Microsoft Exchange Server 2003 Disaster
Recovery
Eileen Brown IT Evangelist Microsoft
Ltd. eileenb_at_microsoft.com http//blogs.msdn.com/e
ileen_brown
4
What we will cover

• Preparing for disaster
• Best practices for backup of Exchange 2003
• Mailbox Recovery Center
• Recovery Storage Group
• Alternate Server Recovery
• Replacing a server

5
Prerequisite Knowledge

• Experience supporting Windows Servers
• Experience supporting Microsoft Exchange Server
  2000 or 2003
• Experience supporting E-Mail clients

Level 200
6
Agenda

• Backup Best Practices
• Mailbox Recovery
• Recovering Stores
• Replacing an Exchange Server
• Alternate Server Recovery

7
Backup Best PracticesBackup Applications

• Windows Backup
• Integrates with Windows Server and Exchange
• Accesses Information Store directly
• Shadow Copy
• Speeds up backup
• New in Windows Server 2003
• Third party backup programs

8
Backup Best PracticesBackup Applications

• Windows Backup
• Integrates with Windows Server and Exchange
• Accesses Information Store directly
• Shadow Copy
• Speeds up backup
• New in Windows Server 2003
• Third party backup programs

9
Backup Best PracticesImplementing Backups

• Design and schedule backups
• Service level agreement
• Tape rotation
• Leave Circular Logging disabled
• Log file location
• Keep log files and databases on separate drives

10
Backup Best PracticesImplementing Backups

• Design and schedule backups
• Service level agreement
• Tape rotation
• Avoid Circular Logging option
• Log file location
• Separate physical drive from Information Store

11
Backup Best PracticesTypes of Backup
12
Backup Best Practices Backing up the Metabase

• Exchange requires IIS to function
• Backup of IIS configuration is critical
• Backup with IIS Manager console
• Within IIS MMC
• Backup with iisback.vbs script
• Csript \SystemRoot\system32\iisback.vbs

http//support.microsoft.com/default.aspx?scidkb
en-us241635Productexch2003
13
Backup Best PracticesBacking up the Metabase

• Exchange requires IIS to function
• Backup of IIS configuration is critical
• Backup with IIS Manager console
• Within IIS MMC
• Backup with iisback.vbs script
• Csript \SystemRoot\system32\iisback.vbs

http//support.microsoft.com/default.aspx?scidkb
en-us241635Productexch2003
14
Backup Best Practices Planning Best Practices

• Write out and follow backup procedure
• What to backup and how often
• Keep alternate hardware on hand
• Run a trial restoration periodically
• Backup Active Directory

15
Backup Best PracticesDesign Best Practices

• Store log files and Information Store on separate
  physical drives.
• Keep Information Store volume under 50 capacity
• Speeds restore process
• Copy damaged database before restore
• Increase message and mailbox retention

16
Backup Best PracticesDesign Best Practices

• Store log files and Information Store on separate
  physical drives.
• Keep Information Store volume under 50 capacity
• Speeds restore process
• Copy damaged database before restore
• Increase message and mailbox retention

17
demonstration

• Backup Best Practices
• Backing up Exchange with Windows Backup
• Backing up the metabase
• Other preparations (item retention settings)

18
Agenda

• Backup Best Practices
• Mailbox Recovery
• Recovering Stores
• Replacing an Exchange Server
• Alternate Server Recovery

19
Mailbox RecoveryDeleted Mailbox Retention

• Mailbox Recovery Center
• New in Exchange 2003
• Quickly recovers deleted mailboxes
• Retain until backed up setting
• Time limit set in System Manager
• As resources allow

20
Mailbox RecoveryRecovering Deleted Items

• Deleted Items folder
• Recovery Storage Group
• PST/OST
• Alternate Server Recovery
• Exmerge
• Brick Level Backups

21
Mailbox RecoveryRecovering Deleted Items

• Deleted Items folder
• Recovery Storage Group
• PST/OST
• Alternate Server Recovery
• Exmerge
• Brick Level Backups

22
Mailbox RecoveryRecovery Storage Group

• Recovers mailboxes, mailbox stores, and items
  (not public folders)
• Prior Versions Alternate Server Recovery
• No downtime
• No additional hardware
• Differs from Storage Group
• MAPI the only protocol
• ExMerge the only access to contents
• Databases do not mount automatically

23
Mailbox RecoveryRecovery Storage Group

• Recovers mailboxes, mailbox stores, and items
  (not public folders)
• Prior Versions Alternate Server Recovery
• No downtime
• No additional hardware
• Differs from Storage Group
• MAPI the only protocol
• ExMerge the only access to contents
• Databases do not mount automatically

24
Mailbox RecoveryRSG and Active Directory
GUID Attribute
msExchMailbox GUID Attribute
GUID Attribute
25
Mailbox RecoveryRSG and Active Directory
GUID Attribute
msExchMailbox GUID Attribute
GUID Attribute
26
Mailbox RecoveryPST/OST Restore Method

• To recover an entire mailbox
• Laptop or Client computer not yet synchronized to
  Exchange server
• Create a PST of the mailbox named username.pst
• Recreate the mailbox on the server
• Use Exmerge

27
Mailbox RecoveryPST/OST Restore Method

• To recover an entire mailbox
• Laptop or Client computer not yet synchronized to
  Exchange server
• Create a PST of the mailbox named username.pst
• Recreate the mailbox on the server
• Use Exmerge

28
Mailbox RecoveryExmerge

• Import/Export tool for Exchange stores
• Updated for Exchange 2003
• Download separately from http//microsoft.com/down
  loads
• User rights

29
Mailbox RecoveryAlternate Server Recovery

• Mailbox no longer exists in mailbox store
• Deleted mailbox retention period has passed
• Nearly identical server hardware in a different
  AD forest
• Restore from a backup, then use ExMerge to create
  .pst file
• Recreate the mailbox on the original server
• Use Exmerge to import

30
Mailbox RecoveryBrick Level Backups

• Allows for direct backup and recovery of
  individual mailboxes
• Third party applications
• Slower backup/recovery
• Bloats backup and mailbox store

31
demonstration

• Recovering items and Mailboxes
• Mailbox Recovery Center
• Restoring items from Recovery Storage Group

32
Agenda

• Backup Best Practices
• Mailbox Recovery
• Recovering Stores
• Replacing an Exchange Server
• Alternate Server Recovery

33
Recovering Stores Options

• Recovery Storage Group
• Exchange 2000 SP3 or later
• Dial-tone method
• Alternate Server Recovery
• Public Folders
• Damaged hardware
• Separate Active Directory forest
• Transaction Logs

34
Recovering Stores Options

• Recovery Storage Group
• Exchange 2000 SP3 or later
• Dial-tone method
• Alternate Server Recovery
• Public Folders
• Damaged Hardware
• Separate Active Directory forest
• Transaction Logs

35
Recovering StoresDial-Tone Method

• Purpose to minimize user downtime when
  recovering from a backup
• Example situation Corrupted Mailbox Store
• Exchange features used
• Recovery Storage Group
• Exmerge 2003
• Mailbox Store re-creation

36
Recovering StoresUsing Dial-Tone Method

• Recent backup
• Incremental or differential plus full
• Cumulative transaction log files
• Improve recovery quality
• Recovery Storage Group

37
Recovering StoresDial-Tone Method 4 Steps
ExMerge
38
demonstration

• Recovering Mailbox Stores Using the Dial-Tone
  Method
• Recovery Storage Group
• Restored from backup
• Finalize dial-tone restore

39
Agenda

• Backup Best Practices
• Mailbox Recovery
• Recovering Stores
• Replacing an Exchange Server
• Alternate Server Recovery

40
Replacing an Exchange ServerRequirements

• Nearly Identical Hardware/OS
• Exchange Media
• Recent Backup
• Active Directory in place

41
Replacing an Exchange ServerProcesses Used

• System State restore
• Active Directory
• Registry
• Exchange Settings
• \disasterrecovery Exchange install
• Information Store Restore
• Transaction Logs

42
Replacing an Exchange ServerSteps

• Install Server
• Perform System State restore
• Install Exchange
• Restore Information Store

43
demonstration

• Replacing an Exchange Server
• Setting up for Alternate Server Recovery
• Restoring the database

44
Agenda

• Backup Best Practices
• Mailbox Recovery
• Recovering Stores
• Replacing an Exchange Server
• Alternate Server Recovery

45
Alternate Server Recovery When to perform

• Public folder
• Mailbox deleted and purged
• Can not use Recovery Storage Group
• Physical damage
• Hardware failure
• Site damage

46
Alternate Server Recovery Requirements

• Backup of Information Store
• Windows Server and Exchange Media
• Hardware
• Time

47
Alternate Server RecoverySettings That Must be
Identical

• Organization name
• Administrative Group name
• Storage group name
• Database
• LegacyExchangeDN

48
Alternate Server RecoveryActive Directory and
LDIFDE

• LDIFDE imports and exports Active Directory
  entries
• Other tools available
• Used to check LegacyExchangeDN and to recreate AD
  entries.

49
Alternate Server Recovery Disaster Recovery
Features

• Install Windows Server and Exchange Server
• Match names
• Restore the Windows backup set made on the server
  being rebuilt
• Recreate Active Directory
• Export items from the database

50
demonstration

• Alternate Server Recovery
• Setting up for Alternate Server Recovery
• Restoring the database

51
Session Summary

• Preparing for Disaster
• Use best practices for backup
• Use the Recovery Storage Group
• To Recover Mailboxes
• To Recover Stores
• Use Exmerge to recovery data from recovered
  servers or PST/OSTs
• Remember alternate server recovery requirements

52
For More Information

• Main TechNet Web site at www.microsoft.com/technet

• Additional resources to support this Session page
  can be found at

www.microsoft.com/technet/tnt1-101
53
For More Information

• Exchange Web Site
• http//www.microsoft.com/exchange
• Windows Server 2003 Web Site
• http//support.microsoft.com/default.aspx?scidfh
  EN-USwinsvr2003

54
MS PressInside Information for IT Professionals
To find the latest IT Professional related titles
visit www.microsoft.com/learning/books/itpro/
55
3rd Party PublicationsSupplementary publications
for IT Pros
These books can be found and purchased at all
good book stores and on-line retailers
56
Microsoft LearningTraining Resources for IT
Professionals

• Troubleshooting Microsoft Exchange Server 2003
• 2011
• Detailed Syllabus www.microsoft.com/learning

To locate a training provider, please
access www.microsoft.com/learning Microsoft
Certified Technical Education Centers are
Microsofts premier partners for training
services
57
Assess your ReadinessMicrosoft Skills Assessment

• What is Microsoft Skills Assessment?
• Self-study learning tool to evaluate readiness
  for product and technology solutions, instead of
  job-roles (certification)
• Windows Server 2003, Exchange Server 2003,
  Windows Storage Server 2003, Visual Studio .NET,
  Office 2003
• Free, online, unproctored, and available to
  anyone
• Answers, Am I ready?
• Determines skills gaps, provides learning plans
  with Microsoft Official Curriculum courses, plus
  more Microsoft learning content suggestions such
  as TechNet resources
• Post your High Score to see how you stack up
• visit http//www.microsoft.com/assessment

58
Become a Microsoft Certified Systems
Administrator (MCSA)

• What is the MCSA certification?
• For IT professionals who manage and maintain
  networks and systems based on the Microsoft
  Windows Server operating system
• How do I become an MCSA on Microsoft Windows
  2000?
• Pass 3 core exams
• Pass 1 elective exam or 2 CompTIA certifications
• Where do I get more information?
• For more information about certification
  requirements, exams, and training, visit
  www.microsoft.com/mcsa

59
Become A Microsoft Certified Systems Engineer
(MCSE)

• What is the MCSE certification?
• Premier certification for IT professionals who
  analyze the business requirements and design,
  plan, and implement the infrastructure for
  business solutions based on the Microsoft Windows
  Server System integrated server software.
• How do I become an MCSE on Microsoft Windows
  2003?
• Pass 6 core exams
• Pass 1 elective exams from a comprehensive list
• Where do I get more information?
• For more information about certification
  requirements, exams, and training options, visit
  www.microsoft.com/mcse

60
Demonstrate Your Security or Messaging
Specialization

• What are MCSA/MCSE specializations?
• MCSA and MCSE specializations allow IT
  professionals to highlight specific expertise or
  technical focus within their job role.
• What specializations are available?
• MCSA Security ? MCSA Messaging
• MCSE Security ? MCSE Messaging
• Where do I get more information?
• For more information about MCSA and MCSE
  specialization requirements, exams, and training
  options, visit www.microsoft.com/mcsa or
  www.microsoft.com/mcse

61
What is TechNet?

• Put the right answers at your fingertips
• TechNet is the comprehensive collection of
  resources to help IT implementers plan, deploy
  and manage Microsoft products successfully

• Monthly updates delivered on DVD or CD
• The definitive resource to help you evaluate,
  deploy and maintain Microsoft products

TechNet Subscription

• Accessible at www.microsoft.com/technet
• Online resources and community
• Subscriber-only Online Services

TechNet Web Site

• Bi-weekly e-newsletter
• Security updates, new resources, and special
  offers

TechNet Flash

• Briefings on the latest Microsoft products and
  technologies
• Hands-on, how to information

TechNet Events and Web Casts

• User Groups
• Managed Newsgroups

TechNet Communities
62
Where Can I Get TechNet?

• Visit TechNet Online atwww.microsoft.com/technet
• Register for the TechNet Flash www.microsoft.com/t
  echnet/usingtn/register/flash.asp
• Join the TechNet Online forum at
  www.microsoft.com/technet/itcommunity
• Become a TechNet Subscriber at www.microsoft.com/t
  echnet/buynow/subscribe
• Attend More TechNet Events or view
  on-linewww.microsoft.com/technet/tcevents/itevent
  s

63
(No Transcript)
64
Session Credits

• Author Bob Carver
• Producer/Editor Alan Le Marquand
• Technical Specialists
• Joel Barker
• Rob Ling
• Aaron Clutter
