Community Organization and Structure

1
Community Organization and Structure
2
Ecotones
3
Boreal Forest/Tundra Ecotone
4
Community properties Abundance
Abundance ( individuals)

• Log Normal distribution of two species

5

• Moths caught in light traps
• Number of species behind the veil
• Number of species found increases as the number
  of individuals sampled increases.

6
Unpolluted stream
Number of diatom species
Polluted stream
Number of individuals per diatom species
7
Community properties Species richness
Abundance of Bird Species found in tin-mining
areas in Indonesia
8
Community properties Species diversity

• Species diversity is comprised of two separate
  items
• Evenness (how evenly distributed among the
  species are the individuals in the community?
• Species richness (number of species)
• The two measures together are referred to as
  heterogeneity

9
Heterogeniety

• 5 species in this forest community (richness)

See Fig. 16.5
10
Community properties Species diversity
Ways to measure Species Diversity

• Shannon-Wiener index (H)
• H -? pi loge pi
• Sums from 1 to the number of species (S)
• p proportion (decimal) of number in species i
  out of all individuals in the sample.
• negative value compensates for log of decimal
  (negative)
• Simpsons index
• A measure of dominance, but the reciprocal can be
  used as a diversity index
• Diversity or 1/?pi2
• Emphasizes the more abundant species

11
Calculation examples

• Five species in the community
• Species A B C D E
• Community A 20 20 20 20 20
• Community B 60 10 10 10 10
• Community C 25 25 25 25 0
• Richness is the same for the first two
  communities, but species diversity is higher in
  Community A.
• Shannon Index
• A - .2(-1.61).2(-1.61).2(-1.61).2(-1.61).2(
  1.61) 1.61
• B - .6(-.511).1(-2.30).1(-2.30).1(-2.30).1(
  -2.30) 1.22
• C - .25(-1.39).25(-1.39).25(-1.39).25(-1.39)
  1.39
• Simpsons diversity index
• A 100(99)/20(19)20(19)20(19)20(19)20(19)
  5.20
• B 100(99)/60(59)10(9)10(9)10(9)10(9)
  2.52
• C 100(99)/25(24)25(24)25(24)25(24)
  4.12

12
Richness gradients

• North to South sampling shows an increasing
  number of species (richness)

13

• Mammals show similar trends

14
(No Transcript)
15
Bird Richness
16
Tree richness
17
25
25
Snails
Tube worms
20
20
15
15
Species diversity
10
10
5
5
Coast
Deep Sea
Coast
Deep Sea
0
0
0
2,000
4,000
6,000
0
2,000
4,000
6,000
Depth (meters)
Depth (meters)
18
Intermediate disturbance hypothesis

• The highest species diversity is found at the
  intermediate level of disturbance.
• High disturbance kills off too many species and
  low disturbance limits them through dominance and
  competition.

19
Coastal boulders as habitat
High disturbance
Low disturbance
Intermediate disturbance
Text Fig. 16.19
20
Keystone species

• Species that help to determine the composition of
  the community
• Generally the top predator
• The predator tends to prefer the most abundant
  prey species
• Competition lowered predator regulates prey
  population sizes
• If keystone species is removed, extinction of
  other species through competition often occurs

21
Community properties Interactions

• Change over time - Succession
• Energy transfer (food webs) and nutrient cycling
• Invasive species affect ecosystems through these
  means in addition to competition both directly
  and indirectly

22
