Software Measurement

1
Software Measurement

• UCLA Computer Science Department
• CS130
• Winter, 2002

2
Reference

• Material in this lecture is taken from chapters
  1-3 of Software Metrics A Rigorous and Practical
  Approach (2nd ed.), Norman E. Fenton and Shari
  Lawrence Pfleeger, 1997, PWS Publishing Company,
  Boston, MA, ISBN 0534954251

3
Overview

• Measurement what is it and why do we do it?
• Measurement basics
• A goal-based software measurement framework

4
Measurement What Is It and Why Do We Do It?

• Measurement in Everyday Life
• Measurement in Software Engineering
• The Scope of Software Metrics

5
Measurement in Everyday Life

• Measurement governs many aspects of everyday
  life
• Economic indicators determine prices, pay raises
• Medical system measurements enable diagnosis of
  specific illnesses
• Measurements in atmospheric systems are the basis
  of weather prediction

6
Measurement in Everyday Life

• How do we use measurement in our lives?
• In a shop, price is a measure of the value of an
  item, and we calculate the bill to make sure we
  get the correct change.
• Height and size measurements ensure clothing will
  fit correctly.
• When traveling, we calculate distance, choose a
  route, measure speed, and predict when well
  arrive
• Measurement helps us to
• Understand our world
• Interact with our surroundings
• Improve our lives

7
Measurement in Everyday Life

• What is Measurement?
• Common thread in previous examples some aspect
  of a thing is assigned a descriptor that allows
  us to compare it with other things.
• More formally the process by which
• Numbers or symbols are assigned to attributes of
  entities in the real world in such a way as to
  describe them.
• According to clearly defined rules.

8
Measurement in Everyday Life

• Definition of measurement process is far from
  clear cut.
• To understand measurement, must ask questions
  that are difficult to answer
• In a room with blue walls, is blue a measure of
  the color of the room?
• A persons height is a commonly understood
  attribute that can be easily measured. What
  about other attributes of people, such as
  intelligence?
• Some measurements (e.g., intelligence, wine
  quality) may have wide error margins is this a
  reason to reject them?
• How do we decide which error margins are
  acceptable and which are not?
• When is a measurement scale acceptable for the
  purpose to which it is put (e.g., is it
  appropriate to measure a persons height in
  kilometers)?
• What types of manipulations can we apply to the
  results of measurement?
• Material in next section (Measurement Basics)
  will allow us to answer these questions.

9
Measurement in Everyday Life

• Making Things Measurable
• What is not measurable, make measurable
  (Galileo Galilei)
• One aim of science is to find ways of measuring
  attributes of things were interested in.
• Measurement makes concepts more visible,
  therefore more understandable and controllable.
• Attributes previously thought to be unmeasurable
  now form basis for decisions affecting our lives
  (e.g., air quality, inflation index).
• Measuring the unmeasurable improves understanding
  of particular entities, attributes
• Act of proposing a particular measure can open
  discussion that will lead to greater
  understanding
• Making new measurement may requiring modifying
  environment or practices (e.g., using a new tool,
  adding a step in a process)

10
Measurement in Everyday Life

• Measurement in Software Engineering
• In many instances, measurement is considered a
  luxury. For many projects
• Measurable targets are not set (e.g., products
  are supposed to be user-friendly, reliable, and
  maintainable, but we dont quantify what that
  means).
• The component costs of projects are not
  quantified or understood.
• Product quality is not quantified.
• Too much reliance on anecdotal evidence (e.g.,
  try our product and youll improve your
  productivity by 50!). Most of the time, theres
  no measurable basis for the claims.

11
Measurement in Everyday Life

• Measurement in Software Engineering (contd)
• When measurements are made, they tend to be
• Incomplete
• Inconsistent
• Infrequent
• Most of the time, were not told anything about
• How experiments were designed
• What was measured and how
• Realistic error margins
• Without this information, cant decide whether to
  apply results to a development effort, and cant
  do an objective study to repeat the measurements.
• Lack of measurement in SW engineering is
  compounded by lack of a rigorous approach.

12
Measurement in Everyday Life

• Software Measurement Objectives
• Assessing status
• Projects
• Products for a specific project or projects
• Processes
• Resources
• Identifying trends
• Need to be able to differentiate between a
  healthy project and one thats in trouble
• Determine corrective action
• Measurements should indicate the appropriate
  corrective action, if any is required.

13
Measurement in Everyday Life

• Types of information required to understand,
  control, and improve projects
• Managers
• What does the process cost?
• How productive is the staff?
• How good is the code?
• Will the customer/user be satisfied?
• How can we improve?
• Engineers
• Are the requirements testable?
• Have all the faults been found?
• Have the product or process goals been met?
• What will happen in the future?

14
Measurement in Everyday Life

• The Scope of Software Metrics
• Cost and effort estimation
• Productivity measures and models
• Data collection
• Quality models and measures
• Reliability models
• Performance evaluation and models
• Structural and complexity metrics
• Capability-maturity assessment
• Management by metrics
• Evaluation of methods and tools

15
Measurement in Everyday Life

• The Scope of Software Metrics some details
• Cost and effort estimation
• Motivation accurately predict costs early in
  the development life cycle.
• Numerous empirical cost models have been
  developed
• COCOMO, COCOMO 2
• Putnams model (see Pressman Ch 3)
• ...

16
Measurement in Everyday Life

• The Scope of Software Metrics some details
• Productivity models and measures
• Estimate staff productivity to determine how much
  specified changes will cost
• Naive measure size divided by effort. Doesnt
  take into account things like defects,
  functionality, reliability.
• More comprehensive models have been developed
  next slide illustrates a possible model.

17
Measurement in Everyday Life

• The Scope of Software Metrics some details
• Possible productivity model

Productivity
Cost
Value
Personnel
Resources
Complexity
Quantity
Quality
HW
Env Cnstrst
Time
Problem difficulty
Reliability
Defects
Functionality
Size
Money
SW
18
Measurement in Everyday Life

• The Scope of Software Metrics some details
• Software quality model

Factor
Criteria
Use
Communicativeness
Usability
Accuracy
Product Operation
Reliability
Consistency
Efficiency
Device Efficiency
Accessibility
Reusability
Metrics
Completeness
Maintainability
Product Revision
Structuredness
Conciseness
Portability
Device Independence
Testability
Legibility
Self-descriptiveness
Traceability
19
Overview

• Measurement what is it and why do we do it?
• Measurement basics
• A goal-based software measurement framework

20
Measurement Basics

• Overview
• The representational theory of measurement
• Measurement and models
• Measurement scales and scale types
• Meaningfulness in measurement

21
Measurement Basics

• Overview
• Understanding of software attributes not as deep
  as understanding of non-software entities (e.g.,
  length, weight, temperature)
• Questions that are relatively easy to answer for
  non-software entities are difficult for software
• How much must we know about an attribute before
  its reasonable to consider measuring (e.g.,
  program complexity)?
• How do we know if weve really measured the
  attribute we want to measure? Does a count of
  the number of defects found in a system measure
  its quality, or does it measure something else?
• Using measurement, what meaningful statements can
  we make about an attribute and the entities that
  possess it (e.g., can we talk about doubling a
  designs quality)?
• What meaning operations can we perform on
  measures (e.g., can we compute the average
  productivity of a group of developers, or the
  average quality of a set of modules)?
• Answering these questions requires developing a
  theory of measurement

22
Measurement Basics

• The representational theory of measurement
• Developed as a classical discipline from the
  physical sciences
• Provides rules for
• Making consistent measurements
• Interpreting data resulting from measurement
• Representational theory of measurement formalizes
  intuition about the way the world works.

23
Measurement Basics

• Empirical relations
• Data obtained as measures should represent
  attributes of observed entities
• Manipulating data should preserve observed
  relationships
• Example Taller than
• Binary relation defined on the set of pairs of
  people. Either
• A is taller than B, or
• B is taller than A
• Empirical relations are not restricted to binary
  relations can be unary (e.g., A is tall),
  ternary (A sitting on Bs shoulders is taller
  than C), etc.

24
Measurement Basics

• Empirical relations (contd)
• Empirical relations are mappings from the
  empirical, real world to a formal mathematical
  world.
• Height maps a set of people to the set of real
  numbers
• Greater functionality (from survey results)

• x has greater functionality than y if (x,y) gt
  60. Relation is (C,A), (C,B), (C,D), (A,B),
  (A,D).
• Surveys can help gain preliminary understanding
  of relationships.

25
Measurement Basics

• Empirical relations (contd)
• Definitions
• Measurement a mapping from the empirical world
  to the formal, relational world.
• Measure number or symbol assigned to an entity
  by the mapping in order to characterize an
  attribute.

26
Measurement Basics

• Rules of Mapping
• Measures must specify domain and range as well as
  the rule for performing the mapping
• Domain real world is domain of mapping that
  defines the measurement
• Range the mathematical world into which
  real-world attributes are mapped
• Examples
• Measuring height
• Is height measured in inches, centimeters, feet?
• Are people measured sitting or standing?
• Are shoes allowed to be worn during the
  measurement?
• Measuring lines of code
• Are lines of code reused without change counted?
• Are non-executable lines counted?
• Declarations
• Compiler Directives
• Comments
• Blank lines

27
Measurement Basics

• The representation condition
• Behavior of measures in number system needs to be
  the same as corresponding elements in the real
  world.
• Formally, a measurement mapping M must map
  entities into numbers and empirical relations
  into numerical relations in such a way that
• Empirical relations preserve numerical relations
• Empirical relations are preserved by numerical
  relations

28
Measurement Basics

• The representation condition example
• Taller than
• A is taller than B iff M(A) gt M(B), where M is a
  mapping from the empirical world to the real
  numbers.
• Whenever Joe is taller than Frank, then M(Joe)
  must be a bigger number than M(Frank)
• Jane can be mapped to a bigger number than John
  only if Jane is taller than John.

29
Measurement Basics

• The representation condition example 2
• Software failures criticality
• Three types of failures examined
• Delayed response
• Incorrect output
• Data loss
• At this point, we have a relation system
  consisting of 3 unary relations
• R1 for delayed response
• R2 for incorrect output
• R3 for data loss
• With this information, we cant yet judge the
  relative criticality of these types of failures.

30
Measurement Basics

• The representation condition example 2 (contd)
• We can find a representation in the set of real
  numbers by choosing three distinct numbers
• M(delayed response) 6
• M(incorrect output)4
• M(data loss)50
• Further investigation of criticality reveals that
  data loss is more critical than incorrect output,
  which in turn is more critical than a delayed
  response.
• To develop a real-number representation for this
  enriched relation, we must be more careful in
  assigning numbers.
• Using gt to mean more critical than, data-loss
  failures must be mapped to a higher number than
  incorrect output failures, which in turn must
  mapped to a higher number than delayed responses.

31
Measurement Basics

• The representation condition (contd)
• There may be many different measures for a given
  attribute (e.g., in., cm., furlongs).
• Any measure satisfying the representation
  condition is a valid measurement
• The richer the empirical relation system, the
  fewer the valid valid measures
• Relational systems are rich if they have a large
  number of relations that can be defined.
• As the number of empirical relations increases,
  so does the number of conditions a measurement
  mapping must satisfy in its representation
  condition.

32
Measurement Basics

• Measurement and models
• Model an abstraction of reality allowing us to
• Strip away unnecessary detail
• View an entity or concept from a particular
  perspective
• Representation condition requires every measure
  to be associated with a model of how the measure
  maps real world entities and attributes to
  elements of a numerical system. These models are
  essential in
• Understanding how measure is derived
• Interpreting behavior of numerical elements when
  we return to the real world.

33
Measurement Basics

• Defining Attributes
• Always a temptation to focus too much on formal,
  mathematical system, rather than on empirical
  system.
• Before we set out to measure something (e.g.,
  program complexity), we need to
• Identify a set of characteristics of the thing
  were trying to measure
• A model that associates the characteristics
• We can then define measures for each
  characteristic, and use the representation
  condition to help understand the relationships.

34
Measurement Basics

• Direct and Indirect Measurement
• Direct measure relates an attribute to a number
  or symbol without reference to no other object or
  attribute (e.g., height).
• Indirect measure
• Used when an attribute must be measured by
  combining several of its aspects (e.g., density)
• Requires a model of how measures are related to
  each other

35
Measurement Basics

• Direct and Indirect Measures for Software
  examples
• Direct
• Length or source code (lines of code)
• Duration of testing process
• Number of defects discovered during test
• Time a developer spends on a project
• Indirect
• Programmer productivity (LOC/workmonths of
  effort)
• Module defect density (number of defects/module
  size)
• Defect detection efficiency ( defects
  detected/total defects)
• Requirements stability (initial
  requirements/total requirements)
• Test effectiveness ratio (number of items
  covered/total number of items)
• System spoilage (effort spent fixing faults/total
  project effort)

36
Measurement Basics

• Measurement for prediction
• So far weve talked about measuring some entity
  that already exists
• Useful for assessing current situation or
  understanding what has happened in the past
• In many cases, we want to predict an attribute of
  an entity that doesnt yet exist (e.g., project
  cost, reliability of fielded system).
• Requires model relating measurement that can be
  taken now to attributes that will be predicted
• Empirical cost models
• Software reliability models
• Model is not sufficient by itself to perform
  required prediction. Need a prediction system
  including
• A model relating the measurements to the desired
  attribute
• A procedure to model parameters
• Procedures for interpreting model results

37
Measurement Basics

• Measurement for prediction
• Accurate predictive measurement is always based
  on measurement in the assessment sense
• Everyone wants to predict key determinants of
  success (e.g., effort to build a new system,
  operational reliability), but...
• There are no magic models. They all depend on
• High-quality measurements of past projects
• High-quality measurements of current project

38
Measurement Basics

• Measurement scales and scale types
• A measurement scale is our mapping, M, together
  with the empirical and numerical relation
  systems.
• If the relation systems (domain and range) are
  obvious from context, sometimes M alone is
  referred to as the scale.
• Three important questions concerning
  representations and scales
• How do we determine when one numerical relation
  system is preferable to another?
• How do we know if a particular empirical relation
  system has a representation in a given numerical
  relation system?
• What do we do when we have several different
  possible representations (and hence many scales)
  in the same numerical relation system?

39
Measurement Basics

• Measurement scales and scale types (contd)
• Three questions
• How do we determine when one numerical relation
  system is preferable to another?
• Answer We can map the scale to a symbolic
  relational system. In practice, this can be
  unwieldy (symbolic vs. numerical manipulation).
  We try to use real numbers whenever possible.
• How do we know if a particular empirical relation
  system has a representation in a given numerical
  relation system?
• Answer This is known as the representation
  problem, one of the basic problems of measurement
  theory. This is a solved problem for various
  types of relation systems characterized by
  specific axioms. Discussion is beyond the scope
  of this course, but solutions can be found in
  texts on measurement theory.
• What do we do when we have several different
  possible representations (and hence many scales)
  in the same numerical relation system?
• Answer This is the uniqueness problem.
  Following slides address this question.

40
Measurement Basics

• Measurement scale types
• Nominal
• Ordinal
• Interval
• Ratio
• Absolute
• One relational system is richer than another if
  all relationships in the second system are
  contained in the first.
• Scale types above are listed in order of
  increasing richness.

41
Measurement Basics

• Measurement scale types (contd)
• Why is this important?
• If we have a satisfactory measure for an
  attribute with respect to an empirical relation
  system, we want to know what other measures exist
  that are acceptable.
• Mapping from one acceptable measure to another is
  called an admissible transformation.
• Example when considering length, admissible
  transformations are of the form MaM.
  Transformations of the form MbaM, or MaMb
  are not acceptable when b ltgt 0.
• The more restrictive the class of admissible
  transformations, the most sophisticated the
  measurement scale.

42
Measurement Basics

• Nominal scale
• Most primitive form of measurement define
  classes or categories, and place each category in
  a particular class or category
• Two major characteristics
• Empirical relation consists only of different
  classes no notion of ordering
• Any distinct number or symbolic representation is
  an acceptable measure no notion of magnitude
  associated with numbers or symbols.
• Any two mappings, M and M, will be related to
  each other in that M can be obtained from M by a
  one-to-one mapping
• Example software faults can belong to one of
  the following classes, according to where they
  were first introduced during development
• Specification
• Design
• Code

43
Measurement Basics

• Measurement types and scale
• Ordinal scale
• Augments nominal scale with ordering information.
• Three major characteristics
• Empirical relation system consists of classes
  that are ordered with respect to the attribute
• Any mapping preserving the ordering (i.e., a
  monotonic function) is acceptable
• Numbers represent ranking only, so arithmetic
  operations have no meaning
• Set of admissible transformations is set of all
  monotonic mappings
• Example software complexity two valid
  measures

44
Measurement Basics

• Measurement type and scale
• Interval scale
• Captures information about size of intervals that
  separate classes.
• Three characteristics
• Preserves order
• Preserves differences, but not ratios
• Addition and subtraction are acceptable, but not
  multiplication and division
• Class of admissible transformations is the set of
  affine transformations MaMb, where agt0.
• Example software complexity suppose the
  difference in complexity between a trivial and a
  simple system is the same as that between a
  simple and a moderate system. Where this equal
  step applies to each class, we have an attribute
  measurable on an interval scale.

45
Measurement Basics

• Measurement type and scale
• Ratio scale
• Most useful scale, common in physical sciences
  captures information about ratios
• 4 characteristics
• Preserves ordering, size of intervals between
  entities, and ratios between entities
• There is a zero element, representing total lack
  of the attribute
• Measurement mapping must start at 0 and increase
  at equal intervals (units)
• All arithmetic can be meaningfully applied to
  classes in the range of the mapping.
• Acceptable transformations are ratio
  transformations MaM, where a is a scalar.
• Example program length can be measured by
  lines of code, number of characters, etc. Number
  of characters may be obtained by multiplying the
  number of lines by the average number of
  characters per line.

46
Measurement Basics

• Measurement type and scale
• Absolute scale
• Most restrictive in terms of admissible
  transformations
• For any two measures, M and M, theres only one
  admissible transformation (identity
  transformation), since theres only one way to
  make the measurement.
• 4 characteristics
• Measurement is made simply by counting the number
  of elements in the entity set.
• Attribute always takes the form of number of
  occurrences of x in the entity
• Only one possible measurement mapping, namely the
  actual count
• All arithmetic analysis of the resulting count is
  meaningful.
• Example lines of code in a module is an
  absolute scale measure.

47
Measurement Basics

• Measurement type and scale - summary

48
Measurement Basics

• Meaningfulness in measurement
• After making measurements, key question is can
  we deduce meaningful statements about entities
  being measured?
• Harder to answer than it first appears consider
  these statements
• The number of errors discovered during the
  integration testing of a program X was at least
  100
• The cost of fixing each error in program X is at
  least 100
• A semantic error takes twice as long to fix as a
  syntactic error
• A semantic error is twice as complex as a
  syntactic error

49
Measurement Basics

• Meaningfulness in measurement (contd)
• First statement seems to make sense
• Second statement doesnt make sense number of
  errors may be specified without reference to a
  particular scale, but cost to fix them must be
• Statement 3 seems sensible the ratio of time
  taken is the same, whether time is measured in
  second, hours, or fortnights
• Statement 4 does not appear to be meaningful and
  requires clarification
• If complexity means time to understand the error,
  than it makes sense
• Other definitions of complexity may not admit
  measurement on a ratio scale (e.g. examples in
  previous slides) in which case statement 4 is
  meaningless.

50
Measurement Basics

• Meaningfulness in measurement
• Definition a statement involving measurement is
  meaningful if its truth value is invariant of
  transformations of allowable scales.

51
Measurement Basics

• Meaningfulness in measurement examples
• John is twice as tall as Fred
• Implies measures are at least on the ratio scale.
  Its meaningful because no matter what
  transformation we use (and all we have is ratio
  transformations), the truth or falsity of the
  statement remains constant.
• Temperature in Tokyo today is twice that in
  London
• Implies a ratio scale, but is not meaningful. We
  measure in F and C. If Tokyo is 40 C and
  London is 20 C, then the statement is true, but
  if Tokyo is 104 F and London is 68 F, the
  statement is no longer true.
• Failure x is twice as critical as failure y
• Not meaningful if we only have an ordinal scale
  for criticality (common scale for software
  failures is catastrophic, significant, moderate,
  minor, and insignificant).

52
Measurement Basics

• Meaningfulness in measurement
• Note that our notion of meaningfulness says
  nothing about
• Usefulness
• Practicality
• Worthwhile
• Ease of measurement

53
Measurement Basics

• Statistical operations on measures
• Analyses dont have to be sophisticated, but we
  want to know something about how a set of data is
  distributed.
• What types of statistical analysis are relevant
  to a given measurement scale?

54
Measurement Basics

• Indirect measurement and meaningfulness
• Done when measuring a complex attribute in terms
  of simpler sub-attributes
• Scale type for an indirect measure M is generally
  no stronger than the weakest of the scale types
  of the sub-attributes
• Example testing efficiencydefects/effort
• Defects is on the absolute scale, while effort is
  on the ratio scale. Therefore effort is on the
  ratio scale.
• What is E2.7v121w26x12y22z-497, where
• v is the number of program instructions
• x and y are the number of internal and external
  documents
• z is the program size in words
• w is a subjective measure of complexity

55
Overview

• Measurement what is it and why do we do it?
• Measurement basics
• A goal-based software measurement framework

56
A Goal-Based Software Measurement Framework

• Classifying software measures
• Determining what to measure

57
A Goal-Based Software Measurement Framework

• Classifying software measures
• Three types of software entities to measure
• Processes collections of software related
  activities
• Products
• Resources entities required by a process
  activity
• Within each class, we have
• Internal attributes measured purely in terms of
  the entity itself
• External attributes measured with respect to
  how entity relates to its environment. Behavior
  of the entity is important
• Managers want to be able to measure and predict
  external attributes
• However, external attributes are more difficult
  to measure than internal ones, and are measured
  late in the development process
• Desire is to predict external attributes in terms
  of more easily-measured internal attributes

58
A Goal-Based Software Measurement Framework

• Determining what to measure
• Measurement is useful only if it helps understand
  the underlying process or one of its resultant
  products
• Goal-Question-Metric (GQM) has been proven to be
  effective in selecting and implementing metrics
• List the major goals of the development project
• Derive from each goal the questions that must be
  answered to determine if goals are being met
• Decide what must be measured in order to be able
  to answer the questions adequately

59
A Goal-Based Software Measurement Framework

• GQM example goal is to evaluate effectiveness
  of coding standard

Goal
Goal
Who is using standard?
What is coder productivity?
What is code quality?
Questions

• Proportion of coders
• Using standard
• Using language

• Experience of coders
• With standard
• With language
• With environment, etc.

Effort
Errors
Code size (lines of code, function points, etc
Metrics
60
A Goal-Based Software Measurement Framework

• GQM example 2 ATT goals, questions, metrics

61
A Goal-Based Software Measurement Framework

• Templates for goal definition
• Purpose to (characterize, evaluate, predict,
  motivate, etc.) the (process, product, model,
  metric, etc.) in order to (understand, assess,
  manage, engineer, learn, improve, etc.) it.
• Example To evaluate the maintenance process in
  order to improve it.
• Perspective Examine the (cost, effectiveness,
  correctness, defects, changes, product measures,
  etc.) from the viewpoint of the (developer,
  manager, customer, user, etc.)
• Example Examine the cost from the viewpoint of
  the manager
• Environment The environment consists mainly of
  the following process factors, people factors,
  problem factors, methods, tools, constraints,
  etc.
• Example the maintenance staff are poorly
  motivated programmers who have limited access to
  tools.
