Overview of Energy Production

1
Overview of Energy Production

• PED 5230

2
ATP Universal Energy Donor
3
ATP

• ATP H2O ? ADP P energy.
• Enzyme - ATPase
• 7.3 kcal/mol (11 kcal/mol)

4
ATP
Energy Out
Energy In

• Where does this energy come from?

• What is the energy used for?

• Swiveling of myosin heads
• Separation of myosin head from actin

ADP

• CrP
• Carbohydrates
• Fats
• Proteins

5
Creatine Phosphate

• CrP ADP ? ATP Cr.
• Enzyme - Creatine Kinase
• Very fast, almost immediate, re-production of ATP
• Very limited production of ATP
• ATP Cr ? CrP ADP
• This ATP comes from other energy systems during
  rest or light exercise

6
Creatine Phosphate
7
ATP and CrP

• CrP produces ATP so rapidly that a reduction in
  ATP levels are rarely seen even at maximal
  exercise.

8
Gimme fuel, Gimme fire Gimme that which I
desire - Metallica
9
Carbohydrates

• Carbohydrates
• Glucose
• Glycogen (stored glucose molecules)
• Anaerobic or Aerobic
• Glycolysis (Anaerobic)
• Glucose ? 2 ATP 2 Lactate 2 H
• Fast ATP production
• Limited ATP production

10
Carbohydrates

• Aerobic
• Glucose O2 ? 36 ATP CO2 H2O
• Fast (for aerobic fuel)
• Limited supply of stored carbohydrate inside the
  body

11
Fats

• Fats (e.g. Palmitate) O2 ? 129 ATP CO2 H2O
• Slow
• Larger molecule
• Mobilization
• Require more O2

12
Available Energy Sources
From Wilmore and Costill
13
Available Energy Sources
Tale 3-4
?
?
14
Protein

• During exercise.
• Kreb cycle intermediates (help with energy
  production)
• Glucose-Alanine cycle (an indirect energy source)
• Oxidation (a direct energy source)
• Only 5-10 of total energy during exercise

15
(No Transcript)
16
Krebs Cycle
17
Glucose-Alanine Cycle

• Alanine converted to glucose in the liver
• Glucose be used to supply the CNS with glucose
  during
• Starvation
• Prolonged exercise

18
Glucose-Alanine Cycle (figure 8-10)
Muscle
Liver
Glucose
Blood
Alanine
NH3
Urea
Kidney
Alanine
19
Oxidation

• Protein oxidation during exercise decreases with
  conditioning

20
Energy Systems

• Anerobic
• ATP-PCr
• Glycolysis
• Aerobic
• 3. Oxidation

21
Energy Systems
22
Energy Systems
23
ATP-PCr
24
Glycolysis
25
Glycolysis

• Glucose, a six carbon sugar, is split into two,
  three-carbon molecules.
• Products
• 4 ATP (2 Net)
• 2 NADH
• 2 Pyruvate (Pyruvic acid)

glycogen
26
Glycolysis
Figure 5-7
27
Glycolysis

• What happens to the ATP made in glycolysis?
• What happens to the NADH?
• What happens to the pyruvate?

28
Oxidation

• Oxidation the process of removing an electron
  from a molecule (e.g. Hydrogen)
• The electron provides the energy needed to reform
  ATP from ADP and P
• Subsystems
• Krebs Cycle
• Electron Transport Chain
• Beta Oxidation

29
Where Does Oxidation Occur?

• Mitochondria (plural)
• Outer membrane
• Intermembrane space
• Inner membrane

30
(No Transcript)
31
The Krebs Cycle
32
Key Enzymes

• Isocitric Dehydrogenase (IDH)
• The rating limiting enzyme
• Inhibited by ATP, NADH, acid (lactic acid) etc.
• Stimulated by ADP, NAD, etc.

33
The Krebs Cycle

• From 1 pyruvate
• 3 CO2
• 1 ATP (GTP)
• 4 NADH
• 1 FADH

34
Actyl-CoA

• Sources of Actyl-CoA
• Glucose (Pyruvate)
• Fatty acids
• Amino acids
• Combines with OAA to form citric acid

35
The Krebs Cycle

• An imperfect cycle
• Products
• CO2
• ATP
• H
• Which product is most important?
• Why?

36
NADH and FADH

• Transport H to Electron Transport Chain

• NADH give 3 ATP for every H
• FADH give 2 ATP for every H

37
Electron Transport Chain
38
Electron Transport Chain

• Inner mitochondrial membrane
• Oxidation removal of electrons (H)
• Series of steps from higher to lower energy
• A chemical and electrical gradient is formed

39
(No Transcript)
40
(No Transcript)
41
Electron Transport Chain

• Phosphorlyation ADP P ? ATP
• Re-entry of H provide energy (Fig. 6-10)
• Linked to the formation of water
• Oxygen is the final electron acceptor
• H2O

42
Oxidation of Carbohydrates
43
Glycolysis
Krebs Cycle
Electron Transport Chain
44
GLYCOLYSIS
Start with glucose
2 NADH
2 net ATP
End with 2 pyruvates
45
KREBS CYCLE
Start with pyruvate being converted to Acetyl-CoA
End up with 4 NADH 1 FADH ATP CO2
46
KREBS CYCLE (Detailed)
47
KREBS CYCLE AND THE ELECTRON TRANSPORT CHAIN
48
(No Transcript)
49

• ALL TOGETHER
• GLYCOLYSIS
• KREBS
• ELECTRON TRANSPORT CHAIN

50

• ALL TOGETHER
• GLYCOLYSIS
• KREBS
• ELECTRON TRANSPORT CHAIN

• ALL TOGETHER
• GLYCOLYSIS
• KREBS
• ELECTRON TRANSPORT CHAIN

NAD NADH
Lactic Acid
51
Glycolysis
52
Aerobic or slow glycolysis

• Glucose 2 Pi 2 ADP 2 NAD ? 2 pyruvate 2
  ATP 2 NADH 2 H2O
• The 2 NADH move into the mitochondria.
• Pyruvate also moves into the mitochondria

53
Anaerobic or fast glycolysis

• Glucose 2 Pi 2 ADP ? 2 lactate 2 ATP H2O.
• The NADH are used to convert pyruvate to lactate.
• Keeps H level low, at least temporarily.

Mitochondria
54
"There are three side effects of acid enhanced
long-term memory, decreased short-term memory,
and I forget the third." - Timothy Leary
55
Lactic Acid

• Initially, most glucose is used aerobicly
• As more glucose is required, due to an increase
  in intensity, more NADH is produced in the
  sarcoplasm
• If the additional NADH cannot transfer H to
  mitochondria, then lactate levels increase
• The more O2 that is supplied to the mitochondria,
  the more NADH will be transfer into the
  mitochondria and the less lactic acid that will
  be produced.

56
Lactic Acid

• Production
• Excess NADH in sarcoplasm
• Inadequate oxygen supply to mitochondria
• Rapid rate of glycolysis
• Removal
• Slow twitch muscle fibers
• Liver
• Heart

57
The Cell-Cell Lactate shuttle

• Figure 5-20.
• Lactate from FT fiber can shuttle to ST fibers
  and be oxidized

58
Glucose Paradox
Figure 5-3
59
Lactic Acid Turnover

• During heavy exercise, lactate levels increase
  because production is greater than removal.
• High amounts of lactic acid cause fatigue but not
  delayed muscle soreness.

60
Lactate levels after a 200-m swim at the same
speed.
61
"I find no sweeter fat than sticks to my own
bones." - Walt Whitman
62
Burning Fats During Exercise

• Mobilization of Fats
• Circulation and Uptake
• Activation
• Translocation
• Beta (?) Oxidation
• Krebs/ETC Oxidation

63
Fat Mobilization
64
Activation and Translocation

• Figure 7-5
• FA bind to acyl-CoA (1) Fatty acyl-CoA
• Move to inner membrane
• CoA is removed and FA attaches to carnitine
• (2) Fatty acyl-carnitine to the inside of the
  mitochondrion
• Carnitine is removed
• Another CoA added, (3) Fatty acyl-CoA

65
(No Transcript)
66
?-Oxidation

• Degrades the (3) fatty acyl-CoA to (4) acetyl-CoA
  by cleaving two carbons at a time
• First carbon is the alpha ? carbon
• Second carbon is the ? carbon
• Palmitate (16 carbons) will provide 8 acetyl CoAs

67
(No Transcript)
68
?-Oxidation

• Acetyl Co-A enters Krebs cycle
• Each acetyl Co-A results in 12 ATP
• 1 NADH and 1 FADH
• Palmitate (16 carbons) will provide 129 ATP
• Triglyceride of stearate (18 C) 460 ATP

69
Fat Burns in a Carbohydrate Flame

• Beta oxidation produces acetyl-CoA
• Acetyl-CoA must bind with oxaloacetate (OAA) in
  order to enter the Krebs cycle
• OAA needs to constantly be replaced.
• Pyruvate can be converted to OAA
• Without adequate pyruvate, there is insufficient
  OAA needed for acetyl-CoA to enter the Krebs
  cycle.

70
Beta Oxidation
71
Fat Utilization During Exercise

• Rest
• 60 fat, 35 carb, 5 protein
• Exercise
• Burn more of everything
• Greater percentage comes from carbohydrates
• Active muscle cells burn mostly all carbohydrates
• Other inactive cells burn fat
• Very hard exercise
• Burn less fat due to an increase in lactic acid
  which inhibits L-HSL and fat mobilzation

72
(No Transcript)
73
Fuel Sources
74
Fuel Sources
75
(No Transcript)
