Processing of Large Document Collections 1

1
Processing of Large Document Collections 1

• Helena Ahonen-Myka
• University of Helsinki

2
Organization of the course

• Classes 17.9., 22.10., 23.10., 26.11.
• lectures (Helena Ahonen-Myka) 10-12,13-15
• exercise sessions (Lili Aunimo) 15-17
• required presence 75
• Exercises are given (and returned) each week
• required 75
• Exam 4.12. at 16-20, Auditorio
• Points Exam 30 pts, exercises 30 pts

3
Schedule

• 17.9. Character sets, preprocessing of text, text
  categorization
• 22.10. Text summarization
• 23.10. Text compression
• 26.11. to be announced
• self-study basic transformations for text data,
  using linguistic tools, etc.

4
In this part...

• Character sets
• preprocessing of text
• text categorization

5
1. Character sets

• Abstract character vs. its graphical
  representation
• abstract characters are grouped into alphabets
• each alphabet forms the basis of the written form
  of a certain language or a set of languages

6
Character sets

• For instance
• for English
• uppercase letters A-Z
• lowercase letters a-z
• punctuation marks
• digits 0-9
• common symbols ,
• ideographic symbols of Chinese and Japanese
• phonetic letters of Western languages

7
Character sets

• To represent text digitally, we need a mapping
  between (abstract) characters and values stored
  digitally (integers)
• this mapping is a character set
• the domain of the character set is called a
  character repertoire ( the alphabet for which
  the mapping is defined)

8
Character sets

• For each character in the character repertoire,
  the character set defines a code value in the set
  of code points
• in English
• 26 letters in both lower- and uppercase
• ten digits some punctuation marks
• in Russian cyrillic letters
• both could use the same set of code points (if
  not a bilingual document)
• in Japanese could be over 6000 characters

9
Character sets

• The mere existence of a character set supports
  operations like editing and searching of text
• usually character sets have some structure
• e.g. integers within a small range
• all lower-case (resp. upper-case) letters have
  code values that are consecutive integers
  (simplifies sorting etc.)

10
Character sets standars

• Character sets can be arbitrary, but in practice
  standardization is needed for interoperability
  (between computers, programs,...)
• early standards were designed for English only,
  or for a small group of languages at a time

11
Character sets standards

• ASCII
• ISO-8859 (e.g. ISO Latin1)
• Unicode
• UTF-8, UTF-16

12
ASCII

• American Standard Code for Information
  Interchange
• A seven bit code -gt 128 code points
• actually 95 printable characters only
• code points 0-31 and 128 are assigned to control
  characters (mostly outdated)
• ISO 646 (1972) version of ASCII incorporated
  several national variants (accented letters and
  currency symbols)

13
ASCII

• With 7 bits, the set of code points is too small
  for anything else than American English
• solution
• 8 bits brings more code points (256)
• ASCII character repertoire is mapped to the
  values 0-127
• additional symbols are mapped to other values

14
Extended ASCII

• Problem
• different manufacturers each developed their own
  8-bit extensions to ASCII
• different character repertoires -gt translation
  between them is not always possible
• also 256 code values is not enough to represent
  all the alphabets -gt different variants for
  different languages

15
ISO 8859

• Standardization of 8-bit character sets
• In the 80s multipart standard ISO 8859 was
  produced
• defines a collection of 8-bit character sets,
  each designed for a group of languages
• the first part ISO 8859-1 (ISO Latin1)
• covers most Western European languages
• 0-127 identical to ASCII, 128-159 (mostly)
  unused, 96 code values for accented letters and
  symbols

16
Unicode

• 256 is not enough code points
• for ideographically represented languages
  (Chinese, Japanese)
• for simultaneous use of several languages
• solution more than one byte for each code value
• a 16-bit character set has 65,536 code points

17
Unicode

• 16-bit character set, e.g. 65,536 code points
• not sufficient for all the characters required
  for Chinese, Japanese, and Korean scripts in
  distinct positions
• CJK-consolidation characters of these scripts
  are given the same value if they look the same

18
Unicode

• Code values for all the characters used to write
  contemporary major languages
• also the classical forms of some languages
• Latin, Greek, Cyrillic, Armenian, Hebrew, Arabic,
  Devanagari, Bengali, Gurmukhi, Gujarati, Oriya,
  Tamil, Telugu, Kannada, Malayalam, Thai, Lao,
  Georgian, Tibetan
• Chinese, Japanese, and Korean ideograms, and the
  Japanese and Korean phonetic and syllabic scripts

19
Unicode

• punctuation marks
• technical and mathematical symbols
• arrows
• dingbats (pointing hands, stars, )
• both accented letters and separate diacritical
  marks (accents, tildes) are included, with a
  mechanism for building composite characters
• can also create problems two characters that
  look the same may have different code values
• -gtnormalization may be necessary

20
Unicode

• Code values for nearly 39,000 symbols are
  provided
• some part is reserved for an expansion method
  (see later)
• 6,400 code points are reserved for private use
• they will never be assigned to any character by
  the standard, so they will not conflict with the
  standard

21
Unicode encodings

• Encoding is a mapping that transforms a code
  value into a sequence of bytes for storage and
  transmission
• identity mapping for a 8-bit code?
• it may be necessary to encode 8-bit characters as
  sequences of 7-bit (ASCII) characters
• e.g. Quoted-Printable (QP)
• code values 128-255 as a sequence of 3 bytes
• 1 ASCII code for , 2 3 hexadecimal digits
  of the value
• 233 -gt E9 -gt E9

22
Unicode encodings

• UTF-8
• ASCII code values are likely to be more common in
  most text than any other values
• in UTF-9 encoding ASCII characters are sent
  themselves (high-order bit 0)
• other characters (two bytes) are encoded using up
  to six bytes (high-order bit is set to 1)

23
Unicode encodings

• UTF-16 expansion method
• two 16-bit values are combined to a 32-bit value
  -gt a million characters available

24
2. Preprocessing of text

• Text cannot be directly interpreted by the many
  document processing applications
• an indexing procedure is needed
• mapping of a text into a compact representation
  of its content
• which are the meaningful units of text?
• how these units should be combined?
• usually not important

25
Vector model

• A document is usually represented as a vector of
  term weights
• the vector has as many dimensions as there are
  terms (or features) in the whole collection of
  documents
• the weight represents how much the term
  contributes to the semantics of the document

26
Vector model

• Different approaches
• different ways to understand what a term is
• different ways to compute term weights

27
Terms

• Words
• typical choice
• set of words, bag of words
• phrases
• syntactical phrases
• statistical phrases
• usefulness not yet known?

28
Terms

• Part of the text is not considered as terms
• very common words (function words)
• articles, prepositions, conjunctions
• numerals
• these words are pruned
• stopword list
• other preprocessing possible
• stemming, base words

29
Weights of terms

• Weights usually range between 0 and 1
• binary weights may be used
• 1 denotes presence, 0 absence of the term in the
  document
• often the tfidf function is used
• higher weight, if the term occurs often in the
  document
• lower weight, if the term occurs in many documents

30
Structure

• Either the full text of the document or selected
  parts of it are indexed
• e.g. in a patent categorization application
• title, abstract, the first 20 lines of the
  summary, and the section containing the claims of
  novelty of the described invention
• some parts may be considered more important
• e.g. higher weight for the terms in the title

31
Dimensionality reduction

• Many algorithms cannot handle high dimensionality
  of the term space ( large number of terms)
• usually dimensionality reduction is applied
• dimensionality reduction also reduces overfitting
• classifier that overfits the training data is
  good at re-classifying the training data but
  worse at classifying previously unseen data

32
Dimensionality reduction

• Local dimensionality reduction
• for each category, a reduced set of terms is
  chosen for classification that category
• hence, different subsets are used when working
  with different categories
• global dimensionality reduction
• a reduced set of terms is chosen for the
  classification under all categories

33
Dimensionality reduction

• Dimensionality reduction by term selection
• the terms of the reduced term set are a subset of
  the original term set
• Dimensionality reduction by term extraction
• the terms are not the same type of the terms in
  the original term set, but are obtained by
  combinations and transformations of the original
  ones

34
Dimensionality reduction by term selection

• Goal select terms that, when used for document
  indexing, yields the highest effectiveness in the
  given application
• wrapper approach
• the reduced set of terms is found iteratively and
  tested with the application
• filtering approach
• keep the terms that receive the highest score
  according to a function that measures the
  importance of the term for the task

35
Dimensionality reduction by term selection

• Many functions available
• document frequency keep the high frequency terms
• stopwords have been already removed
• 50 of the words occur only once in the document
  collection
• e.g. remove all terms occurring in at most 3
  documents

36
Dimensionality reduction by term selection

• Information-theoretic term selection functions,
  e.g.
• chi-square
• information gain
• mutual information
• odds ratio
• relevancy score

37
Dimensionality reduction by term extraction

• Term extraction attempts to generate, from the
  original term set, a set of synthetic terms
  that maximize effectiveness
• due to polysemy, homonymy, and synonymy, the
  original terms may not be optimal dimensions for
  document content representation

38
Dimensionality reduction by term extraction

• Term clustering
• tries to group words with a high degree of
  pairwise semantic relatedness
• groups (or their centroids) may be used as
  dimensions
• latent semantic indexing
• compresses document vector into vectors of a
  lower-dimensional space whose dimensions are
  obtained as combinations of the original
  dimensions by looking at their patterns of
  co-occurrence

39
3. Text categorization

• Text classification, topic classification/spotting
  /detection
• problem setting
• assume a predefined set of categories, a set of
  documents
• label each document with one (or more) categories

40
Text categorization

• Two major approaches
• knowledge engineering -gt end of 80s
• manually defined set of rules encoding expert
  knowledge on how to classify documents under the
  given gategories
• machine learning, 90s -gt
• an automatic text classifier is built by
  learning, from a set of preclassified documents,
  the characteristics of the categories

41
Text categorization

• Let
• D a domain of documents
• C c1, , cC a set of predefined
  categories
• T true, F false
• The task is to approximate the unknown target
  function ? D x C -gt T,F by means of a
  function ? D x C -gt T,F, such that the
  functions coincide as much as possible
• function ? how documents should be classified
• function ? classifier (hypothesis, model)

42
We assume...

• Categories are just symbolic labels
• no additional knowledge of their meaning is
  available
• No knowledge outside of the documents is
  available
• all decisions have to be made on the basis of the
  knowledge extracted from the documents
• metadata, e.g., publication date, document type,
  source etc. is not used

43
-gt general methods

• Methods do not depend on any application-dependent
  knowledge
• in operational applications all kind of knowledge
  can be used
• content-based decisions are necessarily
  subjective
• it is often difficult to measure the
  effectiveness of the classifiers
• even human classifiers do not always agree

44
Single-label vs. multi-label

• Single-label text categorization
• exactly 1 category must be assigned to each dj ?
  D
• Multi-label text categorization
• any number of categories may be assigned to the
  same dj ? D
• Special case of single-label binary
• each dj must be assigned either to category ci or
  to its complement ci

45
Single-label, multi-label

• The binary case (and, hence, the single-label
  case) is more general than the multi-label
• an algorithm for binary classification can also
  be used for multi-label classification
• the converse is not true

46
Category-pivoted vs. document-pivoted

• Two different ways for using a text classifier
• given a document, we want to find all the
  categories, under which it should be filed -gt
  document-pivoted categorization (DPC)
• given a category, we want to find all the
  documents that should be filed under it -gt
  category-pivoted categorization (CPC)

47
Category-pivoted vs. document-pivoted

• The distinction is important, since the sets C
  and D might not be available in their entirety
  right from the start
• DPC suitable when documents become available at
  different moments in time, e.g. filtering e-mail
• CPC suitable when new categories are added after
  some documents have already been classified (and
  have to be reclassified)

48
Category-pivoted vs. document-pivoted

• Some algorithms may apply to one style and not
  the other, but most techniques are capable of
  working in either mode

49
Hard-categorization vs. ranking categorization

• Hard categorization
• the classifier answers T or F
• Ranking categorization
• given a document, the classifier might rank the
  categories according to their estimated
  appropriateness to the document
• respectively, given a category, the classifier
  might rank the documents

50
Applications of text categorization

• Automatic indexing for Boolean information
  retrieval systems
• document organization
• text filtering
• word sense disambiguation
• hierarchical categorization of Web pages

51
Automatic indexing for Boolean IR systems

• In an information retrieval system, each document
  is assigned one or more keywords or keyphrases
  describing its content
• keywords belong to a finite set called controlled
  dictionary
• TC problem the entries in a controlled
  dictionary are viewed as categories
• k1 ? x ? k2 keywords are assigned to each
  document
• document-pivoted TC

52
Document organization

• Indexing with a controlled vocabulary is an
  intance of the general problem of document base
  organization
• e.g. a newspaper office has to classify the
  incoming classified ads under categories such
  as Personals, Cars for Sale, Real Estate etc.
• organization of patents, filing of newspaper
  articles...

53
Text filtering

• Classifying a stream of incoming documents
  dispatched in an asynchronous way by an
  information producer to an information consumer
• e.g. newsfeed
• producer news agency consumer newspaper
• the filtering system should block the delivery of
  documents the consumer is likely not interested in

54
Word sense disambiguation

• Given the occurrence in a text of an ambiguous
  word, find the sense of this particular word
  occurrence
• E.g.
• Bank of England
• the bank of river Thames
• Last week I borrowed some money from the bank.

55
Word sense disambiguation

• Indexing by word senses rather than by words
• text categorization
• documents word occurrence contexts
• categories word senses
• also resolving other natural language ambiguities
• context-sensitive spelling correction, part of
  speech tagging, prepositional phrase attachment,
  word choice selection in machine translation

56
Hierarchical categorization of Web pages

• E.g. Yahoo like web hierarchical catalogues
• typically, each category should be populated by
  a few documents
• new categories are added, obsolete ones removed
• usage of link structure in classification
• usage of the hierarchical structure

57
Knowledge engineering approach

• In the 80s knowledge engineering techniques
• building manually expert systems capable of
  taking text categorization decisions
• expert system consists of a set of rules
• wheat farm -gt wheat
• wheat commodity -gt wheat
• bushels export -gt wheat
• wheat winter soft -gt wheat

58
Knowledge engineering approach

• Drawback rules must be manually defined by a
  knowledge engineer with the aid of a domain
  expert
• any update necessitates again human intervention
• totally domain dependent
• -gt expensive and slow process

59
Machine learning approach

• A general inductive process (learner)
  automatically builds a classifier for a category
  ci by observing the characteristics of a set of
  documents manually classified under ci or ?ci by
  a domain expert
• from these characteristics the learner gleans the
  characteristics that a new unseen document should
  have in order to be classified under ci
• supervised learning ( supervised by the
  knowledge of the training documents)

60
Machine learning approach

• The learner is domain independent
• usually available off-the-shelf
• the inductive process is easily repeated, if the
  set of categories changes
• manually classified documents often already
  available
• manual process may exist
• if not, it still easier to manually classify a
  set of documents than to build and tune a set of
  rules

61
Training set, test set, validation set

• Initial corpus of manually classified documents
• let dj belong to the initial corpus
• for each pair ltdj, cigt it is known if dj should
  be filed under ci
• positive examples, negative examples of a category

62
Training set, test set, validation set

• The initial corpus is divided into two sets
• a training (and validation) set
• a test set
• the training set is used to build the classifier
• the test set is used for testing the
  effectiveness of the classifiers
• each document is fed to the classifier and the
  decision is compared to the manual category

63
Training set, test set, validation set

• The documents in the test are not used in the
  construction of the classifier
• alternative k-fold cross-validation
• k different classifiers are built by partitioning
  the initial corpus into k disjoint sets and then
  iteratively applying the train-and-test approach
  on pairs, where k-1 sets construct a training set
  and 1 set is used as a test set
• individual results are then averaged

64
Training set, test set, validation set

• Training set can be split to two parts
• one part is used for optimising parameters
• test which values of parameters yield the best
  effectiveness
• test set and validation set must be kept separate

65
Inductive construction of classifiers

• A ranking classifier for a category ci
• definition of a function that, given a document,
  returns a categorization status value for it,
  i.e. a number between 0 and 1
• documents are ranked according to their
  categorization status value

66
Inductive construction of classifiers

• A hard classifier for a category
• definition of a function that returns true or
  false, or
• definition of a function that returns a value
  between 0 and 1, followed by a definition of a
  threshold
• if the value is higher than the threshold -gt true
• otherwise -gt false

67
Learners

• Probabilistic classifiers (Naïve Bayes)
• decision tree classifiers
• decision rule classifiers
• regression methods
• on-line methods
• neural networks
• example-based classifiers (k-NN)
• support vector machines

68
Rocchio method

• Linear classifier method
• for each category, an explicit profile (or
  prototypical document) is constructed
• benefit profile is understandable even for
  humans

69
Rocchio method

• A classifier is a vector of the same dimension as
  the documents
• weights
• classifying cosine similarity of the category
  vector and the document vector
