistical significance of results
  • Example Tanay et al. 2002.

20
The role of feature selection
  • Sometimes, people first select genes that appear
    to be differentially expressed between groups of
    samples. Then they cluster the samples based on
    the expression levels of these genes. Is it
    remarkable if the samples then cluster into the
    two groups?
  • No, this doesnt prove anything, because the
    genes were selected with respect to the two
    groups! Such effects can even be obtained with a
    matrix of i.i.d. random numbers.

21
Classification Additional class information
given
object-space
22
Classification methods
  • Linear Discriminant Analysis (LDA, Fisher)
  • Nearest neighbor procedures
  • Neural nets
  • Support vector machines

23
Embedding methods
  • Attempt to represent high-dimensional objects as
    points in a low-dimensional space (2 or 3
    dimensions)
  • Principal Component Analysis
  • Correspondence Analysis
  • (Multidimensional Scaling represents objects for
    which distances are given)

24
Principal Component Analysis
  • Finds a low-dimensional projection such that the
    sum-of-squares of the residuals is minimized

25
Contingency Tables Results from a poll among
people of different nationality
nationality
Ge
Au
It
favorite dish
Pasta
35
12
11
Wiener Schnitzel
23
11
18
Sauerbraten
7
9
19
26
Microarray experiment
Genes
Cdc14
Gle2
Gal1
Experimental condition
Wt yeast
35
12
11
wt yeast galactose
23
11
18
Yeast transgene
7
9
19
27
Correspondence Analysis and Principal Component
Analysis
  • Objects are depicted as points in a plane or in
    three-dimensional space, trying to maintain their
    proximity
  • CA is a variant of PCA, although based on another
    distance measure ?2-distance
  • Embedding tries to preserve ?2-distance

28
Correspondence analysis Interpretation
  • Shows both gene-vectors and condition-vectors as
    dots in the plane
  • Genes that are nearby are similar
  • Conditions that are nearby are similar
  • When genes and conditions point in the same
    direction then the gene is up-regulated in that
    condition.

29
?2-distance
2
(fkj?fk - flj ?fl)
dkl ?
fj ?n
j1..n
30
Correspondence analysis Interpretation
  • Shows both gene-vectors and condition-vectors as
    dots in the plane
  • Genes that are nearby are similar
  • Conditions that are nearby are similar
  • When genes and conditions point in the same
    direction then the gene is up-regulated in that
    condition.

31
G1 S G2
M
Spellman et al took several samples per
time-point and hybridized the RNA to a glass
chips with all yeast genes
32
