GPU Computation Strategies

1
GPU Computation Strategies Tricks

• Ian Buck Stanford University

2
DirectX or OpenGL?

• DirectX
• Render to Texture
• SetRenderTarget()
• No float targets on NV3x
• Write once run anywhere
• DBMON
• Short programs
• Only 96 instr required
• ps_2_a compiler target allows long programs on
  NV3x
• Readback is slow!
• 50 MB/sec

• OpenGL
• 0 to N texture addressing
• GL_TEXTURE_RECTANGLE_EXT
• Readback is fast
• Render to Texture not finalized
• Pbuffer rendering can be slow
• SuperBuffers
• GL_EXT_render_target
• Specialized float formats forATI and NV
• No ARB standard for creating float Pbuffer
• ATI float2 Red and Alpha
• NV float2 Red and Green

3
ATI Radeon 9800XT or NVIDIA GeForce 5900 Ultra?
Instruction Timings
4
Floating Point Precision

• NVIDIA FP32
• s23e8 (largest counting number 16,777,217)
• ATI 24-bit float
• s16e7 (largest 131,073)
• NVIDIA FP16
• s10e5 (largest 2,049)

mantissa
exponent
s
sign 1.mantissa 2(exponentbias)
5
Floating Point Precision

• Common Mistake
• Pack large 1D array in 2D texture
• Compute 1D address in shader
• Convert 1D address into 2D
• FP precision will leave unaddressable texels!

NVIDIA FP32 16,777,217 ATI 24-bit float
131,073 NVIDIA FP16 2,049
6
Multiple Outputs

• Hardware supported multiple outputs
• Not as fast as you think

ATI 9800XT
7
Multiple Outputs

• Software solution
• Let cgc or fxc do dead code elimination
• can be a good idea if shader is separable

kernel void foo (float3 altgt, float3 bltgt,
, out float3 xltgt, out float3 yltgt)
kernel void foo1(float3 altgt, float3 bltgt,
, out float3 xltgt)
kernel void foo2(float3 altgt, float3 bltgt,
, out float3 yltgt)
8
Scatter Techniques

• Problem ai p
• indirect write
• Cant set the x,y of fragment in pixel shader
• Also want to do ai p

9
Scatter Techniques

• Solution 1
• Sort Search
• Shader outputs destination address and data
• Bitonic sort based on address
• Run binary search shader over destination buffer
• Each fragment searches for source data
• See Sorting and Searching course notes

10
Scatter Techniques

• Solution 2
• Render points
• Use vertex shader to set destination
• or just read back the data and reissue

11
Scatter Techniques

• Solution 3
• Vertex Textures
• Render data and address to texture
• Issue points, set point x,y in vertex shader
  using address texture
• Requires texld instruction in vertex program

12
Conditional Mask

• How to efficiently implement if (a) then cb
• Kill instruction or LRP c, a, b, c
• Executes all conditional code
• Using early Z-kill
• Set Zbuffer equal to conditional
• Z test can prevent shader execution

13
Conditional Mask

• Using early Z-kill
• Z-kill operates at 4x4 block resolution
• Good only if locality in conditional

14
Optimizing Execution

• Two methods for GPGPU shader execution

glBegin(GL_QUADS) glVertex2f(left,
bottom) glVertex2f(right, bottom) glVertex2f(rig
ht, top) glVertex2f(left, top) glEnd()
glViewport(0,0,width,height) glBegin(GL_TRIANGLE)
glVertex2f( 0, 0) glVertex2f(width2,
0) glVertex2f( 0, height2) glEnd()
Faster Higher observed bandwidth
15
Performance Issues

• Peak GFLOPS

16
Performance Issues

• NV3x Register Penalty
• The more registers used in a shader, the slower a
  shader executes
• 3-4 R x2 slower
• 5-6 R x3 slower
• 7-8 R x4 slower
• 9-12R x6 slower
• 13-16R x8 slower
• 17-24R x12 slower
• 25-32R x16 slower
• Compiler / driver will try to minimize register
  usage.
• General Rule The more state in your program the
  slower the execution

17
Performance Issues

• Floating Point Texture Bandwidth
• Observed Results
• GeForce 5900 Ultra
• Cache 11.08 GB/sec
• Sequential 4.40 GB/sec
• Random 0.76 GB/sec
• ATI 9800 XT (24-bit)
• Cache 9.15 GB/sec
• Sequential 5.55 GB/sec
• Random 1.80 GB/sec
• Big Penalty for Random Access!

18
Performance Issues

• WinXP Float4 Download and Readback
• NVIDIA
• 1215 MB/sec texture download
• 221 MB/sec glReadPixels rate
• ATI
• 926 MB/sec texture download
• 180 MB/sec glReadPixel rate
• Readback should be faster!
• 680 MB/sec ATI Linux Readback
