Nuclear Chemistry: The solution or the problem

1
Nuclear ChemistryThe solution or the problem?
2
President Bush, second from right, visited the
Calvert Cliffs Nuclear Plant last year with
Constellation Energy officials. By MATTHEW
L. WALDPublished August 22, 2006
3
(No Transcript)
4
John Diesch, manager of the Rentech plant in East
Dubuque, Ill., sees profit in using cheap coal to
produce expensive truck fuel. By MATTHEW L.
WALDPublished July 5, 2006
5
(No Transcript)
6
(No Transcript)
7
Is Nuclear Power a good idea?
8
Smog Eastern China
9
Smog Hanzou, China
10
Smog Los Angeles
11
Smog New York City
12
Smog Hartford, CT
13
Do you have asthma?
14
Can nuclear power help?
Is it true?
15
Connecticut Yankee
Nuclear power plants in the Northeast
Nuclear power in Connecticut
16
Is nuclear power safe?
17
Chernobyl 1986
400 million exposed in 13 countries
18
8,000 deaths over 14 years
3.5 million sick
19
Three Mile Island 1979
20
Cancer rate increase
Mutations to plants and animals
21
Mutations, cancer
Or not?
22
Whats in store?
23
World Market for Nuclear Energy,Alain Bugat,
CEA Chairman,Conference on Nuclear Energy and
Science for the 21st Century,

• The Watergate Hotel, Washington D.C.,
• October 22, 2003

24
Fig 1 Nuclear Reactors in the World
Source AIEA
By the end of 2002 30 countries441 reactors
359 GWe
16 of electricity production 7 of primary energy
25
Fig. 6 Fossil fuels jeopardizing the resources
World estimated reserves Oil 45 Years Gas 65
Years Coal 200-300 Years
Oil Proved reserves (end 1998, in thousand
million barrels)
26
Fig. 8 Generation IV nuclear energy systems
Development of nuclear energy systems

• Deployable by 2030
• With significant advances in
• Sustainability
• Safety and reliability
• Proliferation and physical protection
• Economics
• Competitive in various markets
• Designed for different applications
• Electricity, Hydrogen, Clean water, Heat

EURATOM
27
Fig. 10 World Market for nuclear energy
JAPON Increase from 46 to 100 GWe nucl. power
by 2030
FINLAND Towards a fifth reactor
USA 400 GWe by 2020 (including nuclear energy)
CHINA 20 GWe every year (including nuclear
energy)
SOUTH KOREA to double the installed nuclear
capacity
Coal
Ren. E
Gas
Oil
Hydro
Nuclear
France Plants Renewal
28
Nuclear energy and the military
29
Hiroshima, October 1945
30
(No Transcript)
31
Nagasaki Mushroom Cloud
32
Little Boy and Fat ManHiroshima and Nagasaki
Bombs13 and 20 Kilotons
33
Ivy Mike (1952) 11 Megatons
34
Goodbye Elugelab Island
35
Other nuclear technology close to home
36
Electric Boat, Groton CT
GROTON, Conn, July 2004. Nuclear submarines,
like Virginia, provide a unique contribution to
our nations security and will be increasingly
important in the decades ahead, said Electric
Boat President John Casey, about Virginia
(SSN-774), the nations newest and most advanced
nuclear-powered attack submarine, which returned
today from the successful completion of its first
voyage in open water
37
Natural sources
38
Radon Potential Map of Connecticut
Source http//www.dph.state.ct.us/BRS/radon/radon
_map.htm
39
Other considerations
40
Gas Prices dont go down
41
Nuclear technology you may not be aware of
42
Nuclear battery
43
Lets review the basics today.
44
Nuclear Radiation
45
Subatomic Particles

• Protons- plus charge
• In the nucleus
• Neutrons- neutral
• Electrons - negative charge
• Outside the nucleus

46
Atoms and stability the 1.5/1 ratio
47
Radiation

• Emission from the nucleus
• Unstable nucleus emits a particle or energy ?
  alpha
• ? beta
• ? gamma

48
Alpha Particle

• Same as a helium nucleus
• He2
• 4
• 2He or ?
• Two protons
• Two neutrons

49
Beta Particle ?

• An electron emitted from the nucleus
• 0
• e or ?
• ?1
• A neutron in the nucleus breaks down
• 1 1 0
• n p e
• 0 1
  -1

50
Gamma ? Radiation

• Pure radiation
• Like an X-ray but comes from the nucleus

0g
0
51
Radiation Protection
52
Radiation Protection
53
Our Geiger Counter
54
Po-210

• T1/2 138 days
• If it is a a emitter, what does it form?
• 210Po ? 206Pb 4He

2
82
84
55
Balancing Nuclear Equations

• In the reactants and products
• Atomic numbers must balance
• and
• Mass numbers must balance

56
Alpha decay
57
Beta decay

• 234Th 234Pa 0e
• 90 91 ?1
• beta particle

58
Gamma radiation

• No change in atomic or mass number
• 11B 11B 0 ?
• 5 5
  0
• boron atom in a
• high-energy state

59
Learning Check NR1

• Write the nuclear equation for the beta emitter
  Co-60.

60
Solution NR1

• Write the nuclear equation for the
• Beta emitter Co-60.
• 60Co 60Ni 0 e
• 27 28
  -1

61
Monday Go Nukes vs. No Nukes

• No Nukes score_____

• Go Nukes score____

counterpoint
point
counterpoint
Point
-1 point each
1. (1 point each)
-1 point each
1. (1 point each)
2.
2.
3.
3.
4.
4.
5.
5.
1 point each
Additional points
1 point each
Additional points
1 point each
New speakers
1 point each
New speakers
-1 point each
Interrupt/over time/complain
-1 point each
Interrupt/over time/complain
Up to 5 points
Final statement
Up to 5 points
Final statement
62
Schedule

• Today nuclear chemistry/teach a topic prep.
• Friday, June 2 complete teach a topic/outdoor
  rocket launch
• Monday June 3 nuke debate/begin presentations
• Tuesday, June 4 review nukes/presentations
• Wed June 5 nukes exam/presentations
• Thurs, D-day 1 day of organic chemistry
• Friday, Monday, Tuesday (6/11) finals review

63
Review a, b, and g radiation
64
Example

• A patient is given radioactive iodine ( a b
  emitter) to test thyroid function. What happens
  to the iodine?
• Is this dangerous?
• Is the equation balanced?

131 53
131 54
I Xe ?
65
Answer
131 131 0
53 54 -1
Looks good
66
Name that element

• What element is formed when Pt undergoes b
  emission
• Gold
• What element is formed when Pd undergoes a decay?
• Ruthenium
• What element is formed when Pt undergoes g ray
  emission?
• None- still Pt
• What element would be needed to make gold by b
  decay?
• pt

67
Producing Radioactive Isotopes

• Bombardment of atoms produces various
  radioisotopes

___ n ? He
4
1
Mn
56
2
0
25
What other element is produced?
68
Learning Check NR2

• What radioactive isotope is produced in the
  following bombardment of boron?
• 10B 4He ? 1n
• 5 2
  0

69
Solution NR2

• What radioactive isotope is produced in the
  following bombardment of boron?
• 10B 4He 13N 1n
• 5 2 7
  0
• nitrogen
• radioisotope

70
Half-Life of a Radioisotope

• The time for the radiation level to fall (decay)
  to one-half its initial value
• decay curve
• 8 mg 4 mg 2 mg 1 mg

initial
1 half-life
2
3
71
Examples of Half-Life

• Isotope Half life
• C-15 2.4 sec
• Ra-224 3.6 days
• Ra-223 12 days
• I-125 60 days
• C-14 5700 years
• U-235 710 000 000 years

72
Learning Check NR3

• The half life of I-123 is 13 hr. How much of a
  64 mg sample of I-123 is left after 26 hours?

73
Solution NR3

• t1/2 13 hrs
• 26 hours 2 x t1/2
• Amount initial 64mg
• Amount remaining 64 mg x ½ x ½
• 16 mg
• Or 2 half lives 64?32?16

74
Nuclear Fission

• large nuclei break up
• 235U 1n 139Ba 94Kr 3 1n
• 92 0 56
  36 0

Energy
75
Fission
76
Nuclear Fusion

• small nuclei combine
• 2H 3H 4He 1n
• 1 1
  2 0
• Occurs in the sun and other stars

Energy
77
Learning Check NR4

• Indicate if each of the following are
• Fission (2) fusion
• Nucleus splits
• Large amounts of energy released
• Small nuclei form larger nuclei
• Hydrogen nuclei react

Energy
78
Solution NR4

• Indicate if each of the following are
• Fission (2) fusion
• 1 Nucleus splits
• 1 2 Large amounts of energy released
• 2 Small nuclei form larger nuclei
• 2 Hydrogen nuclei react

79
Try some
80
Matter can neither be created nor destroyed.
Right?

• Wrong
• E mc2

Energy (joules)
Mass (kg)
Speed2
(3 x 108 m/s)2
9 x 1016 m2/s2
81
You try some ?

• Lab

82
5/6Each Lab Group Choose a topic

• 1. Matter and measurement kelsey and christen
• 2. The atom blake shelby
• 3. Periodic Table sarah
• 4. Ionic and covalent compounds
• 5. Chemical reactions jay and steve
• 6. The mole billy and sammie

• 7. Stoichiometry
• 8. Gases chris and kevin
• 9. Solutions
• 10. Energy. Matt and sam
• 11. Reaction rates melysha brianna
• 12. Equilibrium jillian and jenn

83
7/8Each Lab Group Choose a topic

• 1. Matter and measurement zak and cory
• 2. The atom lauren, michelle ali a
• 3. Periodic Table kevin and ali
• 4. Ionic and covalent compounds erin and megan
• 5. Chemical reactions emily and siobhan
• 6. The mole erin and megan

• 7. Stoichiometry ethan
• 8. Gases catherine and amber
• 9. Solutions carly and brigette
• 10. Energy.ali and mary kate
• 11. Reaction rates kyle greg cassie
• 12. Equilibrium

84

• Nuclear Debate Quiz
• 1. What percentage of the worlds electricity
  comes from nuclear power?
• 17
• 2. How many operational nuclear power plants
  currently exist?
• 441
• 3. Which country has the most nuclear power
  plants?
• USA
• 4. Which country relies the most on nuclear
  power?
• France (75)
• 5. Which country is planning on phasing out
  nuclear power by 2030?
• Germany
• 6. True or false?
• Nuclear power has no impact on global warming.
• Mostly true (except for mining, enriching...)

85

• There is a plan to store all nuclear US waste at
  a single location
• Yes- since 1987
• There is nuclear waste within 20 miles of
  Glastonbury
• True (Haddam)
• About half of the electricity in Connecticut
  comes from nuclear power
• True
• Connecticut has only one operational nuclear
  power plant
• True- Millstone
• Nuclear reactors are explosive
• False
• Nuclear power is a renewable energy source
• False.

86

• With breeder reactors the supply of nuclear fuel
  could last thousands of years
• Controversial, but probably true
• Yucca mountain has been designated as the US
  nuclear waste repository since 1987
• true
• Nuclear fuel is flammable
• False
• Todays nuclear reactors rely on fission
• True
• Nuclear fusion reactors have never been made
• False- fusion bombs and tokamaksbut nothing
  sustainable

87
Debate- JobsThe debate is worth 10 points based
on participation and fair play

• 2 Listers
• 2 scorers
• 1 timer
• Each team
• Several debaters
• Several information gatherers
• 1 captain

88
Monday Go Nukes vs. No Nukes

• No Nukes score_____

• Go Nukes score____

Point for nukes
Point for no nukes
1. (1 point each)
1. (1 point each)
2.
2.
3.
3.
4.
4.
5.
5.
1 point each
Additional points
1 point each
Additional points
1 point each
New speakers
1 point each
New speakers
-1 point each
Interrupt/over time/complain
-1 point each
Interrupt/over time/complain
Up to 5 points
Final statement
Up to 5 points
Final statement
89
Let the debate begin
90
1
minute
91
50
seconds
92
40
seconds
93
30
seconds
94
20
seconds
95
10
seconds
96
9
seconds
97
8
seconds
98
7
seconds
99
6
seconds
100
5
seconds
101
4
seconds
102
3
seconds
103
2
seconds
104
1
seconds
105
Time is up.
106
(No Transcript)
107
Review

• 1. Redox
• 2. Nuclear Chemistry
